- Page 1 KOP2555-XHB, KOP2555-S-XHB 46" - 55" 150 lb (117 - 140 cm) (68 kg) ČEŠ TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 2 WARNING ENG - Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
- Page 3 WAARSCHUWING NEL - Vóór de installatie dient u zich ervan te overtuigen dat het dragende oppervlak het totaalgewicht van de apparatuur en de hardware aankan. Alle schroeven moeten stevig vastzitten. Draai de schroeven niet te strak aan, want dit zou kunnen resulteren in schade en/of falen van het product. Het maximale draagvermogen mag nooit worden overschreden.
- Page 4 AVISO POR - Antes de instalar, certifique-se de que a superfície de apoio suporta a carga combinado do equipamento e das ferragens. Os parafusos devem ser bem apertados. Não aperte demasiado os parafusos, pois podem ocor- rer danos ou falhas do produto. Nunca exceder a Capacidade de carga máxima. Utilize sempre um assistente ou equipamento de elevação mecânica para elevar e posicionar o equipamento em segurança.
- Page 5 This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ Táto strana je zámerne prázdna. Esta página foi intencionalmente deixada em branco.
- Page 6 Symbols Símbolos Symboles Symbole Symbolen WARNING Simboli ADVERTENCIA ČEŠ Symboly ADVERTISSEMENT Symboly ACHTUNG Screws must get at least three Símbolos WAARSCHUWING full turns and fit snug. Semboller TÜR AVVERTENZA Los tornillos tienen que dar, ČEŠ VÝSTRAHA por lo menos, tres vueltas VÝSTRAHA completas y quedar ajustados.
- Page 7 Tools Needed for Assembly. Herramientas necesarias para el ensamblaje. Outils nécessaires au montage. To properly tighten screws: Tighten until screw Für den Zusammenbau erforderliche Werkzeuge. head makes contact, then tighten another 1/2 Voor montage benodigd gereedschap. turn. Do not overtighten screws. Attrezzi necessari per l’assemblaggio.
- Page 8 Parts (Before beginning, make sure you have all parts shown below). Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes). Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous). Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind). Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
- Page 9 This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ Táto strana je zámerne prázdna. Esta página foi intencionalmente deixada em branco.
- Page 10 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 11 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 12 WARNING ENG - When installing Peerless mounts to threaded rods, the rods must be 1/2" diameter minimum, 70 KSI tensil strength. The hardware must be installed and supported per the manufacturer's design specifications. Use only compatible hardware. Never exceed maximum load capacity of threaded rods or their supporting surface. Consult a licensed and bonded professional engineer for requirements in your area.
- Page 13 UYARI TUR - Peerless askı aparatlarını çelik cıvatalarla monte ederken, cıvataların çapının asgari 1/2” (13mm) ve çekme mukavemetinin 70 KSI olması gerekir. Donanımın üreticinin tasarım özelliklerine göre monte edilmesi ve desteklenmesi gerekir. Sadece uyumlu donanım kullanın. Asla çelik cıvataların veya destek yüzeyinin azami yük kapasitesini aşmayın.
- Page 14 Remove quite 3/4" retirez (19mm) entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR Adjust Ajuste Réglez Einstellen Aanpassen Regolare Nastavit ČEŠ Nastaviť Ajuste Ayarlayın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 15 3/4" (19mm) Stainless steel 1/2" hex nut (not included). Tuerca hexagonal de 1/2“ de acero inoxidable (no incluidos). Écrou hexagonal de 1/2 po (13mm) en acier inoxydable (non compris). 1/2 Zoll-Edelstahl-Sechskantmutter, p. Zoll (nicht inbegriffen). Roestvrijstalen 1/2“ zeskantige moer (niet bijgeleverd). Dado esagonale 1/2“...
- Page 16 Unlock Destrabe Déverrouiller Entriegeln Ontgrendelen Sblocca Odemknout ČEŠ Odomknúť Desbloquear Kilidi açın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 17 Remove quite retirez entfernen verwijderen rimuovere ČEŠ odstranit odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 18 1/2" (13mm) Remove Loosen. quite Afloje. retirez Desserrez. entfernen Lösen. verwijderen Losdraaien. rimuovere Allentare. ČEŠ odstranit ČEŠ Uvolnit. odstrániť Uvoľniť. remova Desaperte. çıkartın Gevşetin. TÜR TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 19 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 20 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR Maximum 36 in. • lb (4 N.M.). Máxima 36 in. • lb (4 N.M.). Maximum 36 in.
- Page 21 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 22 Replace Remplace 1/2" Remettez en place (13mm) Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 23 1/2" (13mm) Tighten. Apretar. Serrer. Anziehen. Aandraaien. Stringere. Utáhněte. ČEŠ Utiahnite. Apertar. Sıkmak. TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 24 Unlock Destrabe Déverrouiller Entriegeln Ontgrendelen Sblocca Odemknout ČEŠ Odomknúť Desbloquear Kilidi açın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 25 Cable management manejo de cables gestion des câbles Kabelführung kabelbeheer gestione dei cavi vedení kabelů ČEŠ vedenie káblov gestão de cabos kablo yönetimi TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 26 Optional. Opcional. Facultatif. Fakultativ. Facultatief. Opzionale. Volitelné. ČEŠ Voliteľné. Opcional. İsteğe bağli. TÜR Remove quite retirez entfernen verwijderen rimuovere ČEŠ odstranit odstrániť remova çıkartın TÜR Cable management manejo de cables gestion des câbles Kabelführung kabelbeheer gestione dei cavi ČEŠ vedení kabelů vedenie káblov gestão de cabos kablo yönetimi...
- Page 27 Lock Trabe Verrouillez Arretieren Vergrendelen Bloccare Zajistit ČEŠ Zaistiť Bloqueie Kilitleyin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 28 10-1 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto ČEŠ Znova nasadit Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 29 10-2 Lock Trabe Verrouillez Arretieren Vergrendelen Bloccare ČEŠ Zajistit Zaistiť Bloqueie Kilitleyin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 30 11-1 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 31 11-2 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto ČEŠ Znova nasadit Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Page 32 This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ Táto strana je zámerne prázdna. Esta página foi intencionalmente deixada em branco.
-
Page 33: Limited Five-Year Warranty
(from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty. - Page 34 (dalla data dell’installazione originale del prodotto). A sua discrezione, Peerless-AV sostituirà o riparerà, o restituirà il prezzo pagato se il prodotto non è conforme a questa garanzia.
- Page 35 (a partir da data da primeira instalação do produto). A seu critério, a Peerless-AV reparará ou substituirá (ou reembolsará o preço de compra de) qualquer produto que não esteja em conformidade com esta garantia.
- Page 36 Peerless-AV Peerless-AV Europe Peerless-AV de Mexico 2300 White Oak Circle Unit 3 Watford Interchange, Ave de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom Escobedo N.L Mexico 66062 Ph: (800) 865-2112...
