Tekelec EAGLE 5 Commands Error Recovery Manual

Integrated signaling system
Hide thumbs Also See for EAGLE 5:
1
2
Table Of Contents
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669
670
671
672
673
674
675
676
677
678
679
680
681
682
683
684
685
686
687
688
689
690
691
692
693
694
695
696
697
698
699
700
701
702
703
704
705
706
707
708
709
710
711
712
713
714
715
716
717
718
719
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
736
737
738
739
740
741
742
743
744
745
746
747
748
749
750
751
752
753
754
755
756
757
758
759
760
761
762
763
764
765
766
767
768
769
770
771
772
773
774
775
776
777
778
779
780
781
782
783
784
785
786
787
788
789
790
791
792
793
794
795
796
797
798
799
800
801
802
803
804
805
806
807
808
809
810
811
812
813
814
815
816
817
818
819
820
821
822
823
824
825
826
827
828
829
830
831
832
833
834
835
836
837
838
839
840
841
842
843
844
845
846
847
848
849
850
851
852
853
854
855
856
857
858
859
860
861
862
863
864
865
866
867
868
869
870
871
872
873
874
875
876
877
878
879
880
881
882
883
884
885
886
887
888
889
890
891
892
893
894
895
896
897
898
899
900
901
902
903
904
905
906
907
908
909
910
911
912
913
914
915
916
917
918
919
920
921
922
923
924
925
926
927
928
929
930
931
932
933
934
935
936
937
938
939
940
941
942
943
944
945
946
947
948
949
950
951
952
953
954
955
956
957
958
959
960
961
962
963
964
965
966
967
968
969
970
971
972
973
974
975
976
977
978
979
980
981
982
983
984
985
986
987
988
989
990
Table of Contents

Advertisement

Quick Links

Download this manual See also: Feature Manual, Maintenance Manual
®
Tekelec EAGLE
5
Integrated Signaling System
Release 35.1
Commands Error Recovery Manual
910-3638-001 Revision B
October 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAGLE 5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tekelec EAGLE 5

Summary of Contents for Tekelec EAGLE 5

  • Page 1 ® Tekelec EAGLE Integrated Signaling System Release 35.1 Commands Error Recovery Manual 910-3638-001 Revision B October 2006...
  • Page 2 Information in this documentation is subject to change without notice. Unauthorized use or copying of this documentation can result in civil or criminal penalties. Any export of Tekelec products is subject to the export controls of the United States and the other countries where Tekelec has operations.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. Introduction Overview ....................1-2 Scope and Audience ................. 1-2 Related Documentation................1-3 Customer Care Center................1-8 Documentation Packaging, Delivery, and Updates......1-8 Chapter 2. Command Rejected Messages Introduction ....................2-2 Message Listing and Description 2 Chapter 3.
  • Page 4 Table of Contents 910-3638-001 Rev B, October 2006...
  • Page 5 List of Tables Table 2-1. Valid Frame ID Parameter Values ...........2-18 Table 2-2. Valid Values for the bps Parameter .........2-51 Table 2-3. Invalid Parameter Combinations that Generate an E2155 Error Message.................2-56 Table 2-4. Conditions that Generate an E2165 Error Message ....2-61 Table 2-5.
  • Page 6 Command ..2-828 inh-alm Table 2-41. Valid Frame ID Parameter Values ........2-879 Table 2-42. EAGLE 5 ISS Link Cards Not Supported ......2-889 Table 2-43. Default Buffer Configuration Sizes ........2-896 Table 3-1. SEAS Cross Reference Table ............3-3...
  • Page 7 Introduction Overview ......................1-2 Scope and Audience ..................1–2 Related Documentation...................1–3 Customer Care Center ..................1–8 Documentation Packaging, Delivery, and Updates ........1–8 910-3638-001 Revision B, October 2006...

  • Page 8: Chapter 1. Introduction

    This document is organized into the following chapters. Chapter 1, Introduction contains general information about the organization of this manual, the audience, references to other Tekelec documentation you might need, information on customer assistance, documentation packaging, delivery, and updates, and a list of acronyms and abbreviations used in the document.

  • Page 9: Related Documentation

    • The Commands Manual contains procedures for logging into or out of the EAGLE 5 ISS, a general description of the terminals, printers, the disk drive used on the system, and a description of all the commands used in the system.
  • Page 10 Engineering and Administration Center (SEAC) or a Signaling Network Control Center (SNCC). Each procedure includes a brief description of the procedure, a flowchart showing the steps required, a list of any EAGLE 5 ISS commands that may be required for the procedure but that are not supported...
  • Page 11 EAGLE 5 ISS. • The FTP-Based Table Retrieve Application (FTRA) User Guide describes how to set up and use a PC to serve as the offline application for the EAGLE 5 ISS FTP Retrieve and Replace feature. • The Hardware Manual - EAGLE 5 ISS contains hardware descriptions and specifications of Tekelec’s signaling products.
  • Page 12 LSMS documentation set and in the EAGLE 5 ISS documentation set. • The LNP Feature Activation Guide contains procedural information required to configure the EAGLE 5 ISS for the LNP feature and to implement these parts of the LNP feature on the EAGLE 5 ISS: — LNP services —...
  • Page 13 (LNP). • The Provisioning Database Interface Manual defines the programming interface that populates the Provisioning Database (PDB) for the EAGLE 5 ISS features supported on the MPS/EPAP platform. The manual defines the provisioning messages, usage rules, and informational and error messages of the interface.

  • Page 14: Customer Care Center

    Customer Care Center The Customer Care Center offers a point of contact through which customers can receive support for problems that may be encountered during the use of Tekelec’s products. The Customer Care Center is staffed with highly trained engineers to provide solutions to your technical questions and issues seven days a week, twenty-four hours a day.

  • Page 15: Chapter 2. Command Rejected Messages

    Command Rejected Messages Introduction ......................2–2 Message Listing and Description..............2–2 910-3638-001 Revision B, October 2006...

  • Page 16: Introduction

    You cannot enter a command at a system terminal if you have not logged on to the EAGLE 5 ISS, or if your user ID does not have the authorization to access the command class for the command you tried to enter.
  • Page 17 EAGLE 5 ISS. E2003 Cmd Rej: Terminal Authority Violation Commands Used: all commands You cannot enter a command at a terminal that is not authorized for that EAGLE 5 ISS command class. Recovery Perform one of the following: •...
  • Page 18 E2000 Messages Command Rejected Messages E2005 Cmd Rej: Argument frame overflow Commands Used: all commands You entered a command in which the frame for the argument detected an overflow condition. Re-enter the command specifying the correct format for the command. Recovery Re-enter the command specifying the correct format and parameters.
  • Page 19 Refer to the Commands Manual for additional information regarding command syntax. E2010 Cmd Rej: Unrecognized command Commands Used: All commands You entered a command that the EAGLE 5 ISS does not recognize. Recovery 1. Verify that you have typed the command correctly. 910-3638-001 Revision B, October 2006...
  • Page 20 E2000 Messages Command Rejected Messages Refer to the Commands Manual for additional information regarding the correct keyword. 2. Make any necessary corrections, and then re-enter the command. E2011 Cmd Rej: Missing mandatory parameter - <parm> Commands Used: all commands You failed to specify a required parameter value for the entered command. Recovery Re-enter the command specifying a valid mandatory command parameter.
  • Page 21 2. Make any necessary corrections and re-enter the command. E2015 Cmd Rej: Missing parameter identifier Commands Used: All commands that have parameters You specified a parameter without an identifier that the EAGLE 5 ISS requires. Recovery 1. Verify that you have entered all parameters correctly.
  • Page 22 E2000 Messages Command Rejected Messages Recovery Re-enter the command specifying a valid value for this command parameter. Refer to the Commands Manual for additional information regarding the range of values and characters that are valid for the specified command parameter. Call your Customer Care Center if this error message appears again.
  • Page 23 Command Rejected Messages E2000 Messages Recovery Re-enter the command specifying a valid value or character for the command parameter. Refer to the Commands Manual for additional information regarding the range of values and characters that are valid for the specified command parameter. Call your Customer Care Center if this error message appears again.
  • Page 24 E2000 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message specifying the correct syntax for the source table. Call your Customer Care Center if this error message appears again. E2022 Cmd Rej: Invalid destination table You attempted to run this command specifying an invalid syntax assigned to the destination table parameter.
  • Page 25 Command Rejected Messages E2000 Messages E2025 Cmd Rej: Invalid card location Commands Used: act-lbp, dact-lbp, ent-card, tst-slk You specified a loc parameter for a card that is an invalid type for the command. • For the act-lbp and dact-lbp commands, the card type in the specified location must be limds0, limt1, or limch (associated with a limt1 card).
  • Page 26 E2000 Messages Command Rejected Messages Recovery 1. Verify the correct IP address containing the allowable range for the four octets. 2. Re-enter the command specifying the correct octet values for the command parameter. Refer to the Commands Manual for the command parameter. Call your Customer Care Center if this error message appears again.
  • Page 27 Command Rejected Messages E2000 Messages Recovery Re-enter the command specifying a third octet value from 1 to 254 for this command parameter. Call your Customer Care Center if this error message appears again. E2031 Cmd Rej: Octet 4 is out of range, 1 . . . 254 - <parm> Commands Used: all commands You have entered an invalid value in octet 4 of the specified command parameter.
  • Page 28 E2000 Messages Command Rejected Messages Recovery Re-enter the command parameter specifying a valid IP address containing the missing second octet. Call your Customer Care Center if this error message appears again. E2034 Cmd Rej: Octet 3 missing - <parm> Commands Used: all commands You have entered for the specified command parameter an IP address in which the third octet is missing.
  • Page 29 Command Rejected Messages E2000 Messages Recovery Re-enter the command parameter specifying a valid IP address that contains the required four octets. Call your Customer Care Center if this error message appears again. E2037 Cmd Rej: Invalid character in IP address - <parm> Commands Used: all commands The specified command parameter contains an invalid character in the IP address.
  • Page 30 E2000 Messages Command Rejected Messages E2039 Cmd Rej: <parm_desc> too long, min <min>, max <max>, - <parm> Commands Used: all commands You entered a string that is too long and is not limited to the maximum number of characters allowed for this command parameter. For the chg-gsms-opcode command, the opname parameter value and the nopname parameter value must be no more than 8 characters long.
  • Page 31 Command Rejected Messages E2000 Messages E2041 Cmd Rej: String pattern nonconformance, alphabetic - <parm> Commands Used: all commands The referenced string pattern is invalid because it does not conform to the required alphabetic content for the command parameter. Recovery Re-enter the command specifying a pattern conforming to the alphabetic content required for the specified command parameter.

  • Page 32: Table 2-1. Valid Frame Id Parameter Values

    E2000 Messages Command Rejected Messages E2044 Cmd Rej: <parm_desc> value is undefined - <parm> Commands Used: all commands You failed to specify a required parameter value for the entered command. For the chg-gsms-opcode command, if the ndfltact parameter is specified, one of the following values must be specified: pass, discard, atierr, route, forward, duplicate, or dupdisc.
  • Page 33 Command Rejected Messages E2000 Messages E2045 Cmd Rej: <parm_desc> num digits incorrect, min <min> max <max> - <parm> Commands Used: all commands You entered an invalid number of digits for a parameter value. The values represented by <parm>, <min>, and <max> vary according to the specific command entered.
  • Page 34 E2000 Messages Command Rejected Messages E2048 Cmd Rej: Unneeded information found Commands Used: all commands You entered a command in which unnecessary information has been found. Recovery Re-enter the command specifying the correct syntax, format and parameters. Refer to the Commands Manual for additional information regarding the correct format, parameters, and syntax for the command.
  • Page 35 Command Rejected Messages E2000 Messages E2051 Cmd Rej: Incorrect information unit, expecting number - <parm> Commands Used: all commands You supplied an invalid number for a parameter value. The value represented by <parm> varies according to the specific command entered. Recovery Re-enter the command specifying a valid number.
  • Page 36 E2000 Messages Command Rejected Messages E2054 Cmd Rej: Incorrect information unit, expecting mnemonic - <parm> Commands Used: all commands You supplied an invalid mnemonic for a parameter value. The value represented by <parm> varies according to the specific command entered. Recovery Re-enter the command specifying a valid parameter value.
  • Page 37 Command Rejected Messages E2000 Messages Call your Customer Care Center if this error message appears again. E2057 Cmd Rej: Incorrect information unit, translation type - <parm> Commands Used: all commands You supplied an incorrect information unit for the translation type. The translation type from <parm>...
  • Page 38 E2000 Messages Command Rejected Messages Recovery Re-enter the command specifying a valid value for this command parameter. Refer to the Commands Manual for additional information regarding the valid range of values for the command parameter. Call your Customer Care Center if this error message appears again. E2060 Cmd Rej: Lower bound exceeds upper bound of range - <parm>...
  • Page 39 Call your Customer Care Center if this error message appears again. E2065 Cmd Rej: CMD parameter is not a valid Eagle command Commands Used: chg-cmd, rtrv-cmd You entered a cmd parameter containing an invalid EAGLE 5 ISS command specified. The cmd parameter value must be a valid system command. Recovery Re-enter the CMD parameter with the correct EAGLE 5 ISS command parameter.
  • Page 40 E2000 Messages Command Rejected Messages E2067 Cmd Rej: Feature Requires at least DSM4GB Commands Used: enable-ctrl-feat The feature cannot be enabled because the installed DSM card is not configured with at least 4 GB of memory. To enable the feature requires DSM cards with at least 4 GB of memory.
  • Page 41 Command Rejected Messages E2000 Messages Recovery Contact your Customer Care Center. E2070 Cmd Rej: IP Address invalid for Address Class Commands Used: all commands The specified IP Address is invalid. Recovery Re-enter the command specifying a valid IP address. Refer to the Commands Manual for additional information regarding the correct information units required for the command parameter.
  • Page 42 E2000 Messages Command Rejected Messages Recovery Re-enter the command specifying a valid Host Number. Refer to the Commands Manual for additional information regarding the correct information units required for the command parameter. Call your Customer Care Center if this error message appears again. E2075 Cmd Rej: Incorrect information unit, expecting num, new or dflt - %s Commands Used: ent-mrn For the ent-mrn command, valid values that can be specified for the mrnset...
  • Page 43 Command Rejected Messages E2100 Messages Recovery Re-enter the command specifying either a numerical value [1-3000] or dflt for the mrnset parameter. Call your Customer Care Center if this error message appears again. E2083 Cmd Rej: GTTSN parameter mustn't be specified Commands Used: chg-gttsel, ent-gttsel, rtrv-gttsel For the chg/ent/rtrv-gttsel commands, the gttsn parameter must not be specified when the Origin-based SCCP Routing feature is enabled.
  • Page 44 E2100 Messages Command Rejected Messages E2101 Cmd Rej: Card location is unequipped Commands Used: act-cdl, act-lbp, blk-slk, chg-appl-sock, chg-bip-fld, chg-ip-card, chg-ip-lnk, chg-lbp, chg-x25-slk, dact-cdl, dact-lbp, dact-slk, dlt-lbp, disp-bp, disp-bip, disp-mem, dlt-appl-rtkey, dlt-bp, dlt-card, dlt-dlk, dlt-ip-node, dlt-ip-rte, ent-appl-sock, ent-bp, ent-dlk, ent-ip-node, ent-ip-rte, ent-slk, ent-lbp, inh-slk, init-card, rept-stat-cdl, rept-stat-lfs, rept-stat-tstslk, rtrv-appl-rtkey, rtrv-card, rtrv-data-insrv, rtrv-data-rtdb, rtrv-dlk, rtrv-ip-card, rtrv-ip-lnk, rtrv-ip-node,...
  • Page 45 Command Rejected Messages E2100 Messages E2103 Cmd Rej: Failed reading the link table Commands Used: chg-x25-slk, dlt-card, dlt-dlk, dlt-ip-node, dlt-slk, ent-dlk, ent-ip-node, ent-slk, rtrv-dlk, rtrv-ip-node, rtrv-slk, rtrv-x25-slk The Link table is corrupt or cannot be found by the system. The Link table contains the link attribute information and must be accessible.
  • Page 46 E2100 Messages Command Rejected Messages NOTE: For EAGLE 5 ISS 31.6 and later, replace all ASM cards with TSM cards. For the ent-card command, re-enter the ent-card command specifying the correct card type and appl combination. Refer to Appendix A of the Commands Manual for a list of valid Card Types and Application Types for the ent-card command.
  • Page 47 Command Rejected Messages E2100 Messages Recovery - TCP/IP links 1. Display the TCP/IP data links in the database. Enter the rtrv-dlk command. 2. Display the TCP/IP nodes in the database. Enter the rtrv-ip-node command. 3. From the outputs from steps 1 and 2, determine if the card location specified has a TCP/IP node and TCP/IP data link assigned to it.
  • Page 48 E2100 Messages Command Rejected Messages E2109 Cmd Rej: Database maintenance is required [or] Cmd Rej: Database repair is required Commands Used: chg-dstn, chg-feat, chg-ls, chg-rte, chg-x25-dstn, chg-x25-rte, chg-x25-slk, dlt-card, dlt-dlk, dlt-dstn, dlt-ip-node, dlt-ls, dlt-rte, dlt-slk, dlt-x25-dstn, dlt-x25-rte, ent-card, ent-dlk, ent-dstn, ent-ip-node, ent-ls, ent-rte, ent-slk, ent-x25-dstn, ent-x25-rte, rtrv-ip-node The command failed because the system detects that:...
  • Page 49 Command Rejected Messages E2100 Messages 4. If you are performing a duplex backup or restore, verify that the level of the source databases residing on both the active and standby OAM fixed disks are identical. NOTE: The error message text is altered for this condition and says “Database repair is required.”...
  • Page 50 E2100 Messages Command Rejected Messages E2112 Cmd Rej: At least one parameter must be changed Commands Used: chg-gta, chg-gtt, chg-gttsel, chg-inpopts, chg-map, chg-meas, chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc, chg-scr-opc, chg-scrset, chg-scr-sio, chg-scr-tt The command was entered without at least one optional parameter specified, or with an invalid optional parameter specified.
  • Page 51 Command Rejected Messages E2100 Messages E2115 Cmd Rej: NDIGITS parameter mandatory with PREFIX parameter You cannot specify the prefix parameter without specifying the ndigits parameter. Recovery Re-enter the command that generated this error message specifying both the prefix and ndigits parameters. Call your Customer Care Center if this error message appears again.
  • Page 52 E2100 Messages Command Rejected Messages Recovery - For E1/T1 links: 1. Verify the transmission rate of the links in the linkset. Enter the command rtrv-ls:lsn=(the linkset the link is being added to). The transmission rate of the link is shown in the BPS field of the output. 2.
  • Page 53 Command Rejected Messages E2100 Messages If the card type, shown in the TYPE field of the rtrv-card output, is either limds0, limocu, or limt1, specify bps=56000. E2120 Cmd Rej: BPS must be 56000 for card type Commands Used: ent-slk You specified an invalid bits-per-second (bps) rate for the card type. If the card type is either limds0 (includes the multi-port LIM), limt1, or limocu, specify a bps parameter value of 56000.
  • Page 54 E2100 Messages Command Rejected Messages E2122 Cmd Rej: Failed reading linkset table Commands Used: chg-ls, chg-rte, chg-rtx, dlt-dstn, dlt-ls, dlt-rte, dlt-rtx, dlt-slk, ent-ls, ent-rte, ent-rtx, ent-slk, rtrv-gtwy-acthresh, rtrv-ls, rtrv-rte, rtrv-rtx, rtrv-slk, set-gtwy-acthresh The Linkset table is corrupt or cannot be found by the system. The Linkset table must be accessible.
  • Page 55 Command Rejected Messages E2100 Messages Recovery 1. Display the current linkset configuration. Enter the rtrv-ls command specifying the linkset name. 2. Deactivate all links in the linkset. Enter the dact-slk command. 3. Confirm the link status is Out-of-Service-Maintenance-Disabled (OOS-MT-DSBLD). Enter the rept-stat-ls command specifying the linkset name.
  • Page 56 E2100 Messages Command Rejected Messages E2127 Cmd Rej: l2tset must be 1-10 for ANSI links, 11-20 for ITU Commands Used: ent-slk The command was entered with a value for the level 2 timer set parameter (l2tset) that is not allowed for the type of signaling link being entered to the database. •...
  • Page 57 Command Rejected Messages E2100 Messages Recovery Re-enter the dlt-slk command specifying the force=yes parameter. E2129 Cmd Rej: CDPNPFX must be specified Commands Used: chg-inpopts You entered a value for the ncdpnpfx or dltpfx parameter (or both), and did not specify the cdpnpfx parameter. Recovery 1.
  • Page 58 E2100 Messages Command Rejected Messages E2131 Cmd Rej: Parameters not valid for card type Commands Used: ent-slk You specified parameters that cannot be used with the card type specified. The parameters specified for the command must be valid for the type of card in the specified card location.
  • Page 59 NOTE: The link parameter has been added as a synonym for the port parameter. Either port or link can be used for a few more EAGLE 5 ISS releases; then the port parameter will be removed.
  • Page 60 E2100 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the ent-slk command specifying the tset parameter and the l1mode=dce parameter. • Re-enter the ent-slk command without specifying the tset parameter. E2136 Cmd Rej: At least one optional parameter is required Commands Used: chg-acg-noc, chg-appl-sock, chg-assoc, chg-atm-lps, chg-attr-seculog, chg-cmd, chg-cmdclass, chg-dstn, chg-ctrl-feat, chg-e1, chg-eisopts, chg-feat,...
  • Page 61 Command Rejected Messages E2100 Messages Recovery 1. Remove the terminal port from service. Enter the inh-trm command. 2. Re-enter the chg-trm command, specifying the communication parameters to change. 3. Return the terminal port to service. Enter the alw-trm command. E2138 Cmd Rej: Failed reading terminal table Commands Used: chg-trm The Terminal table is corrupt or cannot be found by the system.
  • Page 62 E2100 Messages Command Rejected Messages Recovery Re-enter the chg-trm command specifying a value for the prty parameter of either none, even, or odd. You cannot specify the none value if the type=vt320 parameter is specified. E2141 Cmd Rej: Invalid FC value specified Commands Used: chg-trm You specified an fc parameter value that is not allowed.
  • Page 63 Command Rejected Messages E2100 Messages E2143 Cmd Rej: The terminal state request was unanswered Commands Used: chg-trm There is a problem with the OAM card, the TDM card, or the extended bus interface (EBI) between the two. This problem is preventing the system from determining what state the specified terminal or port is in.
  • Page 64 E2100 Messages Command Rejected Messages E1/T1 MIM cards are those indicated by the terms lime1, limt1, or limch. 1. Display the cards in the database, enter the rtrv-card command. The card must be equipped and must be one of the following cards: •...

  • Page 65: Table 2-2. Valid Values For The Bps Parameter

    Command Rejected Messages E2100 Messages Recovery - ent-card 1. A DSM card is not allowed in the specified card location. The DSM card must be entered in an odd-numbered card location. The n+1 card location next to the DSM card must be empty, where n is the odd-numbered location (for example, if the DSM is in location 1101, then the 1102 card location must be empty).
  • Page 66 E2100 Messages Command Rejected Messages Recovery 1. Verify that the command was entered correctly. 2. Re-enter the ent-slk command. 3. If the command was entered correctly, • Verify the transmission rate of the links in the linkset that you wish to add the link to.
  • Page 67 Command Rejected Messages E2100 Messages E2149 Cmd Rej: TYPE = SCCS and PRTY=NONE combination not allowed Commands Used: chg-trm You specified the type=sccs parameter and the prty=none parameter together. This parameter combination is not allowed by this command. Recovery Re-enter the chg-trm command specifying a different value for either the type or the prty parameter.
  • Page 68 E2100 Messages Command Rejected Messages Recovery Re-enter the command. Refer to the Commands Manual (ent-card command) for additional information regarding valid values for the card location. E2153 Cmd Rej: Card slot location out of range Commands Used: act-dlk, canc-dlk, chg-x25-slk, dlt-card, dlt-dlk, dlt-ip-node, dlt-slk, ent-card, ent-dlk, ent-ip-node, ent-slk, ent-x25-rte, rept-stat-db, rept-stat-dlk, rept-x25-meas, rtrv-card, rtrv-dlk,...
  • Page 69 Command Rejected Messages E2100 Messages Recovery Re-enter the command specifying a card location that is not for an OAM, TDM, MDAL, or HMUX card. Verify that the card type is valid for the command as follows: • dlt-card, ent-card, rtrv-card — all card types except OAM, TDM, MDAL, or HMUX •...

  • Page 70: An E2155 Error Message

    E2100 Messages Command Rejected Messages Table 2-3. Invalid Parameter Combinations that Generate an E2155 Error Message. Command Invalid Parameter Combination Entered You cannot specify the following parameter combinations: act-flash, init-flash - loc and sloc / eloc parameters cannot be specified together - Either loc or sloc / eloc must be specified - appl is required if sloc / eloc are specified - sloc and eloc must be specified together...
  • Page 71 Command Rejected Messages E2100 Messages Table 2-3. Invalid Parameter Combinations that Generate an E2155 Error Message. (Continued) Command Invalid Parameter Combination Entered You intermixed digit manipulation parameters nsdd and nsds chg-gtcnv (new suffix digits), npdd and npds (new prefix digits), or RDMOD (reset digit modifiers).
  • Page 72 E2100 Messages Command Rejected Messages Table 2-3. Invalid Parameter Combinations that Generate an E2155 Error Message. (Continued) Command Invalid Parameter Combination Entered You cannot specify both the stat and lsn parameters in the same rept-stat-ls command. You can only specify one of these parameters, but not both, in this command.
  • Page 73 Command Rejected Messages E2100 Messages Table 2-3. Invalid Parameter Combinations that Generate an E2155 Error Message. (Continued) Command Invalid Parameter Combination Entered You cannot specify the pctype or pcst parameters along with rtrv-rte one of the following parameters: clli, dpc/dpca/dpci/dpcn/dpcn24, lsn, ncai in this command. Only one of the following parameters may be specified: cic, ilns, rtrv-rtx opc or si.
  • Page 74 E2161 Cmd Rej: Removable cartridge contains Eagle data (use FORCE=YES) Commands Used: format-disk The removable cartridge to be formatted contains EAGLE 5 ISS data. To format a cartridge already containing EAGLE 5 ISS data, force=yes must be specified. Recovery 1.
  • Page 75 E2163 Cmd Rej: CLLI used by STP Commands Used: chg-dstn, ent-dstn The specified CLLI is the same as the CLLI that is assigned to the EAGLE 5 ISS. Recovery 1. Enter the rtrv-sid command to verify the CLLI for the EAGLE 5 ISS.

  • Page 76: Table 2-4. Conditions That Generate An E2165 Error Message

    E2100 Messages Command Rejected Messages Table 2-4. Conditions that Generate an E2165 Error Message Command Condition format-disk You specified type=meas or type=system for this command. This requires that a removable cartridge be inserted in the removable cartridge drive. You specified loc=1117 for the command. Specifying card tst-disk location 1117 requires that a removable cartridge must be present in the removable cartridge drive.
  • Page 77 Command Rejected Messages E2100 Messages Recovery - chg-sid 1. Enter the rtrv-sid command to verify the site point code and capability point code. 2. Enter rtrv-dstn to display the destination point codes in the database. 3. Enter rtrv-ls to display the adjacent point codes in the database. 4.
  • Page 78 The capability point codes are shown in the CPCA, CPCI, CPCN, and CPCN 24 fields of the rtrv-sid command output. The site point codes of the EAGLE 5 ISS are shown in the PCA, PCI, PCN, and PCN24 fields of the rtrv-sid command output.
  • Page 79 The point code specified (destination point code or an alias point code), is the same as the site point code of the EAGLE 5 ISS destination point code. The specified Adjacent Point Code cannot match the destination point code of the EAGLE 5 ISS as specified in its self-identity.
  • Page 80 E2100 Messages Command Rejected Messages E2169 Cmd Rej: Point code out of range Commands Used: chg-gta, chg-gtt, chg-ls, chg-map, chg-sid, dlt-gta, dlt-map, ent-dstn, ent-gta, ent-gtt, ent-ls, ent-map, ent-rtx, ent-sid, ent-spc, rtrv-gta, rtrv-gtt The specified point code is out of the allowable range. For the chg-ls and ent-ls commands, if the system is configured for ANSI formatted point code, the network indicator (ni) value of the far end pc parameter must be 6 or greater when the cluster value (nc) is 0.
  • Page 81 Command Rejected Messages E2100 Messages You entered an init-flash command to load an inactive flash GPL onto a card, and the card is currently running an inactive flash GPL. Recovery - act-upgrade 1. Enter the act-upgrade:action=dbstatus command to verify the phase that the upgrade process is in.
  • Page 82 E2100 Messages Command Rejected Messages E2173 Cmd Rej: Failed reading level 3 timer set table Commands Used: chg-l3t The Level 3 Timer Set table is corrupt or cannot be found by the system. The Level 3 Timer Set table contains the level 3 timer set information. Recovery Re-enter the chg-l3t command.
  • Page 83 Command Rejected Messages E2100 Messages E2177 Cmd Rej: Destination parameter not supported Commands Used: chg-db The command was entered specifying the destination (dest) parameter, and the action=backup parameter was not specified. If you specify the dest parameter, the action=backup parameter must also be specified. Recovery Re-enter the chg-db command specifying both the dest and the action=backup parameters.
  • Page 84 E2100 Messages Command Rejected Messages E2180 Cmd Rej: Current stdby OAM db is not supported for this upgrade Commands Used: act-upgrade The database on the standby TDM is not at the proper level for this command. Recovery Enter the act-upgrade:action=dbstatus command to verify the version of the database on the standby TDM.
  • Page 85 Command Rejected Messages E2100 Messages Recovery Re-enter the chg-sid command specifying a value for only one of the following parameters: ncpc, ncpca, ncpci, ncpcn, or ncpcn24. E2183 Cmd Rej: Capability point code is already being used Commands Used: chg-sid You specified a capability point code (cpca, cpci, cpcn, cpcn24) that is already being used to define an STP.
  • Page 86 DPC. The capability point code (cpc) parameter cannot be already assigned as a route destination point code. Recovery 1. Display the route DPCs for this EAGLE 5 ISS. Enter the rtrv-dstn command. 2. Re-enter the chg-sid command, specifying a value for the cpc parameter that differs from all of the DPCs displayed in step 1.
  • Page 87 Command Rejected Messages E2100 Messages 2. Display the destination point codes in the database. Enter the rtrv-dstn command. The ITU-I destination point codes are shown in the DPCI field of the output. 3. Re-enter the chg-sid command specifying a point code that does not match the capability point code, and does not match any point codes in the destination point codes.
  • Page 88 The EAGLE 5 ISS requires that, if destination point codes of a particular point code type are to be used, the EAGLE 5 ISS’s self ID must be defined with a point code of the same point code type.
  • Page 89 Command Rejected Messages E2100 Messages Recovery Re-enter the chg-slt command. Call your Customer Care Center if this error message appears again. E2192 Cmd Rej: Pattern contains invalid characters Commands Used: chg-slt The specified pattern contains characters that are not allowed. The pattern can contain only the characters 0 –...
  • Page 90 E2100 Messages Command Rejected Messages E2195 Cmd Rej: NCDPNPFX already exists in INPOPTS Table Commands Used: chg-inpopts You entered a command to change a New Called Party Number Prefix to the prefix specified in the ncdpnpfx parameter, and the new Prefix already exists in the INPOPTS table.
  • Page 91 Command Rejected Messages E2100 Messages Recovery 1. Display the user IDs in the database. Enter the rtrv-user command. 2. Re-enter the command that generated this error message with a value for the uid parameter (ent-user command) or nuid (chg-user command) that is not shown in the output of step 1.
  • Page 92 E2200 Messages Command Rejected Messages Recovery 1. Display the user IDs in the database. Enter the rtrv-user command. 2. Re-enter the command that generated this error message with a value for the uid parameter that is shown in the output of step 1. E2200 Cmd Rej: Database maint.
  • Page 93 Command Rejected Messages E2200 Messages E2202 Cmd Rej: Shelf location already equipped Commands Used: ent-shlf The shelf specified by the loc parameter already exists in the database. The shelf specified by the loc parameter cannot be in the database. Recovery 1.
  • Page 94 E2200 Messages Command Rejected Messages E2204 Cmd Rej: Waiting for duplex mode in provisioning subsystem Commands Used: Any command used to update a database An attempt was made to update a database immediately following a dual OAM boot, a switchover, or a database repair, and before the detection of an active standby.
  • Page 95 Command Rejected Messages E2200 Messages E2207 Cmd Rej: Location type cannot receive messages Commands Used: send-msg The destination location is not equipped to receive messages. You may have specified the wrong card location (loc parameter). Recovery Re-enter the send-msg command that generated this error message specifying the correct loc parameter value.
  • Page 96 E2200 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the ent-bp command that generated this error message specifying only the dr parameter. • Re-enter the ent-bp command that generated this error message specifying only the da parameter. Call your Customer Care Center if this error message appears again.
  • Page 97 Command Rejected Messages E2200 Messages Call your Customer Care Center if this error message appears again. E2212 Cmd Rej: Invalid card type for this command Commands Used: act-flash, chg-appl-sock, chg-bip-fld, chg-bip-rec, chg-e1, chg-ip-card, chg-ip-lnk, chg-t1, disp-bip, disp-bp, disp-mem, dlt-appl-rtkey, dlt-bp, dlt-e1, dlt-ip-rte, dlt-t1, ent-appl-sock, ent-bp, ent-card, ent-e1, dlt-ip-rte, ent-slk, ent-t1, ent-trace, init-flash, init-imt-gpl, rept-x25-meas, rtrv-appl-rtkey, rtrv-bip,...
  • Page 98 E2200 Messages Command Rejected Messages Recovery - chg-t1, dlt-t1, ent-t1, rtrv-t1 The card specified by the (loc) parameter must be a limt1 card type. 1. Display the card’s configuration. Enter the rtrv-card command specifying the card location that generated this error message. The card’s type is shown in the TYPE field of the output.
  • Page 99 Command Rejected Messages E2200 Messages Call your Customer Care Center if this error message appears again. Recovery - ent-slk Display the card’s configuration. Enter the rtrv-card command specifying the card location that generated this error message. The card’s type is shown in the TYPE field of the output.
  • Page 100 E2200 Messages Command Rejected Messages Recovery - chg-ip-card, rtrv-ip-card This command requires an allowed DSM card. or IPSM 1. Display the card’s configuration. Enter the rtrv-card command specifying the card location that generated this error message. The card’s type is shown in the TYPE field of the output.
  • Page 101 Command Rejected Messages E2200 Messages Recovery - rept-x25-meas The card type can be X.25 signaling links that are equipped in the database. 1. Verify the specified card applications. Enter the rtrv-card command. Cards that can contain an X.25 signaling link are assigned the ss7gx25 application. This is shown in the APPL field in the output.
  • Page 102 E2200 Messages Command Rejected Messages E2213 Cmd Rej: Missing parameter - BC Commands Used: disp-mem, ent-bp You ran this command without specifying the bc parameter (number of data bytes to display). Recovery Re-enter the command that generated this error message specifying the correct bc parameter value.
  • Page 103 Command Rejected Messages E2200 Messages • Re-enter the ent-bp command that generated this error message specifying the correct da parameter value. Call your Customer Care Center if this error message appears again. E2216 Cmd Rej: CDPNPFX must not be NONE Commands Used: chg-inpopts The cdpnpfx parameter cannot have a specified value of none.
  • Page 104 Commands Used: act-file-trns, copy-fta, copy-seculog, disp-fta-dir, dlt-fta You entered the command while another command is already in progress. The EAGLE 5 ISS does not allow this action. Only one file transfer may be active at one time. Recovery Wait until the file transfer is complete, then re-enter the command.
  • Page 105 Command Rejected Messages E2200 Messages E2222 Cmd Rej: CDPNPFX doesn't exist in INPOPTS Table Commands Used: chg-inpopts You entered a command to change or delete a value for the cdpnpfx parameter that is not in the INPOPTS table. Recovery Enter the rtrv-inpopts command. The CDPNPFX field in the output shows a list of valid names.
  • Page 106 E2200 Messages Command Rejected Messages E2225 Cmd Rej: SRC and DEST must be specified Commands Used: chg-db, copy-fta You failed to specify both the source and the destination parameters for this operation. Recovery Re-enter the command that generated this error message specifying correct src and dest parameter values.
  • Page 107 Command Rejected Messages E2200 Messages Recovery Verify the number of cdpnnai values in the INPOPTS table. Enter the rtrv-inpopts command. • If the number of CDPNNAIs listed in the CDPNNAI column of the output is less than 5, re-enter the chg-inpopts command that generated this error message.
  • Page 108 E2200 Messages Command Rejected Messages E2231 Cmd Rej: Use SFILE when specifying DTBL Commands Used: copy-fta You cannot copy information out of source file into a Destination table without specifying both the (dtbl) and (sfile) parameters. A source file must be specified when a Destination table is specified.
  • Page 109 Command Rejected Messages E2200 Messages Call your Customer Care Center if this error message appears again. E2234 Cmd Rej: Must specify ALL=YES to delete all files Commands Used: dlt-fta You attempted to run this command specifying the all parameter not specified or specified as no, and with the filename not specified as well.
  • Page 110 E2200 Messages Command Rejected Messages • Specify appl=oam when initclk and appl are specified, or • Specify appl=eoam when initclk and appl are specified. E2236 Cmd Rej: Must specify GPL name and version Commands Used: chg-gpl, rtrv-stp For the chg-gpl command, if either of the appl or ver parameters are specified, then both of these parameters must be specified.
  • Page 111 Command Rejected Messages E2200 Messages Recovery If you want to execute the aud-data command again, wait for the previously entered aud-data command to finish executing. Otherwise, no action is necessary. E2240 Cmd Rej: Card location must be 1114, 1116, or 1117 Commands Used: copy-fta, disp-fta-dir, disp-tbl, set-lba, set-tbl The command was entered with a card location other than the TDMs (1114, 1116),...
  • Page 112 E2200 Messages Command Rejected Messages E2242 Cmd Rej: Destination card invalid Commands Used: chg-bip-fld, chg-bip-rec, disp-bip, rtrv-bip, tst-bip The command was entered with a card location (loc) that is either an HMUX or MDAL card. These card locations are not valid with these commands. Recovery Re-enter the command specifying a card location that is not an HMUX or MDAL card.
  • Page 113 Command Rejected Messages E2200 Messages E2246 Cmd Rej: Command Class Management feature must be enabled Commands Used: chg-cmd, chg-cmdclass, chg-secu-trm, chg-user, ent-user, rtrv-cmd, rtrv-cmdclass These commands or a configurable command class name are not allowed until the Command Class Management feature has been enabled. You must enable the Command Class Management feature before these commands are supported.
  • Page 114 E2200 Messages Command Rejected Messages Recovery No action required. If you want to activate the echoing of the terminal’s output, enter the act-echo command. E2254 Cmd Rej: Minutes out of range Commands Used: act-lbp, rtrv-log, rtrv-seculog, set-time You specified an invalid range value for the minutes component. The minutes component must be in the range 00–59.
  • Page 115 Command Rejected Messages E2200 Messages 2. Activate the inhibited terminal. Enter the rst-trm or the alw-trm command specifying the number of the inhibited terminal. 3. Re-enter the act-echo command. E2257 Cmd Rej: Terminal is currently out of service Commands Used: act-echo, inh-trm, rmv-trm Table 2-5 lists by command the conditions that may have generated the error message.
  • Page 116 E2200 Messages Command Rejected Messages E2259 Cmd Rej: Terminal already echoing to specified terminal Commands Used: act-echo An attempt was made to echo the terminal’s output to a terminal that is already being used for this purpose. Recovery No action is necessary since the terminal’s output is being echoed to the specified terminal.
  • Page 117 Command Rejected Messages E2200 Messages 2. If you are not the user logged on to the terminal that issued the command that generated this error message, enter the rept-stat-user command to verify the user ID that is logged on to this terminal. The terminal ID is shown in the system ID region of the terminal display.
  • Page 118 E2200 Messages Command Rejected Messages minlen = minimum number of characters required. alpha = minimum number of alpha characters required num = minimum number of number characters required punc = minimum number of punctuation characters required. 2. Re-enter the command specifying a password that contains from five-to-twelve alphanumeric characters.
  • Page 119 Command Rejected Messages E2200 Messages E2266 Cmd Rej: Class name is not an existing configurable command class Commands Used: chg-cmd, chg-secu-trm, chg-user, ent-user The arguments specified by the Configurable Command Class names (parameters CC1 to CC8) must be set to default or provisioned to configurable command class names.
  • Page 120 E2200 Messages Command Rejected Messages Recovery 1. Re-enter the command that generated this error message specifying the correct loc parameter. 2. If this error message appears again, perform the following: • Press the F-11 function key on the terminal, to toggle it to its alternate mode, and re-enter the command.
  • Page 121 Command Rejected Messages E2200 Messages E2272 Cmd Rej: Invalid GPL type for this command Commands Used: alw-card, init-card, init-imt-gpl, rst-card You specified an invalid code parameter or an invalid appl parameter. If the serial parameter is specified, the value specified for the appl parameter must be one of the following: atmansi, ccs7itu, gls, sccp, ss7ansi, ss7gx25, stplan, emdc, or all.
  • Page 122 E2200 Messages Command Rejected Messages Recovery Re-enter the command specifying the tt parameter. E2275 Cmd Rej: Day-to-hour measurement data not yet collected Commands Used: rept-ftp-meas, rept-meas The time that the command was entered to specify a measurement report for day-to-hour measurements (type=avldth or type=mtcdth) was between midnight (00:00) and 59 minutes past midnight (00:59).
  • Page 123 Command Rejected Messages E2200 Messages Recovery Re-enter the command specifying either the (type=avld or type=mtcd) parameter after routine collection is complete. E2278 Cmd Rej: 30-minute measurement collection in progress Commands Used: chg-ctlr-feat, chg-measopts, rept-ftp-meas, rept-meas You entered the chg-ctlr-feat command to turn on the 15 Minute Measurements feature while a 30-minute measurement collection was already in progress.

