  • Page 1  DispenseJet Series DJ-9500 Owner’s Manual...
  • Page 2 NOTICE This is an Asymtek publication, which is protected by copyright. Original copyright date 2008. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Asymtek. The information contained in this publication is subject to change without notice. Manuals on the Internet For the convenience of Asymtek customers and field service representatives, copies of Asymtek manuals can be downloaded from:...

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................1 Overview..............................1 Specifications ............................4 Safety ..............................5 Overview..............................5 Safety Warning Symbols ........................5 Safety of Personnel ..........................5 Preventing Equipment and Workpiece Damage ................... 6 Material Safety ............................6 Theory of Operation ..........................7 Overview..............................
  • Page 4 Troubleshooting ..........................35 Overview.............................. 35 Troubleshooting the DJ-9500 ......................35 Additional Information ........................39 Recommended Facility Items ......................39 Return Material Authorization ......................39 Input/Output Connection ........................40 Needle Assembly, Nozzle, and Seat Configuration ................41 Spares and Accessories........................44 Sample Application Settings .......................
  • Page 5 Table of Figures Figure 1-1 DispenseJet Series DJ-9500 (30cc Fluid Tube w/o Heat Exchanger) ........ 1 Figure 1-2 DispenseJet Series DJ-9520 (30cc Fluid Reservoir w/ Heat Exchanger) ......2 Figure 1-3 DispenseJet Series DJ-9520 (6oz Fluid Tube w/ Heat Exchanger) ........3 Figure 3-1 DJ-9500 Exploded View ......................
  • Page 6 Table of Tables Table 6-1 Nozzle Cleaning Tools ...................... 22 Table 7-1 DJ-9500 Troubleshooting – Symptom Based ..............35 Table 7-2 DJ-9500 Troubleshooting – Set-up Based ................ 37 Table 7-3 DJ-9500 Troubleshooting – Component Based ..............38 Table 8-1 Available Needle/Nozzle and Seat Sizes ................41 Table 8-2 DJ-9500 Spares and Accessories ..................

  • Page 7: Introduction

    Introduction Overview The DispenseJet Series DJ-9500 (Figure 1-1) is a non-contact dispenser providing high-speed delivery and exceptional volumetric control for various fluids, including silicones, underfill, encapsulants, UV adhesives, and silver epoxy. The DJ-9500 jets in tight spaces as small as 175 micrometers and creates fillet wet-out widths as small as 300 micrometers on the dispensed side of the die.

  • Page 8: Figure 1-2 Dispensejet Series Dj-9520 (30Cc Fluid Reservoir W/ Heat Exchanger)

    Stroke Adjustment Knob Fluid Reservoir Junction Box Solenoid Collar (Retainer Assembly) Fluid Chamber Heat Exchanger Thermal Control Assembly Figure 1-2 DispenseJet Series DJ-9520 (30cc Fluid Reservoir w/ Heat Exchanger) Introduction...

  • Page 9: Figure 1-3 Dispensejet Series Dj-9520 (6Oz Fluid Tube W/ Heat Exchanger)

    Fluid Reservoir Stroke Adjustment Knob Junction Box Solenoid Collar (Retainer Assembly) Heat Exchanger Fluid Chamber Thermal Control Assembly Figure 1-3 DispenseJet Series DJ-9520 (6oz Fluid Tube w/ Heat Exchanger) Introduction...

  • Page 10: Specifications

    Specifications Characteristic Specification Size Width: 33 mm Height: 142 mm Depth: 100 mm (135mm w/ Body Heater) Seat and Nozzle Carbide / Stainless Steel Needle Assembly Carbide Fluid Seal PEEK or Flouroloy Fluid Chamber O-Ring Ethylene Propylene or Viton Jet Body 6061-T6 Aluminum/Nickel Plated NPE 303 Stainless Steel Needle Assembly Bearings...

  • Page 11: Safety

    Refer to the safety section of your particular dispensing system Operations Manual prior to installing and operating your DispenseJet Series DJ-9500. Safety is considered a joint responsibility between the original equipment manufacturer (Asymtek) and the end-user (owner).

  • Page 12: Preventing Equipment And Workpiece Damage

    CAUTION! The DispenseJet Series DJ-9500 is a precision instrument of inherently safe design. The use of any dispensing fluid and the related choice of solvent for cleaning, as well as all associated safety precautions is the responsibility of the end-user.

