RIDING
WITH A
HUD
The FENIX AR HUD is designed to illu-
minate your blind spots while riding. A
ultra-wide view camera captures both
your rearview and blind spots in a single
VERTICAL ADJUSTMENT
Adjust the height of the HUD
using the knob on the bottom
of the FENIX AR. Twist left or
right until you can see through
the display clearly.
The Heads-Up Display (HUD) provides
a wide-angle rearview camera, GPS
navigation, speedometer, and other in-
formation.
frame. You should get comfortable with how
it operates prior to riding. Put your helmet
on and go for a walk around your house
and neighborhood. Occasionally glance at
the HUD and familiarize yourself with the
voice commands. First rides should be done
in a large parking lot or on very low traffic
roads. Do not attempt to go for a ride with-
out familiarizing yourself with the FENIX AR
first.
ANGLED ADJUSTMENT
Tilt the HUD slightly forward
or back to change the lateral
viewing angle. You will feel
the HUD slightly click, this is
normal and helps the HUD
maintain its position.
Heads-Up
Display
RADIAL ADJUSTMENT
Rotate the HUD side to side
to adjust the viewing angle.
Adjust the HUD to a angle
where you can see the entire
display clearly.