  • Page 124: Table 2-6. Valid Type/Period Parameters For

    E2200 Messages Command Rejected Messages Recovery Re-enter the command after the 15-minute measurement collection is complete. (The prior period is no longer accessible). E2280 Cmd Rej: Invalid PERIOD for this TYPE or ENTTYPE Commands Used: rept-ftp-meas, rept-meas This error message is output when the period parameter is specified with a report type (type) parameter that is not allowed.

  • Page 125: Table 2-8. Valid Type/Entype Parameters For

    Command Rejected Messages E2200 Messages Recovery Re-enter the command, specifying the compatible type and period parameters. E2281 Cmd Rej: Invalid ENTTYPE for this TYPE Commands Used: rept-ftp-meas, rept-meas You specified an invalid combination of the type (report type) and enttype (entity type) parameters.

  • Page 126: Table 2-9. Valid Type/Enttype Parameters For

    E2200 Messages Command Rejected Messages Table 2-9. Valid type/enttype Parameters for the rept-ftp-meas Command Entity Report Types (type=) parameter Type (enttype) systot comp mtcd mtcdth mtch mtcs nm avl avld avldth gtwy rbase Value link lnkset stplan origni origninc lsdestni lsorigni lsonismt mapscrn...
  • Page 127 Command Rejected Messages E2200 Messages Recovery Perform one of the following: • Re-enter the command specifying the period parameter with values last, active, or all, without specifying the hh, qh, or the day parameter. • Re-enter the command specifying the period=specific and the hh, qh, or the day parameter.
  • Page 128 E2200 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the rept-meas command specifying the period parameter with values last, active, or all without specifying the hh, qh, or the day parameter. • Re-enter the rept-meas command specifying the period=specific and the hh, qh, or the day parameters.
  • Page 129 Command Rejected Messages E2200 Messages Recovery Perform one of the following: • Re-enter the rept-meas command specifying the period=active parameter with an acceptable parameter combination. • Re-enter the rept-meas command specifying either last or specific for the period parameter. E2288 Cmd Rej: Either LSN or LOC and LINK must be specified Commands Used: rept-meas You specified the link entity type, and the lsn parameter or the loc and port/link parameters were not specified.
  • Page 130 E2200 Messages Command Rejected Messages E2290 Cmd Rej: Hourly measurement collection in progress Commands Used: rept-ftp-meas, rept-meas The command was entered with either the type=avldth, type=ntcdth, or type=mtch parameter during routine collection. Recovery Re-enter the command after collection is complete. (The prior period is no longer accessible).
  • Page 131 Command Rejected Messages E2200 Messages E2293 Cmd Rej: TRM parameter not valid for type-enttype combo Commands Used: rept-meas You selected a terminal ID (printer location) that was not compatible with the information being sought, as defined by the type and enttype parameters. Recovery Perform one of the following: •...
  • Page 132 E2200 Messages Command Rejected Messages E2296 Cmd Rej: Both LOC and LINK must be specified Commands Used: rept-meas, rtrv-slk You entered one of the following commands: For the rept-meas command, you cannot specify the enttype=link parameter without specifying either the loc or port/link (or both) parameters. For the rtrv-slk command, you must specify either the loc or port/link, or both parameters.
  • Page 133 Command Rejected Messages E2300 Messages • Re-enter the rept-meas command specifying enttype=link and include the loc and port parameters. • Re-enter the rept-meas command specifying enttype=stplan and include the loc parameter. E2299 Cmd Rej: LINK parameter valid only when ENTTYPE=LINK Commands Used: rept-meas If the port/link parameter is specified, the enttype must be equal to link.
  • Page 134 E2300 Messages Command Rejected Messages E2301 Cmd Rej: LSN parameter not valid for type-enttype combination Commands Used: rept-meas You specified the lsn parameter with an invalid type/enttype parameter combination. You cannot specify the lsn parameter with the following parameters: enttype=stp/tt/stplan/origni/origninc/lnp/np/mapscrn or type=systot.
  • Page 135 Command Rejected Messages E2300 Messages Recovery 1. Display the linksets in the database. Enter the rtrv-ls command. 2. Re-enter the command specifying one of the linkset names from step 1. E2304 Cmd Rej: Invalid TYPE Commands Used: rept-meas, rept-stat-lnp The following Recovery procedures list the appropriate remedial action to take for each command that generates this error message.
  • Page 136 E2300 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the command specifying another type of on-demand measurements report. • Wait until the on-demand measurements report that generated this error message has finished printing, then re-enter the command that generated this error message.
  • Page 137 Command Rejected Messages E2300 Messages The qh parameter must specify a quarter-hourly boundary (the end of the requested quarter-hour for the report) for valid report types (avld, mtcd, nm, rbase, and mtcs are excluded). Recovery Re-enter the command without specifying the hh or qh parameter. E2309 Cmd Rej: NI required Commands Used: rept-meas You omitted the required ni parameter.
  • Page 138 E2300 Messages Command Rejected Messages Recovery Re-enter the disp-disk command that generated this error message specifying the correct SCSI syntax. Call your Customer Care Center if this error message appears again. E2314 Cmd Rej: Invalid filename entered Commands Used: chg-tbl, copy-fta You entered this command specifying an invalid filename.
  • Page 139 Command Rejected Messages E2300 Messages Recovery Re-enter the chg-tbl command that generated this error message specifying the correct id parameter value. Call your Customer Care Center if this error message appears again. E2318 Cmd Rej: Invalid file length Commands Used: chg-tbl You entered an invalid value for the filelength parameter.
  • Page 140 E2300 Messages Command Rejected Messages You may also specify type=emsalm for terminal numbers from 1 to 16. Recovery Re-enter the chg-trm command specifying the correct the type parameter. E2321 Cmd Rej: Communication Settings are not allowed on TELNET terminals Commands Used: chg-trm Communications parameters are invalid for non-serial terminals, which are any terminal number 17 or above.
  • Page 141 Command Rejected Messages E2300 Messages 2. For the ent-dstn and chg-dstn commands, enter the rtrv-sid command to verify the site point codes and capability point codes in the system. The site point codes are shown in the PCA, PCI, and PCN fields of the output. The capability point codes are shown in the CPCA, CPCI, CPCN fields of the output.
  • Page 142 E2300 Messages Command Rejected Messages Recovery - rtrv-tt Perform one of the following actions: • Verify that the alias has been entered correctly and re-enter the command. • Enter the rtrv-tt command without specifying any parameters. E2325 Cmd Rej: Alias type matches DPC type Commands Used: chg-dstn, ent-dstn The command was entered with a destination point code of one type and an alias point code of the same type.
  • Page 143 Command Rejected Messages E2300 Messages 1. Add the specified point code to the Destination Point Code table. Enter the ent-dstn command. 2. Re-enter the command specifying the point code that generated this error message. E2328 Cmd Rej: CLLI not defined in route table Commands Used: rtrv-dstn, rtrv-rte You cannot specify the clli parameter if the value for the clli parameter is not defined in the Route table.
  • Page 144 E2300 Messages Command Rejected Messages Recovery Re-enter the dlt-rte command specifying the lsn parameter. E2331 Cmd Rej: Cannot specify LSN parameter with ALL=YES Commands Used: dlt-rte You specified both the lsn and all=yes parameters. To delete all routes for a given route entry, the all=yes parameter must be used without an lsn value.
  • Page 145 1. Display all destination point codes in the database. Enter the rtrv-dstn command. 2. Display the point code of this EAGLE 5 ISS and its capability point code. Enter the rtrv-sid command. 3. Re-enter the ent-dstn command specifying a point code that is not shown in the outputs of steps 1 and 2.
  • Page 146 E2300 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message specifying the correct clli parameter value. Call your Customer Care Center if this error message appears again. E2336 Cmd Rej: GWSA, GWSM, GWSD are invalid without SCRSET specified Commands Used: chg-ls, ent-ls There is currently no gateway screening screen set assigned to this linkset.
  • Page 147 Command Rejected Messages E2300 Messages Recovery Re-enter the command that generated this error message specifying the correct clli parameter value. Call your Customer Care Center if this error message appears again. E2339 Cmd Rej: PC/CLLI does not match current PC/CLLI of the STP Commands Used: rtrv-dstn, ent-dstn You assigned an invalid value to the clli parameter.
  • Page 148 1. Display the destination point codes in the database. Enter the rtrv-dstn command specifying no parameters. 2. Display the point code and the capability point code of the EAGLE 5 ISS. Enter the rtrv-sid command. 3. Re-enter the ent-dstn command specifying a point code that is not in the...
  • Page 149 Command Rejected Messages E2300 Messages Recovery 1. Display the linkset that generated this error message. Enter the rtrv-ls command specifying the linkset name (lsn) that generated this error message. • If the adjacent point code is an ANSI point code, the adjacent point code of the linkset is shown in the APCA field of the rtrv-ls output.
  • Page 150 E2300 Messages Command Rejected Messages E2343 Cmd Rej: Linkset APC/SAPC is already being used Commands Used: chg-ls, ent-ls The specified adjacent point code (apc) or secondary adjacent point code (sapc) is already assigned to another linkset. Only one linkset can be assigned to an apc or sapc.
  • Page 151 Command Rejected Messages E2300 Messages Recovery 1. Display the linksets in the database. Enter the rtrv-ls command specifying no parameters. 2. Re-enter the command specifying a linkset name from the output in step 1. E2347 Cmd Rej: Linkset table full Commands Used: ent-ls, chg-ls The Linkset table contains the maximum 1024 linksets and an attempt was made to add another linkset.
  • Page 152 E2300 Messages Command Rejected Messages E2349 Cmd Rej: Linkset Type used for cluster route cannot be A or E Commands Used: ent-rte When the destination address is a network cluster address, the linkset can only be a B, C, or D linkset. Recovery Re-enter the ent-rte command specifying a B, C, or D linkset.
  • Page 153 Command Rejected Messages E2300 Messages Recovery - rtrv-rte Re-enter the rtrv-rte command without specifying the lsn parameter. E2353 Cmd Rej: Routeset is full Commands Used: ent-dstn, ent-rte The specified routeset already has six routes in it. A routeset can contain up to six routes.
  • Page 154 E2300 Messages Command Rejected Messages Recovery 1. Display the linksets in the route. Enter the rtrv-rte command specifying the specified route. 2. Display the linksets in the database. Enter the rtrv-ls command. 3. Using the outputs of steps 1 and 2, re-renter the ent-rte command specifying a linkset that is in the database but is not assigned to the specified route.
  • Page 155 Command Rejected Messages E2300 Messages E2358 Cmd Rej: Routeset is empty Commands Used: dlt-rte The command was entered with the all=yes parameter, and the routeset contains no routes. If the all=yes parameter is specified, the routeset must have routes in it. Recovery 1.
  • Page 156 E2300 Messages Command Rejected Messages 2. If the screen set name was entered correctly and this error message appears again, display the screen sets in the database. Enter the rtrv-scrset command specifying no parameters. 3. Re-enter the command specifying a valid screen set name that is in the database.
  • Page 157 Command Rejected Messages E2300 Messages Recovery 1. Display the cards that are defined in the database. Enter the rtrv-card command. Verify that the card you specified in the loc parameter is the correct IPSM card. 2. If you specified the correct card in the loc parameter, go to step 4. 3.
  • Page 158 E2300 Messages Command Rejected Messages E2366 Cmd Rej: LOC must be specified Commands Used: inh-alm, rept-stat-card, unhb-alm The following Recovery procedures list by command the condition that generated the error message and the remedial action to take. For the rept-stat-card command, if the mode parameter is specified, the loc parameter must also be specified.
  • Page 159 Command Rejected Messages E2300 Messages Recovery Re-enter the rept-stat-card command specifying either the loc or stat parameters, but not both. E2368 Cmd Rej: System busy - try again later Commands Used: act-flash, alw-card, alw-map-ss, alw-trm, blk-slk, canc-cmd clr-imt-stats, dact-slk, init-flash, inh-alm, inh-card, inh-map-ss, init-imt-gpl, init-mux, rept-imt-info, rept-imt-lvl1, rept-imt-lvl2, rept-stat-alm, rept-stat-card, rept-stat-clk, rept-stat-eroute,...
  • Page 160 NOTE: The partition=disk parameter is accepted in this situation, as this tests the entire disk and does not care about individual partitions. The partition=disk parameter is used only by Tekelec for debug purposes. Recovery Re-enter the tst-disk command specifying a valid partition parameter value for the disk being tested.
  • Page 161 Command Rejected Messages E2300 Messages E2370 Cmd Rej: Terminal Id not entered Commands Used: rst-trm You cannot enter the reset terminal command without specifying the terminal id (trm) parameter. You must enter the trm parameter for this command to execute. Recovery Re-enter the rst-trm command specifying the trm parameter.
  • Page 162 E2300 Messages Command Rejected Messages E2372 Cmd Rej: Terminal is not equipped Commands Used: rmv-trm, rst-trm The specified trm number has no terminal assigned to it. Recovery 1. Enter the rtrv-trm command to display all the terminals. 2. With the output from step 1 as a guide, re-enter the command specifying a trm number that has a terminal assigned to it.
  • Page 163 Command Rejected Messages E2300 Messages VSCCP cards are shown by the entries DSM in the TYPE field and VSCCP in the APPL field. 2. If there are no SCCP or VSCCP cards in the system, no action is necessary. 3. If there are SCCP or VSCCP cards in the system, re-enter the command. Call your Customer Care Center if this error message appears again.
  • Page 164 E2300 Messages Command Rejected Messages E2377 Cmd Rej: No test link message is sent Commands Used: tst-slk You either entered this command while another action command was in progress, or you specified a card that is not a LIM card. Recovery 1.
  • Page 165 Command Rejected Messages E2300 Messages E2379 Cmd Rej: Missing parameter Commands Used: chg-gta, chg-isupvar-attrib, ent-gta, ent-slk, rept-stat-slk, rtrv-isupvar-attrib For the chg-gta command: • If the value of the xlat parameter is changed from udts/disc to dpc, dpcngt, or dpcssn, then gta/egta or cgpc or opc or cgssn/ecgssn, pc/pca/pci/pcn/pcn24, and ri must be specified.
  • Page 166 E2300 Messages Command Rejected Messages • If the loc parameter specifies a Channel card (limch), the t1loc parameter must specify the E1/T1 MIM card location of the T1 interface that will service the Channel card timeslot. • If the loc parameter specifies an E1/T1 MIM card used as a T1 card (limt1) or Channel card (limch), the timeslot (ts) parameter must also be specified.
  • Page 167 Command Rejected Messages E2300 Messages 2. Use the information displayed in step 1 to determine which ports are not being used. For example, the PST field might display OOS-MT-DSBLD for a port not in use. 3. Enter the chg-trm command specifying the type=none parameter for the terminals on the ports not being used (from step 2).
  • Page 168 E2300 Messages Command Rejected Messages E2383 Cmd Rej: MCP card must be IS-ANR Restrict to enable measplatform Commands Used: chg-measopts You entered the chg-measopts command specifying the platformenable parameter to enable the Measurements Platform collection function. At least one MCPM card must be in the IS-ANR Restrict state before you can enable the Measurements Platform collection function.
  • Page 169 Command Rejected Messages E2300 Messages Recovery - dact-rstst The linkset specified by the lsn parameter must be in both the Linkset table and the DPC’s routeset. In this case, it failed to meet either or both conditions. 1. Acquire the identifying information for the provisioned clusters. Enter the command rept-stat-cluster command without parameters.
  • Page 170 E2300 Messages Command Rejected Messages 2. Re-enter the command specifying the mode=full parameter, and the dpc parameter with a point code from the output of step 1, for a report with the additional information. Re-enter the command specifying no parameters for a summary report. Recovery - rept-stat-dstn You entered the mode=full parameter and the destination point code parameter (dpc, dpca, dpcn, dpcn24, dpci) was not specified, as required.
  • Page 171 Command Rejected Messages E2300 Messages Recovery Re-enter the rept-stat-dstn command that generated this error message specifying the correct (pc) parameter value. Call your Customer Care Center if this error message appears again. E2389 Cmd Rej: No troubles to Display Commands Used: rtrv-trbl The command was entered to display an entry from the trouble log, and no troubles were found.
  • Page 172 E2300 Messages Command Rejected Messages Recovery 1. Enter the rtrv-trm command for a list of valid terminal choices. If the entry in the TYPE column is telnet, the terminal is not a valid choice. 2. Re-enter the act-echo command specifying a valid (that is, a non-telnet) value in the trm parameter.
  • Page 173 Command Rejected Messages E2300 Messages Recovery 1. Display all terminals. Enter the rtrv-trm command. 2. With the output from step 1 as a guide, re-enter the rtrv-trm command for an equipped terminal, or equip the terminal for use. E2394 Cmd Rej: Number out of range Commands Used: chg-appl-sock, chg-assoc, ent-appl-sock, ent-assoc, rtrv-obit, rtrv-trbl You assigned a value to a parameter that was either too great or too small.
  • Page 174 E2400 Messages Command Rejected Messages Recovery Wait until the standby MASP has finished its initialization process. Then re-enter the command. E2401 Cmd Rej: GTA range overlaps a current range Commands Used: chg-gta, chg-gtt, dlt-gta, dlt-gtt, ent-gta, ent-gtt The new gta/egta range cannot include the gta or the egta of an existing range.
  • Page 175 Command Rejected Messages E2400 Messages Recovery - chg-gta, dlt-gta The specified GTA range must exist for the specified GTT set in the STP active database. Note that an exact match is not required. (See example below). 1. Display the global title addresses in the Global Title Translation table. Enter the rtrv-gta command.
  • Page 176 E2400 Messages Command Rejected Messages E2404 Cmd Rej: GTA does not match translation type’s number of digits Commands Used: chg-gtt, dlt-gtt, ent-gtt, rtrv-gtt The global title address specified for the translation type must contain the same number of digits specified in the ent-tt command for that translation type. If the VGTT (variable length GTT) feature is turned on, you can provision up to 10 GTA lengths per translation type.
  • Page 177 Command Rejected Messages E2400 Messages E2406 Cmd Rej: ADJ required if MPC/MSSN is given or MULT=DOM or SHR Commands Used: chg-map, ent-map You entered the command without specifying the adj parameter and with the mated point code (mpc, mpca, mpci, mpcn) and mssn parameters, or with the mult=dom or mult=shr parameters.
  • Page 178 E2400 Messages Command Rejected Messages E2409 Cmd Rej: EGTA cannot be specified without GTA Commands Used: chg-gtt, ent-gtt, rtrv-gtt, rtrv-gta You cannot specify the egta parameter and not specify the gta parameter. Recovery Re-enter the command that generated this error message specifying both the egta and gta parameters.
  • Page 179 Command Rejected Messages E2400 Messages Recovery - chg-map, dlt-cspc, ent-cspc, rtrv-cspc The new concerned signaling point code group could not be found. To change the name of a CSPC group, that CSPC group name must already exist in the CSPC Group Name table.
  • Page 180 E2400 Messages Command Rejected Messages E2413 Cmd Rej: PC already exists in CSPC group Commands Used: ent-cspc The specified point code already exists in the concerned signaling point code group. The point code must exist in the Routing Table and cannot already exist in the specified group.
  • Page 181 Command Rejected Messages E2400 Messages 3. Delete the point code selected in step 2. Enter the dlt-cspc command. 4. Re-enter the ent-cspc command specifying the parameters that generated this error message to enter the desired point code. E2416 Cmd Rej: Unable to access database. Severe database failure Commands Used: chg-gta, chg-gtt, chg-feat, chg-lnpopts, chg-mrn, chg-sccp-serv, chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc,...
  • Page 182 E2400 Messages Command Rejected Messages Recovery 1. Add the destination point code into the Destination Point Code table. Enter the ent-dstn:dpc=xxx command. 2. Add the route to the Route table. Enter the ent-rte:dpc=xxx:lsn=yyy command specifying the linkset name (lsn) associated with this route. 3.
  • Page 183 Command Rejected Messages E2400 Messages NOTE: If a final GTT is specified with the (ri=ssn) and (xlat=dpc) parameters, the specified point code (pc/pca/pci/pcn/pcn24) must exist in the MAP table. For the chg-gta, ent-gta, and ent-gtt commands, if the specified point code is not in the MAP table;...
  • Page 184 E2400 Messages Command Rejected Messages Recovery To delete an entire concerned signaling point code group, re-enter the dlt-cspc command specifying the all=yes parameter. E2422 Cmd Rej: ALL=YES must be specified to delete all SSNs for a PC Commands Used: dlt-map Neither the ssn nor the all parameter was specified;...
  • Page 185 Command Rejected Messages E2400 Messages E2424 Cmd Rej: SRM=YES cannot be entered with ITU point code types Commands Used: chg-map, ent-map You cannot specify the Control of Subsystem Routing Messages (srm=yes) parameter and an ITU point code (pci, pcn, or pcn24). The srm=yes parameter can be specified only with an ANSI point code (pc or pca).
  • Page 186 E2400 Messages Command Rejected Messages Recovery Re-enter the command specifying a value of ri=gt or ri=ssn. E2427 Cmd Rej: MPC does not exist in routing Table Commands Used: chg-map, chg-mrn, chg-sccp-serv, ent-map, ent-mrn The mate remote point code specified is not in the Route table. If a remote MPC is specified, then the remote MPC must exist in the Routing table.
  • Page 187 Command Rejected Messages E2400 Messages • If an ANSI PC parameter is specified (pc or pca), the mpc, if specified, must be mpc or mpca. • If an ITU PC parameter is specified (pci, pcn, or pcn24), the mpc, if specified, must be mpci, mpcn, or mpcn24, respectively.
  • Page 188 E2400 Messages Command Rejected Messages E2431 Cmd Rej: MPC/MSSN pair already exists Commands Used: chg-map, ent-map The values specified for the mate point code (mpc) and mate subsystem number (mssn) are already in the MAP table. If a new mate PC or mate subsystem is specified, then the pair must not already exist in the MAP table.
  • Page 189 Command Rejected Messages E2400 Messages rlghncxa03w 06-06-07 00:34:31 GMT EAGLE5 35.0.0 MAP TABLE IS 2 % FULL (20 of 1024) SSN RC MULT|-----------MATE-----------|SRM GRP NAME SSO MULT MAPSET ID = 255-001-000 252 10 GRP01 MAPSET ID = 255-001-001 255 10 253-001-005 254 GRP01 MAPSET ID =...
  • Page 190 E2400 Messages Command Rejected Messages Recovery chg-gta Re-enter the chg-gta command that generated the error message specifying the force=yes override. E2437 Cmd Rej: New/existing RI must be GT for new/existing XLAT=DPCNGT Commands Used: chg-gta, chg-gtt The translate indicator (xlat) was entered with the value of dpcngt, and the routing indicator (ri) was equal to ssn.
  • Page 191 Command Rejected Messages E2400 Messages Recovery 1. Enter the rtrv-rte command to display the point codes in the routing table. 2. Re-enter the chg-gtt command, with one of the point code values displayed from the output of the rtrv-rte command. E2440 Cmd Rej: Primary PC/SSN pair already exists Commands Used: ent-map The command attempted to enter a primary point code and a primary subsystem...
  • Page 192 E2400 Messages Command Rejected Messages Recovery Re-enter the command specifying the xlat=dpcssn and ssn parameters. E2443 Cmd Rej: NGT can only be specified when XLAT=DPCNGT Commands Used: chg-gtt, ent-gtt You entered the new global title translation type (ngt), and you entered the translate indicator (xlat) with the value of dpc or dcpssn.
  • Page 193 Command Rejected Messages E2400 Messages Recovery Re-enter the command that generated this error message specifying the correct sccpmt parameter value. Call your Customer Care Center if this error message appears again. E2447 Cmd Rej: NUM exceeds maximum table size Commands Used: rtrv-gtt You assigned an invalid value to the num parameter.
  • Page 194 E2400 Messages Command Rejected Messages E2449 Cmd Rej: CSPC group network type does not match PC network type Commands Used: chg-map, dlt-cspc, ent-cspc, ent-map The command was entered with a concerned signaling point code (CSPC) group name (grp) containing point codes whose network type does not match the network type of the specified point code (pc, pca, pci, pcn, or pcn24).
  • Page 195 Command Rejected Messages E2400 Messages E2450 Cmd Rej: PC/SSN does not exist as a mated application Commands Used: chg-gsmmap-scrn, chg-gsms-opcode, ent-gsmmap-scrn, ent-gsms-opcode When you attempt to specify point code parameters (pc/pca/pci/pcn/pcn24 or npc/npca/npci/npcn/npcn24) or subsystem number (ssn or nssn) parameters, you must either specify force=yes or ensure the new point code and subsystem number are previously populated in the SCCP application entity set (Remote Point Code / Mated Application Table).
  • Page 196 E2400 Messages Command Rejected Messages Recovery 1. Display the remote point codes in the MAP table. Enter the rtrv-map command specifying no parameters. This is all that is necessary if the rtrv-map command generated this error message. 2. Enter a desired remote point code that is not in the output of step 1 with the ent-map command.
  • Page 197 Command Rejected Messages E2400 Messages Recovery 1. Display the MAP table. Enter the rtrv-map command specifying no parameters. 2. Select a remote point code to be deleted from the output of step 1 3. Delete the remote point code. Enter the dlt-map command. 4.
  • Page 198 E2400 Messages Command Rejected Messages E2457 Cmd Rej: SSN can only be specified when XLAT=DPCSSN Commands Used: chg-gta, chg-gtt, ent-gta, ent-gtt You entered the subsystem number (ssn), and the translate indicator (xlat) was entered with the value dpc or dpcngt. Recovery Perform one of the following: •...
  • Page 199 Command Rejected Messages E2400 Messages E2460 Cmd Rej: Alias defined as translation type Commands Used: dlt-tt, ent-tt, rtrv-tt The specified alias is defined as a translation type. The alias cannot be specified if it is defined as a translation type. Recovery 1.
  • Page 200 E2400 Messages Command Rejected Messages Recovery 1. The GTT table and Translation Type table contains an extremely large amount of information that could take many hours to display. However, you can use one of the following commands to display a portion of the table or a specific record to determine if there are entries you can delete: •...
  • Page 201 Command Rejected Messages E2400 Messages Recovery 1. Display the Translation Type table. Enter the rtrv-tt command. 2. Re-enter the ent-tt command specifying a different value for the translation type. E2465 Cmd Rej: Translation TYPE defined as an alias Commands Used: chg-gtt, chg-lnp-ttmap, dlt-gtt, dlt-tt, ent-gtt, ent-tt, rtrv-gtt, rtrv-lnp-ttmap, rtrv-tt The specified translation type was defined as an alias for another translation type.
  • Page 202 E2400 Messages Command Rejected Messages Recovery 1. Display the Translation Type table. Enter the rtrv-tt command. 2. Re-enter the ent-tt command specifying a different translation name. E2468 Cmd Rej: TTN specified does not exist Commands Used: chg-gtt, dlt-gtt, dlt-tt, ent-gtt, rtrv-gtt, rtrv-tt The translation type name specified must be in the Translation Type table.
  • Page 203 Command Rejected Messages E2400 Messages Recovery NOTE: If the ANSI-ITU-China SCCP Conversion feature is enabled, this error code will not be generated. Re-enter the command specifying a point code whose network type matches the specified translation type. • If the translation type is an ANSI translation type (type or typea), the point code must be an ANSI point code (pc or pca).
  • Page 204 E2400 Messages Command Rejected Messages E2473 Cmd Rej: TTN and TYPE do not correspond to each other Commands Used: chg-gtt, dlt-gtt, dlt-tt, ent-gtt, rtrv-gtt, rtrv-tt This error message appears if both the translation type and translation name parameters are specified. For this command to be successful, the specified translation type and translation name must be in the translation table.
  • Page 205 Command Rejected Messages E2400 Messages E2477 Cmd Rej: This function is not yet supported You attempted to enter a command that has not yet been developed and enabled. You may have made a clerical error. Recovery Re-enter the command that generated this error message. If this error message appears again, refer to the Commands Manual for valid syntax usage.
  • Page 206 E2400 Messages Command Rejected Messages E2480 Cmd Rej: RI=GT must be specified when XLAT=DPCNGT Commands Used: ent-gta, ent-gtt You entered the translate indicator (xlat) parameter specifying the value dpcngt, and the routing indicator (ri) was entered specifying the value ssn. Recovery Re-enter the command specifying both the xlat=dpcngt and ri=gt parameters.
  • Page 207 Command Rejected Messages E2400 Messages E2485 Cmd Rej: All entered point code elements must be C if any are C Commands Used: chg-scr-blkdpc, chg-scr-blkopc, dlt-scr-blkdpc, dlt-scr-blkopc, ent-scr-blkdpc, ent-scr-blkopc, rtrv-scr-blkdpc, rtrv-scr-blkopc The command was entered with the one of the point code parameters (ni, nc, ncm, zone, area, id, msa, ssa, sp) equal to c (for “Continue”) and the other parameters not equal to c If any of the point code parameters are equal to c, then all the point code parameters must be equal to c.
  • Page 208 E2400 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the command specifying nsfi=stop and either or both of the copy=yes and redirect=yes parameters. • Re-enter the command specifying a value for the nsfi parameter not equal to stop and without the copy=yes or the redirect=yes parameter.
  • Page 209 Command Rejected Messages E2400 Messages NOTE: A ‘wild card’ is a term to describe the parameter value ‘*’ that indicates the full range of values. Do not confuse this usage with the parameter value '**', which SEAS uses for “all and every entry in the database including the value '*'”.
  • Page 210 E2400 Messages Command Rejected Messages E2492 Cmd Rej: The NSFI / RI combination is invalid Commands Used: chg-scr-cgpa, ent-scr-cgpa You specified a combination of values for the ri parameter and the nsfi parameter that is not allowed. • If you specify ri=gt, you can only specify nsfi=tt •...
  • Page 211 Command Rejected Messages E2400 Messages • Re-enter the command specifying wild-card (asterisk) values for both the h0 and h1 parameters. • Re-enter the command specifying values for both the h0 and h1 parameters. Call your Customer Care Center if this error message appears again E2494 Cmd Rej: The NSFI is invalid for this screen type Commands Used: chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc, chg-scr-opc, chg-scrset,...
  • Page 212 E2400 Messages Command Rejected Messages • If the nnc=* and the nncm is not. • If the nni=*, nnc and nncm are not given, and nc or ncm are not wild cards. • If the nnc=*, nncm is not given, and the ncmis not wild. •...
  • Page 213 Command Rejected Messages E2400 Messages Recovery Re-enter the command specifying different values for the ni, nc, ncm parameters for an ANSI point code, zone, area, id parameters for an ITU-I point code, msa, ssa, sp for a 24-bit ITU-N point code, or the npc parameter for an ITU-N point code.
  • Page 214 You exceeded the available capacity for the screen set. If the screen set reaches 100% capacity (indicated by the “100% full” message), the EAGLE 5 ISS will allow subsequent entries. An error will occur, however, when downloading the screen set to the card.
  • Page 215 Command Rejected Messages E2500 Messages Call your Customer Care Center if this error message appears again. E2500 Cmd Rej: Maximum number of screen sets exceeded Commands Used: ent-scrset The system can contain up to 63 user-definable screen sets. The attempt to add a screen set exceeds this limit.
  • Page 216 E2500 Messages Command Rejected Messages 24-bit ITU-N point code - msa, ssa, sp and for the enter and change commands — nmsa, nssa, nsp An example of a point code containing different network types (i.e., mixed types of point codes) is ni-area-npc. This is not allowed. If any of the enter and change commands are entered, an existing point code of one network type can be changed to another network type—as long as all the proper parameters are used.
  • Page 217 Command Rejected Messages E2500 Messages E2503 Cmd Rej: NC cannot be zero when NI is less than 6 Commands Used: chg-scr-aftpc, chg-scr-blkdpc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc, chg-scr-opc, dlt-scr-aftpc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-cdpa, dlt-scr-cgpa, dlt-scr-dpc, dlt-scr-opc, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-dpc, ent-scr-opc, rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-dpc, rtrv-scr-opc The network cluster number must be 1-255, because the network identifier entered is less than or equal to 5.
  • Page 218 E2500 Messages Command Rejected Messages Recovery 1. For service indicator values greater than 2, re-enter the command without specifying the nh0 and nh1 parameters. 2. For service indicator values less than or equal to 2, re-enter the command specifying the nh0 and nh1 parameters. E2506 Cmd Rej: New H0/H1 matches existing wild carded H0/H1 in given SR Commands Used: chg-scr-sio Either the h0 or h1, or both, have been specified where they had previously been...
  • Page 219 Command Rejected Messages E2500 Messages E2508 Cmd Rej: SCMGFID is invalid Commands Used: chg-scr-cdpa, dlt-scr-cdpa, ent-scr-cdpa, rtrv-scr-cdpa You probably did one of the following: • Specified the ssn=1 parameter and failed to specify the scmgfid parameter • Specified the ssn parameter with a value other than 1 and specified the scmgfid parameter These combinations are not allowed.
  • Page 220 E2500 Messages Command Rejected Messages • Re-enter the command specifying the nh0 and nh1 parameters both assigned to wild-card (indicated by an asterisk) values. • Re-enter the command specifying both the nh0 and nh1 parameters assigned to specific values. Call your Customer Care Center if this error message appears again. E2510 Cmd Rej: NI is invalid Commands Used: chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-destfld, chg-scr-dpc,...
  • Page 221 Command Rejected Messages E2500 Messages E2511 Cmd Rej: NC is invalid Commands Used: chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-aftpc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-cdpa, dlt-scr-cgpa, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc, ent-scr-aftpc, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-destfld, ent-scr-dpc, ent-scr-opc, rept-meas, rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-destfld, rtrv-scr-dpc, rtrv-scr-opc For the gateway screening commands:...
  • Page 222 E2500 Messages Command Rejected Messages E2512 Cmd Rej: NCM is invalid Commands Used: chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-aftpc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-cdpa, dlt-scr-cgpa, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc, ent-scr-aftpc, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-destfld, ent-scr-dpc, ent-scr-opc, rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-destfld, rtrv-scr-dpc, rtrv-scr-opc You entered a combination of the parameters ni, nc, and/or ncm that is not allowed.
  • Page 223 Command Rejected Messages E2500 Messages Recovery 1. Enter the rtrv-scr-cgpa command to acquire the current state of the parameters with the given sr parameter. 2. Re-enter the command that generated this error message, using appropriate parameter values acquired in step 1. E2515 Cmd Rej: PC/SSN/RI/SCCPMT does not exist in given SR Commands Used: chg-scr-cdpa, dlt-scr-cdpa, rtrv-scr-cdpa, dlt-scr-cdpa, dlt-scr-cgpa,...
  • Page 224 E2500 Messages Command Rejected Messages E2517 Cmd Rej: PC/SSN/SCMGFID does not exist in given SR Commands Used: chg-scr-cdpa, dlt-scr-cdpa, ent-scr-cdpa, rtrv-scr-cdpa, dlt-scr-cdpa, dlt-scr-cgpa, You entered this command specifying the pc, ssn, or scmgfid parameter set to a value that does not exist in the screening reference. Recovery 1.
  • Page 225 Command Rejected Messages E2500 Messages Recovery 1. Verify the values for the sr and isupmt parameters and the sr and tupmt parameters have been entered correctly, and re-enter the command. 2. If the value for these parameters have been entered correctly and this error message appears again, enter the rtrv-scr-isup:sr= command to display the allowed ISUP information for the specified screening reference.
  • Page 226 E2500 Messages Command Rejected Messages E2522 Cmd Rej: NIC does not exist for given SR Commands Used: chg-scr-sio, dlt-scr-sio, rtrv-scr-sio The command was entered, and the combination of the screening reference (sr) and network indicator code (nic) could not be found in the database. Recovery - rtrv-scr-sio Re-enter the rtrv-scr-sio command specifying no parameters.
  • Page 227 Command Rejected Messages E2500 Messages Recovery Re-enter the command specifying new point code parameters as null values if the ni, zone, msa, or npc point codes are set to c. E2527 Cmd Rej: C value not allowed Commands Used: chg-scr-aftpc, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-aftpc, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc, ent-scr-aftpc, ent-scr-cgpa, ent-scr-destfld,...
  • Page 228 E2500 Messages Command Rejected Messages Recovery Re-enter the rtrv-scr-sio command specifying the screening reference to show all ending priorities, as well as other values for the screening reference. E2530 Cmd Rej: No match on H0 parameter during retrieve Commands Used: rtrv-scr-sio The h0 heading code (h0) was not found.
  • Page 229 Command Rejected Messages E2500 Messages E2533 Cmd Rej: No match on NC parameter during retrieve Commands Used: rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-destfld, rtrv-scr-dpc, rtrv-scr-opc No match for the network cluster (nc) parameter was found. Recovery Re-enter the command specifying the screening reference to show all network clusters, as well as other values for the screening reference.
  • Page 230 E2500 Messages Command Rejected Messages Recovery - rept-meas 1. Verify that you entered the correct origni and ni parameter values in the command. 2. Re-enter the rept-meas command. Contact your Customer Care Center if this error message appears again. E2536 Cmd Rej: No match on NIC parameter during retrieve Commands Used: rtrv-scr-sio The specified network indicator code (nic) parameter was not found.
  • Page 231 Command Rejected Messages E2500 Messages Recovery Re-enter the command specifying the screening reference to show all next screening function identifiers, as well as other values for the screening reference. E2539 Cmd Rej: No match on NSR parameter during retrieve Commands Used: rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-destfld, rtrv-scr-dpc, rtrv-scr-opc, rtrv-scrset, rtrv-scr-sio, rtrv-scr-tt...
  • Page 232 E2500 Messages Command Rejected Messages E2542 Cmd Rej: No match on SI parameter during retrieve Commands Used: rtrv-scr-sio The service indicator (si) was not found. Recovery Re-enter the rtrv-scr-sio command specifying the screening reference to show all service indicators, as well as other values for the screening reference. E2543 Cmd Rej: No match on SSN parameter during retrieve Commands Used: rtrv-scr-aftpc, rtrv-scr-cdpa, rtrv-scr-cgpa No match was found for the subsystem number (ssn) parameter.
  • Page 233 Command Rejected Messages E2500 Messages Recovery Re-enter the command specifying the screening reference to show all zone values, as well as other values for the screening reference. E2546 Cmd Rej: NSFI must be specified Commands Used: chg-scr-blkdpc, chg-scr-blkopc You specified the point code equal to c-c-c and the nsfi parameter was not specified.
  • Page 234 E2500 Messages Command Rejected Messages Recovery Re-enter the command specifying the nsfi=stop parameter. The value stop is the only value that can be specified for the nsfi parameter. E2549 Cmd Rej: NSFI must be FAIL Commands Used: ent-scr-blkdpc, ent-scr-blkopc You specified the point code not equal to c-c-c and the nsfi parameter not equal to fail.
  • Page 235 Command Rejected Messages E2500 Messages E2552 Cmd Rej: NSFI and NSR do not reference an existing screen Commands Used: chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc, chg-scr-opc, chg-scrset, chg-scr-sio, chg-scr-tt, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-dpc, ent-scr-opc, ent-scrset, ent-scr-sio, ent-scr-tt The values specified for thr nsfi and nsr parameters do not reference an existing screen.
  • Page 236 E2500 Messages Command Rejected Messages E2553 Cmd Rej: NSR must be specified for given NSFI Commands Used: chg-scr-blkdpc, chg-scr-blkopc, chg-scr-cdpa, chg-scr-cgpa, chg-scr-dpc, chg-scr-opc, chg-scrset, chg-scr-sio, chg-scr-tt, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-dpc, ent-scr-opc, ent-scrset, ent-scr-sio, ent-scr-tt You specified the nsfi parameter equal to a value other than stop and the nsr parameter was not specified or, for the chg-scr-blkdpc, chg-scr-blkopc, ent-scr-blkdpc, and ent-scr-blkopc commands, You specified the nsfi parameter equal to a value other than fail, and the nsr parameter was not...
  • Page 237 Command Rejected Messages E2500 Messages E2555 Cmd Rej: Point code does not exist in given SR Commands Used: chg-scr-blkdpc, chg-scr-blkopc, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc The point code defined by the ni, nc, and ncm parameters is not defined in the specified screening reference (NPC, the ITU-N standard, or zone area ID, the ITU-I standard).
  • Page 238 E2500 Messages Command Rejected Messages Recovery Re-enter the command specifying a point code containing the following parameters: ANSI point codes – ni, nc, ncm ITU-I point codes – zone, area, id ITU-N point codes – npc 24-bit ITU-N point codes – msa, ssa, sp E2557 Cmd Rej: GWS/GTT shared table is full Commands Used: ent-scr-blkdpc, ent-scr-blkopc, ent-scr-dpc, ent-scr-opc, ent-scr-aftpc, ent-scr-cdpa, ent-scr-cgpa,...
  • Page 239 Command Rejected Messages E2500 Messages • rtrv-scr-tt • rtrv-scr-sio 3. Delete any entries in the gateway screening entities displayed in step 2 that reference the screen set name selected in step 1. This includes the screen set itself. For additional information, refer to the procedures in the Database Administration Manual - Gateway Screening.
  • Page 240 E2500 Messages Command Rejected Messages Recovery 1. Enter one of the following commands to verify the point codes in the screening reference: • rtrv-scr-blkdpc, for the ent-scr-blkdpc command • rtrv-scr-blkopc, for the ent-scr-blkopc command • rtrv-scr-dpc, for the ent-scr-dpc command •...
  • Page 241 Command Rejected Messages E2500 Messages E2560 Cmd Rej: Inhibit rejected, target terminal is not equipped Commands Used: alw-trm, inh-trm, rmv-trm, rst-trm You have attempted to inhibit a terminal number in the allowable range of numbers, but it has not been equipped. This command cannot be completed. Recovery 1.
  • Page 242 E2500 Messages Command Rejected Messages E2564 Cmd Rej: Point code out of range Commands Used: chg-scr-aftpc, chg-scr-cdpa, chg-scr-cgpa, chg-sid, chg-scr-blkdpc, chg-scr-blkopc, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-aftpc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-cdpa, dlt-scr-cgpa, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc, ent-dstn, ent-ls, ent-scr-aftpc, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-cdpa, ent-scr-cgpa, ent-scr-destfld, ent-scr-dpc, ent-scr-opc, rtrv-scr-aftpc, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-cdpa, rtrv-scr-cgpa, rtrv-scr-destfld, rtrv-scr-dpc, rtrv-scr-opc The specified point code was not entered with the correct values.
  • Page 243 Command Rejected Messages E2500 Messages 3. Re-enter the command that generated this error message. 4. If you want to change a current entry in the specified screening entity, enter one of the following commands, with the screening information that you attempted to add within the command that generated this error message.
  • Page 244 E2500 Messages Command Rejected Messages Recovery 1. Delete the screen set association from the linkset. Enter the chg-ls command. 2. Delete the screen set. Re-enter the dlt-scrset command. E2569 Cmd Rej: SIO does not exist in given SR Commands Used: chg-scr-sio, dlt-scr-sio The entry specified by the nic, si, h0, and h1 parameters could not be found.
  • Page 245 Command Rejected Messages E2500 Messages Recovery 1. Display the allowed SIO screening references and the associated service indicators in the database. Enter the rtrv-scr-sio command. The screening references are shown in the SR field of the rtrv-scr-sio command output. The service indicators are shown in the SI field of the rtrv-scr-sio command output.
  • Page 246 E2500 Messages Command Rejected Messages Recovery 1. Verify the screening references in the entity set. Enter one of the following commands: • rtrv-scr-aftpc, for the chg-scr-aftpc command • rtrv-scr-blkdpc, for the chg-scr-blkdpc command • rtrv-scr-blkopc, for the chg-scr-blkopc command • rtrv-scr-cdpa, for the chg-scr-cdpa and dlt-scr-cdpa commands •...
  • Page 247 Command Rejected Messages E2500 Messages E2575 Cmd Rej: TYPE matches existing TYPE in given SR Commands Used: chg-scr-tt The new type matches a type already in the screening reference. Recovery 1. Display the data for this screening reference. Enter the rtrv-scr-tt command.

