Jaypro Sports LS-200RS Installation Instructions Manual

The playground
Hide thumbs

Advertisement

Quick Links

Download this manual
-- LS-200RS --
(THE PLAYGROUND)

Installation Instructions

!
!
WARNING
D O N O T A T T E M P T T O
A S S E M B L E T H I S S Y S T E M
W I T H O U T C A R E F U L L Y
READING AND FOLLOWING ALL
I N S T R U C T I O N S . B E G I N B Y
I D E N T I F Y I N G A N D T A K I N G
I N V E N T O R Y O F A L L P A R T S
Call Jaypro Sports Equipment at 1-800-243-0533
during regular business hours for technical support.
www.jaypro.com
Rev-B
Page 1 of 14

Advertisement

loading

Related Manuals for Jaypro Sports LS-200RS

Summary of Contents for Jaypro Sports LS-200RS

  • Page 1: Installation Instructions

    I D E N T I F Y I N G A N D T A K I N G I N V E N T O R Y O F A L L P A R T S Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support.
  • Page 2 JAYPRO SPORTS LS-200RS THE PLAYGROUND ITEM IMAGE DESCRIPTION 6” x 6” x 157-1/8” LONG SQUARE UPRIGHT POST 8-1/4” x 11” x 7/16” THICK BACK POST PLATE 5” x 5” x 78-3/8” LONG UPPER EXTENSION ARM WITH 8-1/4” x 11” PLATE & 6” x 10-1/2” PLATE 2-3/4”...
  • Page 3 ITEM IMAGE DESCRIPTION 42” x 72” STEEL BACKBOARD GOAL W/ NETTING 4” x 8” x 1/4” THICK MOUNTING TAB WELDMENT 1.315” DIA. x 28” HOLE TO HOLE BRACE PIPE ITEM IMAGE DESCRIPTION Rev-B Page 3 of 14...
  • Page 4 ITEM IMAGE DESCRIPTION 2” x 3” x 1-1/2” WIDE x 3/16” THICK BACKBOARD MOUNTING TAB M16 x 205 mm HEX BOLT M16 WASHER M16 LOCK WASHER M16 HEX NUT M8 x 30 mm HEX BOLT M8 WASHER M8 LOCK WASHER 3/8”...
  • Page 5 ITEM IMAGE DESCRIPTION 3/8” x 1-1/2” CARRIAGE BOLT 3/8” x 1-1/2” LONG HEX HEAD BOLT 3/8” x 1-1/4” LONG HEX HEAD BOLT 1/2” x 6-1/2” LONG HEX HEAD BOLT 3/8-16 HEX NUT 3/8" WASHER 3/8" MEDIUM SPLIT LOCK WASHER 1/2"-13 HEX NUT 1/2"...

  • Page 6: Before You Start

    SUGGESTED TOOLS AND MATERIALS FOR ASSEMBLY (Not Included) 1. 2 Adjustable Wrenches 10. Concrete-1/2 yard or 14-16 2. Socket Set Bags, (80 lb. bags) 3. 9/16" Wrench 11. Phillips Head Screwdriver 4. 3/4" Wrench 12. Electric Drill 5. 15/16" Wrench 13.
  • Page 7 Footing: NOTE: Before digging, call to locate any buried utility lines. a. Dig a hole 54" deep x 36" across. The edge of the hole should be flush with the edge of the playing surface. If you live in an area where heavy frost can occur, it may pose a problem, consult your local building inspector to determine the appropriate hole depth.
  • Page 8 Extension assembly: a. Attach the back post plate to the upper extension arm and position it just beneath the white stripe. b. Attach the lower extension arm to the upper extension arm, assembly as shown. c. Carefully adjust the height of the extension arm assembly so that the height of the top slot of the lower extension arm is 119”...
  • Page 9 Rev-B Page 9 of 14...
  • Page 10 Backboard & Goal Rim Assembly: a. Insert four (4) 3/8” x 1-1/2” carriage bolt heads into the upper rear backboard slots. Carefully lift the backboard and insuring that the four (4) 3/8” x 1-1/2” carriage bolts pass thru the upper extension arm weldment plate ok. Use 3/8” washers, lock washers and hex nut to secure in place.
  • Page 11 Rev-B Page 11 of 14...
  • Page 12 Brace Assembly: a. Attach the backboard mounting tab onto the lower horizontal slots in the backboard with the 3/8” x 1-1/2” long carriage bolt with washers, lock washers and hex nut as shown. Repeat for the other side on the backboard. DO NOT OVER TIGHTEN.
  • Page 13 Rev-B Page 13 of 14...
  • Page 14 Rev-B Page 14 of 14...
