MOUNTING INSTRUCTIONS
There are two mounting options for the BMC.
A) Surface Mount
B) Flush Mount
A) Surface Mount:
- Find a suitable mounting location for the BMC.
- Clean surface with alcohol or similar cleaner.
- Peel double stick tape & adhere to back of BMC then adhere it to mounting location
B) Flush Mount:
- Find a suitable mounting
location for the BMC.
- Ensure you have at least
1 inch of clearance on the
back side of your selected
mounting location.
- With a 3" hole saw, drill
a hole in your selected
location.
- Insert the mounting cup.
Attach retention clip with
allen screw.
- Run cable through the
mounting cup and snap
BMC in to the cup.
WIRING INSTRUCTIONS
Red – 12volt accessory
Black – Ground
Blue – Amplifier turn on
Corporate: SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
Web: www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
The Bluetooth
word mark and logos are registered trademarks owned by Bluetooth SIG,Inc. and any use of such
®
marks by SSV Works is under license.
© 2017 SSV Works, Oxnard, CA 93030
Blue RCA – Right Audio signal to Amplifier
Black RCA – Left Audio signal to Amplifier
BMC Rev. D 4-10-17
Installation and User Guide
BMC
Bluetooth
Media Controller
®