  • Page 248: Table 2-11. Conditions The Generate An E2581 Error Message

    E2500 Messages Command Rejected Messages E2580 Cmd Rej: A specific NIC must be specified in the range (0-3) Commands Used: dlt-scr-sio You either failed to include the nic parameter on the command line, or assigned a value to it that was out of range. Recovery Re-enter the dlt-scr-sio command that generated this error message specifying the correct nic parameter value.
  • Page 249 Command Rejected Messages E2500 Messages Call your Customer Care Center if this error message appears again. 3. If the CRMD feature is turned off (from the output of step 1), turn it on. Enter the chg-feat:crmd=on command. 4. Re-enter the command that generated this error message. E2582 Cmd Rej: Feature corresponding to APPL not ON Commands Used: ent-card, ent-dstn You cannot add to the database a LIM card that uses the ss7gx25 application, if the...
  • Page 250 E2500 Messages Command Rejected Messages Refer to the chg-feat command in the Commands Manual for further information. Recovery 1. Display the features in the database. Enter the rtrv-feat command. 2. If the LAN feature is turned on (from the output of step 1), re-enter ent-card the command.
  • Page 251 Command Rejected Messages E2500 Messages Refer to the Database Administration Manual-System Management and the Commands Manual for details about turning on features with bits and enabling features with access keys. Recovery 1. Display the status of features that are controlled by feature bits in the database.
  • Page 252 E2500 Messages Command Rejected Messages E2585 Cmd Rej: GWS feature must be ON Commands Used: enable-ctrl-feat, ent-card The GWS feature must be turned on prior to issuing this command. Specifically: • enable-ctrl-feat - You must first turn on the GWS feature before you can turn on the ISUP NP with EPAP feature.

  • Page 253: Table 2-12. Valid Port And Application Type Combinations

    Command Rejected Messages E2500 Messages Table 2-12. Valid Port and Application Type Combinations Card Port Supported Application Two-port All supported applications. The two-port LIM supports the DS0, OCU, V35, ATM, or E1 interface. Two-port All supported applications except ss7gx25 (X.25 signaling link), atmansi, (ATM HSL signaling link), or ss7ipgw/ipgwi (IP signaling link) Multi-port...
  • Page 254 E2500 Messages Command Rejected Messages E2588 Cmd Rej: Link must be removed from X.25 route(s) Commands Used: dlt-slk The specified signaling link has an X.25 route assigned to it, and the force=yes parameter was not entered. To delete the signaling link, all associated X.25 routes must be deleted, or the force=yes parameter must be entered.
  • Page 255 Command Rejected Messages E2500 Messages E2591 Cmd Rej: BEI must be YES if APC domain is X.25 Commands Used: chg-ls, ent-ls You cannot specify the bei=no parameter if the domain of the adjacent point code (APC) of the linkset is in the X.25 domain. If the adjacent point code is in the X.25 domain, the bei=yes parameter must be specified, or the bei parameter must be omitted from the command.
  • Page 256 E2500 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2593 Cmd Rej: APC cannot be of a different domain than previous Commands Used: chg-ls The specified APC was not in the same domain as the previous APC assigned to the linkset.
  • Page 257 Command Rejected Messages E2500 Messages E2595 Cmd Rej: SS7 Destination assigned to non-SS7 linkset Commands Used: ent-rte The specified DPC is assigned to the SS7 domain (an SS7 DPC), and the specified linkset (lsn) is assigned to an adjacent point code (APC) that is assigned to the X.25 domain (an X.25 linkset).
  • Page 258 E2500 Messages Command Rejected Messages E2597 Cmd Rej: Cccmmd table must be accessible Commands Used: chg-cmd, rtrv-cmd The cccmmd table was not accessible to the command you entered. Recovery Re-enter carefully the command that generated this error message specifying correct parameter values. Call your Customer Care Center if this error message appears again.
  • Page 259 Command Rejected Messages E2500 Messages E2600 Cmd Rej: Linkset SAPC referenced by route Commands Used: chg-ls You have been prevented from deleting an sapc (Secondary Adjacent Point Code) linkset because it is currently referenced by a route. The command cannot delete an sapc when a route exists for a linkset in the SAPC’s domain or group code.
  • Page 260 TDM are not coherent, use the chg-db:action=repair command. 6. Log into the EAGLE 5 ISS. Enter the login or act-user command. 7. Verify that the database is coherent. Re-enter the rept-stat-db command.
  • Page 261 Command Rejected Messages E2500 Messages Recovery 1. Display the status of the card specified that generated this error message. Enter the rept-stat-card command specifying the card location. The primary state of the card is shown in the PST field. 2. If the primary state of the card displayed in step 1 is not OOS-MT-DSBLD, enter the rmv-card command to make the primary state of the card OOS-MT-DSBLD.
  • Page 262 E2500 Messages Command Rejected Messages E2606 Cmd Rej: Point code must exist within the group Commands Used: chg-mrn You entered the command to change the relative costs specified for more than one point code. At least one of the point codes that you specified does not exist in the group in the Mated Relay Node (MRN) table that is indicated by the point code specified in the pc parameter.
  • Page 263 Command Rejected Messages E2500 Messages Recovery 1. Display the TCP/IP nodes in the database. Enter the rtrv-ip-node command. 2. Re-enter the command specifying an IP address shown in the output of step 1. E2609 Cmd Rej: Only one optional parameter may be specified Commands Used: rept-stat-eroute, rept-stat-lnp, rept-stat-sccp, rtrv-dlk, rtrv-ip-node, rtrv-ip-rte You can enter these commands with only one optional parameter, with the...
  • Page 264 E2500 Messages Command Rejected Messages Recovery - rtrv-ip-rte Enter the command specifying either no parameters, only the loc parameter, only the dest parameter, or only the gtwy parameter. E2610 Cmd Rej: IPADDR assigned to a TCP/IP link Commands Used: ent-dlk, ent-ip-node You assigned an invalid value to the ipaddr parameter.
  • Page 265 Command Rejected Messages E2500 Messages E2612 Cmd Rej: IPPORT already assigned Commands Used: ent-ip-node You tried to assign a different IP application to an IP port (ipport) that, in combination with the IP address used that generated this error message, is already in the database.
  • Page 266 E2500 Messages Command Rejected Messages Recovery 1. Display the IP addresses of the TCP/IP data links. Enter the rtrv-dlk command. 2. Display the IP addresses of the TCP/IP nodes. Enter the rtrv-ip-node command. 3. Re-enter the ent-ip-node command specifying a Class A IP address not shown in the output of step 2, and whose network portion of the address matches the network portion of the IP address assigned to the TCP/IP data link location specified in this command (shown in the output of step 1).
  • Page 267 Command Rejected Messages E2500 Messages E2616 Cmd Rej: IPADDR w/o IPRTE must match first 3 octets of TCP/IP link Commands Used: ent-ip-node You specified an IP address whose network portion does not match the network portion of the IP address assigned to the TCP/IP data link. No iprte parameter (IP address of a TCP/IP router) was assigned.
  • Page 268 E2500 Messages Command Rejected Messages E2619 Cmd Rej: Only one of IPAPPL or IPPORT may be specified Commands Used: dlt-ip-node You specified both the ipappl and ipport parameters. This combination is not allowed by this command. Recovery Re-enter the dlt-ip-node command specifying either the ipappl or ipport parameters, but not both.
  • Page 269 Command Rejected Messages E2500 Messages E2622 Cmd Rej: IPADDR not assigned to specified LOC Commands Used: dlt-ip-node, rtrv-ip-node The command was entered with the ipaddr and loc parameters, and the node specified by the ipaddr parameter could not be found to be connected to the TCP/IP data link specified by the loc parameter.
  • Page 270 E2500 Messages Command Rejected Messages E2624 Cmd Rej: IPAPPL on node not assigned to specified LOC Commands Used: dlt-ip-node You specified the ipappl and the loc parameters, and the ipaddr/ipappl combination could not be found for the specified location. If you enter the command specifying the ipappl and the loc parameters, the ipaddr/ipappl combination must be assigned to the TCP/IP data link specified by the loc parameter.
  • Page 271 Command Rejected Messages E2500 Messages Recovery 1. Display the TCP/IP nodes in the database. Enter the rtrv-ip-node command. 2. Re-enter the dlt-ip-node command specifying an IP port (ipport) that is shown in the output of step 1. E2627 Cmd Rej: IPAPPL on node not connected to any TCP/IP link Commands Used: dlt-ip-node The specified IP application (ipappl) could not be found in the database.
  • Page 272 E2500 Messages Command Rejected Messages Recovery 1. Display the IP links in the database. Enter the rtrv-ip-lnk command. 2. Display the IP hosts in the database. Enter the rtrv-ip-host command. 3. From the outputs of steps 1 and 2, determine if the card location specified in the command that generated this error message, has an IP link assigned to it.
  • Page 273 Command Rejected Messages E2500 Messages Recovery - dlt-dlk The specified TCP/IP data link was not OOS-MT-DSBLD (out of service - maintenance disabled). To delete a TCP/IP data link from the database, that link must be in an OOS-MT-DSBLD state. 1. To display the status of the TCP/IP data link, use the rept-stat-dlk command, specifying the card location.
  • Page 274 E2500 Messages Command Rejected Messages E2632 Cmd Rej: IPRTE address assigned to TCP/IP Link Commands Used: ent-ip-node The specified router IP address (iprte) was already assigned to a TCP/IP link. Recovery 1. Verify the TCP/IP data links in the database. Enter the rtrv-dlk command. 2.
  • Page 275 Command Rejected Messages E2500 Messages E2634 Cmd Rej: IPRTE address must use first 2 octets of Class B TCP/IP Link Commands Used: ent-ip-node You specified a router IP address whose network portion does not match the network portion of the IP address assigned to the TCP/IP data link. The IP address assigned to the TCP/IP router is a Class B IP address.
  • Page 276 E2500 Messages Command Rejected Messages E2636 Cmd Rej: IPADDR assigned to a TCP/IP router Commands Used: ent-dlk The specified IP address (ipaddr) was already assigned to a TCP/IP router. The IP Address must not already be assigned to an existing TCP/IP Default Router. Recovery 1.
  • Page 277 Command Rejected Messages E2500 Messages E2640 Cmd Rej: Redirect function data has already been entered Commands Used: ent-gws-redirect The command was entered, but the gateway screening redirect function data has already been entered. Once specific gateway screening redirect function data is entered, the same ent-gws-redirect command cannot be entered again.
  • Page 278 E2500 Messages Command Rejected Messages Recovery 1. Display the routes in the database. Enter the rtrv-rte command. The point codes that have routes assigned to them are shown in the DPCA field. Only ANSI point codes can be used with the gateway screening redirect function. 2.
  • Page 279 Command Rejected Messages E2500 Messages 3. Delete the X.25 routes shown in step 2. Enter the dlt-x25-rte command. 4. Re-enter the dlt-rte command that generated this error message. E2645 Cmd Rej: Cannot delete last route to DPC ref. by redirect func Commands Used: dlt-rte You cannot delete the last route to the DPC that is referenced by the gateway screening redirect function.
  • Page 280 E2500 Messages Command Rejected Messages Recovery 1. Display X.25 routes. Enter the rtrv-x25-rte command. 2. Display the X.25 addresses for their associated point codes. Enter the rtrv-x25-dstn command. 3. Display the DPC table. Enter the rtrv-dstn command. 4. View the linksets. Enter the rtrv-ls command. 5.
  • Page 281 Command Rejected Messages E2500 Messages Call your Customer Care Center if this error message appears again. E2649 Cmd Rej: Failed reading the X.25 destination table Commands Used: chg-x25-dstn, dlt-x25-dstn, ent-x25-rte, rtrv-x25-dstn The X.25 Destination table is corrupt or cannot be found by the system. The X.25 Destination table contains the shelf attribute information.
  • Page 282 E2500 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the chg-x25-slk command specifying n1=1080 and mps=128. • Re-enter the chg-x25-slk command, and omit both parameters, to accept the system defaults of a 256 byte maximum packet size, and 2104 maximum number of bits in a frame.
  • Page 283 Command Rejected Messages E2500 Messages E2657 Cmd Rej: Point code not defined Commands Used: chg-dstn, chg-gws-redirect, chg-ls, chg-rte, chg-x25-dstn, dlt-dstn, dlt-rmt-appl, dlt-rte, ent-gws-redirect, ent-ls, ent-rmt-appl, ent-rte, ent-x25-dstn, rtrv-dstn, rtrv-rte, rtrv-x25-dstn You cannot specify a destination point code (DPC) that is not defined in the Destination Point Code table.
  • Page 284 E2500 Messages Command Rejected Messages 1. Display the destination point codes in the Destination Point Code table. Enter the rtrv-dstn command. 2. Re-enter the command specifying a destination point code defined in the Destination Point Code table. Recovery - chg-gws-redirect, ent-gws-redirect 1.
  • Page 285 Command Rejected Messages E2500 Messages Recovery 1. Display the X.25 destinations in the database. Enter the rtrv-x25-dstn command. 2. Re-enter the ent-x25-dstn command specifying an X.25 address that is not defined in the X.25 Destination table. E2659 Cmd Rej: X.25 address cannot be referenced by route Commands Used: chg-x25-dstn, dlt-x25-dstn The specified X.25 address (xaddr) is referenced by the X.25 Routing table.
  • Page 286 E2500 Messages Command Rejected Messages The X.25 Destination table already contains the maximum number of destinations, and you attempted to add another X.25 destination. The maximum number allowed depends on the features you have turned on. If you have the X.25 feature turned on, the maximum number is 1024.
  • Page 287 Command Rejected Messages E2500 Messages E2662 Cmd Rej: Maximum SVCAs already defined for link Commands Used: chg-x25-rte, ent-x25-rte You tried to assign an automatic switched virtual circuit (SVCA) to a signaling link (loc and port) that contains the maximum number of switched virtual circuits (SVC).
  • Page 288 E2500 Messages Command Rejected Messages Recovery 1. Display the entries in the X.25 routing table. Enter the rtrv-x25-rte command. 2. Re-enter the command specifying X.25 addresses that are shown in the output of step 1. E2664 Cmd Rej: LC must be specified when TYPE=PVC Commands Used: ent-x25-rte You specified the type=pvc parameter and without the lc parameter.
  • Page 289 Command Rejected Messages E2500 Messages E2666 Cmd Rej: LOC must be specified when TYPE=PVC or SVCA Commands Used: chg-x25-rte, ent-x25-rte You cannot specify the type=pvc or type=svca parameters without specifying the loc parameter. If the type=pvc or type=svca parameters are specified, the loc parameter must be specified.
  • Page 290 E2500 Messages Command Rejected Messages Recovery Re-enter the command specifying the type=svcr parameter without specifying the port parameter. E2669 Cmd Rej: SS7 address does not exist in X.25 destination table Commands Used: ent-x25-rte The specified SS7 address (saddr, the dummy X.25 address assigned to the SS7 destination point code) could not be found in the X.25 destination table.
  • Page 291 Command Rejected Messages E2500 Messages E2671 Cmd Rej: DPC assigned to SS7 address does not exist in SS7 domain Commands Used: ent-x25-rte You specified a value for the SS7 X.25 address (saddr) parameter whose destination point code is not in the SS7 domain. Recovery 1.
  • Page 292 E2500 Messages Command Rejected Messages E2673 Cmd Rej: DPC assigned to SS7 address has no SS7 routes Commands Used: ent-x25-rte The destination point code (DPC) associated with the SS7 address (saddr) does not have any routes assigned to it. For the execution of this command to be successful, the DPC must have at least one route assigned to it.
  • Page 293 Command Rejected Messages E2500 Messages 3. Re-enter the ent-x25-rte command, with X.25 addresses that are shown in the output of step 2 and that are not in the output of step 1. 4. If the X.25 addresses you wish to enter are not shown in the output of step 2, add the X.25 addresses to the X.25 destination table using the ent-x25-dstn command, then re-enter the ent-x25-rte command specifying those X.25 addresses.

