- Page 1 SUPER BEAM260 MOVING HEAD LIGHT MJ-1260 User manual PROFESSIONAL STAGE LIGHTING ====== ======== Thank you for choosing our super beam moving head light. For the sake of your safety, Please read and follow these instructions carefully and keep this manual in a safe place for future...
-
Page 2: Table Of Contents
Catalogue Chapter Page Safe Usage Of The Product -------------------------------------------------------------------------------------------3 Install The Equipment --------------------------------------------------------------------------------------------------4 Fitting The Lamp ---------------------------------------------------------------------------------------------------------4 Power Code Connection -----------------------------------------------------------------------------------------------5 DMX Connection --------------------------------------------------------------------------------------------------------5 DMX Terminator ---------------------------------------------------------------------------------------------------------6 Function Set ----------------------------------------------------------------------------------------------------------------6 Operation Menu -----------------------------------------------------------------------------------------------------------7 Maintenance ----------------------------------------------------------------------------------------------------------------9 Keeping The Product Clean --------------------------------------------------------------------------------------------9 Trouble Shooting -----------------------------------------------------------------------------------------------------------9 Equipment and Appendix... -
Page 3: Safe Usage Of The Product
SAFE USAGE OF THE PRODUCT When unpacking and before disposing of the carton, check there is no transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The product is for indoor use only, IP20. -
Page 4: Install The Equipment
Install The Equipment: Use 2pcs clamp and 1pcs safety cord(need to purchase).Use clamp fix with light hook which in the packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure and fasten the screws attached to each clamp. Make sure the light is installed reliable, and confirm the light which you fixed is strong enough for hanging the light. -
Page 5: Power Code Connection
Power Code Connection: Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off. -
Page 6: Dmx Terminator
DMX Terminator: In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 7: Operation Menu
2. Button Operation DOWN Use button switch and LCD display, can set the address code and function code easily. Check or modify lighting function settings, Press the LCD display or OK button. LCD display panel will display main menus. Function operation menu all have corresponding submenu . Each menu all represent the specific functions of lamps, specific see below "operation menu"... - Page 8 All motors Part motor Light Reset XY motor Manual Auto running Test Running Sound running CH1-CH32(0-255) Simulation Controller Ch1-CH32(0-255) Dmx Value Running time(0-9999) Running count(0-9999) Residue time(Infinite) Residue count (Infinite) Fan 1(0-9999) Fan 2(0-9999) Other Info Temperature 1(0-100) Temperature 2(0-100) PCB1 Ver.: (V1.15) PCB2 Ver.: (V1.22) PCB3 Ver.: (V1.22)
-
Page 9: Maintenance
Default Manual Lamp Setting Electronic Display Reverse Display 180 degree rotation Chinese /English Switch the language of the menu display Display Return to the screen protection Maintenance: To prolong the life of the projector, some maintenance work has to be done to ensure the optical system in good condition. -
Page 10: Equipment And Appendix
The moving head lamp only can work Inspect the power supply and voltage is whether normal. intermittently. Make sure the fan is working well or fans and their filters not blocked Defective projection Make sure the lamp is within its life limit Remove dust or grease from the lenses. - Page 11 Light Green + Light Blue 100~104 Light Blue 105~109 Light Blue + Light Yellow 110~114 Light Yellow 115~119 Light Yellow + Purple 120~124 Purple 125~129 Purple + Warm White 130~134 Warm White 135~139 Warm White + White 140~149 Rainbow effect with veering(Fast ~Slow) 150~203 Rainbow effect with inversion (Slow~Fast) 204~255...
- Page 12 Gobo 9 shake from slow to fast 111~115 Gobo 8 shake from slow to fast 116~120 Gobo 7 shake from slow to fast 121~125 Gobo 6 shake from slow to fast 126~130 Gobo 5 shake from slow to fast 131~135 Gobo 4 shake from slow to fast 136~140 Gobo 3 shake from slow to fast...
-
Page 13: Technical Parameters
Technical Parameters: Voltage : AC100~240V/50-60Hz Power consumption:420W@(220V) Bulb: YODN 260W lamp Lamp : YODN MSD260R9 LAMP Color temperature : 8500K Color: 13 Color + Open, Color half step function Gobo: 13 Fixed gobo + Open, Gobo shake function Prism: 1Pcs 16+8-face rotation prism, Bilateral rotation, Prism superposition function 1Pcs 32-face rotation prism, Bilateral rotation, Prism superposition function Frost: 1Pcs frost mirror Focus: Linear focusing...
