Summary of Contents for Italiana Camini Dida Idro
- Page 1 ® DiDa iDro Pellet boiler stove Installation, use and maintenance page...
-
Page 2: Table Of Contents
SERIAL NO.: Rating plate reference Performance declaration: (DoP - EK n° 092): Rating plate reference Moreover, the company hereby declares that: the DIDA IDRO wood pellet boiler stove complies with the requirements of the European Directives: 2014/35/EC - Low Voltage Directive... - Page 3 Dear Sir/Madam The product is uniquely identified by a number, the We thank you for and congratulate you on choosing our “counterfoil”, which is indicated on the warranty certificate. product. Before using it, we ask that you read this manual carefully, in order for you to be able to make the most of all Please keep: its functions in total safety.
-
Page 4: Safety Information
safety infoRMation ® • The product is not designed for use by people, • the storage of flammable materials at a distance including children, with limited physical, sensory which is less than the safe distances listed in and mental abilities. this manual. -
Page 5: General Information
geneRal infoRMation ® DIMENSIONS (cm) Ø 4 Ø 4 cm aria combustione Ø 8 cm uscita fumi Ø 4 (cm) Ø 4 cm aria Ø 4 cm aria combustione combustione combustion air valvola sicurezza Ø 8 (cm) Ø 8 cm Ø... - Page 6 geneRal infoRMation ® tecHnical cHaRacteRistics in accordance with en 14785 Nominal power Reduced power Available power Power for water Efficiency 91.6 97.6 CO emissions at 13% O 0.010 0.025 Fumes temperature °C Fuel consumption kg/h Tank capacity Draw 12-5 10-3 Autonomy hours Heatable volume *...
-
Page 7: Installation
installation ® PRePaRation anD UnPacKing The packaging materials are neither toxic nor noxious and do not require special disposal. The user is responsible for storing, disposing or and recycling them in a regulatory fashion. Always move the stove vertically with suitable equipment and in observance of safety regulations. - Page 8 installation ® installing tHe claDDing The boiler stove is delivered with the metal sides already fitted, while the ceramic top is packed sepa- rately (fig.1). Position the ceramic top into the special runners on the cast iron top. The D.8 washers are used as shims under the rubber supports, if it is necessary to “level up”...
- Page 9 installation ® ReMaRKs on installation Protection from heat and safety clearances Note that: The surfaces of the building adjacent to the product • installation must be carried out by authorised must be protected against overheating. technical personnel. The insulation to be used will depend on the type of • The appliance must be installed and operated surface in question.
- Page 10 installation ® flUe systeM • be certified, with a chimney plate if metal (Fumes duct, flue and chimney pot) • be of uniform cross section or vary in cross section This chapter has been drawn up pursuant to European only immediately after the outlet, not at some mid regulations EN 13384, EN 1443, EN 1856 and EN point of its length 1457.
- Page 11 installation ® tHe flUe: eXteRnal aiR intaKe Further to the general prescriptions for the fumes duct and flue, the flue: In general, we suggest two ways to ensure a proper • must serve solely to exhaust fumes flow of combustion air. • must be correctly sized to satisfy the requirements of fumes exhaust (EN 13384-1) indirect air intake...
- Page 12 installation ® • The safety valve bleed must be reachable and visible. PlUMbing Waste water must be conveyed via a vertical pipe Plumbing depends on the type of system. through a funnel with backflow air vents, at a suitable However, there are some “general rules”: distance from the point of drainage. • Plumbing must be carried out by qualified This pipe must have the following characteristics: personnel.
- Page 13 installation ® LEGEND Electronic control box Boiler stove Pump (circulator) ACS: Domestic Hot Water EV2: 2-way solenoid valve Ball valve RA: Radiators Cold Water EV3: 3-way solenoid valve Automatic air vent valve Return System Mains water supply NA: Normally open VEC: Closed expansion tank Drain Boiler...
- Page 14 installation ® tHe electRonic ciRcUlatoR (low-energy pump) The product is fitted with a circulator with electronic motor for limiting electricity consumption and complying with European regulations. Electronic performance control a) Control mode Δp – c In this mode, the electronic controller keeps the pump's differential pressure constant at the defined Hs set-point value.
- Page 15 installation ® Below we summarise the signals emitted by low-energy circulators (pumps) with the LED appearing on the control unit of the pump itself. oPeRating sta- Meaning caUse solUtion pump functions Lit with green light Pump running Normal operation according to its setting The pump functions for 10 min in the air relief Fast flashing with...
- Page 16 installation ® cHecKing tHe electRical connections fiRst ignition (coMMissioning) PHases • Make sure you have read and understood this (the power socket must be located in an manual easy to access position) • Remove all flammable materials from the appliance The boiler stove is equipped with an electrical power (manuals, labels, etc).
-
Page 17: Instructions For Use
UseR instRUctions ® synoPtic Panel ON/OFF Button It indicates the operation of the circulator It is also used to confirm/exit (pump). Selection button: access to regulation It indicates the operation of the pellet menu feed motor It indicates that we are operating within Temperature DECREASE button and backward scrolling for selected data the parameters menu (only CAT) - Page 18 UseR instRUctions ® scReW feeDeR filling The required temperature and the power that is chosen automatically by the electronic modulating Loading the pellet screw feeder (coclea) is only neces- system are displayed alternately. sary if the boiler stove is new (and being switched on for the first time) or if the boiler stove had completely run econoMy fUnction out of pellets.
- Page 19 UseR instRUctions ® setting: clocK anD WeeKly PRo- After programming is complete “Prog” will appear on gRaMMing the display; to continue programming Pr 2/Pr 3 press SET and repeat the process above or press ESC to Press the SET button for 5” to enter the programming exit programming.
- Page 20 UseR instRUctions ® ReMote ContRoL code no. 633280 (optional) : ON/OFF Button : button to increase power/working temperature (the displayed variable increases within a menu) : button to decrease power/working temperature (the displayed variable decreases within a menu) : button to switch from manual mode to automatic mode : button to switch from automatic mode to manual mode...
-
Page 21: Maintenance
Maintenance ® before doing any maintenance, disconnect the appliance from the mains. Regular maintenance essential keeping the appliance in good working order. failURe to seRVice tHe boileR stoVe will prevent it from working properly. any problems due to failure to service the stove will void the warranty. - Page 22 Maintenance ® WeeKly Maintenance • Clean the hearth (brush). after normal cleaning, make sure the grate is PRoPeRly seated (a - fig. d); failure to do so can cause the appliance to malfunction. so, before starting up the boiler stove, make sure the grate is seated properly as shown in fig.
- Page 23 Maintenance ® seasonal Maintenance sUMMeR sHUtDoWn carried technical When the stove is not in use, keep the doors, hatches assistance centre) and covers closed. This consists in cleaning the stove inside and out. We recommend emptying out the pellet tank. if the product is used intensively, we sPaRe PaRts recommend cleaning the fumes duct and...
-
Page 24: Troubleshooting
tRoUblesHooting ® if any problems occur, the boiler stove will automatically stop by performing the switch-off operation and a term will be displayed indicating the reason why it has been switched off (see below the different reasons). in the event of a block, in order to restart the boiler stove you must allow it to switch off completely (15 minutes with a beep), and then press the button. - Page 25 tRoUblesHooting ® Message PRobleM solUtion • Check the type of pellet (contact the technician if in al07 Shut-down due to exceeding doubt) maximum fumes temperature. • contact the technician al08 Shutdown due to overheated • check the system has been vented water • contact the technician • Ensure the furnace door is closed...
- Page 28 *941344-GB* ® code 941344-GB 03.17/A...