  • Page 294: Table 2-14. Action If X.25 Route Table Is Full

    E2500 Messages Command Rejected Messages • If the x252000 feature is on, the output shows both x25g=on and x252000=on. Recovery To add a new X.25 route if you have reached the maximum, perform one of the procedures in Table 2-14. Table 2-14.
  • Page 295 Command Rejected Messages E2500 Messages E2678 Cmd Rej: Link not assigned to SS7-X.25 card Commands Used: rept-x25-meas The card containing the signaling link, specified in this command by the loc and port parameters, is not a LIM using the ss7gx25 application. Only signaling links assigned to LIMs using the ss7gx25 application can be specified with this commands.
  • Page 296 E2500 Messages Command Rejected Messages Recovery 1. Display all X.25 routes in the database. Enter the rtrv-x25-rte command. 2. Re-enter the ent-x25-rte command specifying the type=pvc parameter, and a logical channel for the X.25 route that is not assigned to another X.25 route at this logical channel.
  • Page 297 Command Rejected Messages E2500 Messages 2. If the connection type of the specified X.25 signaling link is SVCA, re-enter the command specifying the type=svcr parameter. 3. If the connection type of the specified X.25 signaling link is SVCR, re-enter the command specifying the type=svca parameter.
  • Page 298 E2500 Messages Command Rejected Messages E2686 Cmd Rej: PVC plus SVC must be at least 1 Commands Used: chg-x25-slk You specified the sum of the values for the pvc and svc parameters being 0 (for example, pvc=0 and svc=0). The sum of the values for the pvc and svc parameters must be greater than 0.
  • Page 299 Command Rejected Messages E2500 Messages 3. Perform one of the following: • Re-enter the chg-x25-slk command specifying a value for the pvc parameter that is equal to or greater than the number of logical channels displayed in step 2. • Use the dlt-x25-rte command to delete a logical channel. 4.
  • Page 300 E2500 Messages Command Rejected Messages Recovery 1. Display the signaling links in the database. Enter the rtrv-x25-slk command. 2. Re-enter the chg-x25-slk command specifying a card location that is an X.25 signaling link as shown in step 1. E2691 Cmd Rej: Card is not a SS7GX25 card Commands Used: chg-x25-slk You specified a card that is not assigned the ss7gx25 application.
  • Page 301 Command Rejected Messages E2500 Messages Recovery Re-enter the command that generated this error message specifying the correct byte, word, or dword parameter value. Call your Customer Care Center if this error message appears again. E2694 Cmd Rej: Invalid combination of ADDR and PADDR specified Commands Used: disp-mem, dlt-bp, ent-bp, set-mem You can enter only one of the parameters addr or paddr.
  • Page 302 E2500 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2697 Cmd Rej: IND cannot be greater than 3 Commands Used: ent-bp You cannot enter the ent-bp command specifying a value greater than 3 for the ind parameter.
  • Page 303 Command Rejected Messages 2700 Messages Recovery Re-enter the ent-bp command that generated this error message specifying the correct value p486 for the processor-type portion of the type parameter. Call your Customer Care Center if this error message appears again. E2700 Cmd Rej: ACCESS can only be specified with TYPE=P486-DATA Commands Used: ent-bp You can specify the access parameter only when the value of the processor-type portion of the type parameter is p486.
  • Page 304 E2702 Cmd Rej: At least one MCPM card must be configured in system Commands Used: rept-stat-meas At least one MCPM card must be configured in the EAGLE 5 ISS for the Measurements Platform feature, before you can enter the rept-stat-meas command.
  • Page 305 Command Rejected Messages 2700 Messages E2704 Cmd Rej: Invalid IPADDR Commands Used: chg-ftp-serv, chg-ip-card, chg-ip-lnk, dlt-ftp-serv, ent-ftp-serv, ent-ip-host, rtrv-ftp-serv, rtrv-ip-host, tst-dlk You entered the command for an IP address (ipaddr parameter) that does not exist in the database, or you specified an ipaddr parameter value that does not conform to the value’s specified naming conventions.
  • Page 306 E2700 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message specifying the correct ipaddr parameter value. Call your Customer Care Center if this error message appears again. E2706 Cmd Rej: APPL is invalid for report or entity Commands Used: rept-meas You specified the appl parameter with an enttype parameter value that is not stplan and a type that is not avl.
  • Page 307 Command Rejected Messages E2700 Messages Recovery Re-enter the rept-meas command specifying either the appl, or the loc and port parameters. E2709 Cmd Rej: APPL is invalid for specified PERIOD Commands Used: rept-meas You specified the appl parameter, and either the period=active or period=all parameters.
  • Page 308 E2700 Messages Command Rejected Messages 3. Display the application that is running on each lhost card. Enter the rtrv-card command. The ss7ipgw and iplim applications are ANSI, and the ipgwi and iplimi applications are ITU. 4. Re-enter the chg-assoc command that generated this error message specifying parameters that change the lhost for the association to a new lhost of the same type.
  • Page 309 Command Rejected Messages E2700 Messages E2712 Cmd Rej: RESETCHAR not valid with ACTION=CREATE Commands Used: chg-tbl If action=create is requested, the following parameters must be entered: name, ext, filelength. All other parameters are ignored or defaulted. You attempted to enter the resetchar parameter. Recovery Re-enter the command that generated this error using only the valid parameters.
  • Page 310 E2700 Messages Command Rejected Messages E2715 Cmd Rej: EXT not valid with ACTION=RESET Commands Used: chg-tbl If action=reset is requested, the id parameter must be entered. All other parameters (including ext) are ignored or defaulted. Recovery 1. Re-enter the command that generated this error message specifying only the valid parameters.
  • Page 311 Command Rejected Messages E2700 Messages E2718 Cmd Rej: No match on REDIRECT parameter during retrieve Commands Used: rtrv-scr-sio, rtrv-scr-blkdpc, rtrv-scr-blkopc, rtrv-scr-dpc, rtrv-scr-opc The redirect parameter was not found. If this is what was being verified, no further action is needed. Recovery Re-enter the command without specifying a redirect parameter.
  • Page 312 E2700 Messages Command Rejected Messages E2721 Cmd Rej: Integer value must be less than 65535 Commands Used: ent-bp For 80286 processors, integer values for registers and conditions must be less than 65535. Recovery Re-enter the ent-bp command that generated this error message specifying a ca parameter value less than 65535.
  • Page 313 Command Rejected Messages E2700 Messages Recovery NOTE: Password operations (such as login with expired password) are not supported on a telnet terminal until the OA&M IP Security Enhancement feature is enabled and turned on, thus securing the telnet terminal. 1. Display the status of features in your system that have feature access keys. Enter the rtrv-ctrl-feat command.
  • Page 314 E2700 Messages Command Rejected Messages Recovery 1. Display all site identification STP point codes and capability point codes. Enter the rtrv-sid command. 2. Re-enter the chg-sid command that generated this error message and assign a valid value, acquired in step 1, to the pci parameter. Call your Customer Care Center if this error message appears again..
  • Page 315 E2730 Cmd Rej: SEAS Subsystem has not been provisioned Commands Used: rept-stat-seas The SEAS subsystem has not been provisioned and is not part of the EAGLE 5 ISS maintenance system. NOTE: Once a feature that is controlled using a feature bit is turned on, it cannot be turned off.
  • Page 316 E2700 Messages Command Rejected Messages E2731 Cmd Rej: FORCE=YES must be given to inhibit last OAP terminal Commands Used: inh-trm Only one terminal is in the in-service normal (IS-NR) state. If you disable this port, you lose OAP service. Recovery 1.
  • Page 317 Command Rejected Messages E2700 Messages Recovery 1. Enter the rtrv-t1 command to display the port and card location information for each T1 interface defined in the database. Verify that there is not a T1 interface defined for the port you specified in the ent-t1 command. 2.
  • Page 318 E2700 Messages Command Rejected Messages Recovery 1. Deactivate all signaling links with timeslots that are serviced by the specified T1 interface (for the chg-t1 command), or by each defined T1 interface (for the inh-card command). Enter the dact-slk command. Refer to the Commands Manual for more information. 2.
  • Page 319 Command Rejected Messages E2700 Messages Recovery Call your Customer Care Center if this error message appears again. This is a command that should only be entered when specifically directed to do so by your Customer Care Center. E2739 Cmd Rej: T1 card location is unequipped Commands Used: chg-t1, dlt-t1, ent-t1, rtrv-t1 You entered a command to add, delete, change, or retrieve information for a T1 interface on the E1/T1 MIM card specified in the loc parameter;...
  • Page 320 E2700 Messages Command Rejected Messages E2742 Cmd Rej: T1 is assigned to card Commands Used: dlt-card You cannot delete an E1/T1 MIM card used as a T1 card (card type limt1) that has at least one T1 interface associated with it. You must delete all T1 interfaces associated with the card before the card can be deleted.
  • Page 321 Command Rejected Messages E2700 Messages Recovery 1. Enter the rtrv-t1 command to display the port and card location information for T1 interfaces already defined. 2. Verify that the T1 interface is defined for the port on the T1 card to which you want to assign the signaling link.
  • Page 322 E2700 Messages Command Rejected Messages Recovery 1. Inhibit the card. Enter the inh-card command. 2. Delete the static IP route entry for the card. Re-enter the dlt-ip-rte command. Re-enter the command to delete the entry and specifying the force=yes parameter to delete the entry while the card is allowed.
  • Page 323 E2750 Cmd Rej: UserID already logged on (or is logging on) another terminal Commands Used: act-user, login Your attempt to login to the EAGLE 5 ISS has been denied because your user ID is already logged in, or is being logged in, to the EAGLE 5 ISS at another terminal.
  • Page 324 E2700 Messages Command Rejected Messages Recovery 1. Contact your systems administrator to have the last successful login date associated with your user ID reset to today’s date. 2. Re-enter the login command. E2753 Cmd Rej: Password does not contain enough alphabetic characters If you are the systems administrator: Commands Used: act-user, chg-pid, chg-user, ent-user, login The requirements for the password are given in the scroll area of the logon screen.
  • Page 325 Command Rejected Messages E2700 Messages Recovery 1. Read the requirements for the password in the scroll area of the logon screen. Make sure that you understand all of your site’s password complexity requirements. 2. Re-enter the command, and at the password prompt, type a new password that meets all the password complexity requirements for your site.
  • Page 326 E2700 Messages Command Rejected Messages Recovery 1. Read the requirements for the password in the scroll area of the logon screen Make sure that you understand all of your site’s password complexity requirements. 2. Re-enter the command, and at the password prompt, type a new password that meets all the password complexity requirements for your site.
  • Page 327 E2757 Cmd Rej: Invalid userID/password combination Commands Used: act-user, login Your attempt to login to the EAGLE 5 ISS has been denied because of one of the following: you either entered a user ID or a password not in the EAGLE 5 ISS database, or you entered a user ID-password combination not in the database.
  • Page 328 (for example, systems administrator), and the EAGLE 5 ISS does not allow revocation of a user ID in that category. This safeguard ensures that at least one person always has access to the EAGLE 5 ISS. Recovery Perform one of the following: •...
  • Page 329 E2762 Cmd Rej: Terminal temporarily disabled. Excessive LOGIN failures Commands Used: act-user, login You tried to login to the EAGLE 5 ISS at a terminal that is disabled because the login failure threshold level was exceeded. For security reasons, the site administrator has configured the EAGLE 5 ISS to disable terminals for a specified amount of time, when login failures exceeds a specified number.
  • Page 330 E2700 Messages Command Rejected Messages 2. If the OAM cards are both type GPSM-II, re-enter the command. 3. If one or both OAM cards are not type GPSM-II, you must replace one or both OAM cards with GPSM-II cards before you can turn on the TSC feature. 4.
  • Page 331 Command Rejected Messages E2700 Messages E2766 Cmd Rej: Command cannot be executed on an OAP terminal Commands Used: lock You cannot lock an OAP or SEAS terminal. The specified terminal cannot be an OAP or SEAS terminal. Recovery Enter another command. E2767 Cmd Rej: Keyboard is not locked Commands Used: unlock You entered the unlock command at a terminal the keyboard is not locked, or...
  • Page 332 E2700 Messages Command Rejected Messages E2769 Cmd Rej: Entry already exists for this application at this IP Address Commands Used: ent-ftp-serv You entered a command for an FTP server with an application/IP address combination that already exists in the FTP Server table. An entry for the specified application ID at the specified IP address cannot already exist.
  • Page 333 Command Rejected Messages E2700 Messages Call your Customer Care Center if this error message appears again. E2772 Cmd Rej: Entry already exists for this application at this priority Commands Used: chg-ftp-serv, ent-ftp-serv You entered a command to enter or change an FTP server application and priority parameter combination, and the specified application with the specified priority already exists in the FTP Server table.
  • Page 334 Commands Used: chg-secu-trm You tried to change the terminal access rights for a terminal while a user is logged on to that terminal. The EAGLE 5 ISS does not allow this action. Recovery Re-enter the command when that user ID is logged off.
  • Page 335 You entered the command for a security administration terminal, and tried to change the type parameter to a non-terminal value of printer or none. The EAGLE 5 ISS requires that at least two terminals be configured as security administration terminals in case one of them has a hardware failure.
  • Page 336 Commands Used: ent-gsms-opcode You entered a command to provision a GSM Map opcode and its default action. This command lets you provision the opcodes for which the EAGLE 5 ISS attempts to perform GSM screening. You can specify the point code and subsystem number parameters only if you also specify dfltact=forward, dfltact=duplicate, or dfltact=dupdisc.
  • Page 337 Command Rejected Messages E2700 Messages E2781 Cmd Rej: NDFLTACT parameter must be FORWARD, DUPLICATE, or DUPDISC Commands Used: chg-gsms-opcode You entered a command to specify new attributes for a defined GSM Map opcode. You can modify the default action screening and the user-defined name of an existing opcode.
  • Page 338 You entered the command to define a 24-bit ITU-N point code destination. The EAGLE 5 ISS site ID is not a 24-bit ITU-N point code. Use the chg-sid command to replace the existing site ID with a 24-bit ITU-N point code site ID before you can enter the 24-bit ITU-N point code destination.
  • Page 339 Command Rejected Messages E2700 Messages Recovery Display the current STP site ID. Enter the rtrv-sid command. Refer to the Database Administration - SS7 Manual and the chg-sid command in the Commands Manual for the procedure for replacing the existing ITU-N site ID with a 24-bit ITU-N site ID.
  • Page 340 E2700 Messages Command Rejected Messages E2789 Cmd Rej: NNP,NNAI,NPDD/S,NSDD/S,NGTI,RMGTT invalid if MGTT is OFF Commands Used: chg-gta, chg-gtt, ent-gta, ent-gtt You specified one or more of the parameters nnp, nnai, npdd npds, nsdd, nsds, ngti, and rmgtt. These parameters are not valid in the command if the MGTT feature is off in your system.
  • Page 341 Command Rejected Messages E2700 Messages E2791 Cmd Rej: Quantity control feature capacity exceeded Commands Used: ent-pstn-pres You attempted to enter more PSTNs than were purchased or configured. Enter the rtrv-ctrl-feat command to see provisioned features. Recovery Either delete a PSTN entry before another can be entered, or purchase additional quantity and configure with enable-ctrl-feat.
  • Page 342 E2700 Messages Command Rejected Messages E2794 Cmd Rej: MSGCODE and parmCODE must both be DEFINED Commands Used: chg-isupvar-attrib You entered a command that resulted in either the msgcode or the parmcode having attrib=defined and, the other parmcode or msgcode with an attrib value other than defined.
  • Page 343 Command Rejected Messages E2700 Messages Recovery 1. Display the attributes of ISUP variant table entries. Enter the rtrv-isupvar-attrib command. 2. Re-enter the chg-isupvar-attrib command and change (delete) an existing msgcode entry. Refer to the chg-isupvar-attrib command in the Commands Manual and ‘Changing ISUP Variant Table Entries’...
  • Page 344 E2810 Cmd Rej: Two OAP terminals are already configured Commands Used: chg-trm The EAGLE 5 ISS you are configuring has two terminals configured for OAP using the type=oap parameter, and you attempted to configure a third OAP terminal. You can configure only two OAP terminals on an EAGLE 5 ISS.
  • Page 345 Command Rejected Messages E2700 Messages E2811 Cmd Rej: Comm. attributes cannot be entered for OAP terminal Commands Used: chg-trm You entered the command for an OAP terminal (type=oap) parameter and specified one or more of the communications attributes parameters: baud, prty, sb, and fc.
  • Page 346 E2700 Messages Command Rejected Messages 2. To turn on either: • The SEAS feature. Enter the chg-feat:seas=on, or • The LNP feature. Enter the enable-ctrl-feat command. Refer to the LNP Feature Activation Guide and call your Customer Care Center before starting this procedure. 3.
  • Page 347 Command Rejected Messages E2700 Messages E2815 Cmd Rej: PC and RC must be entered as a pair Commands Used: chg-mrn, ent-mrn, chg-sccp-serv You entered a command that specified a point code, but did not specify a relative cost for the point code. Both the point code parameter and relative code parameter must be specified together in the command.
  • Page 348 E2700 Messages Command Rejected Messages E2818 Cmd Rej: A maximum of 8 PCs are allowed in a group Commands Used: ent-mrn, chg-mrn You entered a command to add one or more point codes to a group in the Mated Relay Node (MRN) table, and the point code group already contains 8 point codes.
  • Page 349 Command Rejected Messages E2700 Messages E2821 Cmd Rej: Could not access removable disk Commands Used: act-upgrade, copy-disk During an upgrade procedure or a copy-disk command action, there was an unsuccessful attempt to read a removable disk. A formatted removable cartridge containing the next release is required for the upgrade.
  • Page 350 E2700 Messages Command Rejected Messages Recovery Re-enter the copy-fta command specifying the correct dloc parameter value. Call your Customer Care Center if this error message appears again. E2824 Cmd Rej: Could not access standby fixed disk Commands Used: copy-fta, copy-gpl, format-disk You may have a hardware problem.
  • Page 351 Command Rejected Messages E2700 Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again. E2828 Cmd Rej: Source and destination disks not compatible Commands Used: copy-fta, format-disk You may have a hardware problem. Recovery Re-enter the command that generated this error message.
  • Page 352 E2700 Messages Command Rejected Messages E2831 Cmd Rej: Current database not coherent Commands Used: chg-db, format-disk Resolving this issue is beyond the scope of this manual. Recovery Refer to the Database Administration Manual - System Management for detailed instructions. Call your Customer Care Center if this error message appears again. E2832 Cmd Rej: MTPRSI is only valid if MTPRS or ITUMTPRS feature is ON Commands Used: chg-stpopts You cannot specify the mtprsi parameter, if the ANSI MTP restart (MTPRS) or the...
  • Page 353 Command Rejected Messages E2700 Messages E2833 Cmd Rej: MTPRSIT parameter is only valid if MTPRS feature is ON Commands Used: chg-stpopts You cannot specify the mtprsit parameter, if the MTP Restart (MTPRS) feature is off. The mtprsit parameter can be specified only if the ANSI MTP restart (MTPRS) feature is turned on.
  • Page 354 E2700 Messages Command Rejected Messages Re-enter the command that generated this error without specifying the mtprse parameter. E2836 Cmd Rej: Too many nested cluster dstn entered Commands Used: ent-dstn You cannot specify the ncai parameter, because you have already provisioned 500 nested clusters.
  • Page 355 Commands Used: chg-dstn You specified the ncai=no parameter to change a provisioned nested cluster point code to a non-nested cluster point code. The EAGLE 5 ISS does not allow this action since the previously provisioned members of the cluster have a different route set.
  • Page 356 E2700 Messages Command Rejected Messages E2839 Cmd Rej: Invalid parameter for ITU-N 24bit point code Commands Used: chg-appl-rtkey, chg-dstn, ent-dstn, ent-ls You specified a 24-bit ITU-N point code and a 14-bit ITU-N alias or ANSI alias point code. An ANSI point code cannot have a 24-bit ITU-N alias point code. You specified a 14-bit ITU-N point code and a 24-bit ITU-N alias or ANSI alias point code.
  • Page 357 Command Rejected Messages E2700 Messages Recovery 1. Display a list of the current linksets and their status. Enter the rtrv-ttmap command. 2. Re-enter the command that generated this error message and set the lsn parameter to indicate a linkset that has room to spare. 1.
  • Page 358 E2700 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message specifying a different lsn parameter value. Call your Customer Care Center if this error message appears again. E2844 Cmd Rej: ETT not defined for LSN and IO specified Commands Used: chg-ttmap, dlt-ttmap, ent-ttmap, rtrv-ttmap You failed to specify the existing translation type parameter ett when entering this command.
  • Page 359 Command Rejected Messages E2700 Messages Recovery Re-enter the ent-ttmap command that generated this error message specifying a different mtt parameter value. Call your Customer Care Center if this error message appears again. E2847 Cmd Rej: IF IO or ETT specified, BOTH opt. parms must be specified Commands Used: dlt-ttmap If you specify one of these two parameters, you need to specify the other one as well.
  • Page 360 E2700 Messages Command Rejected Messages E2849 Cmd Rej: PC must already exist in the MRN table Commands Used: chg-mrn, dlt-mrn, rtrv-mrn You specified a point code parameter value that does not already exist in the Mated Relay Node (MRN) table. The point code must exist in the MRN table before you can change, delete, or retrieve the table information for the point code.

  • Page 361: Table 2-15. Routesets Feature With Maximum Values

    Command Rejected Messages E2700 Messages You entered a value for mtpxlq that exceeds the allowable sum of destinations provisioned as determined by adding the values of the mtpdpcq and mtpxlq parameters (mtpdpcq + mtpxlq <= sum). When the number of x-list entries (mtpxlq) is specified, the total number of DPCs (mtpdpcq) and x-list entries (mtpxlq) provisioned cannot exceed the space available in the Route table.
  • Page 362 E2700 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2853 Cmd Rej: ELEI is only valid for cluster destinations Commands Used: chg-dstn, ent-dstn You specified the elei parameter, and you specified a DPC that is not a cluster destination.
  • Page 363 Command Rejected Messages E2700 Messages Recovery 1. Perform one of the following: • Display the cluster DPCs. Enter the rept-stat-cluster command. • Display network destinations. Enter the rtrv-dstn command. 2. Re-enter the command you originally entered specifying the aliasa/aliasi/aliasn/ aliasn24 parameter, and a value for the dpc/dpca/dpci/dpcn/dpcn24 parameter that is not listed as a cluster or network destination in the output from Step 1.
  • Page 364 E2700 Messages Command Rejected Messages E2856 Cmd Rej: ELEI is only valid if the CRMD feature is ON Commands Used: chg-dstn, ent-dstn You specify the exception-list exclusion indicator (elei) parameter, if the Cluster Routing and Management Diversity (CRMD) feature is turned off. The CRMD feature must be turned on before the elei parameter can be specified.
  • Page 365 Command Rejected Messages E2700 Messages E2858 Cmd Rej: SLSCI is only valid for ANSI link sets Commands Used: chg-ls, ent-ls You cannot specify the slsci=yes parameter, if the linkset does not have an ANSI APC. The slsci parameter can only be specified for ANSI linksets. Recovery Perform one of the following: •...
  • Page 366 E2700 Messages Command Rejected Messages Recovery 1. Display the linkset information. Enter the rtrv-ls command. The LNKS column lists the total number of links assigned to the linkset. 2. Re-enter the command specifying a value for the tfatcabmlq parameter that is less than the number of links found in step 1, and that is in the parameter’s range (0, 1-16).
  • Page 367 Command Rejected Messages E2700 Messages E2863 Cmd Rej: Destination’s alias PCs must be full PCs Commands Used: chg-dstn, ent-dstn, rtrv-dstn You cannot use an asterisk to designate the network indicator (ni), network cluster (nc), or network cluster member (ncm). Recovery Re-enter the command that generated this error message specifying a numerical value for all three segments of the point code using the full point code format.
  • Page 368 E2868 Cmd Rej: Invalid NCAI parameter has been entered Commands Used: chg-dstn, ent-dstn You specified the ncai parameter for a destination address that is not a cluster destination. The EAGLE 5 ISS does not allow this action. 2-354 910-3638-001 Revision B, October 2006...
  • Page 369 Command Rejected Messages E2700 Messages Recovery Re-enter the command without specifying the ncai parameter. 1. View the cluster DPCs and the routeset information for all configured clusters. Enter the rept-stat-cluster command. The cluster DPCs are displayed in the DPCA field (for example, 7-7-* is a cluster destination). 2.
  • Page 370 E2700 Messages Command Rejected Messages NOTE: Once a feature that is controlled using a feature bit is turned on, it cannot be turned off. Refer to the chg-feat command in the Commands Manual for further information. Recovery 1. Verify whether the LFS feature is turned on. Enter the rtrv-feat command. If the LFS feature is off, you must turn it on.
  • Page 371 Command Rejected Messages E2700 Messages Recovery 1. Enter the rtrv-sid command specifying the cpcx parameter to verify the capability point code’s existence. 2. Re-enter the chg-sid command without specifying the ncpc/ncpca/ncpci/ncpcn/ncpcn24 parameter. Re-enter the chg-sid command specifying both the ncpc/ncpca/ncpci/ncpcn/ncpcn24 parameter and the cpc/cpca/cpci/cpcn/cpcn24 parameter, ensuring that you use the same point code type for both.
  • Page 372 E2700 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2875 Cmd Rej: Network/Cluster cannot have alias DPC members Commands Used: ent-dstn Alias ANSI point codes cannot have the same network identifier (ni) and network cluster (nc) subfields as a cluster point code that is already defined.
  • Page 373 Command Rejected Messages E2700 Messages Call your Customer Care Center if this error message appears again. E2878 Cmd Rej: Ordered routes cannot be assigned to cluster members Commands Used: ent-rte A route is already provisioned for ni-nc-xxx (where xxx is * or pc). You cannot enter a route on a linkset different than the one already provisioned, unless the specified destination addresses’s NCAI (nested cluster allowed indicator) is set to yes.

  • Page 374: For Mtpdpcq And Mtpxlq Parameters

    E2700 Messages Command Rejected Messages 2. Re-enter the dlt-rte command that generated this error message. 1. Verify that the DPC you specified is a member of a cluster. Enter the rept-stat-cluster command. This command displays routeset information for all configured clusters. The cluster DPCs are displayed in the DPCA field.
  • Page 375 Command Rejected Messages E2700 Messages 3. Calculate the maximum value for the mtpdpcq parameter, using the information from Table 2-16 and Steps 1 and 2. 4. Re-enter the chg-stpopts command specifying a value for the mtpdpcq parameter that does not exceed the command requirements as calculated in Step 3.
  • Page 376 You must first delete an existing CPC before you can add a new one. Recovery 1. Display the CPCs currently configured in the EAGLE 5 ISS database. Enter the rtrv-sid command. 2. Delete one of the existing CPCs. Enter the chg-sid:cpc=xxx-xxx-xxx:ncpc=none command, where xxx-xxx-xxx is a point code you select from the output in step 1.
  • Page 377 Command Rejected Messages E2700 Messages If the ncai=yes, then the specified destination address is a member of a provisioned nested cluster where the attributes of the ordered routes assigned to the cluster can be changed. Perform one of the procedures in the following Recovery procedures. Recovery - Change ordered route attributes for the cluster.
  • Page 378 E2700 Messages Command Rejected Messages Recovery - rept-stat-dstn You specified a point code in the format ni-nc-** or ni-nc-*** and the mode=full parameter. The mode=full parameter requests detailed status information for a single point code, and specifying point codes in the format ni-nc-** or ni-nc-*** requests summary status for a range of point codes;...
  • Page 379 You have specified a value for the mtpdpcq parameter that is less than the number of DPCs configured in the EAGLE 5 ISS database. This parameter is used to specify the maximum number of DPCs that you can configure in the database.
  • Page 380 Recovery These commands cannot be entered from a OAP terminal. You must be logged in to an EAGLE 5 ISS terminal to use these commands. E2890 Cmd Rej: DPC must be specified as wildcard when used with STAT Commands Used: rept-stat-dstn You specified both the dpc and the stat parameters, but you did not specify the point code in wild card format (ni-nc-** or ni-nc-***).
  • Page 381 Command Rejected Messages E2700 Messages E2892 Cmd Rej: LOC is not LFS capable Commands Used: act-lbp, chg-lbp, dact-lbp, dlt-lbp, ent-lbp, rept-stat-lfs, rtrv-lbp You entered the command and identified a card location that does not meet the command criteria. The card location (loc) must identify a provisioned limds0, limt1, or limch (which is associated with a limt1) card configured with either an ss7ansi or a ccs7itu application.
  • Page 382 E2700 Messages Command Rejected Messages 2. Use the output from step 1 to determine a value for the rep parameter that meets the command criteria. 3. Re-enter the command specifying the rep parameter with the value you selected in step 2. E2894 Cmd Rej: LBP has already been provisioned Commands Used: ent-lbp You cannot configure a loopback point ID that was used in a previous...
  • Page 383 Command Rejected Messages E2700 Messages E2896 Cmd Rej: DS0 and NEI link elements do not support non-latching tests Commands Used: act-lbp, chg-lbp, ent-lbp You entered the command and specified either the rle=ds0 or the rle=nei parameter, and you specified the lfst=nlt parameter instead of the lfst=llt parameter.
  • Page 384 E2700 Messages Command Rejected Messages E2898 Cmd Rej: LBP cannot exceed previously defined NEI LBP value Commands Used: ent-lbp You cannot specify a value for the lbp parameter that exceeds the lbp parameter value previously defined for a loopback point with rle=nei specified. The network element interface (NEI), specified by the rle=nei parameter, identifies the last remote link element on the signaling link;...
  • Page 385 Command Rejected Messages E2900 Messages E2900 Cmd Rej: NEI LBP must be defined as the last link element Commands Used: chg-lbp, ent-lbp You entered the command and tried to configure a network element interface (NEI) remote link element (RLE), whose loopback point (LBP) ID does not define the last element on the link.
  • Page 386 E2900 Messages Command Rejected Messages E2902 Cmd Rej: LBP or ALL parameter must be specified exclusively Commands Used: dlt-lbp You entered the dlt-lbp command and specified both the lbp and the all parameters. This combination is not allowed. The all parameter deletes all loopback points for the specified signaling link, whereas the lbp parameter deletes a specific loopback point.
  • Page 387 100 milliseconds (0.10 seconds). Recovery 1. Display the current values of the EAGLE 5 ISS’s node-level processing option indicators, maintained in the STP’s options table. Enter the rtrv-stpopts command. The TRATFRPR field displays the value you entered for the tfatfrpr parameter for the chg-stpopts command.
  • Page 388 E2900 Messages Command Rejected Messages E2906 Cmd Rej: LFS test is completing, cannot be canceled Commands Used: dact-lbp A previously issued act-lbp command is about to complete. A new dact-lbp command cannot be accepted until the act-lbp command completes. Recovery 1.
  • Page 389 Command Rejected Messages E2900 Messages E2910 Cmd Rej: RLE and LFST must be specified when database is not used Commands Used: act-lbp If you specify any one of the rle, rep, lfst, orclli parameters, the database is not used to look up their values; therefore, you must specify the lfst and rle parameters.
  • Page 390 For example, suppose the previously defined values for the rep parameter were 1 and 2. The EAGLE 5 ISS defaults to 2 because no integer exists between 1 and 2. The sequence of rep parameter values would now be 1, 2, 2 but the two same values cause the EAGLE 5 ISS to generate error message E2914.
  • Page 391 Command Rejected Messages E2900 Messages Recovery 1. Acquire the current descriptive parameters. Enter the rtrv-stpopts command. 2. Re-enter the chg-stpopts command that generated this error message, and assign a valid value, acquired in step 1, to the mtp10alt parameter. E2916 Cmd Rej: Link must not be active to execute command Commands Used: act-cdl, act-lbp, dact-cdl, dact-lbp, tst-slk The link that you use for testing cannot be active.
  • Page 392 E2900 Messages Command Rejected Messages Recovery Re-enter the rept-stat-slk command that generated this error message without specifying the l2stats parameter. Call your Customer Care Center if this error message appears again. E2919 Cmd Rej: LOC and PORT must be specified to display Level2 stats Commands Used: rept-stat-slk You cannot display Level2 stats without specifying values for both the loc and port parameters.
  • Page 393 Command Rejected Messages E2900 Messages Recovery Perform one of the following: • Re-enter the command that generated this error message after giving the link time to complete any activities in progress. • Re-enter the command that generated this error message but specify a different link.
  • Page 394 E2900 Messages Command Rejected Messages A locally initiated loopback is not found, and is assumed to be a remote loopback. The maximum number of tests is currently running; therefore, the dact-lbp command is not allowed for the remote loopback. At least one active test must complete before you re-enter the dact-lbp command.
  • Page 395 E2927 Cmd Rej: The linkset is provisioned locally Commands Used: ent-slk OAP attempted to provision GWS on a linkset that has GWS on it already through an EAGLE 5 ISS terminal. Recovery Re-enter the ent-slk command that generated this error message specifying the correct slc parameter value.
  • Page 396 E2900 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the command that generated this error message specifying off for the gwsa, gwsm, or gwsd parameters. • Re-enter the command that generated this error message without specifying the gwsa, gwsm, and gwsd parameters. Call your Customer Care Center if this error message appears again.
  • Page 397 E2931 Cmd Rej: SEAS Gateway Screen Set Names cannot be changed locally Commands Used: chg-ls You entered the command at an EAGLE 5 ISS terminal and tried to change a SEAS gateway linkset. Gateway linksets can be configured only from a OAP terminal and not from an EAGLE 5 ISS terminal.
  • Page 398 Commands Used: rtrv-log You specified a combination of start date (sdate) and start time (stime) that is later than the current date-time combination. The EAGLE 5 ISS does not allow you to specify a time in the future to retrieve logs.
  • Page 399 Commands Used: rtrv-log You tried to enter a retrieve log command while another retrieve log command was already in progress. The EAGLE 5 ISS does not allow two retrieve log commands to be in progress at the same time. Recovery Wait until the active retrieve log command finishes processing, and re-enter the command.
  • Page 400 Care Center. E2941 Cmd Rej: Invalid combination - EDATE with STIME Commands Used: rtrv-log You specified the stime parameter and the edate parameter. The EAGLE 5 ISS does not allow this combination. Recovery Re-enter the rtrv-log command specifying another valid combination of the time (stime/etime) and date (sdate/edate) parameters.
  • Page 401 Command Rejected Messages E2900 Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again. E2944 Cmd Rej: Invalid INTRVL value specified Commands Used: set-gtwy-acthresh, set-scrrej-prmtrs, set-uim-acthresh You assigned an invalid value to the intrvl parameter. Valid values are 5, 10, 15, 20, 25, 30.
  • Page 402 E2900 Messages Command Rejected Messages NOTE: Leaving a removable cartridge in the MDAL for a prolonged period can cause damage. Remove the cartridge after the command or procedure completes. E2946 Cmd Rej: No match on DESTFLD parameter during retrieve Commands Used: rtrv-scr-sio You set the nsfi parameter to the destfld value, but no match was found.