  • Page 13: Theory Of Operation

    Theory of Operation Overview The DJ-9500 is a normally closed, air-actuated, spring-return mechanism, which uses momentum transfer principles to expel precise volumes of material. Pressurized air is regulated by a high-speed solenoid to retract the Needle Assembly from the seat. Fluid, fed into the fluid chamber, flows over the seat. When the air is exhausted, the needle travels rapidly to the closed position, displacing fluid through the seat and nozzle in the form of a droplet.

  • Page 14: Body Heater

    Body Heater The Body Heater helps hold the DJ-9500 series assembly at constant temperature to protect it against transient temperature fluctuation in the machine. The Heat Exchanger version will supply a fluid at a constant temperature. Stroke Adjustment Knob Assembly Reservoir Holder Needle Assembly Fluid Reservoir...

  • Page 15: Installation

    Installation Overview The DJ-9500 is designed for use on Asymtek DispenseMate, Axiom X 1000, Spectrum S-820, and Spectrum S-900 Series Dispensing Systems. This section includes installation instructions applicable for each of these systems. This section includes the following installation instructions: Unpacking the DJ-9500 •...
  • Page 16 To install the DJ-9500: 1. Mount the DJ-9500 on the dovetail bracket and tighten with the 4-mm hex wrench. 2. Make the electrical connections according to the appropriate machine configuration shown in Figure 4-1 and Figure 4-2. 3. Connect the pneumatic hoses as shown in Figure 4-1 and Figure 4-2. You should hear a click when the hose is inserted properly.

  • Page 17: Figure 4-1 Connection Diagram - Axiom X-1000

    Figure 4-1 Connection Diagram – Axiom X-1000 Installation...

  • Page 18: Figure 4-2 Connection Diagram - Spectrum S-900 Series

    Figure 4-2 Connection Diagram – Spectrum S-900 Series  NOTE The connections in Figure 4-2 also apply to Asymtek’s DispenseMate and Spectrum S-820 platforms. Installation...

  • Page 19: Setup

    Setup Overview This section describes the procedures required to setup the DJ-9500 for dispensing.  NOTE Refer to the Fluidmove User Guide for detailed instructions on software configuration. Setting Up the DJ-9500 To setup the DJ-9500: 1. Make sure the DJ-9500 is completely assembled. See Section 6 - Maintenance and Service for complete assembly and disassembly instructions.

  • Page 20: Figure 5-1 Connecting The Fluid Reservoir (30Cc Fluid Tube W/O Heat Exchanger)

    Fluid Reservoir Feed Tube Assembly Fluid Chamber Figure 5-1 Connecting the Fluid Reservoir (30cc Fluid Tube w/o Heat Exchanger) Setup...

  • Page 21: Figure 5-2 Connecting The Fluid Reservoir (30Cc Fluid Reservoir W/ Heat Exchanger)

    Fluid Reservoir Heat Exchanger Heat Exchanger Release Lever Fluid Chamber Figure 5-2 Connecting the Fluid Reservoir (30cc Fluid Reservoir w/ Heat Exchanger) Setup...

  • Page 22: Figure 5-3 Connecting The Fluid Reservoir (6Oz Fluid Reservoir W/ Heat Exchanger)

    Fluid Reservoir Heat Exchanger Heat Exchanger Release Lever Fluid Chamber Figure 5-3 Connecting the Fluid Reservoir (6oz Fluid Reservoir w/ Heat Exchanger) Setup...

  • Page 23: Maintenance And Service

    Maintenance and Service Overview Performing the recommended maintenance and service procedures increases the life of your DispenseJet Series DJ-9500 and ensures high quality dispensing performance for every production run. Refer to Figure 6-1 when performing the following maintenance and service procedures. Disassembling the DJ-9500 –...

  • Page 24: Figure 6-1 Disassembling Wetted Parts (Dj9520 W/Cup Seal And Unitized Nozzle Shown)

    Stroke Adjustment Knob Jet Body Needle Assembly Collar/Retainer Assembly Heat Exchanger Seal Fluid Chamber O-Ring Unitized Nozzle Thermal Control Assembly (TCA) Figure 6-1 Disassembling Wetted Parts (DJ9520 w/Cup Seal and Unitized Nozzle shown) Maintenance and Service...

  • Page 25: Cleaning And Inspecting The Dj-9500 - Wetted Parts

    Cleaning and Inspecting the DJ-9500 – Wetted Parts Removing the Cup Seal To remove the cup seal: 1. Disassemble the DJ-9500 as described previously. 2. Wipe fluid residue from the needle assembly. 3. Inspect the lower end of the jet body and inside the Thermal Control Assembly body and cooling passages for the presence of fluid.

