- Page 1 ® LAYMA IDRO 18-22 Pellet boiler stove Installation, use and maintenance page 2...
-
Page 2: Table Of Contents
PELLET BOILER STOVE, bearing the brand ITALIANA CAMINI, named LAYMA IDRO 18-22 SERIAL NO.: Rating plate reference LAYMA IDRO 18 Performance declaration: (DoP - EK n° 154): LAYMA IDRO 22 Performance declaration: (DoP - EK n° 155): Moreover, the company hereby declares that:... -
Page 3: Introduction And Who The Manual Is For
Dear Sir/Madam The product is identified by a number, the “counterfoil”, We thank you for and congratulate you on choosing our which is on the warranty certificate. product. Before using it, we ask that you read this booklet carefully, in Please keep: order for you to be able to make the most of the functionality •... -
Page 4: Safety Information
safety infoRMation ® • The product is not designed for use by • Cleaning the fumes duct with cleaning products. DO NOT CLEAN THE PRODUCT people, including children, with limited WITH FLAMMABLE PRODUCTS. Risk of physical, sensory and mental abilities. • The appliance is designed for cooking fire or blowback. -
Page 5: Dimensions
DiMensions ® DIMENSIONS (cm) Ø 8 Ø 5 smoke outlet combustion air 14 14 The hydraulic connections depend on the optional extras kit. Instructions are provided in the “hydraulic installation” section. 60,5 UseR/installeR... -
Page 6: Technical Data
The above data is for guidance only and was taken during the certification phase by a notified body under the conditions specified by the standard. layMa iDRo 22 layMa iDRo 22 layMa iDRo 18 layMa iDRo 18 Nominal power Reduced power... -
Page 7: Unpacking
UnPacKing ® PRePaRation anD UnPacKing The packaging materials are neither toxic nor noxious and do not require special disposal. The end user is responsible for storing, disposing of and recycling them in a regulatory fashion. Always move the stove vertically with suitable equipment and in observance of safety regulations. - Page 8 UnPacKing ® six screws because the pack is shared with other products. Use the three M4 screws for the grille rubber elements Detail of grille (g) and pack with removable handle and small parts (M). to ReMove tHe PRoDUct fRoM tHe Pallet To remove the stove from the pallet (see diagrams below with numbers matching instructions) 1.
- Page 9 connecting tHe fUMe eXHaUst PiPe ® tHe eXHaUst PiPe to be connecteD The drawings are for guidance only, useful for to tHe fUMe MotoR is locateD in tHe the installation, but they may not refer to the pellet tank. specific model. Open the lid of the pellet tank and take the pipe Unscrew the three screws securing the centring bracket to the back of the stove staffa di centraggio...
-
Page 10: Water Circuit Installation
WateR ciRcUit installation ® PIPE KIT Measurements in mm this edge identifies the floor R-RW KIT Hydraulic connections template in mm R2 KIT Hydraulic connections template in mm COLD ONLY FOR COLD H HEATING DELIVERY HEATING DELIVERY HEATING RETURN SECURITY DISCHARGE SECURITY DISCHARGE COLD H HEATING RETURN... - Page 11 WateR ciRcUit installation ® PlUMbing We offer four internal kits (optional) The products are equipped with closed expansion PiPe Kits tanks. comprised of delivery and return pipe in the event that if the expansion tank is built into the the other components are installed externally (pump, product, this does not ensure proper etc.).
- Page 12 WateR ciRcUit installation ® oPtional HyDRaUlic Kits All kits are supplied with instructions for their connection to the boiler stove. The technicians have a dedicated paper template for each product. Make sure to use the correct template for the model being installed. Position the template flush with the floor and aligned with the left hand side of the outer edge boiler stove.
-
Page 13: Terminal Board
teRMinal boaRD ® teRMinal boaRD There is a bracket with a terminal board and 2 cableways* on the back (remove the protective cover fixed by two screws). Examples of possible connection configurations are given below. * The cableways are provided in the pack above the product structure. -
Page 14: Installation
installation ® ReMaRKs on installation Protection from heat and safety clearances The surfaces of the building adjacent to the product Note that: must be protected against overheating. • installation must be carried out by authorised The insulation to be used will depend on the type of technical personnel;... - Page 15 installation ® flUe systeM • be certified, with a chimney plate if metal (Fumes duct, flue and chimney pot) • be of uniform cross section or vary in cross section This chapter has been drawn up pursuant to European only immediately after the outlet, not at some mid regulations EN 13384, EN 1443, EN 1856 and EN 1457.
- Page 16 installation ® tHe flUe coMbUstion aiR intaKe In general, we suggest two ways to ensure a proper Further to the general prescriptions for the fumes duct flow of combustion air. The air must be drawn from and flue, the flue: outside* • must serve solely to exhaust fumes Please remember to also ensure air exchange for...
