SKC 223-105A Operating Instructions

Standard five station charger models -
• 223-102A Five station charger for 222 series pumps
• 223-103A Five station charger for Sidekick EX / TX / MTX series pumps, Universal
EX / TX / MTX / MA / AZ / MAZ series pumps and AirChek 52 pump
• 223-105A Five station charger for Universal XR series pumps
• 223-106A Five station charger for AirChek 2000 pump
• 223-109A Five station charger for AirChek 3000 pump
Please read these instructions before using the charger!

Specifications

Model Input
223-102A 100-240V ~ 50/60Hz
223-103A 100-240V ~ 50/60Hz
223-105A 100-240V ~ 50/60Hz
223-106A 100-240V ~ 50/60Hz
223-109A 100-240V ~ 50/60Hz

Introduction

The SKC Ltd five station chargers provide five charging outputs with a fixed 15 hour
constant current charge for SKC NiCd and NiMH battery packs. At the end of the 15
hour charge, the chargers automatically switch each of the five outputs individually to a
trickle charging rate to prevent overcharging.
The chargers are supplied with four inter-changeable electrical supply input plugs
suitable for use in the United Kingdom, Europe, USA / Canada and Australia / New
Zealand.

Warnings

These chargers are designed for use specifically with the stated SKC pump models and
are not intended for use with any other SKC or non-SKC products.
These chargers must not be used to charge non-rechargeable batteries.
These chargers are for indoor use only, with enclosure rating of IP40, and must
therefore be protected against exposure to moisture.
Operating temperature range - 0°C to +40°C, 95% RH non-condensing.
Use of a non-SKC charger to charge SKC pump battery packs may cause damage to
the battery pack and / or pump and will void the battery pack and / or pump warranty,
also the intrinsic safety rating of the pump may be invalidated.
Standard Five Station Chargers
Output x5 Battery Pack Specification
55mA NiCd 2cell 2.4V 0.55Ah
180mA NiCd/NiMH 4cell 4.8V 2.0Ah
180mA NiCd/NiMH 5cell 6.0V 2.0Ah
180mA NiCd/NiMH 4cell 4.8V 2.0Ah
180mA NiMH 4cell 4.8V 2.0Ah
www.skcltd.com
Operating Instructions
