MODULAR ICE MAKER
MACHINE A GLACE MODULAIRE
EISBEREITER FÜR SEPARATEN VORRATSBEHÄLTER
IJSMACHINE MET LOSSE OPSLAGBUNKER
MAQUINA DE CUBITOS MODULAR
FABBRICATORE MODULARE DI GHIACCIO
Installation MANUAL
NOTICE D'INSTALLATION
INSTALLATIONSANLEITUNG
INSTALLATIE VOORSCHRIFT
MANUAL DE INSTALACION
MANUALE PER L'INSTALLAZIONE
FOR QUALIFIED INSTALLER ONLY
RESERVE A L'INSTALLATEUR
FÜR DEN INSTALLATEUR
VOOR DE BEVOEGDE INSTALLATEUR
SOLAMENTE PARA INSTALADOR CUALIFICADO
SOLTANTO PER INSTALLATORI QUALIFICATI
89/336
73/23
FM-600ALHE
FMN-440ALHE
FM-481ALGE
FM-481ALGE-N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hoshizaki FM-600ALHE
Summary of Contents for Hoshizaki FM-600ALHE
- Page 1 89/336 73/23 MODULAR ICE MAKER FM-600ALHE MACHINE A GLACE MODULAIRE FMN-440ALHE FM-481ALGE EISBEREITER FÜR SEPARATEN VORRATSBEHÄLTER FM-481ALGE-N IJSMACHINE MET LOSSE OPSLAGBUNKER MAQUINA DE CUBITOS MODULAR FABBRICATORE MODULARE DI GHIACCIO INSTALLATION MANUAL NOTICE D’INSTALLATION INSTALLATIONSANLEITUNG INSTALLATIE VOORSCHRIFT MANUAL DE INSTALACION MANUALE PER L’INSTALLAZIONE FOR QUALIFIED INSTALLER ONLY RESERVE A L’INSTALLATEUR...
- Page 2 ENGLISH Note: 1. This icemaker needs a Storage Bin. The IMPORTANT recommended Storage Bin is HOSHIZAKI 1. In order to carry out safe and proper installation ICE STORAGE BIN, Model B-300SD(PD) of the product, please read this booklet or B-500SD(PD) with Top Kit - 8C, B-...
- Page 3 Icemaker manufacturer’s guidelines and are beyond the control of Hoshizaki. 3. The icemaker should not be located next to ovens, grills or other high heat producing Bolt equipment.
- Page 4 ENGLISH pipe). Equivalent pipe lengths that exceed capacity is less than 1.6kW at an evaporating 20 m should be increased in size to 3/8” temperature of -18°C, condensing temperature OD liquid line and 5/8” OD suction line. 43°C, return gas temperature 5°C, liquid temperature 43°C and ambient temperature 35°C.
- Page 5 ENGLISH [FM-600/FMN-440] Supply of replacement fuse covers can be obtained from Hoshizaki Parts/Service Centres. * When the power supply cord is connected, it must have a capacity of not less than 4A. The main power Fuses should be rated at 13A and approved to BS supply must be equipped with an earth leakage circuit 1362.
- Page 6 ENGLISH 7) The icemaker’s suction pressure regulator is set to an evaporating temperature of -25°C (FM-600), -22°C (FMN-440) or -18°C (FM-481). DO NOT change this setting. 8) Ensure the refrigeration system’s running suction pressure is 1 bar (FM-600), 1.4 bar (FMN-440) or Water Supply Tap 2.1 bar or less (FM-481) to provide the correct evaporating temperature.
- Page 7 HOSHIZAKI EUROPE LTD. UNIT A, STAFFORD PARK 18, TELFORD, SHROPSHIRE TF3 3DJ ENGLAND PHONE: 01952-291777 92E2AN20B (060112)