  • Page 403: Table 2-18. Valid Dev/Port Parameter Combinations

    Command Rejected Messages E2900 Messages Recovery 1. Enter the rtrv-scr-cgpa command without specifying the scmgid parameter, to acquire the current state of the parameter. 2. Re-enter the rtrv-scr-cgpa command that generated this error message, using the appropriate scmgid parameter value acquired in step 1. Call your Customer Care Center if this error message appears again.
  • Page 404 E2900 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2951 Cmd Rej: LSN must be specified Commands Used: inh-alm, unhb-alm You failed to enter the required linkset name (lsn) parameter when you specified the dev parameter with a value of ls.
  • Page 405 Command Rejected Messages E2900 Messages Recovery Re-enter the command that generated this error message specifying the correct id parameter value. Call your Customer Care Center if this error message appears again. E2954 Cmd Rej: DEV state does not allow alarms to be inhibited Commands Used: inh-alm The device you selected was servicing an action command when you entered this command.
  • Page 406 E2900 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E2956 Cmd Rej: NCM must be * when using Network Routing Commands Used: chg-dstn, chg-rte, dlt-dstn, dlt-rte, ent-dstn, ent-rte, rtrv-dstn, rtrv-rte You entered a destination point code that has an invalid format for network routing.
  • Page 407 Command Rejected Messages E2900 Messages Call your Customer Care Center if this error message appears again. E2962 Cmd Rej: <device> is <condition> Commands Used: chg-db, copy-disk, copy-meas, copy-gpl, format-disk The command cannot complete because it cannot write to the specified device (either a removable cartridge or fixed disk) for the reason described in the condition.
  • Page 408 E2900 Messages Command Rejected Messages Recovery - Removable cartridge is inaccessible (internal problem) Remove and re-install the MDAL and cartridge or a spare. Recovery - Fixed disk is not inserted Insert a fixed disk for the current system release. Recovery - Fixed disk is not initialized 1.
  • Page 409 IPGWx and IPLIMx cards in the source data base. Recovery 1. Use the chg-netopts command to specify an EAGLE 5 ISS PVN network address in the source database, • that is not the same as the destination address of a IP static route, •...
  • Page 410 E2900 Messages Command Rejected Messages Refer to the command description in the Commands Manual for valid parameters for the command. For the rept-stat-alm command, you specified the dev parameter, but did not specify the required display parameter. Recovery inh-alm, unhb-alm Re-enter the command that generated this error message specifying fewer parameters.
  • Page 411 Command Rejected Messages E2900 Messages E2967 Cmd Rej: Active OAM database is incoherent Commands Used: all commands The database was found to be incoherent, which means that a previous database update was unsuccessful, leaving the coherency indicator unchanged. During the subsequent attempted execution of an upgrade procedure, an error was detected when either of the following was issued: act-upgrade:action=convertoam or act-upgrade:action=convertstp...
  • Page 412 E2900 Messages Command Rejected Messages Recovery 1. Verify that you typed the command correctly. 2. Make any necessary corrections, and then re-enter the command. Refer to the Commands Manual for information regarding the correct command usage. Call your Customer Care Center if this error message appears again. E2970 Cmd Rej: Action requires ICNP feature to be configured Commands Used: rept-meas You attempted an action that requires the IntraCarrier Number Portability and IN...
  • Page 413 An action command is a command that changes the state of entities within the EAGLE 5 ISS. For more information, refer to the Commands Manual. Recovery 1. Wait until the disk activity subsides or the action command completes.
  • Page 414 E2900 Messages Command Rejected Messages Recovery Re-enter the command specifying a valid port for the card type and application. E2973 Cmd Rej: If specified, BPS must be 56000 for Multi Port LIM Commands Used: ent-slk You entered a bps value that is not valid for a multi-port LIM or an E1/T1 MIM used as a T1 card.
  • Page 415 Command Rejected Messages E2900 Messages The link parameter values a1, b1, a2, b2, a7, and b7 can be specified only for the following cards: • DCM with card type dcm and application iplim or iplimi. • E1/T1 MIM • E5-E1T1 •...
  • Page 416 E2980 Cmd Rej: Must be in upgrade phase 3 or full function mode Commands Used: init-network You entered the command and the EAGLE 5 ISS was not in Upgrade Phase 3 mode or Full Function mode. Upgrade Phase 3 mode means that the MASPs are running GPLs that match the major revision defined for the approved GPLs, but the other network processors are only prepared to be upgraded.
  • Page 417 E2981 Cmd Rej: Already in nodal isolation Commands Used: init-network You entered the command, and the EAGLE 5 ISS detected that there were no in-service active links. The init-network command requires that at least one ss7ansi or ccs7itu card must exist with an in-service active link.
  • Page 418 E2900 Messages Command Rejected Messages • If the database on the removable cartridge is coherent and the current partition of the fixed disk is incoherent, restore the database from the removable cartridge. Enter the following command: chg-db:action=restore:src=remove • If the backup and current partitions on the active TDM are coherent and the backup and current partitions on the standby TDM are incoherent, repair the database.
  • Page 419 Command Rejected Messages E2900 Messages E2986 Cmd Rej: Relative Cost (RC) is required for PC/SSN and MPC/MSSN Commands Used: ent-map If the pc/ssn and mpc/mssn parameter pairs are specified, the rc parameter must be specified. Recovery Re-enter the ent-map command specifying the pc/ssn and mpc/mssn parameter pairs and the relative cost (rc) parameter.
  • Page 420 You specified the relative cost (rc) parameter value for a true point code that is greater than the relative cost for its mate. If the pc parameter value is an EAGLE 5 ISS true point code, the subsystem must have a lower relative cost than all other mated subsystems in the group.
  • Page 421 Command Rejected Messages E2900 Messages E2992 Cmd Rej: Mate parameters: MPC, MSSN, MateRC are required together Commands Used: chg-map The mpc, mssn, and materc parameters must be specified together in the command. Recovery Re-enter the chg-map command specifying values for the mpc, mssn, and materc parameters.
  • Page 422 E2900 Messages Command Rejected Messages Recovery If you want to change the mate of the true point code, delete the current mate and re-enter the chg-map command to enter the new mate. E2996 Cmd Rej: Intermed GTT Load sharing feature must be on Commands Used: chg-mrn, ent-mrn You entered the command to add, change, or delete an entry in the Mated Relay Node (MRN) table.
  • Page 423 Commands Used: chg-mrn, chg-sccp-serv, ent-mrn You entered a command to add or change a point code entry in the Mated Relay Node table, and the specified point code is the same as the EAGLE 5 ISS site identifier (SID). This is not allowed.
  • Page 424 E2900 Messages Command Rejected Messages 2-410 910-3638-001 Revision B, October 2006...
  • Page 425 Command Rejected Messages E3000 Messages E3000 Cmd Rej: DPC is referenced by SCCP in MRN table or SCCP Serv table Commands Used: dlt-dstn You cannot delete a Destination Point Code (DPC) that is referenced by an SCCP as a point code in the Mated Relay Node (MRN) table. The specified destination cannot be referenced by an SCCP as a destination point code in the Mated Relay Node (MRN) table or the SCCP SEV table.
  • Page 426 E3000 Messages Command Rejected Messages Recovery Re-enter the rtrv-seculog command specifying a new time for the (stime) parameter (in the form hhmmss—hh=hours (00-23), mm=minutes (00-59), ss=seconds (00-59)) that is earlier than the time specified for the (etime) parameter. E3003 Cmd Rej: Modification of security log not allowed Commands Used: copy-fta, copy-tbl You cannot specify the values (170, 500 or 502) for the Source table (stbl) parameter, the Destination table (dtbl) parameter, or both.
  • Page 427 Command Rejected Messages E3000 Messages E3005 Cmd Rej: Security log command already in progress Commands Used: copy-seculog, rept-stat-seculog, rtrv-seculog You cannot enter a security log command while another security log command is already in progress. Two security log commands cannot be in progress at the same time.
  • Page 428 E3000 Messages Command Rejected Messages E3009 Cmd Rej: LNP feature must be ON Commands Used: chg-acg-noc, chg-db, chg-feat, chg-lnp-serv, chg-cmd, chg-lnpopts, chg-map, chg-measopts, chg-oap-config, chg-secu-trm, chg-sid, chg-ss-appl, chg-user, dlt-lnp-serv, dlt-ss-appl, enable-ctrl-feat, ent-acg-noc, ent-card, ent-lnp-serv, ent-map, ent-ss-appl, ent-user, rept-ftp-meas, rept-meas, rept-stat-lnp, rept-stat-lsms, rst-card, rtrv-cmd, rtrv-cmdclass, rtrv-lnp-serv, rtrv-lnpopts, rtrv-sid, rtrv-ss-appl The LNP feature (refer to the enable-ctrl-feat command) must be turned on...
  • Page 429 Command Rejected Messages E3000 Messages E3012 Cmd Rej: LNP subsystem is offline in database Commands Used: alw-map-ss You cannot run this command while the LNP subsystem is offline in the database. Recovery 1. Activate the LNP subsystem. Enter the chg-ss-appl:appl=lnp:nstat=online command. 2.
  • Page 430 E3000 Messages Command Rejected Messages Recovery 1. To delete the specified route, you must first delete the point code from the MRN table or the SCCP SEV table. Enter the dlt-mrn command. 2. When point code has been deleted from the MRN table or the SCCP SEV table, re-enter the command to delete the specified route.
  • Page 431 Command Rejected Messages E3000 Messages E3019 Cmd Rej: Conflicts with existing entry Commands Used: dlt-rmt-appl, ent-rmt-appl The following conditions may cause this error: • You entered a point code of the same network type (ANSI/ITUI/ITUN) that does not match the point code already in the Remote Application table for that type.
  • Page 432 E3000 Messages Command Rejected Messages Recovery Perform one of the following: • Re-enter the chg-gsmopts command specifying a value other than none for the multcc parameter. • Reset the value specified for the multcc parameter. Enter the following command: chg-gsmopts:multcc=xxx:nmultcc=none E3040 Cmd Rej: <reserved word>...
  • Page 433 Command Rejected Messages E3000 Messages E3042 Cmd Rej: Command Response Timeout, freeing up scroll area Commands Used: Any command While in keyboard send/receive (KSR) mode, you entered a command but received no response from the OAM card. Recovery 1. Re-enter the command that generated this error message. 2.
  • Page 434 E3000 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the rept-imt-info command specifying the report=err parameter and either the mode, erronly, sbucket, and ebucket parameters. • Re-enter the rept-imt-info command specifying the report=util parameter without specifying the mode, erronly, sbucket, and ebucket parameters.
  • Page 435 Command Rejected Messages E3000 Messages 3. If the state of both IMT buses is not OOS-MT-DSBLD, place the IMT bus you wish to test out of service with the rmv-imt command. 4. Re-enter the tst-imt command specifying the IMT bus placed out of service in step 3.
  • Page 436 E3000 Messages Command Rejected Messages Recovery Re-enter the command specifying either the s or sloc parameters. E3049 Cmd Rej: Ending bucket cannot be less than starting bucket Commands Used: rept-imt-info The value of the ending bucket (ebucket) parameter was less than the value of the starting bucket (sbucket) parameter.
  • Page 437 Command Rejected Messages E3000 Messages E3052 Cmd Rej: IMT statistics collection in progress - Repeat later Commands Used: clr-imt-stats, init-flash, init-imt-gpl, init-mux, rept-imt-info, rept-imt-lvl1, rept-imt-lvl2, tst-imt The command was entered when the system was collecting the Interprocessor Message Transport (IMT) statistics for the hourly performance monitoring report. Recovery Wait for the system to finish collecting the IMT statistics, then re-enter the command.
  • Page 438 E3000 Messages Command Rejected Messages Recovery 1. Display a list of all currently defined overload levels. Enter the rtrv-acg-noc command. 2. Re-enter the command specifying one of the overload levels from step 1. E3055 Cmd Rej: Failed reading ACG MIC table Commands Used: ent-acg-mic The Automatic Call Gapping (ACG) Manually Initiated Control (MIC) table is corrupt or cannot be found by the system.
  • Page 439 Command Rejected Messages E3000 Messages E3057 Cmd Rej: Parameters SERV and DGTS are not allowed for TYPE=ALL Commands Used: chg-acg-mic, dlt-acg-mic, ent-acg-mic, rtrv-acg-mic If the manually initiated control applies to all query services (type=all), the serv and dgts parameters cannot be specified. NOTE: If the type=all parameter is specified, a MIC with type=all must exist.
  • Page 440 E3000 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the command that generated this error message without specifying the nd parameter. • Re-enter the command that generated this error message specifying the type of control type=all parameter. NOTE: If the type=all parameter is specified, a MIC with type=all must exist.
  • Page 441 Command Rejected Messages E3000 Messages Recovery Perform one of the following actions: • Re-enter the command specifying the serv=ain parameter and the aintvl parameter. • Re-enter the command specifying the serv=in parameter and the intvl parameter. E3062 Cmd Rej: Parameter INTVL is required Commands Used: ent-acg-mic If the query service specified is the Intelligent Network (serv=in), the optional IN interval index (intvl) parameter must be specified.
  • Page 442 E3000 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the command specifying the serv=in parameter and the intvl parameter. • Re-enter the command specifying the serv=ain parameter and the aintvl parameter. E3064 Cmd Rej: DGTS parameter must be 3 or 6–10 Commands Used: chg-acg-mic, dlt-acg-mic, ent-acg-mic, rtrv-acg-mic You specified an invalid value for the digits of the global title address (dgts)
  • Page 443 Command Rejected Messages E3000 Messages E3066 Cmd Rej: A MIC of TYPE=ALL already exists Commands Used: ent-acg-mic If the type=all parameter is specified, a manually initiated control (MIC) that applies to all query services (type=all) parameter must not already exist. Recovery 1.
  • Page 444 E3000 Messages Command Rejected Messages 3. Delete ACG controls that are not needed. Enter the dlt-acg-mic command. 4. Re-enter the command that generated this error message. E3069 Cmd Rej: Parameter ND, DRTN, INTVL, or AINTVL is required Commands Used: chg-acg-mic If you enter this command specifying the type=all parameter.
  • Page 445 Command Rejected Messages E3000 Messages E3071 Cmd Rej: Parameter DRTN or INTVL is required Commands Used: chg-acg-mic When you enter this command specifying the serv=in parameter, you must specify at least one of these optional parameters: drtn or intvl. Recovery Perform one of the following actions: •...
  • Page 446 E3000 Messages Command Rejected Messages Recovery 1. Display the values of ACG controls assigned to certain queries. Enter the rtrv-acg-mic command. 2. Re-enter the command that generated this error message specifying a MIC that is shown in the output generated in step 1. E3074 Cmd Rej: AND parameter must be 6 or 10 Commands Used: chg-acg-noc, ent-acg-noc You specified a value other than 6 or 10 for the AIN number of digits (and)
  • Page 447 Command Rejected Messages E3000 Messages E3076 Cmd Rej: The specified overload level has already been defined Commands Used: ent-acg-noc The LNP process can be programmed to take remedial action at ten different levels of overload severity. The controlling variable is the threshold LNP query rates for node overload levels.
  • Page 448 E3000 Messages Command Rejected Messages E3078 Cmd Rej: DPC cannot be defined as a remote application IPC Commands Used: dlt-dstn You entered a command to delete a dpc and specified a remote application Internal Point Code (IPC) for the dpc parameter value. This is not allowed. Recovery 1.
  • Page 449 Command Rejected Messages E3000 Messages Recovery Re-enter the ent-gsmmap-scrn command specifying one of the required default screening action parameters. E3081 Cmd Rej: NACTION parameter must be FORWARD, DUPLICATE, or DUPDISC Commands Used: chg-gsmmap-scrn You entered a command to change attributes for a defined GSM MAP Screening entry.
  • Page 450 E3000 Messages Command Rejected Messages E3083 Cmd Rej: NACTION must be specified (FORWARD, DUPLICATE, or DUPDISC) Commands Used: chg-gsmmap-scrn You entered a command to change the attributes for a defined GSM MAP Screening entry. The attributes (nforbid and naction) filter or allow SCCP messages containing MAP opcodes, CgPA and CdPA addresses, np, nai, and forbidden parameters.
  • Page 451 Command Rejected Messages E3000 Messages Recovery 1. Display the point code and its existing relative cost parameter values. Enter the rtrv-mrn command. 2. Change the relative cost for the point code. Enter the chg-mrn command specifying the point code and the new relative cost parameters. E3086 Cmd Rej: New PC and RC must be entered as a pair Commands Used: ent-mrn You entered a command to add a new point code to the Mated Relay Node (MRN)
  • Page 452 E3000 Messages Command Rejected Messages You entered the chg-measopts command to turn on the Filename with CLLI feature but the Measurements Platform collection function is not enabled. You must enable the Measurements Platform collection function before you can use this command. You entered the enable-ctrl-feat command to turn on the MTP MAP Screening feature but the Measurements Platform collection function is not enabled.
  • Page 453 Command Rejected Messages E3000 Messages E3089 Cmd Rej: FTP Server password must be 1 - 15 characters in length Commands Used: chg-ftp-serv, ent-ftp-serv You entered a command to enter or change information for a Measurements Platform FTP server. A prompt appeared asking you for the FTP server password You either pressed the Return key after the prompt without entering the FTP server password, or you entered a password that was more than 15 characters long.
  • Page 454 E3000 Messages Command Rejected Messages Recovery -gsmmap-scrn commands 1. If you specified ent-gsmmap-scrn:action=forward, duplicate, or dupdisc, you must include the pc/pca/pci/pcn/pcn24 and ssn parameters. 2. If you specified chg-gsmmap-scrn:naction=forward, duplicate, or dupdisc, you must include the npc/npca/npci/npcn/npcn24 and nssn parameters. Recovery -gsms-opcode commands 1.
  • Page 455 2. Verify that at least one STC card is configured in the system. If an STC card is not installed in the system, you cannot use this command until STC cards are installed and provisioned, and the EAGLE 5 Integrated Monitoring Support feature is installed and operating.
  • Page 456 E3000 Messages Command Rejected Messages 2. Enter the rtrv-ip-lnk command to verify the card location for the local host name IP address. 3. If the card location for the local host IP address is not shown for the local host IP address in the output from step 2, enter the chg-ip-lnk command to define the card location.
  • Page 457 Command Rejected Messages E3000 Messages E3097 Cmd Rej: GPSM-II required to support more than 700 links Commands Used: enable-ctrl-feat, ent-slk If you entered the enable-ctrl-feat command to enable the 6000 Routesets Controlled Feature. To enable the 6000 Routesets feature, both OAM cards in locations (1113 and 1115) must be running GPSM-II cards.
  • Page 458 E3100 Messages Command Rejected Messages E3098 Cmd Rej: PPSMSGTA must not be NONE Commands Used: chg-gsmopts You cannot specify a value of none for the ppsmsgta parameter. Recovery Re-enter the chg-gsmopts command specifying a valid value for the ppsmsgta parameter. E3099 Cmd Rej: PPSMSGTA must be specified when NPPSMSGTA is specified Commands Used: chg-gsmopts You cannot specify the nppsmsgta parameter without specifying the ppsmsgta...
  • Page 459 Command Rejected Messages E3100 Messages E3101 Cmd Rej: Maximum number of PPSMSGTAs already provisioned Commands Used: chg-gsmopts You cannot add a ppsmsgta value to the GSMOPTS table because the maximum of three ppsmsgta values are already provisioned. Recovery 1. Display the ppsmsgta parameter values currently in the GSMOPTS table. Enter the rtrv-gsmopts command.
  • Page 460 E3100 Messages Command Rejected Messages 2. From the output from step 1, verify the XGTT Table Expansion feature has been purchased and installed in your system. Call your Customer Care Center for assistance. 3. From the output from step 1 determine the status of the GTT feature. •...
  • Page 461 Command Rejected Messages E3100 Messages 486 processors and must be replaced. Call your Customer Care Center. for assistance if necessary. 2. When all SCCP cards have at least 586 processors, re-enter the enable-ctrl-feat command to enable the XGTT feature. E3105 Cmd Rej: XGTT requires both OAMs running on GPSMII cards Commands Used: enable-ctrl-feat You cannot enable the Expanded Global Title Translation (XGTT) Table Expansion feature if both OAM cards are not type GPSM-II.
  • Page 462 E3100 Messages Command Rejected Messages E3107 Cmd Rej: XMAP requires at least a 586 processor for SCCP GPLs Commands Used: enable-ctrl-feat You entered a command to enable the Expanded MAP Table (XMAP) feature, but one or more SCCP cards in the system have less than a 586 processor. Before you can turn on the XMAP feature, all SCCP cards in the system must have at least 586 processors.
  • Page 463 Command Rejected Messages E3100 Messages E3109 Cmd Rej: Temporary feature key is not allowed for the feature Commands Used: enable-ctrl-feat You entered a command to enable a Controlled Feature, but a temporary feature access key is not allowed for this feature. Controlled feature access keys may be temporary or permanent.
  • Page 464 E3100 Messages Command Rejected Messages Recovery 1. Display the state of the signaling links in the database.Enter the rept-stat-slk command. The state of the signaling links should be either in-service normal (IS-NR) or out-of-service maintenance-disabled (OOS-MT-DSBLD). (As shown in the PST field of the rept-stat-slk command output).
  • Page 465 Command Rejected Messages E3100 Messages Call your Customer Care Center if this error message appears again. E3117 Cmd Rej: No available primary MCP Commands Used: rept-ftp-meas, rept-meas When you entered the command, the Measurements Platform feature was turned on but there was no primary MCP (Measurement Collection Processor)) available in the system.
  • Page 466 E3100 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again. E3121 Cmd Rej: Domain indicated by GTIx must match that of existing TT Commands Used: ent-gttsel The domain you specified with the gti/gtia/gtii/gtin/gtin24=4 parameter does not match the domain of the translation type (tt).
  • Page 467 Command Rejected Messages E3100 Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again. E3124 Cmd Rej: Failed Reading LNP SS Appl table Commands Used: chg-map, chg-ss-appl, dlt-ss-appl, ent-map, ent-ss-appl, rtrv-ss-appl The LNP TT SS Appl table is corrupt or cannot be found by the system.
  • Page 468 E3100 Messages Command Rejected Messages Recovery 1. Enter the rtrv-lnp-serv command to retrieve a list of all LNP services and translation types. 2. Perform one of the following actions: • Use the chg-lnp-serv command to change the syntax of the service type that is currently assigned to the translation type, to that of the desired service type.
  • Page 469 Command Rejected Messages E3100 Messages A maximum of eight unique LNP services can each be assigned one translation type apiece. Recovery 1. Display a list of all LNP services. Enter the rtrv-lnp-serv command. 2. Re-enter the chg-lnp-serv command specifying an ntt that is not listed in the output from step 1.
  • Page 470 E3100 Messages Command Rejected Messages E3147 Cmd Rej: Translation Type referenced in LNP database Commands Used: dlt-lnp-serv A translation type cannot be deleted if it is referenced by a current LNP database entry. Recovery 1. Display the GTT table. Enter the rtrv-gtt command. 2.
  • Page 471 Command Rejected Messages E3100 Messages Recovery 1. Enter the rtrv-ss-appl command to retrieve a list of all subsystem applications. 2. Use the dlt-ss-appl command to delete one of the existing subsystem applications listed in step 1. 3. Re-enter the ent-ss-appl command that generated this error message. E3150 Cmd Rej: Application already assigned Commands Used: ent-ss-appl You attempted to add a duplicate subsystem application.
  • Page 472 E3100 Messages Command Rejected Messages E3153 Cmd Rej: Subsystem must be inhibited before it can be OFFLINE Commands Used: chg-ss-appl This command changes the status of the LNP subsystem application between offline and online. You must inhibit the LNP subsystem before taking it offline. Recovery 1.
  • Page 473 Command Rejected Messages E3100 Messages E3172 Cmd Rej: Alias is not assigned to SERV Commands Used: dlt-lnp-serv The alias you entered must be associated with the LNP service you are trying to delete. Recovery 1. Display a list of the LNP services and their associated aliases. Enter the rtrv-lnp-serv command.
  • Page 474 E3100 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again. E3199 Cmd Rej: To change or delete SERV, it must have no LNP aliases Commands Used: dlt-lnp-serv, chg-lnp-serv You must delete all aliases associated with the LNP service before you can change or delete the service.
  • Page 475 Command Rejected Messages E3100 Messages E3210 Cmd Rej: CPCTYPE cannot be specified with NCPC Commands Used: chg-sid The cpctype and ncpc parameters cannot be specified together. If the cpctype parameter is specified, an ncpc, ncpca, ncpci, ncpcn, or ncpcn24 parameter cannot be specified in the command.
  • Page 476 E3100 Messages Command Rejected Messages Recovery 1. Display the necessary information about the current self-identification. Enter the rtrv-sid command. 2. Perform one of the following actions: • If the output of step 1 indicates that the cpctype=stp, re-enter the chg-sid command that generated this error message specifying the correct cpctype parameter value.
  • Page 477 Command Rejected Messages E3100 Messages Recovery Perform one of the following actions: • Re-enter the chg-lnp-serv command without specifying the ndv parameter. • Re-enter the chg-lnp-serv command specifying a different value for the ndv parameter. E3233 Cmd Rej: System serial number has not been locked Commands Used: enable-ctrl-feat The feature that you attempted to enable does not have the system serial number locked in the database.
  • Page 478 E3100 Messages Command Rejected Messages E3243 Cmd Rej: Unknown hardware configuration Commands Used: chg-feat, enable-crtl-feat Ensure that the system is configured at the proper hardware baseline. Recovery Re-enter the command. Call your Customer Care Center if this error message appears again. E3244 Cmd Rej: UIM number does not exist in UIM Threshold table Commands Used: dlt-uim-acthresh You specified an invalid UIM number.
  • Page 479 Command Rejected Messages E3100 Messages a. Verify that the PLNP feature is on. Enter the rtrv-feat command. If the PLNP feature is not on, you must turn it on. b. Turn on the PLNP feature. Enter the chg-feat:plnp=on command. c. Re-enter the ent-lnp-serv command specifying serv=pcs. Re-enter the chg-lnp-serv command specifying nserv=pcs.
  • Page 480 E3100 Messages Command Rejected Messages E3252 Cmd Rej: A TTN-reserved service type name only if it matches SERV Commands Used: chg-lnp-serv, ent-lnp-serv You specified the ttn parameter set to a reserved service type name that did not match the one assigned to the serv parameter. Recovery Perform one of the following actions: •...
  • Page 481 Command Rejected Messages E3100 Messages Table 2-19. Valid Parameter Combinations for an E3269 Error Message If you specify the h0 (nh0) You can specify the h1 (nh1) parameter as: parameter as: A single value A single value A single value A range A single value An asterisk (*) entry...
  • Page 482 E3100 Messages Command Rejected Messages Table 2-20. Valid Values for the nsfi Parameter Commands Valid Values stop chg-scr-aftpc, ent-scr-aftpc, rtrv-scr-aftpc cgpa, stop, fail, or destfld chg-scr-blkdpc, ent-scr-blkdpc stop, fail, dpc, blkdpc, sio, or cgpa chg-scr-blkopc, ent-scr-blkopc stop or aftpc chg-scr-cdpa, ent-scr-cdpa, rtrv-scr-cdpa stop, cdpa, or tt...
  • Page 483 Command Rejected Messages E3100 Messages E3272 Cmd Rej: PC does not match existing entry in given SR Commands Used: chg-scr-blkdpc, chg-scr-blkopc, chg-scr-destfld, chg-scr-dpc, chg-scr-opc, dlt-scr-blkdpc, dlt-scr-blkopc, dlt-scr-destfld, dlt-scr-dpc, dlt-scr-opc, ent-scr-blkdpc, ent-scr-blkopc, ent-scr-dpc The values specified for the area, id, msa, narea, nc, ncm, ni, nid, nnpc, npc, nsp, nssa, nzone, sp, ssa, or zone point code parameters do not match the existing entry specified by the screening reference (sr) parameter.
  • Page 484 E3100 Messages Command Rejected Messages Recovery Wait until the system has completed the upgrade that is in progress; then re-enter the command. E3278 Cmd Rej: RMIN must be less than or equal to RMAX Commands Used: chg-assoc In the command that you entered, the specified rmin parameter value was greater than the specified rmax value.
  • Page 485 Command Rejected Messages E3100 Messages You entered an ent-slk command to add an IPLIMx M3UA signaling link to a linkset, and the linkset has the mtprse parameter value set to yes. IPLIMx M3UA links must be in a linkset with mtprse=no; they do not support MTP Restart procedures.
  • Page 486 E3100 Messages Command Rejected Messages Recovery 1. If the signaling link is not an IPLIMx signaling link, re-enter the ent-slk command without specifying the ipliml2 parameter. 2. If the signaling link is an IPLIMx signaling link, re-enter the ent-slk command specifying the ipliml2 parameter. E3282 Cmd Rej: All links in linkset must have same IPLIML2 setting Commands Used: ent-slk To add an IPLIMx M3UA signaling link to a linkset, you must specify...
  • Page 487 STP true point code exists in the mated applications (MAP) table. Recovery 1. View a list of (pc/pca/pci/pcn) point codes assigned to the EAGLE 5 ISS. Enter the rtrv-sid command. 2. Assign mated application values to the true point code (pc/pca/pci/pcn) and subsystem number (ssn).
  • Page 488 Mated Applications (MAP) table. Recovery 1. View the point codes (pca) assigned to the EAGLE 5 ISS. Enter the rtrv-sid command. 2. Assign mated application values for the true point code (pc/pca) and subsystem number (ssn).
  • Page 489 Command Rejected Messages E3100 Messages Call your Customer Care Center if this error message appears again. E3290 Cmd Rej: True PC already exists in MAP table Commands Used: ent-map You attempted to enter this command specifying an invalid parameter. Recovery Re-enter the ent-map command that generated this error message specifying the correct parameter.
  • Page 490 E3100 Messages Command Rejected Messages E3293 Cmd Rej: Invalid offset Commands Used: disp-tbl, set-lba, set-tbl The value specified for the offset parameter was not valid. Recovery Re-enter the command specifying the correct offset parameter value. Call your Customer Care Center if this error message appears again. E3294 Cmd Rej: Security tables may not be altered Commands Used: disp-tbl, set-lba, set-tbl The table specified by the tblid parameter is either the Security Log, User ID, or...
  • Page 491 Command Rejected Messages E3100 Messages Recovery Call your Customer Care Center. E3297 Cmd Rej: Failed reading trouble text table Commands Used: set-uim-acthresh The system Trouble Text Table must be accessible for the command to execute. A failure occurred in reading the table. Recovery Re-enter the set-uim-acthresh command.
  • Page 492 E3300 Messages Command Rejected Messages 2. Verify that the Network Security Enhancements feature has been purchased and installed in your system. Contact your Customer Care Center for assistance. 3. Enable the Network Security Enhancements feature. Enter the enable-ctrl-feat command specifying the appropriate part number and access key information.
  • Page 493 Command Rejected Messages E3300 Messages Recovery Re-enter the command specifying a valid value and format for this command parameter. Refer to the Commands Manual for the format and valid values for this command parameter. Call your Customer Care Center if this error message appears again. E3302 Cmd Rej: Data missing for <parm>...
  • Page 494 E3300 Messages Command Rejected Messages E3304 Cmd Rej: Unexpected character(s) <data> after <parm> (C<col>) Commands Used: all OAP commands The command you entered contains unexpected characters (<data>) for the specified parameter (<parm>). (C<col>) indicates the column number of the last character of the data that generated the error message.
  • Page 495 Command Rejected Messages E3300 Messages Recovery Re-enter the command specifying an in-range value and proper format for this command parameter. Refer to the Commands Manual for the format and valid values for this command parameter. Call your Customer Care Center if this error message appears again. E3307 Cmd Rej: Too many parameters specified for <parm>...
  • Page 496 E3300 Messages Command Rejected Messages E3309 Cmd Rej: Rejection threshold argument - not valid (C<col>) Commands Used: all OAP commands The command you entered contains an invalid rejection threshold argument. (C<col>) indicates the column number of the last character of the data that generated this error message.
  • Page 497 Command Rejected Messages E3300 Messages Recovery Re-enter the command specifying the correct syntax and format for this command parameter. Refer to the Commands Manual for the correct values and format for this command parameter. Call your Customer Care Center if this error message appears again. E3312 Cmd Rej: Occurrence argument - not valid (C<col>) Commands Used: all OAP commands The command you entered contains an invalid occurrence argument.
  • Page 498 E3300 Messages Command Rejected Messages E3314 Cmd Rej: <command> command not supported by this implementation (C<col>) Commands Used: all OAP commands The command you entered <command> is invalid because it is not supported by the current implementation. (C<col>) indicates the column number of the last character of the data that generated this error message.
  • Page 499 Command Rejected Messages E3300 Messages Recovery Re-enter the command specifying the correct syntax and format for this command parameter. Refer to the Commands Manual for the correct values and format for this command parameter. Call your Customer Care Center if this error message appears again. E3317 Cmd Rej: Input parameter argument - range error (C<col>) Commands Used: all OAP commands The command you entered contains an unacceptable input parameter argument,...
  • Page 500 E3300 Messages Command Rejected Messages E3319 Cmd Rej: Input parameter argument - point code range error (C<col>) Commands Used: all OAP commands The command you entered contains an invalid input parameter argument caused by a point code range error. (C<col>) indicates the column number of the last character of the data that generated this error message.
  • Page 501 Command Rejected Messages E3300 Messages Recovery Re-enter the command specifying the correct syntax and format for this command parameter. Refer to the Commands Manual for the correct values and format for this command parameter, specifically for the sequence-number parameter. Call your Customer Care Center if this error message appears again. E3322 Cmd Rej: Input parameter ‘<parm>’...
  • Page 502 E3300 Messages Command Rejected Messages E3324 Cmd Rej: Input parameter - use of parameter not supported by this implementation (C<col>) Commands Used: all OAP commands The command you entered is erroneous because the use of an input parameter is not supported by this implementation. (C<col>) indicates the column number of the last character of the data that generated this error message.
  • Page 503 E3327 Cmd Rej: Eagle can only accept messages of 450 or fewer bytes (C<col>) Commands Used: all OAP commands A system software error has occurred: the EAGLE 5 ISS has received a message longer than 450 bytes. (C<col>) indicates the column number of the last character of the data that generated this error message.
  • Page 504 E3400 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3332 Cmd Rej: GTA, CGPC, OPC and CGSSN are mutually exclusive Commands Used: chg-gta, dlt-gta, ent-gta, rtrv-gta The cgpc, cgssn, gta and opc parameters are mutually exclusive. Each of these parameters must be specified individually in separate commands.
  • Page 505 Command Rejected Messages E3400 Messages Recovery 1. Display the card’s configuration, using the rtrv-card command specifying the card location (loc). The card’s application is shown in the APPL field of the output. 2. If the card’s application is atmansi or atmitu, re-enter the command specifying the port/link=a parameter.
  • Page 506 E3400 Messages Command Rejected Messages 2. If the card in the specified location is a low-speed card, not a atmitu or limatm card, re-enter the ent-slk command specifying the parameters for low-speed signaling links: ecm, l1mode, l2set, pcrn1, pcrn2, and tset 3.

  • Page 507: Table 2-21. Possible Low-Speed And High-Speed Link

    Command Rejected Messages E3400 Messages If the addition of either a low-speed signaling link or an ATM or E1 ATM high-speed signaling link exceeds the total number of low-speed and high-speed signaling links allowed in the system, the ent-slk command is rejected. The addition of an ATM or E1 ATM high-speed signaling link decreases the number of low-speed signaling links that can be supported by the system.
  • Page 508 E3400 Messages Command Rejected Messages 2. Use Table 2-21 on page 2-493 to determine the number of low-speed links that the system allows, based on the number of ATM and/or E1 ATM high-speed links the system contains. 3. If you need to add a link to the system and the system already contains the maximum number of allowed links, you must first delete an existing link (use the dlt-slk command) and then add the new link to the system.
  • Page 509 Command Rejected Messages E3400 Messages E3412 Cmd Rej: SRCLPSET and LPSET cannot be equal Commands Used: chg-atm-lps You entered this command specifying the same parameter value for both srclpset, and lpset for an action=copy. The srclpset parameter provides the value of the source parameter set to be copied.
  • Page 510 E3400 Messages Command Rejected Messages E3415 Cmd Rej: LOC and CLASS cannot be specified together Commands Used: rtrv-slk The loc and class parameters cannot be specified together in the same command. The loc parameter provides information about a single card at a certain location. The class parameter provides information about the class of either low-speed or ATM high-speed signaling links, as specified.

  • Page 511: Table 2-22. Valid Transmission Rates For The Bps Parameter

    Command Rejected Messages E3400 Messages Recovery 1. Display the card’s configuration. Enter the rtrv-card command specifying the card location (loc). The card’s type is shown in the TYPE field of the output. 2. If the card in the specified location is a low-speed card, not an limatm or lime1atm card, re-enter the ent-slk command specifying a bps rate of either 4800, 9600, 19200, 56000, 64000.

  • Page 512: Table 2-23. Routesets Feature With Maximum Values For The Mtpdpcq And Mtpxlq Parameters

    E3400 Messages Command Rejected Messages E3421 Cmd Rej: DSTN5000 feature must be enabled Commands Used: chg-stpopts, enable-ctrl-feat You attempted to turn on a Routesets Feature without the 5000 Routesets Feature first being turned on. The 5000 Routesets Feature must be turned on before you can turn on the 6000, 7000 or 8000 Routesets Feature.
  • Page 513 Command Rejected Messages E3400 Messages Recovery - Enter mtpdpcq or mtpxlq parameter 1. Verify the number of mtpdpcq and mtpxlq entries currently allocated. Enter the rtrv-stpopts command. 2. Re-enter the command specifying a value for the mtpdpcq and mtpxlq parameters that does not exceed the command requirements. E3422 Cmd Rej: Echo capability not applicable on originating terminal Commands Used: act-echo, canc-echo You entered your own terminal ID number for the trm parameter value.
  • Page 514 E3400 Messages Command Rejected Messages Refer to the Commands Manual for additional information regarding the command format, parameters, and syntax. E3425 Cmd Rej: Invalid parameter for SS7ANSI, ATMANSI, IPLIM, or SS7IPGW Commands Used: ent-trace You entered a parameter that is invalid for an ANSI SS7 card running the ss7ansi, atmansi, iplim, or ss7ipgw GPL.
  • Page 515 Command Rejected Messages E3400 Messages Recovery Re-enter the ent-trace command specifying the correct format and parameters. Refer to the Commands Manual for additional information regarding the command format, parameters, and syntax. E3428 Cmd Rej: Invalid parameter for CCS7ITU or IPLIMI Commands Used: ent-trace The following parameters are invalid for ITU SS7 cards running the ccs7itu or iplimi GPLs: gt, entityid, dn, imei, imsi, lrn, tn, and tlnpisuptype.
  • Page 516 E3400 Messages Command Rejected Messages Recovery 1. Turn on the SCCPCNV feature. Enter the chg-feat:sccpcnv=on command. 2. Turn on the TCAPCNV feature. Enter the chg-feat:tcapcnv=on command Call your Customer Care Center if this error appears again. E3433 Cmd Rej: DPC parameter must be specified Commands Used: inh-alm, unhb-alm You must specify the dpc parameter value if the dev=route parameter is specified.
  • Page 517 Command Rejected Messages E3400 Messages Recovery 1. Enter the rept-stat-trbl command to identify the critical alarms that have been inhibited. The letter I after the message reference number (MRN) indicates that the alarm has been inhibited. Critical alarms are identified by *C.
  • Page 518 E3400 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error appears again. E3438 Cmd Rej: Lvl 1 Removable detected during upgrade Commands Used: act-upgrade The removable cartridge required for the upgrade has upgrade phase indicators. The upgrade command expects the disks to be in certain phases before executing a specific action.
  • Page 519 Command Rejected Messages E3400 Messages E3440 Cmd Rej: Active TDM in unknown upgrade mode Commands Used: act-upgrade The TDMs have upgrade phase indicators. The upgrade command expects the disks to be in certain phases before executing a specific action. This message appeared because the active TDM is not in the correct phase.
  • Page 520 E3400 Messages Command Rejected Messages E3443 Cmd Rej: THRES parameter valid only with CONVERTNET/CONVERTSTP Commands Used: act-upgrade You cannot specify the thres parameter without specifying the convertnet or convertstp parameters. Recovery Perform one of the following actions: • Re-enter the act-upgrade command without specifying the thres parameter.
  • Page 521 Command Rejected Messages E3400 Messages E3445 Cmd Rej: Connection not compatible with SLK IPLIML2 setting Commands Used: chg-appl-sock, ent-appl-sock, chg-assoc, ent-assoc You specified the lhost parameter for a local host on an IPLIMx card. The local host connection is not valid for the setting of the ipliml2 parameter for the signaling link assigned to the specified local host connection.
  • Page 522 E3400 Messages Command Rejected Messages 2. Enter the rtrv-ip-lnk command to display the card location for the new local host IP address. 3. Enter the rtrv-slk command for the card location to display the linksets containing links assigned to the signaling link ports for the card. 4.
  • Page 523 Command Rejected Messages E3400 Messages E3448 Cmd Rej: LHOST has open socket or association Commands Used: chg-ip-lnk, dlt-slk You entered a command to change the local host IP address. The local IP address cannot be changed if the current or new local host has open sockets or associations (the open parameter set to yes using the ent-assoc or chg-assoc command).
  • Page 524 Telnet terminal, that is, a terminal (trm) set to value greater than 16. The command you entered requires the ISUP Normalization feature to be enabled and possibly a feature for a Tekelec-defined or user-defined ISUP Normalization Variant to be enabled. 2-510...
  • Page 525 Command Rejected Messages E3400 Messages Recovery - chg-ctrl-feat Display the status of the features in your system that have feature access keys. Enter the rtrv-ctrl-feat command. • If the feature is enabled, re-enter chg-ctrl-feat command specifying the appropriate part number to change the on/off status. •...
  • Page 526 E3400 Messages Command Rejected Messages Refer to the ISUP Variant procedures in the Database Administration Manual - Secure Gateway Manual and the Commands Manual to enable each required feature. 2. When the feature is enabled, re-enter the command. E3452 Cmd Rej: Invalid Feature Access Key Commands Used: enable-ctrl-feat The fak parameter value that you entered has one of the following conditions: •...

