SAFETY INFORMATION
Do not attempt to disassemble or repair the BMC yourself. Please call SSV Works for
technical assistance or repair information. Changes or modifications to the BMC not
authorized by SSV Works will void the warranty.
SSV Works recommends disconnecting the negative battery terminal before
!
beginning any installation.
KIT INCLUDES
- Bluetooth Media Controller
- Mounting Cup
- Retention Clip
TOOLS NEEDED
- 3" Hole Saw (for flush mount intallation only)
- Wire Strippers
- Wire Crimpers
BLUETOOTH PAIRING
®
1. Open the Bluetooth setup program
®
on the mobile device and activate the
Bluetooth feature.
2. Turn on BMC using the power button
(Center LED will have 2 quick blinks
then pause)
3. Press the power button again and the
center LED will blink rapidly.
4. The device will show up as "SSVworks
BMC". Select this device.
5. The center LED will go solid to indicate
pairing is complete.
- Machine Screw
- Allen Wrench
- Double Sided Stick Tape Pad
6. The SSV Works BMC was designed
to default to maximum volume when
turned on. This is so the paired device
can be used as the master volume
control.
If the BMC will be used as the master
volume control, the volume on the
paired device should be set to 90%,
then any volume adjustment can be
done on the BMC.
Note: A previously paired Bluetooth
®
mobile device will automatically
connect to the BMC when unit is
turned on (if it is within range).
BUTTON LOCATIONS AND FUNCTIONS
2
4
6
1. Center logo LED Indicator
- Fast Blinking – Discoverable Mode
- 2 Quick blinks – Looking for Paired
device
- Solid on – Device paired and ready
for use
2. Play/Pause Button
3. Power Button – Press and hold for 2
seconds to turn on.
3
1
7
4. Track Back Button
- Quick press to go to Previous track
5. Track Forward Button
- Quick press to go to Next track
6. Volume Down Button
7. Volume Up Button
5
