COMPACT DISC STEREO SYSTEM
Z-L120
8B-MA6-906-01
001120AKP-P9
EZ
OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE INSTRUCCIONES
ISTRUZIONI PER L'USO
GEBRUIKSAANWIJZING
NÁVOD K OBSLUZE
HASZNÁLATI UTASĺTÁS
INSTRUKCJA OBSŁUGI
En
(English)
D
(Deutsch)
F
(Français)
E
(Español)
I
(Italiano)
NL
(Nederland)
Č
(Česky)
M
(Magyar)
Po
(Polski)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-L120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa Z-L120

Summary of Contents for Aiwa Z-L120

  • Page 1 COMPACT DISC STEREO SYSTEM Z-L120 OPERATING INSTRUCTIONS (English) BEDIENUNGSANLEITUNG (Deutsch) MODE D’EMPLOI (Français) MANUAL DE INSTRUCCIONES (Español) ISTRUZIONI PER L’USO (Italiano) GEBRUIKSAANWIJZING (Nederland) NÁVOD K OBSLUZE Č (Česky) HASZNÁLATI UTASĺTÁS (Magyar) INSTRUKCJA OBSŁUGI (Polski) 8B-MA6-906-01 001120AKP-P9...

  • Page 2: Precautions

    Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren utsätte för osnylig laser-strålning, som överskrider gränsen för laserklass 1. NOTE AIWA CO. LTD. - JAPAN - DECLARES UNDER ITS OWN RESPONSIBILITY THAT THE PRODUCT OBSERVERA DESCRIBED IN THIS MANUAL IS IN COMPLIANCE Så...

  • Page 3: Table Of Contents

    Electric Power TABLE OF CONTENTS 1 Power sources — Connect this unit only to power sources specified in the Operating Instructions, and as marked on the unit. 2 AC power cord PRECAUTIONS ..............1 - When disconnecting the AC power cord, pull it out by the AC power plug.

  • Page 4: Preparations

    PREPARATIONS To position the antennas CONNECTIONS FM antenna: Extend fully and position for the best possible reception. The use of an outdoor antenna is recommended for better IMPORTANT reception. • Connect the speakers, antennas and all optional equipment MW/LW antenna: first.

  • Page 5: Remote Control

    REMOTE CONTROL BEFORE OPERATION Inserting batteries Detach the battery cover on the rear of the remote control and insert two R6 (size AA) batteries. ECO/DEMO POWER 6 STANDBY/ON R6 (AA) TAPE, TUNER/BAND, When to replace the batteries VIDEO/AUX/PHONO,CD The maximum operational distance between the remote control and the sensor on the main unit should be approximately 5 meters To turn the unit on (16 feet).

  • Page 6: Sound

    SOUND AUDIO ADJUSTMENTS SETTING POWER ECONOMIZING MODE When you set power economizing mode to “ECO ON” or “ECO AUTO”, the unit reduces power consumption by conducting four ECO operations as follows. T-BASS • The unit (all the illumination of the display) blacks out when the ROCK power is turned off.

  • Page 7: Radio Reception

    RADIO RECEPTION PRESETTING STATIONS MANUAL PRESETTING 1 Press TUNER/BAND repeatedly to select the band. The unit can store a total of 32 preset stations. Presetting allows you to tune in to a station directly. Stations are assigned preset numbers, beginning from 1 in consecutive order for each band (FM, MW, LW).

  • Page 8: Reception By Preset Number

    RECEPTION BY PRESET NUMBER SEARCHING WITH THE HELP OF RDS CODES Each RDS station identifies the type of program (* PTY) which it is currently broadcasting. If you specify a PTY, the unit can 0-9, +10 automatically detect a suitable station from the preset stations. In addition, the * EON (Enhanced Other Networks) service works BAND...
  • Page 9 To cancel EON PTY search standby mode TO SEARCH FOR A SPECIFIED PTY Keep PTY pressed until “EON PTY” and the specified PTY are displayed alternately. (Do not release PTY yet.) At this time, press 1 Press PTY. a SET while still pressing PTY. “EON OFF” is displayed and The programme type of the currently tuned station is displayed.