  • Page 26: Cleaning The Static Seal

    Cleaning the Static Seal To clean the static seal:  NOTE The static seal does not need to be removed from the needle assembly for cleaning. 1. Gently wipe excess fluid from inside walls of the seal using a swab (P/N 7204301). 2.

  • Page 27: Cleaning The Nozzle

    Cleaning the Nozzle To clean the nozzle: 1. Open the Stroke Adjustment Assembly (counterclockwise) until the red part aligns with the sleeve to release the spring load on the needle assembly. 2. Loosen the Collar/Retainer Assembly ½ turn. The retainer will rotate to the open position. ...

  • Page 28: Table 6-1 Nozzle Cleaning Tools

    Table 6-1 Nozzle Cleaning Tools Nozzle Sizes Part No. Nozzle Cleaning Tool 0.025mm (0.001in) Contact Asymtek Nozzle Cleaner customer service 0.050mm (0.002in) to order 0.075mm (0.003in) 7208918 VIAL WIRE,25PC., .0025 DIA 0.100mm (0.004in) 901935 KIT,WIRE,CLN,MUSIC W, .003” DIA. 0.125mm (0.005in) 0.150mm (0.006in) 0.200mm (0.008in) 901922...

  • Page 29: Assembling The Dj-9500 - Wetted Parts

    Assembling the DJ-9500 – Wetted Parts To assemble the wetted parts: 1. Ensure all wetted parts are clean and free of cured fluid. 2. Install the seal as described below: Cup Seal a. Insert the cup seal into the fluid chamber lip side first by placing the seal on the seal tool (P/N 7201416), and pushing the seal into the chamber (Figure 6-7 and Figure 6-8).

  • Page 30: Figure 6-12 Stroke Adjustment Assembly Fully Opened

    3. Adjust the stroke adjust knob so that the top of the red ring is visible at the top of the sleeve (Figure 6-12). Sleeve Figure 6-12 Stroke Adjustment Assembly Fully Opened 4. Insert the O-ring into the fluid chamber (Figure 6-13). 5.

  • Page 31: Figure 6-16 Unitized Nozzle In Fluid Chamber Cavity Recess

    Unitized Nozzles a. Place the Unitized Nozzle into the recessed area of the Fluid Chamber (Figure 6-16). b. Install the Fluid Chamber/Unitized Nozzle over the needle assembly and against the base of the jet body. Make sure the chamber is engaged with the alignment pin in the jet body base (Figure 6-17).

  • Page 32: Figure 6-20 Stroke Adjustment

    9. Pull down on the Stroke Indicator Ring. 10. Tighten the stroke adjust knob until it bottoms out (do not over tighten) 11. Release the Stroke Indicator Ring and it will lock into place. If it does not lock in place, slightly back off the stroke adjustment assembly until it does.

  • Page 33: Removing And Replacing The Needle Assembly

    Removing and Replacing the Needle Assembly To remove the Needle Assembly: 1. Remove the DJ-9500 from the platform as described in “Disassembling the DJ-9500 – Wetted Parts” previously in this section. 2. Wipe the fluid residue from the needle assembly. 3.

  • Page 34: Figure 6-23 Inserting The Needle

    4. Line up the needle with the inner seal and the jet bearings (Figure 6-23). 5. Slide the needle through the bearings and slide the insertion tool base into the jet body. 6. Hand-tighten the base until it stops against the jet body. Figure 6-23 Inserting the Needle 7.

  • Page 35: Lubricating The Retainer Assembly And Stroke Adjustment Assembly

    Figure 6-25 Needle and Flange Fully Seated 12. Apply a light coating of lubricant (P/N 48-0018) to the inside of the sleeve on the detents and threads. WARNING! Failure to lubricate detents will lead to rapid wearing of the sleeve and failure. 13.

  • Page 36: Removing And Replacing The Solenoid Valve Or Thermal Control Assembly (Tca)

    Removing and Replacing the Solenoid Valve or Thermal Control Assembly (TCA) To remove and replace the solenoid valve or TCA: 1. Remove the DJ-9500 from the platform and remove the fluid chamber, seat, and nozzle as described in “Disassembling the DJ-9500 – Wetted Parts”...

  • Page 37: Figure 6-27 Loosening The Four Socket Head Screws (Dj-9520)

    DJ-9520 Heat Exchanger Version a. Pull down the Heat Exchanger Handle to release and remove the Heat Exchanger. b. While the Release Handle is still down, loosen the four socket head cap screws using a 2.5 mm hex wrench through the holes in the cover on the junction box (DO NOT remove the three (3) button head screws).

