- Page 1 S 135E - S135 Dust extractors START-UP, OPERATING AND MAINTENANCE INSTRUCTIONS...
-
Page 2: Specifications
SPECIFICATIONS TYPE S 135 S 135E RATED SUPPLY VOLTAGE ~230 V - 50 Hz ~230 V - 50 Hz RATED POWER INPUT 1200 W max 1200 W max RATED CURRENT INPUT DUST EXTRACTION INTENSITY/RATE 170 m 170 m NEGATIVE PRESSURE 1500 mm/H 1500 mm/H WEIGHT [kg]... -
Page 3: Rating Plate
INTRODUCTION This extractor has been designed and manufactured for professional applications, and it should be used for these purposes. The extractor is designed for the extraction of dry dust only. WARNING! Never allow the extractor to suck in flammable substances, explosives, solvents, welding vapours, burning substances, fuels, lubricating oils, alcohols, paints, or thinners. -
Page 4: Principle Of Operation
PRINCIPLE OF OPERATION CHARACTERISTICS All the features of the device have been combined in one unit to in order to allow the execution of the following functions at the same time: dust extraction; automatic operation of electric tool (S135E); access to the power supply socket without the need to use extra extension cords. SUCTION SECTION Consists of: turbine;... -
Page 5: Installation
INSTALLATION Warning: The machine has to be set in a dry and well-ventilated place, where the air is changed at a minimum of once an hour; fresh air content (without equipment supporting ventilation) - 50%. Temperature in the place of work: 10-35° ° ° ° C, humidity: 50-90%. The surface, on which the machine stands, may be inclined at no more than 5-10 degrees. -
Page 6: Maintenance
In case of a power failure set all switches in the OFF position to prevent spontaneous switching on of the unit when power comes back on (S135E). Warning: Use RUPES 001.1606/C dust bags only. Always carefully check the dust bags. If dust gets inside the unit, it may cause serious damage. -
Page 7: Declaration Of Conformity
POSSIBLE ABNORMALITIES AND HOW TO ELIMINATE THEM EFFECTS REASONS REMEDY It is not possible to start up the dust Power failure Check if the plug is in the socket extractor Power supply cable, switch or motor Contact an authorised service centre have defects Dust extractor does not start Failure of electronic module or... - Page 8 RUPES DUST EXTRACTOR WIRING DIAGRAM FOR S135E WIRING DIAGRAM FOR S135...
-
Page 9: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS 1. NTS Sp. z o.o. [Ltd.] - the exclusive representative of RUPES s.p.a. in the Republic of Poland guarantees the highest quality and correct working of the machine operated in compliance with its operating instructions. 2. The Buyer obtains a 12-month warranty starting from the date the machine was purchased . This period will be extended by the number of days the machine is kept in the warranty repair service. - Page 10 Poland, 05-083 Zaborów tel.: (022) 752 06 00 e-mail: nts@nts.com.pl Borzęcin DuŜy ul. Warszawska 749 fax: (022) 752 05 92 http://www.nts.com.pl...