  • Page 527: For The Mtpdpcq And Mtpxlq Parameters

    Command Rejected Messages E3400 Messages Recovery 1. Display the system serial number that is in the database. Enter the rtrv-serial-num command. 2. Re-enter the enable-ctrl-feat command specifying the correct serial number. Follow the naming conventions listed above. Call your Customer Care Center if this error appears again. E3454 Cmd Rej: Routesets Feature Quantity must be increased Commands Used: chg-stpopts The number of routes being set beyond 5000 is more than the Feature Quantity...
  • Page 528 E3400 Messages Command Rejected Messages Recovery 1. Display the status of features in your system that have feature access keys. Enter the rtrv-ctrl-feat command. 2. Verify that the correct Routesets feature has been purchased and installed in your system. Contact your Customer Care Center if you need assistance. 3.
  • Page 529 Command Rejected Messages E3400 Messages NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off. Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled. Refer to the Database Administration Manual-System Management and to the Commands Manual for details about turning on features with bits and enabling features with access keys.
  • Page 530 E3400 Messages Command Rejected Messages Features that are Permanently On include all controlled features with quantity feature access keys (like LNP ported TNs), and the following: • 15 Minute Measurements • ANSI/ITU/China SCCP Conversion • Enhanced GSM MAP Screening (EGMS) •...
  • Page 531 Command Rejected Messages E3400 Messages Call your Customer Care Center if this error message appears again. E3459 Cmd Rej: LNP ported TNs 6million Qty Feat Require at least TSM768MB Commands Used: enable-ctrl-feat You cannot enable the LNP Ported TNs 6 Million Quantity Key Feature. Not all TSM cards have at least 768 MB of memory.
  • Page 532 E3400 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3462 Cmd Rej: LNP ported TNs 24million Qty Feat Require at least DSM2GB Commands Used: enable-ctrl-feat You cannot enable the LNP Ported TNs 24 Million Quantity Key Feature. Not all DSM cards have at least 2 GB of memory.
  • Page 533 Command Rejected Messages E3400 Messages Call your Customer Care Center if this error message appears again. E3465 Cmd Rej: STPOPTS HMUXTVG must be turned on for this feature Commands Used: chg-ctrl-feat You entered the command to enable the 6000 Routesets controlled feature. However, this command cannot be executed due to a possible error in the STP Options table.
  • Page 534 E3467 Cmd Rej: FTP SERV table must contain one entry with application USER Commands Used: act-ftp-trns You entered a command to activate an FTP transfer on the EAGLE 5 ISS, but the FTP Server table does not have an entry specifying the application USER.
  • Page 535 Command Rejected Messages E3400 Messages E3470 Cmd Rej: SRCTSET and TSET cannot be equal Commands Used: chg-m2pa-tset You cannot specify the same parameter value for both srctset and tset. The srctset parameter indicates which timer set is to be copied into the timer set specified by the tset parameter.
  • Page 536 E3400 Messages Command Rejected Messages Recovery 1. Enter the rtrv-ctrl-feat command to display the status of features in your system that have feature access keys. 2. Verify that the MO SMS (Portability Check for Mobile Originated SMS) feature has been purchased and installed in your system. Contact your Customer Care Center if you need assistance.
  • Page 537 Command Rejected Messages E3400 Messages Recovery Perform one of the following actions: • Verify that the HOME SMSC address was entered correctly, and re-enter the dlt-home-smsc command. • Verify the HOME SMSC address does not exist. Enter the rtrv-home-smsc command specifying the smsc parameter. E3477 Cmd Rej: SMSC Address already exists Commands Used: ent-home-smsc The specified HOME SMSC address entry already exists in the HOME...
  • Page 538 E3400 Messages Command Rejected Messages 2. Delete an existing entry from the HOME SMSCADDR table. Enter the dlt-home-smsc command. 3. Add the address entry into the HOME SMSCADDR table. Re-enter the ent-home-smsc command. E3479 Cmd Rej: MO SMS feature must be enabled Commands Used: dlt-home-smsc, ent-home-smsc, rtrv-home-smsc You entered a command involving Home SMSC specific addresses, which identify Short Message Service Centers.
  • Page 539 • For an E5-E1T1 card, you can provision links A...A15 and B...B15. 3. To provision additional signaling links beyond the quantity feature installed, contact your local Tekelec Sales Representative for assistance with purchasing another SE-HSL SLK quantity feature. 910-3638-001 Revision B, October 2006...
  • Page 540 E3400 Messages Command Rejected Messages E3483 Cmd Rej: CAS=ON is not supported on this card Commands Used: ent-e1, chg-e1 You cannot specify the cas=on parameter for the HC-MIM or the E5-E1T1 cards. You cannot specify the cas=on parameter when chanbrdg=on has been specified. You cannot specify the cas=on parameter for port values 3 through 8.
  • Page 541 Command Rejected Messages E3400 Messages Recovery 1. Display the cards in the system. Enter ther rtrv-card command. 2. Based on the ouput of step 1, if low capacity MIM card is present, perform one of the following actions: • remove the card and continue with provisioning. •...
  • Page 542 E3400 Messages Command Rejected Messages Refer to the Commands Manual for the valid combination of parameters specific to the command that generated this error message. E3488 CMD Rej: RECOVERED is allowed only in channel bridging mode Commands Used: chg-e1, chg-t1, ent-e1, ent-t1 The recovered option is only valid for a port that is in channel bridging (chanbrdg=on) mode.
  • Page 543 Command Rejected Messages E3400 Messages HIPR cards must be in card locations xy09 and xy10 (x is the frame, y is the shelf): • On any shelf that contains one or more HC-MIM or E5-E1T1 cards. When link parameter values a4-a31 and b4-b31 are specified, the system verifies that HIPR cards are in card locations xy09 and xy10 on the same shelf with the specified HC-MIM card.
  • Page 544 E3400 Messages Command Rejected Messages Recovery Re-enter the command specifying a channel bridged master E1/T1 port instead. E3492 Cmd Rej: ADD/DROP mode provisioned FORCE=YES required Commands Used: inh-card If channel bridging (Add/Drop mode) is active then force=yes is required to inhibit the card.
  • Page 545 Command Rejected Messages E3400 Messages — Enter the command chg-gsmopts:multcc=xxx:nmultcc=yyy, which replaces the value xxx with value yyy in the GSM Options MULTCC list. For more information about the Default Country Codes and Multiple Country Codes, refer to the Commands Manual. E3494 Cmd Rej: Link is invalid for card location Commands Used: dact-slk, dlt-slk, ent-slk, rtrv-slk You cannot provision a links a4, b4, …, a31, b31 and specify an even-numbered...
  • Page 546 E3400 Messages Command Rejected Messages The chanbrdg=on parameter indicates whether an odd-numbered port is to pair with its even-numbered port for non-signaling data pass through. Recovery Re-enter the command specifying even-numbered (n+1) card location. Refer to the Commands Manual for the valid combination of parameters specific to the command that generated this error message.
  • Page 547 Command Rejected Messages E3500 Messages Recovery 1. Display the GTT Selector table. Enter the rtrv-gttsel command. 2. Re-enter the ent-gttsel command specifying values for the above parameters that are not in the database. E3499 Cmd Rej: GTT Selector does not exist in GTIN24-TT-NP(V)-NAI(V) Commands Used: chg-gttsel, dlt-gttsel You specified an entry that does not match an existing gtin24, tt, np/nai, and npv/naiv parameter combination as required.
  • Page 548 • The rn parameter of an ent-homern or dlt-homern command. • The none value is not allowed for GSM MAP SRI Redirect feature prefix values. The EAGLE 5 ISS does not allow this action. 2-534 910-3638-001 Revision B, October 2006...
  • Page 549 Command Rejected Messages E3500 Messages Recovery Re-enter the command specifying a valid parameter value. E3505 Cmd Rej: Prepaid SMS Intercept Ph1 feature must be ON Commands Used: chg-gsmopts, chg-srvsel, ent-srvsel You must enable and turn on the Prepaid Short Message Service Intercept (PPSMS) Phase 1 feature before using the specified command and parameters.
  • Page 550 E3500 Messages Command Rejected Messages Recovery 1. Determine if the translation type that you want to use already exists in the translation type table. Enter the rtrv-tt command. 2. Re-enter the ent-tt command specifying a different translation type. E3511 Cmd Rej: CCNC and MCCMNC parameters must be entered together Commands Used: chg-gsmopts If you specify one of the following parameters, you must specify the other as well: ccnc and mccmnc.
  • Page 551 Command Rejected Messages E3500 Messages To add a new ccnc/mccmnc parameter combination, enter the chg-gsmopts:ccnc=xx:mccmnc=yy command where xx (the value of the ccnc parameter) and yy (the value of the mccmnc parameter) specify the ccnc/mccmnc parameter combination to add. To delete an existing ccnc/mccmnc parameter combination, enter the chg-gsmopts:ccnc=xx:mccmnc=none command where xx (the value of the ccnc parameter) specifies the ccnc/mccmnc parameter combination to delete.
  • Page 552 E3500 Messages Command Rejected Messages E3518 Cmd Rej: Active OAM must be equipped with E586 hardware You attempted to bring INP online, but your active Operations, Administration, and Maintenance (OAM) module is not equal to the task. You need to upgrade the hardware.
  • Page 553 Command Rejected Messages E3500 Messages Recovery Perform one of the following actions: • Delete an entry from the Service Selector table. Enter the dlt-srvsel command. • Change an entry in the Service Selector table. Enter the chg-srvsel command. E3523 Cmd Rej: At least one parameter must be changed(NSNP, NSNAI, NSERV) Commands Used: chg-srvsel You must specifying at least one of the following parameters: nsnp, nsnai, or nserv.
  • Page 554 E3500 Messages Command Rejected Messages Table 2-26. Conditions that Generate an E3524 Error Message Commands Condition To specify these commands, the INP feature must be chg-inpopts, turned on. dlt-homern, ent-homern, rtrv-homern, rtrv-inpopts To specify the cpctype=inp parameter, the INP chg-sid, rtrv-sid feature must be turned on.
  • Page 555 Command Rejected Messages E3500 Messages CAUTION: Creating a system clock outage will probably result in the loss of traffic on all links. The following scenarios will result in system clock outages. Trying to initialize both MASPs at one time by specifying param appl=oam. Performing a simplex MASP configuration (that is, a system with a one TDM).
  • Page 556 E3500 Messages Command Rejected Messages Recovery 1. Display the multcc parameter values currently in the MULTCC list. Enter the rtrv-gsmopts command. 2. Re-enter the chg-gsmopts command specifying a value for the nmultcc parameter that does not appear as a multcc value in the output from step 1. E3534 Cmd Rej: E1 Port test command in progress Commands Used: tst-e1 A port test is in progress on this e1port.
  • Page 557 Command Rejected Messages E3500 Messages 2. Define a correct IP address for the card. Enter the chg-ip-card command. 3. Verify that the port and ipaddr parameters in the chg-ip-lnk command specify unique addresses for ports A and B. 4. Re-enter the chg-ip-lnk command specifying the correct parameters. Call your Customer Care Center if this error message appears again.
  • Page 558 E3500 Messages Command Rejected Messages E3542 Cmd Rej: Failed reading GSM SSN Table Commands Used: dlt-gsm-ssn, ent-gsm-ssn, rtrv-gsm-sasn The GSM SSN table is corrupt or cannot be found by the system. Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again.
  • Page 559 Command Rejected Messages E3500 Messages E3545 Cmd Rej: Failed reading SERV Selector Table Commands Used: chg-srvsel, dlt-srvsel, ent-srvsel, rtrv-srvsel The Service Selector table is corrupt or cannot be found by the system. Recovery Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again.
  • Page 560 E3500 Messages Command Rejected Messages Recovery Contact your Customer Care Center if you need to change the serial number. E3550 Cmd Rej: GTT must be on before EGTT can be on Commands Used: chg-feat You cannot turn on the Enhanced Global Title Translation (EGTT) feature because the Global Title Translation (GTT) feature is turned off.
  • Page 561 Command Rejected Messages E3500 Messages Recovery Re-enter the command specifying either the np or the npv parameter, but not both. E3552 Cmd Rej: NAI and NAIV must not be specified together Commands Used: chg-gttsel, chg-srvsel, dlt-gttsel, dlt-srvsel, ent-gttsel, ent-srvsel, rtrv-gttsel, rtrv-srvsel You cannot specify both the nai and naiv parameters together.
  • Page 562 E3500 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the command specifying gtii/gtin/gtin24=4 and specify either the np/nai or the npv/naiv parameter combinations. • Re-enter the command specifying gtii/gtin/gtin24=2 without specifying the np/nai or the npv/naiv parameter combinations. E3555 Cmd Rej: NP(V) and NAI(V) must be specified for given GTI value Commands Used: chg-gttsel, chg-srvsel, dlt-gttsel, dlt-srvsel, ent-gttsel, ent-srvsel...
  • Page 563 Command Rejected Messages E3500 Messages Recovery 1. Display the features in the database. Enter the rtrv-feat command. 2. If the EGTT feature is off (from the output of step 1), re-enter the command. Call your Customer Care Center if this error message appears again. 3.
  • Page 564 E3500 Messages Command Rejected Messages E3558 Cmd Rej: CdPA GTT Selector already exists in GTI-TT-NP(V)-NAI(V) Commands Used: ent-gttsel The specified CdPA GTT selector was not entered because an entry that matches the values specified for the gti, tt, and np/nai or npv/naiv parameter combination, already exists in the GTT Selector table.
  • Page 565 Command Rejected Messages E3500 Messages Recovery 1. Display the existing GTT set entries. Enter the rtrv-gttset command. In the output, the existing GTT sets are listed in the GTTSN column. 2. Re-enter the ent-gttset command specifying a value for the gttsn parameter that does not already exist.
  • Page 566 E3500 Messages Command Rejected Messages E3563 Cmd Rej: NAI entries per TT-NP combination has reached allowed max Commands Used: chg-gttsel, ent-gttsel The specified Nature of Address Indicator (NAI) could not be entered into the GTT Selector table because no more than 5 NAI entries per Translation Type-Numbering Plan (TT-NP) combination are allowed.
  • Page 567 Command Rejected Messages E3500 Messages Recovery Re-enter the command specifying a valid value for the GTT Set. E3566 Cmd Rej: GTT Set specified by GTTSN has GTT Selectors assigned to it Commands Used: dlt-gttset You cannot delete a GTT set that has GTT selectors assigned to it. The value specified for the GTT set name (gttsn) parameter is being used by one or more GTT selectors.
  • Page 568 E3500 Messages Command Rejected Messages E3568 Cmd Rej: NTT can only be specified when XLAT=DPCNGT Commands Used: chg-gta, ent-gta You cannot specify the ntt parameter without specifying the translate indicator xlat=dpcngt parmeter. If the ntt parameter is specified, the xlat=dpcngt parameter must be specified.
  • Page 569 Command Rejected Messages E3500 Messages NOTE: If the ANSI-ITU-China SCCP Conversion feature is enabled, this error code will not be generated. Recovery 1. Determine the network domain of the GTT set. Enter the rtrv-gttset command. The network domain is listed in the NETDOM column of the output.
  • Page 570 E3500 Messages Command Rejected Messages E3572 Cmd Rej: RI must be SSN when CCGT is YES Commands Used: chg-gta, ent-gta You specified the ccgt=yes parameter, but you did not specify ri=ssn parameter as required. For the chg-gta command, this applies to new or existing values for these parameters.
  • Page 571 Command Rejected Messages E3500 Messages E3575 Cmd Rej: The sum of the values for NPCFMTI must be equal to 14 Commands Used: chg-stpopts The sum of all the values specified by the npcfmti parameter (m1+m2+m3+m4) must equal 14. If the ITU national point code format has less than four numbers, the parts of the point code format not being used must be specified as 0.
  • Page 572 E3500 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the command specifying ri=gt or ri=ssn, and ccgt=no. • Re-enter the command specifying ri=ssn and ccgt=yes. E3578 Cmd Rej: NP and NAI must be specified as DFLT together Commands Used: chg-gttsel, dlt-gttsel, rtrv-gttsel The np and nai parameters must both be specified as dflt and both must be specified together (np=dflt:nai=dflt).
  • Page 573 Command Rejected Messages E3500 Messages E3581 Cmd Rej: SSN value must be the LNP, INP or EIR SSN Commands Used: alw-map-ss, inh-map-ss You specified a subsystem (ssn) parameter that does not represent the LNPQS, INPQS, or EIR subsystem. The specified ssn parameter value must represent the LNPQS, INPQS, or EIR subsystem.
  • Page 574 E3500 Messages Command Rejected Messages E3584 Cmd Rej: Feature configuration requires DSM card with VSCCP appl Commands Used: ent-card The following features require a DSM card(s) running the vsccp application: • Enhanced GSM MAP Screening (EGMS) = E3899 • Equipment Identity Register (EIR) •...
  • Page 575 Command Rejected Messages E3500 Messages Recovery Re-enter the command specifying a valid destination IP address as per the conditions listed above. E3586 Cmd Rej: Dest IP Address already exists for this card Commands Used: ent-ip-rte The specified destination IP address (dest) parameter already exists for the card in the location specified by the loc parameter.
  • Page 576 E3500 Messages Command Rejected Messages Recovery To delete a static IP route entry for the specified card, 1. Display the existing destination IP addresses for the card. Enter the rtrv-ip-rte command specifying the loc parameter. 2. Re-enter the dlt-ip-rte command specifying a valid destination IP address for the entry you want to delete for the specified card.
  • Page 577 Command Rejected Messages E3500 Messages Recovery 1. To continue to use the feature, you must purchase the feature from Tekelec. Contact your Customer Care Center. 2. When you have purchased the feature and obtained a permanent feature access key, re-enter the enable-ctrl-feat command to enable the feature.

  • Page 578: Table 2-27. On/Off Features And Part Numbers

    E3500 Messages Command Rejected Messages Recovery If you need to change the serial number, contact your Customer Care Center. E3593 Cmd Rej: Part Number does not belong to an On/Off Feature Commands Used: chg-ctrl-feat You entered a part number associated with a quantity feature entry. The On/Off status of a feature associated with quantity cannot be changed by this command.
  • Page 579 Command Rejected Messages E3500 Messages Table 2-27. On/OFF Features and Part Numbers (Continued) Feature Part Number JAPAN Normalization 893002901 KOREA Normalization 893003001 LNP Short Message Service (LNP SMS) 893006601 MALAYSIA Normalization 893001601 MEXICO Normalization 893002201 MTP Map Screening 893013501 NETHERLANDS Normalization 893001001 Network Security Enhancement 893009101...
  • Page 580 E3500 Messages Command Rejected Messages Recovery 1. Display the local A and B network IP addresses and the current defrouter IP address for this card. Enter the rtrv-ip-card command specifying the loc parameter for this card. 2. Re-enter the chg-ip-card command specifying a defrouter IP address that is local to the A or B network for this card.
  • Page 581 Command Rejected Messages E3500 Messages 2. Display the current ipaddr and submask addresses. Enter the rtrv-ip-lnk command. 3. Re-enter the chg-ip-lnk command specifying ipaddr and submask values that are on this network. E3598 Cmd Rej: LNP ELAP Configuration and WNP features must be ON Commands Used: enable-ctrl-feat You entered a command to enable the LNP SMS feature.
  • Page 582 E3600 Messages Command Rejected Messages Recovery 1. Display those features in the system that are controlled with feature access keys. Enter the rtrv-ctrl-feat command. 2. Verify that the LNP SMS feature has been purchased and installed in your system. Contact your Customer Care Center for assistance. 3.
  • Page 583 Command Rejected Messages E3600 Messages Recovery Wait for all tests to complete, then re-enter the tst-t1 command. E3616 Cmd Rej: APC/SAPC type and group code must match DPC Commands Used: chg-rte, ent-rte, chg-rtx, ent-rtx The route destination type and group codes that you specified do not match the route’s linkset Adjacent / Secondary Adjacent Point Code type and group codes.
  • Page 584 Commands Used: chg-netopts You entered a command to change the Private Virtual Network (PVN) IP address and the PVN subnet mask in the system. The EAGLE 5 Integrated Monitoring Support featurecopy function must be turned off before you can change the PVN and PVN submask addresses in the system.
  • Page 585 E3630 Cmd Rej: Entry is already defined as the STP Options DefCC Commands Used: chg-gsmopts You entered a value for the multcc or nmultcc parameter that already defined as the STP Options Default Country Code (defcc). The EAGLE 5 ISS does not support duplicate use of these entries. Recovery 1.
  • Page 586 E3600 Messages Command Rejected Messages E3634 Cmd Rej: Cannot set DefCC to none if a GSM Options MULTCC is defined Commands Used: chg-stpopts You cannot specify a Default Country Code of none (defcc=none) if a GSM Options MULTCC entry is already defined. Recovery If a GSM Options MULTCC is already defined, specifying defcc=none is invalid.
  • Page 587 Call your Customer Care Center if this error message appears again. E3641 Cmd Rej: Specified OAP not available Commands Used: act-oap-config For the act-oap-config command to execute, the link from the EAGLE 5 ISS to the specified OAP(s) must be in service. Recovery 1.
  • Page 588 Commands Used: act-oap-config You specified the oap=a, oap=b, or oap=all parameter with the act-oap-config command. For the command to execute, the specified OAP(s) must be configured, and the link from the EAGLE 5 ISS to the OAP(s) must be in service. Recovery 1.
  • Page 589 Command Rejected Messages E3600 Messages Call your Customer Care Center if this error message appears again. E3646 Cmd Rej: GWS must be ON before CNCF can be ON Commands Used: chg-feat The Gateway Screening (GWS) feature must be turned on before you can turn on the CNCF feature.
  • Page 590 E3600 Messages Command Rejected Messages 4. Re-enter the ent-lnp-serv command specifying serv=wnp. 5. Re-enter the chg-lnp-serv command specifying nserv=wnp. E3648 Cmd Rej: XLAT must be DPCSSN and RI must be SSN if PC is the True PC Commands Used: chg-gta, ent-gta If the value of the pc/pca/pci/pcn/pcn24 parameter is the STP’s true point code, you must specify dpcssn for the new or existing xlat parameter and ssn for the new or existing ri parameter.
  • Page 591 Command Rejected Messages E3600 Messages Recovery 1. Enter the rtrv-gws-actset command. The ACT NAME field in the output shows a list of valid action names. 2. If the value you entered appears in the output, call your Customer Care Center. 3.

  • Page 592: Table 2-28. Tsm And Tdm Memory Requirements

    E3600 Messages Command Rejected Messages Recovery Call your Customer Care Center if this error message appears again. E3663 Cmd Rej: Failed accessing the memory equipage table Commands Used: chg-db The Memory Equipage table is corrupt or cannot be found by the system. Recovery Re-enter the chg-db command that generated this error message.
  • Page 593 Command Rejected Messages E3600 Messages E3668 Cmd Rej: No other optional parameters may be specified with “ALL” Commands Used: chg-gws-actset You entered this command specifying all=none specified and with values for other optional parameters. If all=none is specified, you cannot specify other optional parameters.
  • Page 594 E3600 Messages Command Rejected Messages Recovery Re-enter the chg-gws-actset command without specifying identical values for more than one stop action within a stop action set. Call your Customer Care Center if this error message appears again. E3672 Cmd Rej: ACTNAME already exists in GWS Action Set Table Commands Used: chg-gws-actset The value you entered for the actname parameter is already defined in the database.
  • Page 595 Command Rejected Messages E3600 Messages Recovery Re-enter the command specifying rdct for the last step action in the action set. E3675 Cmd Rej: An ACTNAME must be specified Commands Used: chg-gws-actset You entered a new gateway screening stop action set in the database, but you did not specify a value for the actname parameter.
  • Page 596 E3600 Messages Command Rejected Messages E3680 Cmd Rej: No match on ACTNAME parameter during retrieve Commands Used: all gateway screening retrieve commands The entered GWS stop action set name (actname) was not found. Recovery Enter the command specifying the screening reference to show all action set name identifiers, as well as other values for the screening reference.
  • Page 597 Command Rejected Messages E3600 Messages 2. If both the GWS and LNP features are on (from the output of step 1), re-enter the chg-feat command. 3. If GWS and/or LNP are off (from the output of step 1): NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off.
  • Page 598 E3600 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3684 Cmd Rej: TLNP and RDCT cannot be in the same action set Commands Used: chg-gws-actset You cannot specify both the tlnp and rdct stop actions within the same action set.
  • Page 599 Command Rejected Messages E3600 Messages E3687 Cmd Rej: Cannot enter MULTCC if STP Options DefCC is NONE Commands Used: chg-stpopts You cannot specify a GSM Options MULTCC entry when the STP Options Default Country Code is defined as none (defcc=none). Recovery 1.
  • Page 600 E3600 Messages Command Rejected Messages E3689 Cmd Rej: Period must be 1/4 hour boundary Commands Used: rept-ftp-meas, rept-meas The command was entered with the period=specific and qh parameters, and values for the minutes portion of the qh parameter were not 00, 15, 30, and 45. The value of the qh parameter is in the form of HHMM, where HH is the hour, MM is the minutes.
  • Page 601 Command Rejected Messages E3600 Messages E3692 Cmd Rej: Cannot turn on feature with EMDC provisioned Commands Used: chg-ctrl-feat The command to turn on the 15 Minute Measurements collection feature is not supported with an EMDC card provisioned. Theses features are mutually exclusive.
  • Page 602 E3695 Cmd Rej: Command not supported for non-IPGWx linksets Commands Used: rept-stat-iptps You entered a command to report the current and peak IPGWx TPS utilization, but the linkset specified is not an IPGWx linkset. The EAGLE 5 ISS does not support this command for non-IPGWx linksets. Recovery 1.
  • Page 603 Command Rejected Messages E3600 Messages Refer to the Commands Manual and the Database Administration Manual - System Management for details about enabling features with access keys. 4. Turn the feature on. Enter the chg-ctrl-feat command. 5. When the feature is turned on, re-enter the chg-measopts command. E3698 Cmd Rej: At least one MCP card must be IS-NR Commands Used: chg-ctrl-feat When you entered the command, no Measurements Collection Processor card...
  • Page 604 E3700 Messages Command Rejected Messages • For the ent-map command, you entered a true point code for the pci parameter. • For the ent-trace or rtrv-data-rtdb command, you entered the imei= parameter. Recovery 1. Display the status of features in your system that have feature access keys. Enter the rtrv-ctrl-feat command.
  • Page 605 Command Rejected Messages E3700 Messages 3. If the SEAS feature is off (from the output of step 1), turn it on. Enter the chg-feat command. 4. When the SEAS feature is turned on, re-enter the chg-oap-config command that generated this error message. E3701 Cmd Rej: X.25 packet size parameter requires SEAS feature Commands Used: chg-oap-config The SEAS feature must be turned on before the x25ps parameter can be specified.
  • Page 606 Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled. Refer to the procedure “Activating the LNP Feature on the EAGLE 5 ISS” in the LNP Feature Activation Guide for details.
  • Page 607 Refer to the LNP Feature Activation Guide for details about Activating the LNP Feature on the EAGLE 5 ISS. 4. Re-enter the chg-oap-config command that generated this error message. Call your Customer Care Center if this error message appears again.
  • Page 608 Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled. Refer to the procedure “Activating the LNP Feature on the EAGLE 5 ISS” in the LNP Feature Activation Guide for details.
  • Page 609 Command Rejected Messages E3700 Messages 3. If there is not an entry in the HOSTNAME field of the output, enter names for aname (OAP A) and/or bname (OAP B). Enter the chg-oap-config command. 4. Re-enter the act-oap-config command that generated this error message. E3708 Cmd Rej: OAP CFG required before OAP update Commands Used: act-oap-config The database must be configured for single or dual OAP(s) for either the SEAS or...
  • Page 610 When you issue the ent-card command to add a card that requests service from either an SCCP card or VSCCP card, the EAGLE 5 ISS adds the current TPS level to the estimated TPS level for the new card. The EAGLE 5 ISS uses the following values to derive the TPS estimate: 53 for LSL (cards provisioned as SS7ANSI, CCS7ITU or SS7GX25 cards), 480 for ATM cards, and 1000 for IPLIM cards.
  • Page 611 Command Rejected Messages E3700 Messages (UAM 0330) if the threshold is exceeded. The SCCP TPS threshold also triggers this error message when you issue the ent-card command and the resulting TPS level (the current TPS plus the estimated TPS for the new card) exceeds the threshold level configured.
  • Page 612 E3700 Messages Command Rejected Messages Recovery Re-enter the set-uim-acthresh command specifying both the limit and intrvl parameters. E3718 Cmd Rej: SEAC CLLI required before OAP update Commands Used: act-oap-config The database must be configured for the SEAC Common Language Location Identifier for the SEAS feature, before this command can be executed.
  • Page 613 Command Rejected Messages E3700 Messages 3. If there is not an entry in the X.25 PACKET SIZE field of the output, specify an x25ps value, using the chg-oap-config command. 4. Re-enter the act-oap-config command that generated this error message. Call your Customer Care Center if this error message appears again. E3720 Cmd Rej: SEAS X.25 mode required before OAP update Commands Used: act-oap-config The database must be configured for X.25 mode for the SEAS feature, before this...
  • Page 614 E3700 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again or if the MDAL is at a level other than 1. NOTE: Leaving a removable cartridge in the MDAL for a prolonged period can cause damage. Remove the cartridge after the command or procedure completes.
  • Page 615 Command Rejected Messages E3700 Messages E3727 Cmd Rej: Max number of cards of application type already exist Commands Used: ent-card You cannot exceed the maximum number of cards allowed for that application type in the database. Refer to the ent-card command and Appendix A of the Commands Manual for additional card information.

  • Page 616: Table 2-29. Valid Subnet Mask Values

    E3700 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the act-upgrade command without specifying the appl parameter. • Re-enter the act-upgrade command specifying the appl and action=convertnet parameters. E3731 Cmd Rej: Invalid Hostname Commands Used: chg-appl-sock, chg-assoc, dlt-ip-host, ent-appl-sock, ent-assoc, ent-ip-host, rtrv-appl-sock, rtrv-assoc, rtrv-ip-host The value specified for the hostname is invalid.
  • Page 617 Command Rejected Messages E3700 Messages Table 2-29. Valid Subnet Mask Values Class A Networks Class A or B Networks Class A, B, or C Networks 255.248.0.0 255.255.248.0 255.255.255.248 255.252.0.0 255.255.252.0 255.255.255.252 255.254.0.0 255.255.254.0 255.255.128.0 255.255.255.128 Recovery Re-enter the command specifying a value for the submask parameter derived from Table 2-29 on page 2-602.
  • Page 618 E3700 Messages Command Rejected Messages E3735 Cmd Rej: Hostname must be unique Commands Used: ent-ip-host You tried to enter a hostname (host) that is already in the IP host table. The host name to be added must be unique. Recovery 1.
  • Page 619 Command Rejected Messages E3700 Messages Recovery ent-appl-sock 1. Display the socket data. This information is shown in the SNAME field of the output. Enter the rtrv-appl-sock command specifying no parameters. 2. Re-enter the ent-appl-sock command specifying a socket name that does not match any of the socket names displayed in the SNAME field in the output of step 1.
  • Page 620 E3700 Messages Command Rejected Messages 2. Delete an existing entry from the IP host table. Enter the dlt-ip-host command specifying the host parameter for the entry you want to delete. 3. Add the desired IP host entry to the IP Host table. Re-enter the ent-ip-host command specifying the host parameter entry you want to add.
  • Page 621 Command Rejected Messages E3700 Messages E3741 Cmd Rej: If TIMER is specified, TVALUE must be specified Commands Used: chg-dcmps If you enter the chg-dcmps command specifying the timer parameter, you must also specify the tvalue parameter. Recovery Re-enter the chg-dcmps command specifying both the timer and the tvalue parameters.
  • Page 622 E3700 Messages Command Rejected Messages Recovery Re-enter the chg-ip-card command specifying a value for the domain name that conforms to the specified naming conventions. Call your Customer Care Center if this error message appears again. E3746 Cmd Rej: No other optional parms can be entered with SRCSET Commands Used: chg-dcmps You entered this command specifying the srcset parameter and at least one other optional parameter.
  • Page 623 Command Rejected Messages E3700 Messages E3748 Cmd Rej: Socket Table full Commands Used: ent-appl-sock The maximum number of sockets allowed per system was exceeded with the entry of this command. The allowed maximum is 250 sockets per system. Recovery Call your Customer Care Center. E3749 Cmd Rej: If IPADDR is specified SUBMASK is required Commands Used: chg-ip-lnk When entering the chg-ip-lnk command, you specified a value for the ipaddr...
  • Page 624 E3700 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3752 Cmd Rej: Max IP connections exceeded Commands Used: ent-appl-sock Your attempt to enter an IP connection that exceeds the maximum allowed per system. Recovery Call your Customer Care Center.
  • Page 625 Command Rejected Messages E3700 Messages Recovery 1. Verify that the card at the specified location is a DCM card running the SS7IPGW application. Enter the rtrv-card command. This information is shown in the TYPE and APPL fields of the output. 2.
  • Page 626 E3700 Messages Command Rejected Messages Recovery 1. Determine the service indicator value as shown in the SI column of the output. Enter the rtrv-appl-rtkey or rtrv-rmt-appl command. 2. Re-enter the command specifying the ssn parameter and si=3. Call your Customer Care Center if this error message appears again. E3758 Cmd Rej: If Domain name is specified, RSTDOMAIN is not valid Commands Used: chg-ip-card You cannot specify the rstdomain parameter if the domain parameter is specified.
  • Page 627 Command Rejected Messages E3700 Messages Recovery - ent-ip-host 1. Display the host names and IP addresses currently in the IP Host table. Enter the rtrv-ip-host command specifying no parameters. 2. Re-enter the ent-ip-host command specifying the host name and an IP address that does not match any of the entries currently in the IP Host table.
  • Page 628 E3700 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. Recovery - dlt-ip-host 1. Display the host names and IP addresses currently in the IP Host table. Enter the rtrv-ip-host command specifying no parameters. 2.
  • Page 629 Command Rejected Messages E3700 Messages Recovery 1. Display the Routing Key table. Enter the rtrv-appl-rtkey command. 2. If the routing key you specified is shown in the output from step 1, re-enter the command. Call your Customer Care Center if this error message appears again. E3765 Cmd Rej: Fully specified connection required to change OPEN Commands Used: chg-appl-sock, chg-assoc You tried to change the setting of the open parameter, to yes but you did not...
  • Page 630 E3700 Messages Command Rejected Messages E3768 Cmd Rej: Link B not supported for device Commands Used: ent-slk, rept-stat-slk The command you entered requires that you specify port/link=a for cards running the ss7ipgw or ipgwi applications. Recovery Re-enter the command that generated this error message specifying the port/link=a parameter.
  • Page 631 Command Rejected Messages E3700 Messages E3772 Cmd Rej: Only one SS7IPGW or IPGWI link allowed in mated linkset Commands Used: ent-slk The mated IPGWx linkset specified already has an assigned signaling link. A mated linkset can have only one signaling link. If the specified linkset has a mate linkset, only 1 SS7IPGW or IPGWI signaling link can be assigned to the specified linkset.
  • Page 632 E3700 Messages Command Rejected Messages E3775 Cmd Rej: SERIAL param valid only with APPL param Commands Used: init-card The serial parameter can be used only with the appl parameter. Recovery Re-enter the init-card command specifying both the appl and serial parameters.

  • Page 633: Table 2-30. Conditions That Generate An E3779 Error Message

    Command Rejected Messages E3700 Messages You may have encountered this error during an upgrade, when one OAM may be booted from a removable cartridge and the other from the fixed disk. This action could cause different GPLs to be running in the active and standby OAM cards. Recovery Use the following commands, or command combinations, to boot both OAM cards with the same GPL version from the removable cartridge:...
  • Page 634 E3700 Messages Command Rejected Messages E3780 Cmd Rej: Syntax Error Found Commands Used: Pass-through commands The command you entered does not conform to the required syntax. Recovery Re-enter the command as the rules require. Refer to the Commands Manual for the syntax rules for the command. Call your Customer Care Center if this error message appears again.
  • Page 635 Command Rejected Messages E3700 Messages E3782 Cmd Rej: Command Not Found Commands Used: Pass-through commands The pass-through command you entered was not found. Recovery Re-enter the command specifying the correct information. Refer to the Commands Manual for information about the command. Call your Customer Care Center if this error message appears again.
  • Page 636 E3700 Messages Command Rejected Messages E3786 Cmd Rej: CIC Range overlaps an existing routing key Commands Used: dlt-appl-rtkey, ent-appl-rtkey You entered a circuit identification code range (cics to cice) that overlaps an existing routing key. Recovery 1. Display the conflicting circuit identification code range for the existing routing key.
  • Page 637 Command Rejected Messages E3700 Messages Recovery Re-enter the command specifying values for the opc, cics, and cice parameters for si=4, 5, or 13 and routing key type=full. E3789 Cmd Rej: OPC, CICS, CICE are not allowed with SI unless SI is 4, 5, or 13 Commands Used: chg-appl-rtkey, dlt-appl-rtkey, ent-appl-rtkey, rtrv-appl-rtkey You specified the opc, cics, and cice parameters specified, but the si parameter...
  • Page 638 E3700 Messages Command Rejected Messages E3792 Cmd Rej: Gtwy IP Address must be local to this cards A, B network Commands Used: ent-ip-rte For the card in the location specified in the loc parameter, you specified a gateway IP address in the gtwy parameter of the command that is not local to the A or B network of the card.
  • Page 639 Command Rejected Messages E3700 Messages 2. To add another route entry for the card, delete an existing route entry from the table. Enter the dlt-ip-rte command. 3. Re-enter the ent-ip-rte command to add the new route entry for the card. E3795 Cmd Rej: LNP ported NPANXXs 300K Qty Feat Requires at least DSM2GB Commands Used: enable-ctrl-feat You attempted to enable the LNP ported NPANXX 300K Quantity Keys, but not...
  • Page 640 E3700 Messages Command Rejected Messages Recovery 1. Upgrade your hardware. 2. Re-enter the enable-ctrl-feat command specifying the appropriate part number and access key information. Call your Customer Care Center if this error message appears again. E3798 Cmd Rej: Measurement Preparation in progress, Retry later Commands Used: chg-db Since there is measurement preparation in progress, the upload to the OAM (finishedl) cannot be started.
  • Page 641 Command Rejected Messages E3800 Messages E3800 Cmd Rej: BLM/DCM card must be provisioned and IS-NR for bulk download Commands Used: chg-db You specified the chg-db:action=beginedl command, but the Bulk Load Module (BLM) and DCM cards do not meet the requirements for a bulk download.
  • Page 642 E3800 Messages Command Rejected Messages init-card:loc=xxxx where xxxx is the location of the BLM or DCM card. 3. Re-enter the chg-db:action=beginedl command. Call your Customer Care Center if this error message appears again. E3802 Cmd Rej: BLM must be provisioned and IS-NR for an upload Commands Used: chg-db You specified the chg-db:action=finishedl command.
  • Page 643 Command Rejected Messages E3800 Messages Recovery 1. Determine the status of the database. Enter the rept-stat-db:display=all command. 2. If the BLM database is not coherent, enter the following command: init-card:loc=xxxx where xxxx is the location of the BLM card. 3. From the LSMS, restart the bulk download, and then re-enter the chg-db command that generated this error message.
  • Page 644 E3800 Messages Command Rejected Messages • Wait for LSMS to cancel the download, in which case the following message appears: 5061.1498 SYSTEM INFO LSMS Bulk Download cancelled at LSMS • Cancel the download. Enter the chg-db:action=canceledl command. E3807 Cmd Rej: Failed reading Secondary Point Code (SPC) table Commands Used: chg-sid, dlt-spc, ent-spc, rtrv-spc The Secondary Point Code table must be accessible for the command to execute.
  • Page 645 2. Enter the rtrv-sid command to display the point codes currently in the SID table. The EAGLE 5 ISS’s true point code is shown in the PCA field. Capability point codes are shown in the CPCA, CPCI, CPCN, and CPCN24 fields.
  • Page 646 E3800 Messages Command Rejected Messages Recovery 1. Display the system’s true point code with the rtrv-sid command. The system’s true point code is shown in the PCA field. 2. Re-enter the chg-sid command that generated this error message specifying a value for the pc/pca parameter that does not exist as an SPC, as shown in the output from step 1.
  • Page 647 Command Rejected Messages E3800 Messages E3815 Cmd Rej: The maximum number of SPCs has already been defined Commands Used: ent-spc The maximum number of Secondary Point Codes (SPCs) you can enter into the database is 40. When you entered the command, you specified a SPC that would have been the 41st entry in the database.
  • Page 648 E3800 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3821 Cmd Rej: SPC & DPC must be the same network type Commands Used: chg-dstn, ent-dstn You specified the spc parameter, but its network type (ANSI, ITU-N, or ITU-I) does not match the network type for the destination point code (DPC).
  • Page 649 Command Rejected Messages E3800 Messages E3825 Cmd Rej: New CIC range overlaps an existing routing key Commands Used: chg-appl-rtkey You entered a new circuit identification code range (ncics-to-ncice) that overlaps an existing routing key. Recovery 1. Enter the rtrv-appl-rtkey command specifying the new CIC range to see the conflicting circuit identification code range for the existing routing key.
  • Page 650 E3800 Messages Command Rejected Messages Recovery 1. Enter one of the following commands to verify that a routing key or controlled feature already exists with the parameters that you entered: • the rtrv-appl-rtkey command • the rtrv-ctrl-feat command 2. If there is no routing key or controlled feature in the output identical to the parameters you entered, re-enter the command.
  • Page 651 Command Rejected Messages E3800 Messages Recovery 1. Determine if the type=ss7ipgw or type=ipgwi and ipgwapc=yes. Enter the rtrv-ls command specifying the linkset name (lsn). 2. If the criteria identified in step 1 are met, re-enter the ent-slk command. Call your Customer Care Center if this error message appears again. E3830 Cmd Rej: DPC must not specify a cluster route for IPGWAPC link set Commands Used: chg-rte, ent-rte You specified a cluster route for a destination point code (dpc) for a link set that...

