Oxford Square Media & Accent Cabinet
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
Stock # BH15-084-899-07
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
Date 2015-06-16 Rev 2 Factory: KONRIC
1-866-942-5362
www.whalenstyle.com
Page 1
LOT NUMBER:
DATE PURCHASED:
Factory No. 16086
/
/
Advertisement
Table of Contents
Related Manuals for Better Homes and Gardens BH15-084-899-07
Summary of Contents for Better Homes and Gardens BH15-084-899-07
- Page 1 LOT NUMBER: DATE PURCHASED: Oxford Square Media & Accent Cabinet Stock # BH15-084-899-07 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Oxford Square Media & Accent Cabinet (BH15-084-899-07) DATE OF MANUFACTURE: June 2015 MADE IN CHINA FITS UP TO MOST 55”...
- Page 3 Stock # BH15-084-899-07 Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
- Page 4 Stock # BH15-084-899-07 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (1) B- Left Side Frame (1) C- Right Side Frame (1)
- Page 5 Stock # BH15-084-899-07 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (12+1 extra)
- Page 6 Stock # BH15-084-899-07 Assembly Instructions Magnetic Catch #5 x 5/8” Screw (2 used in this step) (4 used in this step) ⑩ ⑥ 1. Unpack the unit and confirm that you have all the hardware and required parts listed. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch.
- Page 7 Stock # BH15-084-899-07 Assembly Instructions A/B/C Cam Bolt (12 used in this step) ② 3. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Left and Right Side Frames (B and C), as shown in the illustration.
- Page 8 Stock # BH15-084-899-07 Assembly Instructions 1-1/2” Screw Wood Dowel (2 used in this step) (2 used in this step) ③ ⑤ 4. Insert 2 Wood Dowels (3) into the inner holes on the bottom edge of Partition Panel (E). Tap in with a rubber mallet, if necessary.
- Page 9 Stock # BH15-084-899-07 Assembly Instructions Wood Dowel Cam Lock (4 used in this step) (6 used in this step) ③ ① 6. Insert four Wood Dowels (3) into the inner holes on both ends of the Bottom Panel (D). DO NOT insert the Wood Dowels into the Cam Bolt holes.
- Page 10 Stock # BH15-084-899-07 Assembly Instructions B/C/E Wood Dowel Cam Lock (6 used in this step) (6 used in this step) ③ ① 9. Insert six Wood Dowels (3) into the inner holes on the top edge of the Side Frames (B and C) and the Partition Panel (E).
- Page 11 Stock # BH15-084-899-07 Assembly Instructions 11. Tightly screw the Center Support (F) into the threaded hole on the Bottom Panel (D) and set the adjustable floor leveler to the correct height. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 11 Factory No.
- Page 12 Stock # BH15-084-899-07 Assembly Instructions 5/8” Washer Head Screw (32 used in this step) ⑦ 12. Now, go back and securely tighten all the Cam Locks and Wood Screws. Make sure that all the parts are tight and there are no gaps between the pieces. This will help keep the unit square.
- Page 13 Stock # BH15-084-899-07 Assembly Instructions 3/4” Bolt (4 used in this step) ④ 15. Stand the assembled unit upright. 16. Attach 2 Cable (K) to the center of the Back Panel (J) using two 3/4” Bolts (4) per wheel. You...
- Page 14 Stock # BH15-084-899-07 Assembly Instructions Knob Knob Bolt (2 used in this step) (2 used in this step) ⑪ ⑫ 17. Attach one Knob (11) to the front side of each Door (H and I) with the provided Knob Bolt (12).
- Page 15 Stock # BH15-084-899-07 Assembly Instructions Shelf Support Cam Lock Cover (16 used in this step) (18 used in this step) ⑧ ⑨ 21. With the doors open, insert eight Shelf Supports (8) into the desired holes in the sides of each compartment behind the glass door.
- Page 16 Stock # BH15-084-899-07 Assembly Instructions NOTE: You must install the Strip Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 23. Remove the paper backing of Stop Rail (L), then properly align the Stop Rail with the top edge of the stopper template on Top Panel (A).
- Page 17 Stock # BH15-084-899-07 Assembly Instructions Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 25. Ask for assistance to position the assembled unit at the desired location against a wall. 26. In case of uneven floors, the Floor Levelers are provided at the bottom of front legs for the necessary adjustment.
-
Page 18: Care And Maintenance
Stock # BH15-084-899-07 Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
