Configure Yealink IP Phones
for Asterisk Phone System
Facility Manual

Advertisement

Table of Contents
loading

Related Manuals for Yealink SIP-T28

Summary of Contents for Yealink SIP-T28

  • Page 1 Configure Yealink IP Phones for Asterisk Phone System Facility Manual...

  • Page 2: Table Of Contents

    Contents 1.  Log in the web management ............................2  2.  Configure the account ..............................3  3.  Configure the DSS Key as BLF ............................4  4.  Configure the DSS Key as Intercom ..........................5  5.  How to auto provision ..............................5  1) Use DHCP Option 66 to update firmware massively via HTTP .................

  • Page 3: Log In The Web Management

    This document is going to show you how to configure a Yealink phone to work with Asterisk. Note 1: The model we are using in this document is Yealink SIP-T28, and all the screen shots are based on its firmware version 2.41.0.60. There might be some difference between different models or firmware versions.

  • Page 4: Configure The Account

    2. Configure the account Select Account ① Select one Account ② Select it as on ③ Fill in these fields ④ Check Note2 ⑤Voicemail...

  • Page 5: Configure The Dss Key As Blf

    Yealink – Asterisk corresponding table for account settings: Yealink Asterisk Register Name User Extension User Name User Extension Password secret Voice Mail My Voicemail After the above settings, Line 1 (Account1) must be available to make calls. Note 2: If the SIP server is behind a NAT, you should enable “NAT Traversal” as “STUN” and then specify a STUN Server.

  • Page 6: Configure The Dss Key As Intercom

    4. Configure the DSS Key as Intercom Select Phone ① Select DSS Key ② Intercom code + ⑤ Extension number Select Intercom ③ Select the right line ④ After the above settings, DSS Key3 will work as an Intercom key with extension 102. 5.

  • Page 7: Configure The Phone For Update Check When Powering On

    [ firmware ] HTTP Server path = /tmp/download.cfg TFTP Server address server_type = http in Option 66 server_port = 80 Firmware name http_url = http://www.xxxx.com/AP/ firmware_name = 2.2.0.0.rom ③ For T28, name the CFG file by y000000000000.cfg and put it to TFTP server For T26, name the CFG file by y000000000004.cfg and put it to TFTP server For T22, name the CFG file by y000000000005.cfg and put it to TFTP server For T20, name the CFG file by y000000000007.cfg and put it to TFTP server...
  • Page 8 Provisioning server Select Power on The provisioning server must contain the CFG files. After the above settings, every time when http://www.xxxx.com/AP power on, the phone will download the CFG files from automatically.

  • Page 9: Appendix

    Appendix 1. Default Basic Dial Code on Asterisk Voice Mail（My Voicemail） Pickup a call Intercom 2. Use DHCP Option 66 to update firmware massively via FTP In this way, there’s no need to configure at the phones. ① Specify an address(TFTP) for Option 66 in your DHCP Server TFTP Server address in Option 66 ②...
  • Page 10 TFTP Server address in Option ② Prepare a CFG file as below [ firmware ] TFTP Server path = /tmp/download.cfg server_type = tftp server_ip = 10.1.4.47 Firmware name server_port = 69 firmware_name = 2.2.0.0.rom ③ For T28, name the CFG file by y000000000000.cfg and put it to TFTP server For T26, name the CFG file by y000000000004.cfg and put it to TFTP server For T22, name the CFG file by y000000000005.cfg and put it to TFTP server For T20, name the CFG file by y000000000007.cfg and put it to TFTP server...
