If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
Upholstered Side Wing Chair
Stock
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
Date 2015-06-12 Rev. 1 Factory: FUKIFU
# BH15-084-399-01
# BH15-084-399-02
1-866-942-5362
www.whalenstyle.com
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 17137
/
Advertisement
Table of Contents
Related Manuals for Better Homes and Gardens Upholstered Side Wing Chair
Summary of Contents for Better Homes and Gardens Upholstered Side Wing Chair
- Page 1 LOT NUMBER: DATE PURCHASED: / Upholstered Side Wing Chair Stock # BH15-084-399-01 # BH15-084-399-02 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions...
- Page 2 QUALITY GUARANTEE We are confident that you will be delighted with your Whalen Furniture purchase. Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations.
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A - Backrest (1) B - Seat Frame with Cushion (1) C - Front Leg (2) (1) Ø5/16” x 2-1/4” Bolt (6+1 extra) (2) Ø5/16”...
- Page 4 Assembly Instructions Lock Washer (6 used in this step) ③ Flat Washer (6 used in this step) ④ 2-1/4” Bolt 3-1/4” Bolt (2 used in this step) (4 used in this step) ① ② DO NOT fully tighten the bolts or nuts initially until all the bolts or nuts are ready to assemble.
- Page 5 Assembly Instructions 2-1/4” Bolt (4 used in this step) ① Flat Washer Lock Washer (4 used in this step) (4 used in this step) ③ ④ 5. Fit the Front Legs (C) to the front corners of the Seat Frame (B). Insert four 2-1/4” Bolts (1) with the Washers (3 and 4) through the drilled holes on the corner blocks and screw into the threaded inserts on the Front Legs.
-
Page 6: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Never use water to clean your furniture as it may cause damage to the finish.