- Page 17 installation ® cHecKing tHe electRical connections (the power socket must be located in an easy to access position) The stove is equipped with an electrical power cord or connection to a 230V 50 Hz socket, preferably with an electromagnetic switch. Variations in voltage of more than 10% can compromise the operation of the stove.
-
Page 18: Assembly Of The Cladding
coveR ® Description Reference for figures below Quantity Ceramic tile on combustion chamber door Ceramic lower front panel Metal side panel Ceramic top The metal grille for the top is in the neck of the stove structure with three M4 screws, washers and two rubber elements for fastening. - Page 19 coveR ® fitting the ceramic tile to the combustion chamber door (1) 1. Open the combustion chamber door using the removable handle (M) and screw in the ceramic tile (using the two M4 screws and washers), as shown in the figure and detail image on this page. installeR...
- Page 20 coveR ® fitting the ceramic lower front panel (2) 1. With the combustion chamber door open, unscrew the two screws to remove the metal lower front panel. 2. Screw the ceramic tile onto the metal lower front panel (using two M4 screws and washers). 3.
- Page 21 coveR ® fitting the side panels (3) The side panels are hooked at the bottom and screwed at the top. 1. Position the rubber elements, as in the detail image below, and hook the side panels onto the structure. rubber elements 2.
- Page 22 coveR ® fitting the ceramic top (4) The upper part of the cover is comprised of a hot air outlet grille and ceramic top. 1. Fit the two rubber elements provided with the grille to rubber the upper part of the grille. elements 2.
-
Page 23: Instructions For Use
UseR instRUctions ® FIRST IGNITION (COMMISSIONING) PHASES loaDing tHe Pellets into tHe Pellet • Make sure you have read and understood this tanK manual. To access the reservoir, open the cover using the • Remove all flammable materials from the appliance handle* (manuals, labels, etc.). - Page 24 UseR instRUctions ® synoPtic Panel button for setting the required room LED that indicates an alarm temperature or for entering the condition menu (set room.temp.) button for setting the stove power LED that indicates that the pellet level (set power) feed motor is running on/off and confirm/exit menu button LED that indicates pump operation...
- Page 25 UseR instRUctions ® • To confirm the menu, press the button. To set the room (AIR) temperature, press (the LED will come ON), the current operating temperature • To return to the previous menu, press the button for 3 seconds. will be displayed. By using the button or the • To exit the menu, press the button for button, you can adjust the temperature to reach the 6 seconds.
- Page 26 UseR instRUctions ® stanD-by fUnction eXteRnal tHeRMostat This automatic function allows the boiler stove to be It must be connected via the blue cable to the serial switched off, after a pre-set time of 10 minutes (can be port located on the back of the boiler stove. It must changed by TAC during installation), when the required have a dry, normally open contact (e.g.
- Page 27 UseR instRUctions ® Scroll through the following menu (OFF is the default setting): - M2-1: enables the programmable thermostat - M2-2: day program - M2-3: week program - M2-4: weekend program - M2-5: exit Select the required menu and confirm by pressing the button.
-
Page 28: Maintenance
Maintenance ® Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance is essential to keeping the appliance in good working order. Failure to service the product properly will prevent it from working properly. any problems due to failure to service the stove will void the warranty. Daily Maintenance Do not dump the cleaning residue into the pellet tank. - Page 29 Maintenance ® Daily Maintenance 1. Operate the swab under the pellet loading cover. 2. Open the combustion chamber door (P) using the removable handle. 3. Empty the ash tray (B) and grate (C) into a non-flammable container (the ashes may still contain embers and/or hot parts) or vacuum if cold.
- Page 30 Maintenance ® WeeKly Maintenance With the product switched off and cold, after having operated the swab as per regular maintenance, the inspection window below the combustion chamber should be vacuumed (*). To access it, remove the deflector (D), which is only resting in place.
- Page 31 Maintenance ® seasonal Maintenance sUMMeR sHUtDoWn carried technical During the period of disuse, keep the stoves doors, assistance centre) hatches and lids closed. This consists in cleaning the stove inside and out. We recommend emptying out the pellet tank. Place dehumidifying salts in the combustion chamber.
-
Page 32: Troubleshooting
tRoUblesHooting ® if any problems occur, the boiler stove will automatically stop by performing the switch-off operation and a message will be displayed indicating the reason why it has been switched off (see below for the various reasons). in the event of a block, in order to restart the boiler stove you must allow it to switch off completely (15 minutes with a beep), and then press the button. - Page 33 tRoUblesHooting ® Message PRobleM solUtion displays when the logic board al4 extractor is not detecting the right fumes • Contact the technician. failure fan speed There are two possibilities: NO flame: • Check that the grate is seated properly and is clean. displays when ignition times out • Check that there are pellets in the tank and grate.
- Page 36 *941394-GB* ® code 941394-GB 05.17/C...