  • Page 38: Figure 6-28 Pushing The Coolant Line Through The Junction Box

    4. Disconnect the 2-pin connector and remove the solenoid valve. 5. Replacing the TCA only: a. Disconnect the 4-pin connector. b. Push the translucent green coolant line into the junction box to gain access to the TCA connection (Figure 6-28). Apply a light coating of lubricant (P/N 48-0018) to the line to ease the movement.

  • Page 39: Figure 6-32 Pressing The Tca Into The Junction Box

    f. Press the long, black portion of the TCA into the groove on the junction box (Figure 6-32). g. Attach the electrical connectors on the TCA (Figure 6-33). Figure 6-32 Pressing the TCA into the Figure 6-33 TCA Electrical Connectors Junction Box 6.

  • Page 40: Figure 6-35 Junction Box To Valve Body Alignment

    DJ-9520 Heat Exchanger Version a. With the cam lever down to the open position, thread in the four (4) socket head cap screws. b. Attach the Valve Body Alignment Tool (P/N 7214835) to the Junction Box and Collar and tighten the adjustment knob hand tight. Adjustment Knob Junction Box...

  • Page 41: Troubleshooting

    Troubleshooting Overview To quickly identify problems, look for obvious signs such as burnt, missing, damaged, or loose parts, as well as fluid obstructions and leakages. If a problem recurs, there may be other root causes. Tables 8-1 through 8-3 facilitate troubleshooting based on symptom, set-up, and component. Refer to Figure 9-2 for part identification.
  • Page 42 Table 8-1 DJ-9500 Troubleshooting – Symptom Based (Continued) Symptom Possible Cause Recovery Any of the causes above As above. Check dot parameters and jet Changed software settings configuration values. Poor Quality Jetting Thoroughly clean. Inspect all sealing Dirty, worn, or damaged wetted parts and mating surfaces for scratches and (fluid chamber, fluid seal, chamber traces of fluid.

  • Page 43: Table 7-2 Dj-9500 Troubleshooting - Set-Up Based

    Table 7-2 DJ-9500 Troubleshooting – Set-up Based Set-up Variable Effect Notes If this is a new process, contact Asymtek for assistance in process development. If this is a qualified process, fluid properties may have changed. The fluid may have exceeded its Dispense Fluid pot life, or been mishandled or set-up incorrectly.

  • Page 44: Table 7-3 Dj-9500 Troubleshooting - Component Based

    Table 7-3 DJ-9500 Troubleshooting – Component Based Component Quality Troubleshooting Questions Size and Is it the correct size? Was it installed in the correct orientation? Does Seat orientation a new seat have the same behavior? Size and Is it the correct size? Was it cleaned completely? Does a new nozzle Nozzle cleanliness have the same behavior?

  • Page 45: Additional Information

    Additional Information Recommended Facility Items In addition to the supplied accessories and tools, it is recommended that the following items be available at your facility: • Personal Protective Equipment recommended in applicable MSDS • Bench Lamp and Magnifier Set • Ultrasonic Cleaning System •...

  • Page 46: Input/Output Connection

    Input/Output Connection 7-PIN Female Circular Plastic Connector (Cable P/N 210751) Pin Num Signal name SOLENOID SOLENOID UNUSED HTR PWR HTR PWR HTR RTD (-) HTR RTD (+) 28-PIN Female Circular Plastic Connector (Cable P/N 7212229) Pin Num Signal name Pin Num Signal name +24V UNUSED...

  • Page 47: Needle Assembly, Nozzle, And Seat Configuration

    Needle Assembly, Nozzle, and Seat Configuration The DispenseJet Series DJ-9500 is configured at the Asymtek factory for your application. Configuration includes selecting appropriate needle/nozzle and seat sizes and identifying the model of the machine on which the jet will be installed. The optimal needle, nozzle and seat combination is determined based on your application needs.
  • Page 48 Table 8-1 Available Needle/Nozzle and Seat Sizes (Continued) Part No. Description For Standard Nozzles: 210734-1 SEAT, C TYPE, 0.20mm (0.008in) 210734-2 SEAT, C TYPE, 0.25mm (0.010in) 210734-3 SEAT, C TYPE, 0.38mm (0.015in) 210734-6 SEAT, C TYPE, 0.75mm (0.030in) 210734-8 SEAT, C TYPE, 1.00mm (0.040in) 210734-12 SEAT, C TYPE, 1.50mm (0.060in) 210753-3...
  • Page 49 Table 8-1 Available Needle/Nozzle and Seat Sizes (Continued) Part No. Description For Active Nozzles: 7216389-1 SEAT, ACTIVE, Z TYPE, 0.125mm (0.005in) 7216389-2 SEAT, ACTIVE, Z TYPE, 0.15mm (0.006in) 7216389-3 SEAT, ACTIVE, Z TYPE, 0.20mm (0.008in) 7216389-4 SEAT, ACTIVE, Z TYPE, 0.25mm (0.010in) 7216389-5 SEAT, ACTIVE, Z TYPE, 0.38mm (0.015in) 7216389-6...