  • Page 652: Table 2-19. Valid Parameter Combinations For An E3269 Error Message

    E3800 Messages Command Rejected Messages Refer to Table 2-31 for valid parameter combinations for specific actions and service indicator values. Table 2-31. Valid Parameter Combinations for Routing Key Types using the chg-appl-rtkey Command Action DPC* SI* SSN CICS CICE NCICS NCICE SPLIT NAME Split CIC Range...
  • Page 653 Command Rejected Messages E3800 Messages Recovery Re-enter the command specifying a value for split that is greater than the value specified for cics. Call your Customer Care Center if this error message appears again. E3833 Cmd Rej: SPLIT must be less than or equal to CICE Commands Used: chg-appl-rtkey The value entered for the circuit identification code split range (split) must be less than or equal to the value entered for the ending circuit identification code (cice).
  • Page 654 E3800 Messages Command Rejected Messages Recovery 1. Enter the rtrv-card command to verify that the card at the specified location is a DCM card running the SS7IPGW application. This information is shown in the TYPE and APPL fields of the output. 2.
  • Page 655 Command Rejected Messages E3800 Messages Call your Customer Care Center if this error message appears again. E3838 Cmd Rej: SPLIT, NCICS, NCICE are not allowed with SI unless SI is 4, 5, or 13 Commands Used: chg-appl-rtkey You entered a value for a circuit identification code split range (split), a new starting circuit identification code (ncics), or a new ending circuit identification code (ncice), along with a value for the service indicator (si) that is other than 4, 5, or 13 (or tup, isup, or qbicc).
  • Page 656 E3800 Messages Command Rejected Messages Refer to the Commands Manual for information on the command format, parameters, and syntax. Call your Customer Care Center if this error message appears again. E3841 Cmd Rej: Dynamic rtkeys + SRKQ exceed max allowed rtkey limit Commands Used: chg-sg-opts The sum of the values specified for the static routing key quantity (srkq) parameter and dynamic routing key entries on any SS7IPGW or IPGWI card...
  • Page 657 Command Rejected Messages E3800 Messages Recovery 1. Verify the values specified for the static routing key quantity (srkq) parameter and the total number of static entries in the Static Routing Key table. Enter the rept-stat-rtkey command. 2. Perform one of the following actions: •...

  • Page 658: Command

    E3800 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the rtrv-appl-rtkey command without specifying the loc parameter • Re-enter the rtrv-appl-rtkey command specifying mode=dynamic and the loc parameter Call your Customer Care Center if this error message appears again. E3845 Cmd Rej: DYNRTK feature must be enabled to perform this operation Commands Used: chg-sg-opts You attempted to change an IP...
  • Page 659 Command Rejected Messages E3800 Messages NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off. Refer to the chg-feat command in the Commands Manual for further information. Recovery 1. Display the features in the database. Enter the rtrv-feat command. 2.

  • Page 660: Table 2-32. Reason That Card Requires A Full Data Download

    E3800 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the init-sys command without specifying the force parameter. • Re-enter the init-sys command specifying both the data and force parameters. E3849 Cmd Rej: Card(s) cannot warm restart - FORCE parameter required Commands Used: init-card, init-sys You specified the data=persist parameter without the force parameter.
  • Page 661 Command Rejected Messages E3800 Messages Table 2-32. Reason that Card Requires a Full Data Download (Continued) xxxxxxxx value Description HW ERR Hardware error bit checks on the card fail AUDIT FAILED Checksum comparisons of the LNP database fail AUDIT TIMEOUT LNP initialization audit timed out NO AUDIT Unable to perform LNP DB audit.
  • Page 662 E3800 Messages Command Rejected Messages 2. Turn on the MTPRS feature. Enter the chg-feat:itumtprs=on command. 3. Perform one of the following actions: • Re-enter the command that generated this error message. • Re-enter the command that generated this error message without specifying the mtprse parameter.
  • Page 663 Command Rejected Messages E3800 Messages E3854 Cmd Rej: NCICS unspecified, NCICE must be greater than or equal to CICS Commands Used: chg-appl-rtkey The value entered for the new ending circuit identification code (ncice) must be greater than or equal to the value entered for the starting circuit identification code (cics), when the new starting circuit identification code (ncics) is not specified.
  • Page 664 E3800 Messages Command Rejected Messages Recovery Re-enter the chg-sg-opts command that generated this error message. Call your Customer Care Center if this error message appears again. E3857 Cmd Rej: Unexpected response message error Commands Used: chg-sg-opts This command generated an unexpected response message. Recovery Re-enter the chg-sg-opts command that generated this error message.
  • Page 665 Command Rejected Messages E3800 Messages E3859 Cmd Rej: Cannot assign LHOST to the B interface Commands Used: chg-appl-sock, ent-appl-sock You cannot provision a socket LHOST with a host name that is associated with the B interface. Recovery 1. Determine the associated IP address for the host name. Enter the rtrv-ip-host command.
  • Page 666 E3800 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E3861 Cmd Rej: Cannot echo to OAP terminal Commands Used: act-echo You specified an OAP port for the trm parameter, which is not allowed. Recovery 1.
  • Page 667 Command Rejected Messages E3800 Messages Recovery Display the features in the database. Enter the rtrv-feat command. • If the SLSOCB feature is turned on, re-enter the command that generated this error message. • If the SLSOCB feature is turned off, turn the feature on: Enter the chg-feat:slsocb=on command.
  • Page 668 • specify links b16...b31, • specify E1 or T1 ports 3 through 8, • specify linkclass=unchan for an E1 port, • bring an HC-MIM card in an EAGLE 5 ISS shelf into service, • provision a second SE-HSL port. Recovery 1.
  • Page 669 Command Rejected Messages E3800 Messages Recovery 1. Display the features in the database. Enter the rtrv-feat command. • If the MPC feature is turned on, re-enter the command that generated this error message. • If the MPC feature is turned off, turn it on. Enter the chg-feat:mpc=on command.
  • Page 670 E3800 Messages Command Rejected Messages Recovery 1. Display the features in the database. Enter the rtrv-feat command. • If the GTT feature is turned on (GTT = on), re-enter the chg-feat command. • If the GTT feature is off, turn it on. Enter chg-feat:gtt=on command. NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off.
  • Page 671 Command Rejected Messages E3800 Messages Recovery 1. Verify that the card at the specified location is running the IPGWI application. Enter the rtrv-card command. 2. If the card is not running the IPGWI application, re-enter the ent-slk command. Call your Customer Care Center if this error message appears again. E3873 Cmd Rej: Card GPL type IPGWI requires a link set with IPGWAPC=YES Commands Used: ent-slk When entering an IP link (type=ipgwi) with the ent-slk command, the linkset...
  • Page 672 E3800 Messages Command Rejected Messages • You can enter just the sname and asname for a new routing key. • You can change only the sname (with the nsname parameter) and the asname (with the nasname parameter) of an existing routing key. Recovery Re-enter the command specifying only the dpc and si parameters to identify the routing key.
  • Page 673 Command Rejected Messages E3800 Messages Recovery 1. Enter the rtrv-card command to verify that the card at the specified location is a DCM card running the IPGWI application. This information is shown in the TYPE and APPL fields of the output. 2.

  • Page 674: Table 2-33. Valid Cic Ranges For Si And Msu Types

    E3800 Messages Command Rejected Messages E3878 Cmd Rej: CIC outside of valid range for SI Commands Used: chg-appl-rtkey, dlt-appl-rtkey, ent-appl-rtkey, rtrv-appl-rtkey You specified a starting Circuit Identification Code (cics) or ending Circuit Identification Code (cice) that is out of range for the routing key SI. The cics and cice parameters are valid only if si=4, 5, or 13.
  • Page 675 Command Rejected Messages E3800 Messages E3879 Cmd Rej: The MPC feature must be ON before ITUDUPPC can be ON Commands Used: chg-feat You tried to turn on the ITU National Duplicate Point Code (ITUDUPPC) feature, but the Multiple Point Code (MPC) feature is not on. The MPC feature must be turned on before you can turn on the ITUDUPPC feature.
  • Page 676 E3800 Messages Command Rejected Messages E3881 Cmd Rej: Group Code of destination and Secondary PC must match Commands Used: chg-dstn, ent-dstn You specified an ITU-N destination that does use a secondary point code (spc). The group code of the ITU-N destination must match the group code of the SPC. The group code (aa-zz) is the two-letter code appended to the last subfield of an ITU-N point code (for example, si is the group code in SPC: 128-15-1-1-si).
  • Page 677 Command Rejected Messages E3800 Messages Table 2-34. Conditions that Generate an E3883 Error Message Commands Condition chg-ls, The GSM Map Screening feature must be turned on before ent-ls the gsmscrn parameter can be specified. chg-sccpopts The GSM Map Screening feature must be enabled and turned ON when gmstcapce parameter is specified.
  • Page 678 E3800 Messages Command Rejected Messages E3884 Cmd Rej: SSN/TYPE combination already exists Commands Used: ent-gsmssn-scrn You attempted to enter an ssn/type parameter combination that already exists in the GSM SSN Screening table. The subsystem number and type pairs must be unique.
  • Page 679 Command Rejected Messages E3800 Messages E3887 Cmd Rej: OPCODE already exists Commands Used: ent-gsms-opcode You specified a value for the opcode parameter that already exists in the GSM MAP Op-Code table. You must specify a unique value. Recovery 1. Display the GSM MAP Op-Code table. Enter the rtrv-gsms-opcode command.
  • Page 680 E3800 Messages Command Rejected Messages E3890 Cmd Rej: Failure reading the GSM MAP SCRN Table Commands Used: chg-gsmmap-scrn, dlt-gsmmap-scrn, ent-gsmmap-scrn, rtrv-gsmmap-scrn The GSM MAP screening table must be accessible for the command to execute. A failure occurred in reading the table. Recovery Re-enter the command.
  • Page 681 Command Rejected Messages E3800 Messages E3894 Cmd Rej: SADDR and EADDR must have the same number of digits Commands Used: ent-gsmmap-scrn, rtrv-gsmmap-scrn The saddr parameter does not contain the same number of digits as the eaddr parameter. The saddr and the eaddr parameter must contain the same number of digits.
  • Page 682 E3800 Messages Command Rejected Messages Recovery 1. Display a list of existing entries. Enter the rtrv-gsmmap-scrn command. 2. Re-enter the ent-gsmmap-scrn command specifying a single or range entry that does not already exist or that does not overlap any other range entry in the database.
  • Page 683 Command Rejected Messages E3900 Messages E3900 Cmd Rej: GSM Map Screening feature must be enabled Commands Used: dlt-gsms-opcode, dlt-gsmmap-scrn, dlt-gsmssn-scrn, rtrv-gsmmap-scrn, rtrv-gsms-opcode, rtrv-gsmssn-scrn The command failed because the GSM MAP Screening feature is not enabled. NOTE: Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled.
  • Page 684 E3900 Messages Command Rejected Messages E3902 Cmd Rej: FORBID can not be STATE or LOCATION for the given OPNAME Commands Used: chg-gsmmap-scrn, ent-gsmmap-scrn, rtrv-gsmmap-scrn To specify the nforbid/forbid=state/location parameter, the operation code referenced by the specified opname must have a value of 71. The nforbid/forbid=state/location option is only valid for ATI MAP operation codes;...
  • Page 685 Command Rejected Messages E3900 Messages E3904 Cmd Rej: DFLTACT cannot be ATIERR unless OPCODE=71 Commands Used: chg-gsms-opcode, ent-gsms-opcode You specified the dfltact/ndfltact=atierr parameter with a value other than 71 for the opcode parameter. If you specify the dfltact/ndfltact=atierr parameter, you must specify opcode=71.
  • Page 686 E3900 Messages Command Rejected Messages 2. To create a CdPA entry, enter the ent-gsmmap-scrn command specifying the opname, cgsr, and cdsr parameters. 3. To display any portion of the EGMS MAP Screen Table, specify the rtrv-gsmmap-scrn command and the appropriate opname, cgsr, and optionally the cdsr parameter(s) E3906 Cmd Rej: The GSM MAP Screening table is full Commands Used: ent-gsmmap-scrn...
  • Page 687 Command Rejected Messages E3900 Messages 2. Verify that all HMUX cards are in service with the rept-stat-card command. 3. Re-enter the act-upgrade command. Call your Customer Care Center if this error message appears again. E3910 Cmd Rej: Translation TYPEN24 specified does not exist Commands Used: dlt-tt, rtrv-tt The translation type specified (typen24) must be in the Translation Type table.
  • Page 688 E3900 Messages Command Rejected Messages E3912 Cmd Rej: Translation TYPEN already exists Commands Used: ent-tt The translation type (typen) specified already exists in the translation type table. You cannot add a translation type that already exists. Recovery 1. Determine if the translation type you want to use already exists in the translation type table.
  • Page 689 Command Rejected Messages E3900 Messages E3915 Cmd Rej: CdPA GTT Selector already exists in GTII-TT-NP(V)-NAI(V) Commands Used: ent-gttsel The specified CdPA selector was not entered because an entry that matches the values specified for the gtii, tt, and np/nai or npv/naiv parameter combination, already exists in the GTT Selector table.
  • Page 690 E3900 Messages Command Rejected Messages This example assumes that gttsn=ansi2 is an existing GTT set in the database. Recovery 1. Display the GTT Selector table. Enter the rtrv-gttsel command. 2. Re-enter the command specifying a parameter combination that exists in the database.
  • Page 691 Command Rejected Messages E3900 Messages E3920 Cmd Rej: VGTT cannot be On if any SCCP card has a 486 processor Commands Used: chg-feat You attempted to bring VGTT online, but your hardware is inadequate and requires upgrading. To turn on both the VGTT and LNP features requires that you have all DSM cards on your system.
  • Page 692 E3900 Messages Command Rejected Messages E3922 Cmd Rej: GTT must be ON before INP can be ON Commands Used: chg-feat You cannot turn on the INAP Number Portability (INP ) feature, if the Global Title Translation (GTT) feature is turned off. The GTT feature must be turned on before you can turn on INP feature.
  • Page 693 Command Rejected Messages E3900 Messages Call your Customer Care Center if this error message appears again. E3925 Cmd Rej: HOMERN Table is full Commands Used: ent-homern The HOMERN table is full. You must delete a routing number before another one can be added.
  • Page 694 E3900 Messages Command Rejected Messages E3928 Cmd Rej: STP True PC and INP SSN do not exist in MAP table Commands Used: ent-ss-appl You attempted to reserve an INP subsystem number (ssn) for an application, but the STP true point code/subsystem number combination has not been defined in the mated applications (MAP) table.
  • Page 695 LNP telephone numbers can be increased, DSMs running the VSCCP application with the correct amount of memory must be configured in the EAGLE 5 ISS. Refer to the LNP Feature Activation Guide and call your Customer Care Center before starting the process.
  • Page 696 E3900 Messages Command Rejected Messages E3932 Cmd Rej: GFLEX, INP, or GPORT feature must be ON Commands Used: chg-stpopts, ent-trace Table 2-35 lists by command the conditions that may detect this error. The table is followed by a procedure that provides a remedy to the error. Table 2-35.
  • Page 697 Command Rejected Messages E3900 Messages Recovery Re-enter the chg-sid command that generated this error message, but this time do one of the following actions: • Specify a value other than inp or eir for the cpctype parameter. • Specify cpcn/ncpcn/ncpcn24 or cpci/ncpci for the point code. E3935 Cmd Rej: DRANP and DRANPV must not be specified together Commands Used: chg-inpopts, rtrv-inpopts You cannot specify both the dranp and dranpv parameters.
  • Page 698 E3900 Messages Command Rejected Messages Recovery 1. Display the existing values for the above parameters. Enter the rtrv-srvsel command. 2. Re-enter the ent-srvsel command specifying values that do not already exist in the database for the above parameters. E3938 Cmd Rej: Entry does not exist with specified GTI-TT-NP(V)-NAI(V)-SSN Commands Used: chg-srvsel, dlt-srvsel You specified an entry that does not match an existing gti, tt, np/nai and npv/naiv, and ssn parameter combination as required.
  • Page 699 Command Rejected Messages E3900 Messages Recovery Perform one of the following actions: • Re-enter the command that generated this error message specifying a valid value for the nserv/serv parameter. (Note that the nsnai/snai parameter may not be specified if you specify serv=inpq). •...
  • Page 700 E3900 Messages Command Rejected Messages Recovery Re-enter the command that generated this error message performing one of the following actions: • Re-enter the command that generated this error message specifying nserv/serv = gflex, inpq, inpmr, gport, smsmr, mnpsms, or eir. •...
  • Page 701 Command Rejected Messages E3900 Messages Recovery Perform one of the following corrections: • Re-enter the ent-srvsel command specifying the snp and snai parameters. • Re-enter the ent-srvsel command specifying a valid value for the serv parameter. E3945 Cmd Rej: SERV must not be GFLEX when SNAI = RNIDN/RNNDN/RNSDN Commands Used: rtrv-srvsel You specified the serv=gflex parameter with one of the following values for the snai parameter: rnidn, rnndn, or rnsdn.
  • Page 702 E3900 Messages Command Rejected Messages E3947 Cmd Rej: Entry already exists with specified GTIN-TT-NP(V)-NAI(V)-SSN Commands Used: ent-srvsel You cannot specify a value for a parameter that matches the value of an existing gtin, tt, np(v), nai(v), and ssn parameter combination. Recovery 1.
  • Page 703 Command Rejected Messages E3900 Messages E3950 Cmd Rej: Standby MASP is inhibited Commands Used: Any command used to update a database You entered a command to update the system database. The database cannot be updated because the standby MASP is inhibited. Recovery 1.
  • Page 704 E3900 Messages Command Rejected Messages E3955 Cmd Rej: Invalid combination of parameters for a partial routing key Commands Used: chg-appl-rtkey, dlt-appl-rtkey, ent-appl-rtkey, rtrv-appl-rtkey You specified parameters that do not define a full routing key, and the specified parameter combination is invalid for a partial routing key. The following types of partial routing keys are supported: •...
  • Page 705 Command Rejected Messages E3900 Messages Call your Customer Care Center if this error message appears again. E3957 Cmd Rej: When type=partial or default, specify attributes Commands Used: chg-appl-rtkey You specified the routing key type specified as partial or default, and you did not enter the attributes parameters rcontext, pstncat, pstnid, or norm.
  • Page 706 E3900 Messages Command Rejected Messages Recovery Re-enter the appropriate command specifying type=default and a valid combination of parameters for a default routing key. E3960 Cmd Rej: When type=DEFAULT, other allowed parameters are SNAME/LOC Commands Used: dlt-appl-rtkey You specified the routing key type specified as default, and one or more parameters that were not sname or loc.
  • Page 707 E3963 Cmd Rej: HMUXTVG must be ON before E5IS can be ON Commands Used: chg-feat, chg-meas You entered a command to turn on the EAGLE 5 Integrated Monitoring Support feature (chg-feat:e5is=on). However, this command cannot be executed due to a possible error in the STP Options table.
  • Page 708 E3966 Cmd Rej: Max number of STC cards per shelf is entered Commands Used: ent-card You tried to add an STC card to a shelf for the EAGLE 5 Integrated Monitoring Support feature. The shelf already contains the maximum three STC cards.
  • Page 709 E3968 Cmd Rej: Invalid hardware for E5IS COPY to be on Commands Used: chg-eisopts You entered a command to enable the copy function for the EAGLE 5 Integrated Monitoring Support feature. The required hardware is not in the system for the command.
  • Page 710 E3900 Messages Command Rejected Messages Recovery Re-enter the command. Call your Customer Care Center if this error message appears again. E3986 Cmd Rej: LNP and GPORT features are mutually exclusive Commands Used: chg-feat You tried to turn on either the GSM mobile number portability (G-Port) feature or or the LNP ported TNs Quantity feature access key, but one of the two features is already turned on.
  • Page 711 Command Rejected Messages E3900 Messages Recovery 1. Display the features in the database. Enter the command rtrv-feat command. 2. If the GTT feature is on (gtt=on from the output of step 1), turn the G-Port feature bit on. Enter the chg-feat:gport=on command. Call your Customer Care Center if this error message appears again.
  • Page 712 E3900 Messages Command Rejected Messages 3. If the G-Port feature bit is off (gport=off) from the output of step 1), enter the command chg-feat:gport=on to turn the G-Port feature bit on. 4. Re-enter the command that generated this error message. Call your Customer Care Center if this error message appears again.
  • Page 713 Command Rejected Messages E3900 Messages Refer to the Database Administration Manual-System Management and the Commands Manual for details about enabling features with access keys. Recovery 1. Display the features in the database. Enter the commands rtrv-feat and rtrv-ctrl-feat. 2. If the G-Port feature is turned on, re-enter the command that generated this error message.
  • Page 714 E3900 Messages Command Rejected Messages E3993 Cmd Rej: GTIA/GTI must not be specified when (N)SERV= GPORT Commands Used: chg-srvsel, ent-srvsel, rtrv-srvsel You cannot specify the gtia parameter or gti parameter when nserv=gport. Recovery Re-enter the command specifying the gtii or gtin parameter and the nserv=gport parameter.
  • Page 715 Command Rejected Messages E3900 Messages E3997 Cmd Rej: GFLEX or GPORT feature must be on or EIR feature must be enabled Commands Used: rtrv-gsmopts The command you entered is invalid unless one of the following conditions is true: • the G-Flex feature is on, or •...
  • Page 716 E3900 Messages Command Rejected Messages • Re-enter the rtrv-gsmopts command that generated this error message. Call your Customer Care Center if this error message appears again. E3998 Cmd Rej: NSNAI = NONE only allowed when NSERV = INPQ Commands Used: chg-srvsel If you specify the nsnai=none parameter, you must specify the nserv=inpq parameter.
  • Page 717 Command Rejected Messages E4000 Messages E4001 Cmd Rej: Group Code of DPCN and OPCN must match Commands Used: ent-appl-rtkey The group codes for the dpcn and opcn parameter values must match when you specify both parameters in the command. A two-letter group code is required for ITU-N point codes and spare point codes (DPCN/OPCN) when the ITU Duplicate Point Code feature (ITUDUPPC) is turned on, and not allowed when the feature is off.
  • Page 718 E4000 Messages Command Rejected Messages E4004 Cmd Rej: PSTNCAT=1 requires ITU-I or ITU-N point code Commands Used: chg-appl-rtkey If you specify a value of 1 for the Public Switched Telephone Network (PSTN) Category parameter (pstncat=1), you must specify an ITU-I or ITU-N point code. The parameter value pstncat=1 can be used only with routing keys that specify ITU-N or ITU-I point codes.
  • Page 719 Command Rejected Messages E4000 Messages 2. If the INP or G-Port feature is on (from the output of step 1), • Re-enter the command that generated this message. Call your Customer Care Center if this error message appears again. 3. If the INP or G-Port feature is off (from the output of step 1), •...
  • Page 720 E4000 Messages Command Rejected Messages Recovery 1. Display all GTAs for the specified translation type. Enter the rtrv-gtt command. 2. Delete all of the GTAs of a particular length. Enter the dlt-gtt command. When the last address of a particular length is deleted, that length no longer counts toward the 10 lengths supported per translation type.
  • Page 721 Command Rejected Messages E4000 Messages E4010 Cmd Rej: GTA length is not defined for GTTSET Commands Used: chg-gta, dlt-gta, rtrv-gta You cannot change, delete, or retrieve a GTA length that has not been defined for the specified GTT set. Recovery 1.

  • Page 722: Table 2-37. Valid Pvn Subnet Mask Values

    E4000 Messages Command Rejected Messages Table 2-37. Valid PVN Subnet Mask Values Valid for Class B Networks 255.255.0.0 255.255.248.0 255.255.192.0 255.255.252.0 255.255.224.0 255.255.254.0 255.255.240.0 255.255.255.128 Recovery Re-enter the chg-netopts command specifying a valid pvnmask parameter value. E4013 Cmd Rej: T1 Port test command not in progress Commands Used: tst-t1 There is no active test in progress on this t1port.
  • Page 723 Command Rejected Messages E4000 Messages E4015 Cmd Rej: CGSR or CDSR shouldn't be specified when SADDR is specified Commands Used: rtrv-gsmmap-scrn For the rtrv-gsmmap-scrn command, if you specify the saddr parameter, the cgsr or cdsr parameters cannot be specified. Recovery Re-enter the rtrv-gsmmap-scrn command specifying the saddr parameter, without specifying the cgsr or cdsr parameters.
  • Page 724 E4000 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the rtrv-gsmmap-scrn command without specifying the action or forbid parameters • Re-enter the rtrv-gsmmap-scrn command specifying the action or forbid parameters, but do not include either the cdsr parameter or the combination of saddr (with or without eaddr), npv, and naiv parameters.
  • Page 725 Command Rejected Messages E4000 Messages E4026 Cmd Rej: STP options HMUXABUS or HMUXBBUS must be set=yes Commands Used: clr-imt-stats, rept-imt-info, init-mux The command you entered cannot be executed due to a possible error in the STP Options table. Recovery Call your Customer Care Center and report you received error message E4026, and that the STP Options table appears to be in error.
  • Page 726 E4000 Messages Command Rejected Messages Recovery Perform one of the following actions: • Re-enter the ent-gtcnv command specifying the (nai) and (np) parameters, and a value other than 22 for the (gtixlat) parameter. • Re-enter the ent-gtcnv command specifying gtixlat=22 without specifying the nai and np parameters.
  • Page 727 Command Rejected Messages E4000 Messages E4036 Cmd Rej: At least TTA, TTI must be specified for a direction of BOTH Commands Used: chg-gtcnv, dlt-gtcnv If you specify that the direction of conversion is BOTH (dir=both), the ANSI translation type (tta) and the ITU translation type (tti) parameters must also be specified.

