DEHACO IBEX Series Operation And Maintenance Manual page 25

6.8.2 Wear limit tool
Wear limit
6.8.3 Wear limit tool pin
IBEX 130GS t/m IBEX 400GS
X
Detail 'A'
IBEX 600GS t/m IBEX 4000GS
© 2018 Dehaco B.V. • Operation and maintenance manual IBEX Hydraulic breakers G-type – Version 17-08-2018
New tool
X
Y
E
E
C
A
New tool
222 mm
IBEX 70GS
188 mm
IBEX 130GS
343 mm
IBEX 135GS
275 mm
IBEX 170GS
310 mm
IBEX 200GS
310 mm
IBEX 320GS
416 mm
IBEX 400GS
542 mm
IBEX 600GS
557 mm
IBEX 900GS
707 mm
IBEX 1200GS
750 mm
IBEX 1800GS
800 mm
IBEX 2200GS
735 mm
IBEX 2800GS
785 mm
IBEX 3200GS
X
22,5 mm
IBEX 70
25,5 mm
IBEX 130
21,5 mm
IBEX 135
17 mm
IBEX 170
30 mm
IBEX 200
20 mm
IBEX 320
22,5 mm
IBEX 400
A
54
IBEX 600GS
60
IBEX 900GS
72
IBEX 1200GS
80
IBEX 1800GS
90
IBEX 2200GS
100
IBEX 2800GS
100
IBEX 3200GS
105
IBEX 4000GS
6. Maintenance
Wear limit
172 mm
150 mm
230 mm
210 mm
210 mm
210 mm
250 mm
350 mm
350 mm
400 mm
400 mm
450 mm
450 mm
500 mm
Y
18,5 mm
21,5 mm
19,5 mm
13 mm
26 mm
16 mm
18,5 mm
B C D
30 51 37
32 57 29
40 69 37
40 77 37
45 87 42
50 97 47
50 97 47
50 102 47
E
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
25