  • Page 50: Spares And Accessories

    Spares and Accessories Table 8-2 and Table 8-3 list available spares and accessories. You may order entire kits or by individual part number. Table 8-2 DJ-9500 Spares and Accessories Part Number Part Description Description 7200538 KIT, CONSUMABLE, VALVE, DJ-9500 Valve Cleaning/ Consumables Kit 01-0022-00 BOOT,VAC .120 ID OLIVE For 6-oz kit, use P/N 7202648...

  • Page 51: Table 8-3 Dj-9520 Spares And Accessories

    Table 8-3 DJ-9520 Spares and Accessories Part Part Description Description Number 7214872 KIT, CONSUMABLE, VALVE, DJ-9520 Valve Cleaning/ Consumables Kit 193840 SWAB,RND/RND TIP,10/PKG For 6-oz kit, use P/N 7202648 210765 ASSY,FEED TUBE,FLUID,PKG-50 Assembly lubricant 901922 KIT,WIRE,CLN,TUNG,.007"DIA 901923 KIT,WIRE,CLN,TUNG,.011"DIA 901924 KIT,WIRE,CLN,TUNG,.014"DIA 901935 KIT,WIRE,CLN,TUNG,.003"DIA 955055...

  • Page 52: Sample Application Settings

    Sample Application Settings See Table 8-4 and 5 for a list of settings that affect DJ-9500 performance. Values are application Table dependent. Refer to the Fluidmove User Guide or Online Help for detailed software instructions. Values are saved in the Fluidmove configuration, fluid, heater, and program files. A column is provided for you to record your current settings.
  • Page 53 Table 8-5 Software Settings (Continued) Category Parameter Units Current Settings Teach a Settling Time Program>Edit>Edit Dot Down Speed inch/sec Parameters Down Accel inch/sec Dispense Gap inch Num Shots Multi-shot Delta Dwell inch Dwell Time Retract Distance inch Retract Speed inch/sec Retract Accel inch/sec Mid-move 1...

  • Page 55: Illustrated Parts List

    Illustrated Parts List Table 9-1 identifies components referred to in Figure 9-1 to Figure 9-3. The item numbers associated with the description correspond to the callout numbers in the illustration. Part number information is also available on Asymtek’s Find-A-Part web page: http://webstore.asymtek.com/awweblive/apps/findapart_index.asp Table 9-1 Illustrated Parts List...
  • Page 56 Table 9-1 Illustrated Parts List (Continued) Item No. Part No. Description 7214821 ASSY, J-BOX,DJ-9500,W CLAMP 7214840 ASSY, J-BOX,BODY HEATER,DJ-9500 7214890 ASSY, J-BOX, NO-HEAT, DJ9500 SCREW,M3X.05, COSKET CAP X30 49-3330 (Torque to 12in-lbs) 7212295 DRAW PLATE HEAT EX, DJ9500 CAM RELEASE MECHANISM 48-9930 PIN.DOWEL,.125 X .438 LG 7212288...

  • Page 57: Figure 9-1 Dj-9500 Illustrated Parts List (Cup Seal, Standard Nozzle, And 30Cc Mount)

    34 35 Figure 9-1 DJ-9500 Illustrated Parts List (Cup Seal, Standard Nozzle, and 30cc Mount) Illustrated Parts List...

  • Page 58: Figure 9-2 Dj-9520 Illustrated Parts List (Cup Seal, Unitized Nozzle, And 30Cc Mount)

    Figure 9-2 DJ-9520 Illustrated Parts List (Cup Seal, Unitized Nozzle, and 30cc Mount) Illustrated Parts List...

  • Page 59: Figure 9-3 Dj-9520 Illustrated Parts List (Static Seal, Active Nozzle, And 6Oz Mount)

    Figure 9-3 DJ-9520 Illustrated Parts List (Static Seal, Active Nozzle, and 6oz Mount) Illustrated Parts List...
  • Page 60 Asymtek Headquarters 2762 Loker Avenue West Carlsbad, CA 92010-6603 USA Tel: (760) 431-1919 P/N 7218010, Revision D © 2010...