  • Page 10: Cd Playing

    CD PLAYING BASIC OPERATIONS Today many stations transmit so-called RDS (Radio Data System) codes that contain a variety of additional CD EDIT/CHECK information along with the regular sound signals. DISC DIRECT z OPEN/ PLAY 1-3 Identical RDS stations with alternative CLOSE RANDOM/ frequencies (AF)

  • Page 11: Programmed Play

    To check the remaining time PROGRAMMED PLAY During play (except random play or programmed play), press CD EDIT/CHECK on the remote control while pressing SHIFT. The amount of time remaining until all tracks finish playing is displayed. To restore the playing time display, repeat the above. Up to 30 tracks can be programmed from any of the inserted discs.

  • Page 12: Tape Playback

    TAPE PLAYBACK RECORDING BASIC RECORDING BASIC OPERATIONS aSET Preparation • Use Type I (normal) tapes only. • Set the tape to the point where recording will start. • Note that recording is done on only one side of the tape. Use Type I (normal) tapes only.

  • Page 13: Ai Edit Recording

    6 Press w on deck 1 to start recording on the first AI EDIT RECORDING side. 4 flashes for 10 seconds, and then CD play and recording DISC of edited tracks for the first side start simultaneously. When DIRECT the end of the tape is reached, deck 1 enters the recording PLAY 1-3 stop mode.

  • Page 14: Programmed Edit Recording

    6 Repeat step 5 for the rest of the tracks for side PROGRAMMED EDIT RECORDING A track whose playing time is longer than the remaining time cannot be programmed. DISC 7 Press CD EDIT/CHECK while pressing SHIFT on DIRECT the remote control to select side B and PLAY 1-3 programme the tracks for side B.

  • Page 15: Clock And Timer

    CLOCK AND TIMER SETTING THE SLEEP TIMER SETTING THE CLOCK The unit can be turned off automatically at a specified time. When the clock is set, the “:” between the hours and minutes flashes. When the clock setting is canceled due to a power failure, Use the remote control.

  • Page 16: Setting The Timer

    SETTING THE TIMER You can change the source that was selected in step 1 by pressing one of the function buttons before pressing a in step 3. The timer recording period and tape length When the length of the tape to be recorded is shorter than the timer recording period, w on deck 1 is released before the timer is off.

  • Page 17: Other Connections

    Care of discs When connecting a turntable • When a disc becomes dirty, wipe the disc from the center out Use an Aiwa turntable equipped with a built-in equalizer amplifier. with a cleaning cloth. LISTENING TO EXTERNAL SOURCES • After playing a disc, store the disc in its case. Do not leave the disc in places that are hot or humid.

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE SPECIFICATIONS If the unit fails to perform as described in these Operating Main unit CX-ZL120 Instructions, check the following guide. FM tuner section Tuning range 87.5 MHz to 108 MHz GENERAL Usable sensitivity (IHF) 13.2 dBf There is no sound. Antenna terminals 75 ohms (unbalanced) •...

  • Page 19: Parts Index

    PARTS INDEX/KENNZEICHNUNG DER BEDIENELEMENTE/ NOMENCLATURE/INDICE DE LAS PARTES/INDICE DELLE PARTI/ ONDERDELEN/OPŘEHLED OVLÁDACÍCH PRVKY/ ALKATRÉSZJEGYZÉK/INDEKS CZĘŚCI Name/Bedienelemet Nom/ Page/Seite/Page/ Name/Bedienelemet Nom/ Page/Seite/Page/ Nombre/Nome/Benaming/ Página/Pagina/Pagina/ Nombre/Nome/Benaming/ Página/Pagina/Pagina/ Označení/Név/Nazwa Strana/Oldal/Strona Označení/Név/Nazwa Strana/Oldal/Strona 1 1 VOLUME ..........5,15 ! ! DISC DIRECT PLAY1-3 ......9,10,12,13 2 TAPE ............
