5-pc dining set

Advertisement

Quick Links

If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
Providence 5-pc Dining Set
Stock # BH44-084-499-05
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
Date 2015-04-09 Rev. 1 Factory: FUKIFU
LOT NUMBER:
DATE OF PURCHASE: / /
Page 1
Factory No. 17137

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BH44-084-499-05 and is the answer not in the manual?

Questions and answers

Summary of Contents for Better Homes and Gardens BH44-084-499-05

  • Page 1 LOT NUMBER: DATE OF PURCHASE: / / Providence 5-pc Dining Set Stock # BH44-084-499-05 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
  • Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing. CATALOG: Providence 5-pc Dining Set (BH44-084-499-05) MADE IN CHINA MAXIMUM LOAD 181.4 kg / 400 lb...
  • Page 3 Stock # BH44-084-499-05 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Chair Backrest (4) B- Seat (4) C- Chair Front Leg (8) D- Table Top (1)
  • Page 4 Stock # BH44-084-499-05 Assembly Instructions ① 1-3/4” Bolt (2 used in this step) Large Flat Washer ③ 3-1/4” Bolt (6 used in this step) Large Lock Washer (4 used in this step) (6 used in this step) ⑤ ④ DO NOT fully tighten the bolts or nuts initially until all the bolts or nuts are ready to assemble.
  • Page 5 Stock # BH44-084-499-05 Assembly Instructions Large Flat Washer (4 used in this step) 2-1/4” Bolt ② Large Lock Washer (4 used in this step) used in this step ⑤ ④ 5. Attach 2 Front Legs (C) to the front corner blocks of the Seat Frame (B) by inserting the 2-1/4” Bolts (2) with the Large Washers (4 and 5) through the drilled holes on the corner blocks and screw into the threaded inserts on the Front Legs.
  • Page 6 Stock # BH44-084-499-05 Assembly Instructions 9. Place the Table Top (D) upside down on a level and protective surface, as shown above. Remove the additional wood blocks attached at the corners by unscrewing the wood screws. These are used for shipping purposes only.
  • Page 7 Stock # BH44-084-499-05 Assembly Instructions 1-1/4” Bolt (4 used in this step) ⑥ Small Flat Washer Small Lock Washer M10 x 30 mm Wood Dowel (4 used in this step) (8 used in this step) (4 used in this step) ⑨...
  • Page 8 Stock # BH44-084-499-05 Assembly Instructions E /F 1-1/4” Bolt (2 used in this step) ⑥ Small Lock Washer (2 used in this step) ⑦ Small Flat Washer (2 used in this step) ⑧ M10 x 30 mm Wood Dowel (4 used in this step) ⑨...
  • Page 9: Care And Maintenance

    Stock # BH44-084-499-05 Care and Maintenance  From time to time please ensure there are no loose nuts on the product.  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
