ADJUSTABLE BASKETBALL SYSTEM
ASSEMBLY INSTRUCTIONS AND OWNER'S MANUAL
MODEL: CV553B
!
WARNING
FAILURE TO COMPLY WITH ANY OF
THE WARNINGS IN THESE INSTRUCTIONS
MAY RESULT IN SERIOUS PERSONAL
INJURY.
FAILURE TO COMPLY MAY ALSO
RESULT IN PROPERTY DAMAGE.
PLEASE HEED ALL WARNINGS AND
CAUTIONS TO ENSURE YOUR SAFETY.
DO NOT ATTEMPT TO ASSEMBLE
THIS SYSTEM WITHOUT CAREFULLY
READING AND FOLLOWING ALL
INSTRUCTIONS. BEGIN BY IDENTIFYING
AND TAKING INVENTORY OF ALL PARTS
USING THE PARTS LIST PROVIDED.
Keep this instruction manual in case you have to contact the manufacturer for replacement parts.
!
www.jaypro.com
(800) 243-0533
976 Hartford Tpke, Waterford, CT 06385
USA
1
Advertisement
Related Manuals for Jaypro Sports CV553B
Summary of Contents for Jaypro Sports CV553B
- Page 1 ADJUSTABLE BASKETBALL SYSTEM ASSEMBLY INSTRUCTIONS AND OWNER'S MANUAL MODEL: CV553B WARNING FAILURE TO COMPLY WITH ANY OF THE WARNINGS IN THESE INSTRUCTIONS MAY RESULT IN SERIOUS PERSONAL INJURY. FAILURE TO COMPLY MAY ALSO RESULT IN PROPERTY DAMAGE. PLEASE HEED ALL WARNINGS AND CAUTIONS TO ENSURE YOUR SAFETY.
-
Page 2: Before You Start
TOOLS AND MATERIALS REQUIRED FOR ASSEMBLY (Not Included) 1. 2 Adjustable Wrenches 10. Concrete-1/2 yard or 14-16 2. Socket Set Bags, (80 lb. bags) 3. 9/16" Wrench 11. Phillips Head Screwdriver 4. 3/4" Wrench 12. A minimum of 2 Ladders 5. - Page 3 Verify all parts listed on packing list are present prior to installation. 13 10 13 16 10 13 17 N PARTS LIST ITEM QTY DESCRIPTION Main Post Actuator Spring-Assist Cartridge Some Nylon washers may be Pole padding factory assembled. Gusset Padding 12 8 Main Extension Arm HARDWARE LIST...
- Page 4 NOTE: Before digging, call to locate any buried utility lines. ’ NOTE: At rim height 10 , distance from the face of backboard to the ” front of Main Post(A) is 36 , Choose the proper location to dig for the concrete footing: STEP A a.
- Page 5 STEP C a. Mix the concrete according to the instructions on the bags. Note that a thicker mix of concrete will dry stronger than a thin mix. Pour the concrete into the hole, stopping approximately 18 inches from the top of the hole.
- Page 6 WARNING *BECAUSE OF THE SIZE AND WEIGHT OF THE SYSTEM, A MINIMUM OF THREE ADULTS ARE REQUIRED FOR THE FOLLOWING STEPS* STEP1 Slide a 16mm Thick Washer (U3) over each of the J-Bolts (U2) as shown in FIGURE 1A. Remove the Padding from Main Post (A). Place the Main Post (A) over the J-Bolts. Slide a 16mm Thick Washer (U3), a Lock washer 16mm (U6) and thread a 16mm Hex Nut (U4) to each J-bolt.
- Page 7 STEP 4 Slide Steel Sleeve (J) thru the tube welded at the top end of Spring- Assist Cartridge (C). Slide the Rim Height Indicator (K) over Steel sleeve, leave it beside the Spring-Assist Cartridge (C). Place the top of Spring-Assist between Main Extension (F), align the Steel Sleeve (J) with the second set of welded tubes on the Main Extension Arm (F), slide one Washer M16 (#12) over one Hex Bolt M16x320mm (#6), and slide this Bolt all the way thru Main Extension...
- Page 8 STEP 7 Crank the Main extension arm as low as possible. Attach the Backboard assembly to Main Extension Arm (F) by using a Hex Bolt m16x320mm (#7), two M16 Flat Washers(#12), two Nylon washers (#2) and one Lock Nut M16 (#15). Note: Nylon washers go between Main extension arm Bracket (F) and Backboard mounting bracket.