  • Page 728: Table 2-38. Routing Keys And Supported Pstn Categories

    E4000 Messages Command Rejected Messages Table 2-38. Routing Keys and Supported PSTN Categories and PSTN IDs for PSTN Category 1 pstnid for pstncat = 1 Routing norm=ye 1=ITU 2=ETSI 3=UK 4=GERMA Key Entry Type s is valid Q.767 PNO-ISC7 N ISUP Type Full-CIC ANSI...
  • Page 729 Command Rejected Messages E4000 Messages E4039 Cmd Rej: MULTGC=YES not allowed if ITUDUPPC feature is OFF Commands Used: chg-ls, ent-ls You cannot specify a value of yes for the Multiple Group Codes Allowed (multgc=yes) parameter if the International National Duplicate Point Code (ITUDUPPC) feature is turned off.
  • Page 730 E4000 Messages Command Rejected Messages Recovery Re-enter the command and specify only valid routing key parameters or only valid key attribute parameters. E4042 Cmd Rej: ISUP Normalization feature must be enabled to set NORM=YES Commands Used: chg-appl-rtkey This feature requires the ISUP Normalization ON/OFF controlled feature as well as a separate ON/OFF controlled feature for each ISUP variant that can be normalized.
  • Page 731 Command Rejected Messages E4000 Messages Recovery Re-enter the ent-slk command and reference a link set with a card application of ipgwi or iplimi. E4046 Cmd Rej: E1 is assigned to card Commands Used: dlt-card Before you can delete a 2-port E1 card or an E1/T1 MIM card that is being used as an E1 card (card type lime1 that has an E1 interface associated with it), you must first delete all E1 interfaces associated with the card.
  • Page 732 E4000 Messages Command Rejected Messages Refer to the Commands Manual for detailed information about the use of the ent-slk command. 2. Allow the card. Re-enter the alw-card command. E4048 Cmd Rej: All signaling links serviced by the E1 must be deactivated Commands Used: chg-e1, inh-card You entered a command that requires all signaling links assigned to the specified E1 card to be deactivated before the command can execute.
  • Page 733 Command Rejected Messages E4000 Messages E4050 Cmd Rej: E1PORT specified by E1LOC is not equipped Commands Used: ent-slk The E1 interface for the e1port specified by the e1port parameter on an E1 card or, E1/T1 MIM card being used as an E1 card specified by the e1loc parameter, is not defined in the database.
  • Page 734 E4000 Messages Command Rejected Messages E4052 Cmd Rej: E1 specified by E1LOC/E1PORT is using CAS, TS=16 not allowed Commands Used: ent-slk You specified a timeslot value of 16 for an E1 interface that has Channel Associated Signaling (CAS) enabled. When CAS is enabled for an E1 interface, you cannot assign timeslot 16 to that E1 interface.
  • Page 735 Command Rejected Messages E4000 Messages Recovery chg-e1, dlt-e1, rtrv-e1 1. Display all e1port and loc parameter information. Enter the rtrv-e1 command specifying no parameters.Verify that you specified the correct e1port and loc parameters. 2. If the specified e1port or loc are incorrect, re-enter the command specifying the correct e1port and loc parameters.
  • Page 736 E4000 Messages Command Rejected Messages 2. If you need to correct any part of the command information, re-enter the chg-e1 command specifying the correct information. 3. If you need to change the cas parameter value, you must first delete timeslot 16 from the E1 interface before you enter the command again.
  • Page 737 Command Rejected Messages E4000 Messages Recovery Re-enter the ent-slk command specifying an E1 interface on an E1 card that is on the same shelf with the Channel card. E4059 Cmd Rej: Failed reading the E1/T1 table Commands Used: chg-e1, chg-t1, dlt-card, dlt-e1, dlt-t1, ent-e1, ent-slk, ent-t1, rtrv-e1, rtrv-t1 A failure occurred while reading the E1/T1 table.
  • Page 738 E4000 Messages Command Rejected Messages Recovery Enter the chg-ls command to update apc/sapc group code. E4062 Cmd Rej: Inhibit IPSM card(s) before changing feature status Commands Used: chg-ctrl-feat You must first inhibit all IPSM cards in the system before the EAGLE OA&M IP Security Enhancements feature can be turned on or off.
  • Page 739 Command Rejected Messages E4000 Messages E4064 Cmd Rej: Host Name Referenced by Application Socket or Association Commands Used: dlt-ip-host You cannot delete a host name from the IP Host table if the host name is still referenced by one or more application sockets or associations. Before a host name can be deleted from the IP Host table, you must first delete all application socket or association references to the host name.
  • Page 740 E4000 Messages Command Rejected Messages E4066 Cmd Rej: Matching routing key already entered for AS Commands Used: ent-appl-rtkey The specified AS name (asname) parameter and routing key could not be added to the Routing Key table because an entry that matches the specified AS name and routing key already exists in the Routing Key table.
  • Page 741 Command Rejected Messages E4000 Messages Recovery Re-enter the command specifying either the sname or the asname parameter. Refer to the Commands Manual for detailed information about the use of these commands. E4069 Cmd Rej: Entry already exists with specified GTIN24-TT-NP(V)-NAI(V)-SSN Commands Used: ent-srvsel You specified an entry that matches an existing gtin24, tt, np/nai or npv/naiv, and ssn parameter combination, which is not allowed.
  • Page 742 E4000 Messages Command Rejected Messages E4075 Cmd Rej: Invalid name for adapter type Commands Used: chg-appl-sock, chg-assoc, dlt-assoc The command specified a name that is invalid for the IP connection type. The command was rejected to prevent the erroneous change or deletion of a provisioned IP connection.
  • Page 743 Command Rejected Messages E4000 Messages E4077 Cmd Rej: Parameters incompatible with adapter type Commands Used: dlt-appl-rtkey You cannot specify the rcontext and loc parameters together in the same command line. The loc parameter is only used with dynamic (TALI-only) routing keys and dynamic routing keys do not support routing context. Recovery Re-enter the dlt-appl-rtkey command specifying the rcontext and loc parameters using separate command lines.
  • Page 744 E4000 Messages Command Rejected Messages E4081 Cmd Rej: Maximum number of connections already provisioned for AS Commands Used: ent-as You entered a command to add an M3UA/SUA association to an existing application server (AS). The AS already has the maximum of 16 associations (M3UA/SUA/M2PA IP connections).
  • Page 745 Command Rejected Messages E4000 Messages Recovery Re-enter the ent-gsmmap-scrn command that generated this error message specifying either * or numbers for the np and naiv parameters. E4089 Cmd Rej: Unable to change adapter when assigned to an AS Commands Used: chg-assoc You entered a command to change the adapter value (M3UA, SUA, or M2PA) for an association.
  • Page 746 E4000 Messages Command Rejected Messages E4092 Cmd Rej: Too many associations per SLK Commands Used: chg-assoc You entered a command that would result in more than one association per signalling link. On IPLIM/IPLIMI cards only one association is allowed per signalling link.
  • Page 747 Command Rejected Messages E4000 Messages E4096 Cmd Rej: Association name already exists Commands Used: ent-assoc You entered a command to add an association to the IPAPSOCK table. The table already contains an association with the name that you specified in the command. Recovery 1.
  • Page 748 E4000 Messages Command Rejected Messages The connection state of the associations bound to the M3UA/SUA associations for the AS must be open=no before you can enter, change, or delete the AS. Recovery - chg-assoc, dlt-assoc 1. Display the associations and their connection states. Enter the rtrv-assoc command.
  • Page 749 Command Rejected Messages E4100 Messages Recovery 1. Display the association names that currently exist in the IPAPSOCK table. Enter the rtrv-assoc command. Verify that you specified an existing association name. 2. Re-enter the command specifying an existing association name, as shown in the output from step 1.
  • Page 750 The EDBADCM GPL is used by the DCM card to transmit the LSMS LNP database to the EAGLE 5 ISS for enhanced bulk download. The EDBABLM GPL is used by the TSM card for enhanced bulk download. If LNP ELAP Configuration is turned on, the Eagle LNP Application Processor (ELAP) provides the functionality for accomplishing bulk loading.
  • Page 751 Command Rejected Messages E4100 Messages • If none of the features listed in this message description are turned on, you cannot use the db=mps parameter in the rept-stat-db command. You can enter the rept-stat-db command specifying other parameter values for database and card status information. E4106 Cmd Rej: Use REPT-STAT-MPS when LNP ELAP Configuration is ON Commands Used: rept-stat-lsms The LNP ELAP Configuration feature is turned on in your system;...
  • Page 752 E4100 Messages Command Rejected Messages E4108 Cmd Rej: Host assignment to IPLIM/IPLIMI card not supported Commands Used: chg-assoc, ent-assoc You entered a command to add an association to the IPAPSOCK table or change the characteristics of an association in the table. You specified a port that is on an IPLIM or IPLIMI card.
  • Page 753 Command Rejected Messages E4100 Messages E4113 Cmd Rej: Measurement collection in progress, Retry later Commands Used: copy-disk, format-disk The command you entered is not allowed at this time because the OAM measurements collection is in progress. Measurement requirements for disk access are not compatible with the copy-disk and format-disk commands.
  • Page 754 E4100 Messages Command Rejected Messages Recovery Re-enter the command specifying dir=itoa and the tti parameter. E4116 Cmd Rej: Wildcard/Asterisk invalid for direction of BOTH Commands Used: chg-gtcnv, dlt-gtcnv, ent-gtcnv The use of wildcards is not allowed if the direction of conversion is both (dir=both).
  • Page 755 Command Rejected Messages E4100 Messages Refer to the Commands Manual for details about the valid use of wildcards with these command. Recovery Re-enter the command specifying the tti=*, np=*, and nai=* parameters when specifying dir=itoa. E4119 Cmd Rej: Key values: DIR, TTA, TTI, NP, NAI already exist Commands Used: ent-gtcnv The command is invalid because the key dir, tta, tti, np, or nai value(s) have already been specified for this Global Title Conversion table entry.
  • Page 756 E4100 Messages Command Rejected Messages Recovery Re-enter the command specifying encode=hdb3 for the 2-port E1 card. E4122 Cmd Rej: Both NP and NAI must be specified if either is present Commands Used: chg-gtcnv, dlt-gtcnv If you specify either the np or nai parameter, you must specify both of these parameters.
  • Page 757 Command Rejected Messages E4100 Messages Recovery 1. Display all apc/sapc entries for the specified linkset. Enter the rtrv-ls:lsn command. 2. Delete the apc/sapc entry. Enter the chg-ls command specifying action=delete, if necessary. E4125 Cmd Rej: Maximum SAPC entries exceeded Commands Used: chg-ls No additional secondary adjacent point code (sapc) entry can be added.
  • Page 758 E4100 Messages Command Rejected Messages Recovery 1. Display all the destination point codes in the Destination Point Code table. Enter the rtrv-ls:lsn command for the given linkset. 2. Re-enter the chg-ls command specifying a point code from the output in Step 1.
  • Page 759 Command Rejected Messages E4100 Messages Recovery 1. For the dlt-na command, enter the rtrv-na command to display the existing network appearances. Verify the network appearance that you want to delete. 2. Re-enter the command that generated this message without specifying the gc parameter for the network appearance.
  • Page 760 E4100 Messages Command Rejected Messages Recovery 1. Enter the rtrv-sid and rtrv-spc commands to verify the group code. 2. Re-enter the ent-na command specifying the correct group code (gc) parameter for the network appearance. E4136 Cmd Rej: NA entry already equipped Commands Used: ent-na You entered a command to define a network appearance that already exists in the Network Appearance table.
  • Page 761 Command Rejected Messages E4100 Messages E4139 Cmd Rej: RC Already Equipped Commands Used: chg-appl-rtkey, ent-appl-rtkey You attempted to add or change the routing context value of a routing key without satisfying the following criteria: • The routing context value in a routing key must be unique (multiple routing keys can not have identical routing context values).
  • Page 762 E4100 Messages Command Rejected Messages E4146 Cmd Rej: CTX parameter is invalid for this card Commands Used: ent-bp You cannot specify the bit-mapped microengine context mask (ctx) parameter for a card that is not an IXP-based card with processor type=IXP. Recovery Re-enter the ent-bp command specifying the correct format and parameters.
  • Page 763 Command Rejected Messages E4100 Messages E4149 Cmd Rej: ARM register must be specified Commands Used: ent-bp The ca, cb, and drarm register values must be specified for an IXP-based card with processor type=arm. Recovery Re-enter the ent-bp command specifying a valid combination of parameters. Valid ca, cb, and drarm register values for an IXP-based card ARM processor are sp, lr, pc, and r0..r15.
  • Page 764 E4100 Messages Command Rejected Messages E4152 Cmd Rej: Invalid combination of TYPE and DATA parameters Commands Used: ent-bp The data parameter is only valid with breakpoint type=data. Recovery Re-enter the ent-bp command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of the ent-bp command.
  • Page 765 Command Rejected Messages E4100 Messages E4155 Cmd Rej: DR parameter is invalid for this card Commands Used: ent-bp The register indirect memory dump (dr) parameter is not valid on an IXP-based card. Recovery Re-enter the ent-bp command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of the ent-bp command.
  • Page 766 E4100 Messages Command Rejected Messages E4158 Cmd Rej: ADDR parameter is invalid for this card Commands Used: ent-bp The addr parameter is valid only for cards with PROM-based COM processors (such as TSMs); that is, when proc=com is specified for DS0 cards.A HIPR or IMTPCI card was specified and the ADDR parameter used.
  • Page 767 Command Rejected Messages E4100 Messages E4161 Cmd Rej: Routing Context parameter is required for SUA Commands Used: chg-appl-rtkey, ent-appl-rtkey, ent-as Routing context is mandatory for routing keys associated with an AS containing SUA ASPs. Recovery - chg-appl-rtkey, ent-appl-rtkey You attempted to add or change a routing key without specifying a routing context value.
  • Page 768 E4100 Messages Command Rejected Messages E4166 Cmd Rej: Enhanced GSM Map Screening must be ON Commands Used: enable-ctrl-feat The command to enable the MTP MAP Screening feature was not allowed because the Enhanced GSM MAP (EGMS) feature must be enabled first. NOTE: Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled.
  • Page 769 Command Rejected Messages E4100 Messages E4168 Cmd Rej: At least one Non-Key parm that is to be changed is required Commands Used: chg-gtcnv The command is invalid because it does not specify at least one non-key parameter to be changed. Recovery Re-enter the chg-ctcnv command specifying at least one of these non-key parameters: npdd, npds, nsdd, nsds, or rdmod.
  • Page 770 E4100 Messages Command Rejected Messages Recovery Re-enter the command specifying either prefix digit manipulation or suffix digit manipulation parameters, but not both. E4171 Cmd Rej: SCCP Conversion feature must be enabled Commands Used: chg-gta, chg-gtcnv, chg-gtt, chg-gttset, chg-stpopts, dlt-gtcnv, ent-gta, ent-gtcnv, ent-gtt, ent-gttset, rtrv-gta, rtrv-gtcnv, rtrv-gttset The ANSI/ITU/24 Bit SCCP Conversion feature must be enabled before you can specify the netdom=cross parameter.
  • Page 771 Command Rejected Messages E4100 Messages E4172 Cmd Rej: Can't switch existing Pfx/Sfx, use RDMOD to reset Commands Used: chg-gtcnv You cannot switch the prefix and suffix digit modifier parameters in a single command because they are mutually exclusive. To change the values from prefix to suffix or the reverse, first use the rdmod parameter to reset the current digit modifier values.
  • Page 772 E4100 Messages Command Rejected Messages E4174 Cmd Rej: NGTI only valid when PC and GTTSN are different domains Commands Used: chg-gta, ent-gta The New GTI Code (ngti) parameter is valid only when the translated point code (pc) and GTT set name (gttsn) are different domains. The ngti parameter can be specified only when the translated point code and the translation type are in different domains, or are both in the ITU domain.
  • Page 773 Command Rejected Messages E4100 Messages E4177 Cmd Rej: EIR and INP are mutually exclusive Commands Used: chg-feat, enable-ctrl-feat You cannot enable and turn on the EIR feature if the INP feature is turned on. Conversely, you cannot enable and turn on the INP feature, while the EIR feature is turned on.
  • Page 774 E4179 Cmd Rej: EIR feature cannot be enabled if ASM/TSM is present Commands Used: enable-ctrl-feat The Equipment Identity Register (EIR) feature cannot be enabled if the EAGLE 5 ISS contains TSM cards (i.e., the test verifies that no SCCP GPLs are present). The EIR feature requires DSM cards, not TSM cards.
  • Page 775 Command Rejected Messages E4100 Messages Recovery 1. Display the existing values for the above parameters. Enter the rtrv-srvsel command. 2. Re-enter the ent-srvsel command specifying values that do not already exist in the database for the above parameters. E4182 Cmd Rej: STP True PC and EIR Subsystem do not exist in MAP table Commands Used: ent-ss-appl To reserve an EIR subsystem number (ssn) for an application, the STP true point code/EIR subsystem number combination must be previously defined in the...
  • Page 776 E4100 Messages Command Rejected Messages 3. If both the INP and EIR features are off, perform either of the following: • Turn on the INP features. Enter the chg-feat:inp=on command. • Turn on the EIR feature. Enter the chg-ctrl-feat:eir=on command. NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off.
  • Page 777 Command Rejected Messages E4100 Messages 3. Enable the EIR feature. Enter the enable-ctrl-feat command and the appropriate part number and access key information. Refer to the “Activating the EIR Feature” procedure in the Feature Manual - EIR, and call your Customer Care Center before starting the process. 4.
  • Page 778 E4100 Messages Command Rejected Messages E4188 Cmd Rej: LNP or EIR must be enabled or INP must be ON Commands Used: rtrv-ss-appl This command is not valid unless one of the following conditions is true: the Local Number Portability (LNP) feature is enabled or the Equipment Identity Register (EIR) feature is enabled or the INAP Number Portability (INP) feature is NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off.
  • Page 779 Command Rejected Messages E4100 Messages Recovery Re-enter the command that generated this error message specifying the same ssn value for ITU-I, ITU-N, ITU-I Spare, and ITU-N Spare point codes. E4191 Cmd Rej: GFLEX/GPORT/EIR feature must be on Commands Used: chg-gsmopts This command requires one of the following features turned on: G-Flex, G-Port, or EIR.
  • Page 780 E4100 Messages Command Rejected Messages E4192 Cmd Rej: GFLEX or EIR feature must be on Commands Used: ent-trace, rtrv-data-rtdb The G-Flex or Equipment Identity Register (EIR) feature must be turned on before you can specify the imsi parameter. NOTE: Once a feature that is controlled using a feature bit has been turned on, it cannot be turned off.
  • Page 781 Command Rejected Messages E4100 Messages Call your Customer Care Center if this error message appears again. E4193 Cmd Rej: Spare Point Code Feature must be enabled Commands Used: ent/chg-dstn, ent/dlt-cspc, ent/chg-map, ent-na, ent/dlt/rtrv-spc, ent/chg/vfy-sid, ent/chg/dlt/rtrv-scr-aftpc, ent/chg/dlt/rtrv-scr-cdpa, ent/chg/dlt/rtrv-scr-cgpa, ent/chg/dlt/rtrv-scr-blkdpc, ent/chg/dlt/rtrv-scr-blkopc, ent/chg/dlt/rtrv-scr-destfld, ent/chg/dlt/rtrv-scr-dpc, ent/chg/dlt/rtrv-scr-opc The Spare Point Code feature must be enabled before the above commands can support Spare Point Code parameters.
  • Page 782 E4100 Messages Command Rejected Messages Recovery Re-enter the command without specifying Spare Point Codes. E4196 Cmd Rej: Spare Point Code Feature not compatible with TALI socket Commands Used: chg-appl-sock, enable-ctrl-feat, ent-appl-sock The Spare Point Code feature cannot be enabled if TALI sockets have been provisioned for an IPGWI card.
  • Page 783 Command Rejected Messages E4200 Messages E4199 Cmd Rej: NGTI only valid when PC and TYPE are different domains Commands Used: chg-gtt, ent-gtt The New GTI Code (ngti) parameter is valid only when the translated point code (pc) and translation type (type) are different domains. Recovery 1.
  • Page 784 E4200 Messages Command Rejected Messages Recovery Display the features in the database. Enter the rtrv-feat command to verify the status of the SCCPCNV and TCAPCNV features and the rtrv-ctrl-feat command to verify the status the ANSI-ITU-China SCCP Conversion feature. Call your Customer Care Center if this error message appears again. E4202 Cmd Rej: SCCP Conversion feature requires at least TSM Hardware Commands Used: enable-ctrl-feat You cannot enable the ANSI-ITU-China SCCP Conversion feature because a...
  • Page 785 Command Rejected Messages E4200 Messages Recovery Re-enter the command specifying the enum value equal to or greater than the snum value. E4205 Cmd Rej: ENUM range does not match SNUM: 1-999 or 1000-1499 Commands Used: rtrv-log, rtrv-trbltx You specified the enum value not in the same range as its mate parameter, snum. Both parameters must be in the same range, either 1-999 (for UAMs) or 1000-1499 (For UIMs).
  • Page 786 E4200 Messages Command Rejected Messages Recovery Re-enter the rtrv-log command specifying only the next parameter. E4209 Cmd Rej: OUTGRP and SNUM/ENUM combination invalid Commands Used: rtrv-trbltx You cannot specify both the outgrp and snum/enum parameters. When the outgrp parameter is specified, the snum and enum parameters cannot be specified.
  • Page 787 Command Rejected Messages E4200 Messages Recovery Re-enter the rtrv-log command specifying sdate/stime values greater than the edate/etime. E4212 Cmd Rej: Cannot execute command until table initialization complete Commands Used: rtrv-log You entered a command that cannot be executed until the table initialization of the ELOG and UIM logs has completed.
  • Page 788 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying dev=e1port and the loc and e1port parameters. Refer to the Commands Manual for detailed information about the use of this command. E4215 Cmd Rej: LOC and T1PORT parameter combination must be specified Commands Used: inh-alm, unhb-alm You specified the dev=t1port parameter, which requires that both the loc and the t1port parameters be specified.
  • Page 789 Command Rejected Messages E4200 Messages E4217 Cmd Rej: Linkset cannot reference self as mate Commands Used: chg-ls You cannot specify the linkset itself as the mate. A mate to a linkset must be another unique linkset. Recovery Re-enter the chg-ls command that generated this error message specifying a linkset (lsn=) that is not itself.
  • Page 790 E4200 Messages Command Rejected Messages E4220 Cmd Rej: Mated linksets must have APCs of same network type Commands Used: chg-ls The command is invalid because the parameter and the adjacent point code parameter (apc, apca, apci, apcn, apcn24) are different network linkset types. Mated linksets must have APCs that share a common network type.
  • Page 791 Command Rejected Messages E4200 Messages E4222 Cmd Rej: Card having link in mate linkset must first be inhibited Commands Used: chg-ls The specified card was not OOS-MT-DSBLD (out of service - maintenance disabled). The command is invalid because the card hosting the signaling link in the specified mate linkset is not inhibited.
  • Page 792 E4200 Messages Command Rejected Messages Recovery 1. Verify that the card in the specified location is running an unmated SS7IPGW or IPGWx application. Enter the rtrv-card command. 2. If the card is not running an unmated SS7IPGW or IPGWx application, re-enter the ent-slk command specifying the correct card location.
  • Page 793 Command Rejected Messages E4200 Messages Recovery Re-enter the command that generated this error message specifying both the ngt parameter and the ri=gt parameter. E4235 Cmd Rej: NGT can only be specified when XLAT=DPC or DPCNGT Commands Used: chg-gtt, ent-gtt You specified the ngt parameter without also specifying the xlat=dpc or xlat=dpcngt parameter.
  • Page 794 E4200 Messages Command Rejected Messages E4237 Cmd Rej: NTT can only be specified when XLAT=DPC or DPCNGT Commands Used: chg-gta, ent-gta You specified the ntt parameter without also specifying the xlat=dpc or xlat=dpcngt parameter. When the ANSI-ITU-China SCCP Conversion feature is on, the ntt parameter can be specified only when the xlat parameter value is dpc or dpcngt.
  • Page 795 Command Rejected Messages E4200 Messages Recovery Perform one of the following actions: • If you used the chg-gsmmap-scrn command, re-enter the command and do not specify the cdsr parameter and do specify at least one of these other required parameters: naction, ncdsr, ncgsr, nforbid, npc/npca/ npci/npcn/npcn24, or nssn.
  • Page 796 E4200 Messages Command Rejected Messages E4241 Cmd Rej: Link test must not be running on requested link Commands Used: act-cdl, act-lbp, dact-lbp You entered this command while a tst-slk command was running. These tests cannot be performed simultaneously. Recovery Perform one of the following actions: •...
  • Page 797 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4243 Cmd Rej: Link test command in progress Commands Used: tst-slk You entered this command for a specified signaling link that is already performing a link test. All link test commands are rejected until the current test is completed.
  • Page 798 E4200 Messages Command Rejected Messages E4245 Cmd Rej: Card does not support command driven loopback Commands Used: act-cdl, rept-stat-cdl The card in the specified card location (loc) does not support command-driven loopback. Recovery 1. Enter the rtrv-card command to verify the card type and application at the specified location is one of the following: •...
  • Page 799 Command Rejected Messages E4200 Messages E4247 Cmd Rej: Command driven loopback not in progress Commands Used: dact-cdl You attempted to deactivate a command-driven loopback on a signaling link that is not currently in command-driven loopback but is running a link test. Recovery 1.
  • Page 800 E4200 Messages Command Rejected Messages Recovery 1. Display the existing linksets. Enter the rtrv-ls command linksets. 2. Perform one of the following: • Re-enter the chg-ls command and specify another mate linkset from those listed in the output of step 1 that is suitably equipped as a mate linkset.
  • Page 801 Command Rejected Messages E4200 Messages Recovery Re-enter the ent-ls command that generated this error message without specifying the iptps parameter. Call your Customer Care Center if this error message appears again. E4253 Cmd Rej: LSUSEALM not allowed for non-IPGWx linksets Commands Used: chg-ls, ent-ls You cannot specify the lsusealm parameter for non-IPGWx linksets.
  • Page 802 E4200 Messages Command Rejected Messages Recovery 1. Display the System TPS in the database with the rtrv-ctrl-feat command. Then display the IPTPS values for the existing linksets with the rtrv-ls command. (The error occurs when the sum of the provisioned System TPS plus the new TPS being defined is greater than the system TPS limit).
  • Page 803 Command Rejected Messages E4200 Messages E4258 Cmd Rej: Target card is not a DSM card with VSCCP appl Commands Used: rtrv-data-insrv, rtrv-data-rtdb The card specified by the loc parameter is not a DSM card running the VSCCP application. Recovery 1. Display the cards in the system. Enter the rtrv-card command. DSM VSCCP cards are identified by the entries DSM in the TYPE field and VSCCP in the APPL field in the rtrv-card command output.
  • Page 804 E4200 Messages Command Rejected Messages E4262 Cmd Rej: A specified SI value must be 3 for SUA Commands Used: chg-appl-rtkey, ent-appl-rtkey, ent-as If specified, the service indicator (si) parameter must be (si=3) for routing keys that are associated with SUA Application Servers. For SCCP MSU traffic, the routing key service indicator (si) value associated with an AS containing SUA ASPs must be 3 (SCCP) for the following key types: •...
  • Page 805 Command Rejected Messages E4200 Messages E4264 Cmd Rej: Parameter PCST / NPCST is not allowed with C for blocked SR Commands Used: chg/dlt/ent/rtrv-scr-aftpc, chg/dlt/ent/rtrv-scr-cdpa, chg/dlt/ent/rtrv-scr-cgpa, chg/dlt/ent/rtrv-scr-blkdpc, chg/dlt/ent/rtrv-scr-blkopc, chg/dlt/ent/rtrv-scr-destfld, chg/dlt/ent/rtrv-scr-dpc, chg/dlt/ent/rtrv-scr-opc A command and parameter combination is not allowed: • The command ent-scr-blkopc or ent-scr-blkdpc with combination of parameter pcst and subparameter c is not allowed for a blocked screening reference (SR).
  • Page 806 E4200 Messages Command Rejected Messages E4267 Cmd Rej: Invalid timing source for channel bridging Commands Used: ent-e1, chg-e1, ent-t1, chg-t1 To use the chanbrdg parameter, you must also specify a timing source (e1tsel). The timing source valid entries are master (internal), slave (line), or recovered from its paired port.
  • Page 807 Command Rejected Messages E4200 Messages Recovery Enter the command specifying the screening reference to show all next screening function identifiers, as well as other values for the screening reference. E4270 Cmd Rej: Failed reading Application Socket table Commands Used: enable-cntrl-feat The Application Socket table could not be read.
  • Page 808 E4200 Messages Command Rejected Messages 2. Create an AS with new routing keys and routing context. 3. Change the routing key routing context. • The routing context value in a routing key may only be changed if all of the ASPs associated with the routing key are open=no. For SPLIT AS routing key changes, the old AS and the new AS must both meet this criteria.
  • Page 809 Command Rejected Messages E4200 Messages Recovery 1. Verify the E1PORT setting for the card location in question. Enter the rtrv-e1 command. 2. Re-enter the command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of these commands.
  • Page 810 E4200 Messages Command Rejected Messages E4277 Cmd Rej: LINKCLASS=UCH is not valid for even numbered card loc Commands Used: ent-e1 You cannot specify the linkclass=unchan parameter for even-numbered card locations. Recovery Re-enter the ent-e1 command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of the ent-e1 command.
  • Page 811 Command Rejected Messages E4200 Messages Verify the route is an IPGW route. Enter the rtrv-rte command. Re-enter the command specifying the Private point code prefix. E4280 Cmd Rej: Alias PCs exceed Max allowed for Feature Quantity Commands Used: enable-ctrl-feat You cannot enable the 7000 Routesets feature and the 8000 Routesets feature because 8000 alias point codes are already assigned in the system.
  • Page 812 E4200 Messages Command Rejected Messages Refer to the Commands Manual for detailed information about the use of the ent-slk command. Recovery E5-E1T1 card 1. Verify the E1 port setting for the card location in question. Enter the rtrv-e1 command. 2. Re-enter the ent-slk command specifying link=a for SE-HSL un-channelized links.
  • Page 813 Command Rejected Messages E4200 Messages E4283 Cmd Rej: Command cannot be executed on a Telnet terminal Commands Used: act-file-trns, act-upgrade, lock The specified command can not be issued from a Telnet terminal (terminal IDs 17 to 40). You cannot initiate an upgrade conversion from a Telnet terminal. You cannot initiate a transfer of files in the File Transfer Area from a Telnet terminal.
  • Page 814 E4200 Messages Command Rejected Messages E4285 Cmd Rej: Enhanced GSM Map Screening feature must be ON Commands Used: chg-gsmmap-scrn, chg-gsms-opcode, chg-ls, ent-gsmmap-scrn, ent-gsms-opcode, ent-ls The Enhanced GSM MAP Screening (EGMS) feature must be on when certain parameters are specified. Refer to the Recovery procedures below for the commands and remedial actions required.
  • Page 815 Command Rejected Messages E4200 Messages Recovery - ent-gsms-opcode EGMS feature must be turned on when: • opcode=* • pc or pca is specified Recovery - ent-ls EGMS feature must be turned on when - gsmscrn=on for ANSI linkset Recovery - Verifying the EGMS Feature Review the command and verify the need for the EGMS parameters: 1.
  • Page 816 E4200 Messages Command Rejected Messages Recovery Re-enter the command without specifying the eaddr parameter. E4287 Cmd Rej: CDSR does not exist in the database Commands Used: chg-gsmmap-scrn, dlt-gsmmap-scrn, rtrv-gsmmap-scrn You entered a command containing an OPNAME and CGSR for which a CdPA Screening Reference (cdsr) does not exist.
  • Page 817 Command Rejected Messages E4200 Messages Recovery 1. Display the existing GSM MAP Screening CgPA entries. Enter the rtrv-gsmmap-scrn command. 2. Re-enter the command specifying a value for the cgsr or ncgsr parameters that is not in the output from step 1. E4290 Cmd Rej: CDSR must be specified when NCDSR is specified Commands Used: chg-gsmmap-scrn You cannot specify the ncdsr parameter without specifying the cdsr parameter.
  • Page 818 E4200 Messages Command Rejected Messages 5. Enable the EGMS feature. Enter the enable-ctrl-feat command and the appropriate part number and access key information. Refer to the Commands Manual and the Database Administration Manual – Features for more information about enabling this feature. 6.
  • Page 819 Command Rejected Messages E4200 Messages Recovery 1. Display the existing GSM MAP Screening CdPA entries. Enter the rtrv-gsmmap-scrn command. 2. Re-enter the command specifying a value for the cdsr or the ncdsr parameter that is not in the output from step 1. E4294 Cmd Rej: Meas for Enh GSM MAP Screening not supported on EOAM Commands Used: rept-meas You cannot generate a Measurements Report on an Enhanced Operations,...
  • Page 820 E4200 Messages Command Rejected Messages 2. Display the status of the EIR feature in the database. Enter the rtrv-ctrl-feat command. 3. If the ANSIGFLEX system option is enabled, you must disable it (issue the chg-stpopts:ansigflex=no command), before you can turn on the G-Port, INP, or EIR features.
  • Page 821 Command Rejected Messages E4200 Messages Recovery You cannot specify an ITU entry if the ansigflex=yes parameter has been specified for the system. 1. Disable the ansigflex system option. Enter the chg-stpopts:ansigflex=no command. 2. Re-enter the command specifying ITU service selector. E4298 Cmd Rej: Alias PC table is full Commands Used: chg-dstn, ent-dstn You cannot provision more than 8000 entries in the Alias PC table.
  • Page 822 E4200 Messages Command Rejected Messages E4300 Cmd Rej: Conns cannot exist in rtkeys with and without rcontext Commands Used: chg-appl-rtkey, ent-appl-rtkey, An attempt was made to enter or change the routing context value of a routing key value already associated with an AS that is not allowed. An AS can not be simultaneously assigned to routing keys with routing contexts and to routing keys without routing contexts.
  • Page 823 Command Rejected Messages E4200 Messages Recovery chg-sid 1. Determine the STP self-identity destination point code, CLLI, and capability point codes associated with the STP in its active database. Enter the rtrv-sid command. 2. Verify the PCx value exists. The PCx value must exist to use the chg-sid command.
  • Page 824 E4200 Messages Command Rejected Messages E4318 Cmd Rej: VENDID already exists in VENDID table Commands Used: ent-vendid The specified ID entry is already present in the Vendor ID table. To change vendor information, you must first delete the vendor ID and create a new one. Recovery Re-enter the ent-vendid command specifying a different ID.
  • Page 825 Command Rejected Messages E4200 Messages Recovery 1. Display features in the database. Enter the rtrv-feat and rtrv-ctrl-feat commands. 2. If the correct feature or features are turned on (see the output of step 1), re-enter the command that generated this message. 3.
  • Page 826 E4200 Messages Command Rejected Messages E4322 Cmd Rej: VENDIDLEN may only be changed if VENDID table is empty Commands Used: ent-vendid The VENDIDLEN value may only be changed if the Vendor ID list is empty. VENDIDLEN determines the allowed length for all Vendor ID values and must be entered before any VEND=Vendor ID value is allowed.
  • Page 827 Command Rejected Messages E4200 Messages Recovery 1. Enter the rept-stat-mps command to determine the ELAP version installed. 2. If the installed ELAP version is not 5.0 or higher, you must upgrade the software level. Contact your Customer Care Center for assistance. 3.
  • Page 828 E4200 Messages Command Rejected Messages Recovery 1. Use chg-prefix to provision a prefix for the GSM MAP SRI Redirect feature. 2. Re-enter the ent-vendid command that generated this message. E4328 Cmd Rej: IS412GSM must be provisioned before SERVERPFX Commands Used: chg-gsmopts The IS-41-to-GSM Migration parameter, chg-gsmopts:is412gsm=x, must be provisioned before specifying the serverpfx parameter.
  • Page 829 Command Rejected Messages E4200 Messages 2. Delete the conflicting IP route. Enter the dlt-ip-rte command. 3. Re-enter the chg-netopts command. E4331 Cmd Rej: Specified network addr assigned to a IP card Ethernet Port Commands Used: chg-netopts The IP network address specified by the pvn and pvnmask parameters is the same IP network address assigned to Ethernet A or B of one of the IPLIMx or IPGWx cards.
  • Page 830 E4200 Messages Command Rejected Messages E4334 Cmd Rej: Requires C-linksets parameter tfatcabmlq to be set to 0 Commands Used: chg-ss7opts The TFA/TCA Broadcast Minimum Link Quantity (tfatcabmlq) parameter for one or more C-linksets is not set to 0. The linkset restrict (lsrestrict) parameter cannot be set to off until the tfatcabmlq parameter for all C-linksets is set to 0.
  • Page 831 Command Rejected Messages E4200 Messages E4339 Cmd Rej: Common screening list feature invalid Commands Used: chg-csl, dlt-csl, ent-csl, rtrv-csl The common screening list feature specified is not valid. The part number (pn) parameter or feature name (feature) parameter identify the particular enabled screening feature for which the screening data will be associated.

  • Page 832: Table 2-39. Number Of Allowed Prefixes

    E4200 Messages Command Rejected Messages Recovery Re-enter the chg-prefix command specifying a feature prefix of the correct length. E4343 Cmd Rej: Feature Prefix too long Commands Used: chg-prefix The specified feature prefix length is greater than the maximum prefix-length requirements for that feature-type. The length of the specified feature prefix is too long.
  • Page 833 Command Rejected Messages E4200 Messages E4345 Cmd Rej: Feature Prefix already exists Commands Used: chg-prefix The specified feature prefix already exists. To add or change a prefix, you must first delete a prefix. Recovery Re-enter the chg-prefix command specifying a different feature prefix. 1.
  • Page 834 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying a valid feature name. E4348 Cmd Rej: Feature Prefix Number invalid Commands Used: chg-prefix The value specified for the prefixnum parameter is not valid. Recovery Re-enter the chg-prefix command specifying a valid prefixnum parameter value.
  • Page 835 Command Rejected Messages E4200 Messages E4352 Cmd Rej: SUBNETID table is full Commands Used: ent-subnetid The Subnet ID table maximum allowed number of entries is 50. To add a new entry, you must first delete an existing entry. Recovery 1. Display the Subnet ID table information. Enter the rtrv-subnetid command.
  • Page 836 E4200 Messages Command Rejected Messages 1. Display the Subnet ID table. Enter the rtrv-subnetid command. 2. Delete an existing Subnet ID entry. Enter the dlt-subnetid command. 3. Add the new Subnet ID entry. Enter the ent-subnetid command. E4355 Cmd Rej: SUBNETID does not exist in SUBNETID table Commands Used: dlt-subnetid The specified Subnet ID entry is not in the Subnet ID table.
  • Page 837 Command Rejected Messages E4200 Messages • If the G-Port and GWS (Gateway Screening) features are enabled and turned off perform the following actions: — Enter the chg-ctrl-feat:gport=on and chg-ctrl-feat:gws=on commands. Refer to the Commands Manual and Feature Manual - G-Port for additional details.
  • Page 838 E4200 Messages Command Rejected Messages E4358 Cmd Rej: SUBNETIDLEN may only be changed if SUBNETID table is empty Commands Used: ent-subnetid The subnetidlen value may only be changed if the Subnet ID table is empty. The subnetidlen parameter determines the allowed length (number of digits) for all subnet ID values and must be entered before any subnet ID value can be entered.
  • Page 839 Command Rejected Messages E4200 Messages Recovery 1. Provision a prefix for the ISUP NP with EPAP feature. Enter the chg-prefix command. 2. Re-enter the ent-subnetid command that generated this message. E4360 Cmd Rej: VENDIDLEN must be set before Vendor ID may be entered Commands Used: ent-vendid The vendidlen value must be specified before any Vendor ID may be entered.
  • Page 840 E4200 Messages Command Rejected Messages E4362 Cmd Rej: SUBNETDLEN must be set before Subnet ID may be entered Commands Used: ent-subnetid The subnetidlen value must be specified before any subnet ID may be entered. The subnetidlen determines the allowed length (number of digits) for all subnet ID values and must be specified before any subnetid value can be specified.
  • Page 841 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4365 Cmd Rej: Either TLNP or ISUP NP with EPAP must be enabled Commands Used: chg-gws-actset To provision a GWS TLNP Stop Action, either the Triggerless LNP (TLNP) feature must be turned on, or the ISUP NP with EPAP feature must be enabled.

  • Page 842: Table 2-40. Parameter Combinations For The

    E4200 Messages Command Rejected Messages E4366 Cmd Rej: DEV type is not supported by specified location Commands Used: inh-alm, unhb-alm You specified a card location that does not support the device type specified. The loc parameter must be specified if the device dev=card, slk, dlk, e1port, or t1port parameter is specified.
  • Page 843 Command Rejected Messages E4200 Messages The specified command cannot be assigned to a configurable class. The login command is rejected as a parameter. The login command is available to all users, and can not be assigned to a configurable class. Recovery Re-enter the chg-cmd command.
  • Page 844 E4200 Messages Command Rejected Messages Refer to the Commands Manual for detailed information about the use of the chg-th-alm command. E4374 Cmd Rej: Association in maximum allowed application servers Commands Used: ent-as The maximum number of adapter states (M3U/SUA associations) for a single SS7IPW or IPGWI card is 50.
  • Page 845 Command Rejected Messages E4200 Messages E4376 Cmd Rej: Maximum matching Route Exceptions already exist for DPC Commands Used: chg-rtx, ent-rtx Only one pair of identical exception route conditions, that differ only in their LSN assignment, may exist for a given DPC. •...
  • Page 846 E4378 Cmd Rej: Maximum Route Exceptions already exist for this STP Commands Used: ent-rtx The overall number of exception routes and normal routes that may be defined for the EAGLE 5 ISS cannot be over 8000. Recovery 1. Display the Route table. Enter the rtrv-rte command.
  • Page 847 Command Rejected Messages E4200 Messages For example, the following command entry is not allowed because the specified starting and ending CIC ranges are the same: ent-rtx:dpc=ansi pc:cic={0-16383}:ecic={0-16383} Recovery 1. View the Route table. Enter the rtrv-rtx command. 2. Re-enter the ent-rtx command specifying a CIC range that does not overlap an existing CIC range.
  • Page 848 E4200 Messages Command Rejected Messages A remote host is one that resides in a different network or subnetwork. A local host resides within the EAGLE. Recovery If you are attempting to enter an IP host that does not reside in the EAGLE, then re-enter the ent-ip-host command specifying type=remote.
  • Page 849 Command Rejected Messages E4200 Messages NOTE: An IPLNK entry must be provisioned before an IPHOST entry can be provisioned with a corresponding IP Address. Similarly, the IPHOST entry must be deleted before the IPLNK entry with a corresponding IP Address can be set to 0.0.0.0.
  • Page 850 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying different values for the pointcode1 and pointcode2 parameters. E4388 Cmd Rej: Exception route cannot be assigned to adjacent point code Commands Used: ent-rtx For the ent-rtx command, you cannot specify a Destination Point Code that is also an Adjacent Point Code.
  • Page 851 Command Rejected Messages E4200 Messages Recovery 1. Turn on the Nested Cluster Routing feature. Enter the chg-feat:ncr=on command. 2. Re-enter the ent-rtx command. E4392 Cmd Rej: Assigned SLKs must be deleted before apcntype can be changed Commands Used: ent-ls, chg-ls You cannot change the value of the apcntype parameter for a linkset that still has links assigned to it.
  • Page 852 E4200 Messages Command Rejected Messages For the chg/ent-ls commands, the Origin Based SCCP Routing feature must be enabled whenever the value specified for the gttmode parameter is acdcd, cgacdcd, acdcgcd, acdcdcg, cgcd, cdcg, or cg. For the chg-sccpopts command, the Origin Based SCCP Routing feature must be enabled whenever the specified value for the dfltgttmode is acdcd, cgacdcd, acdcgcd, acdcdcg, cgcd, cdcg, or cg, or when the dfltcgpcasn or dfltcgpcisn parameters are specified.
  • Page 853 Command Rejected Messages E4200 Messages Recovery 1. Display the GTT Selector table. Enter the rtrv-gttsel command specifying the gtin, tt, and (np(v), and nai(v) if gtin=4 or gtin24=4) parameter combination. 2. Re-enter the ent-gttsel command specifying a different range values for the gtin, tt, and (np(v), and nai(v) if gtin=4 or gtin24=4) parameter combination from those that already exist in the GTT Selector table.
  • Page 854 E4200 Messages Command Rejected Messages E4399 Cmd Rej: Set type of GTT Set Name doesn't match Commands Used: chg-gta, ent-gta The value specified for the GTT set name (gttsn) parameter does not match the corresponding set type entry in the GTTSET table. The following GTT set names and matching GTT set types may be specified: •...
  • Page 855 Command Rejected Messages E4200 Messages Recovery Perfom one of the following: Re-enter the command specifying the cgssnsn parameter without specifying the cggtasn, opcsn, cgpcsn, and selid parameters. Re-enter the command specifying the cggtasn, opcsn, cgpcsn, and selid parameters without specifying the cgssnsn parameter. E4402 Cmd Rej: SETTYPE must be CDGTA when NETDOM=CROSS Commands Used: chg-gttset, ent-gttset, rtrv-gttset For the ent-gttset command, the value specified for the GTT set type (settype)
  • Page 856 E4200 Messages Command Rejected Messages E4404 Cmd Rej: End value must be greater than or equal to a starting value Commands Used: chg-gta, chg-rtx, dlt-gta, dlt-rtx, ent-gta, ent-rtx, rtrv-gta, rtrv-rtx For the ent/chg/dlt/rtrv-gta commands, the value specified for the ecgssn must be greater than or equal to the value specified for the cgssn.
  • Page 857 Command Rejected Messages E4200 Messages E4407 Cmd Rej: CGPCx parm must be specified if GTTSN is type of CGPC Commands Used: ent-gta, chg-gta, dlt-gta The cgpc/cgpca/cgpci/cgpcn/cgpcn24 parameter must be specified if the value specified for the GTTSN set type is cgpc. Recovery Re-enter the command specifying the cgpc/cgpca/cgpci/cgpcn/cgpcn24 parameter, and a value for the GTTSN set type of cgpc.
  • Page 858 E4200 Messages Command Rejected Messages E4410 Cmd Rej: CgPA GTT Selector already exists in GTIN24-TT-NP(V)-NAI(V) Commands Used: ent-gttsel The CgPA GTT Selector could not be added to the GTT Selector table because an entry that matches the specified gtin24, tt, np(v), nai(v), cgssn and/or selid parameter combination already exists.
  • Page 859 Command Rejected Messages E4200 Messages E4413 Cmd Rej: CgPA GTT Selector already exists in GTI-TT-NP(V)-NAI(V) Commands Used: ent-gttsel The CgPA GTT Selector could not be added to the GTT Selector table because an entry that matches the specified gti, tt, np(v), nai(v), cgssn and/or selid parameter combination already exists.
  • Page 860 E4200 Messages Command Rejected Messages E4416 Cmd Rej: Cannot delete to DSTN that has exception routes Commands Used: dlt-rtx You cannot delete the last route to a destination that is referenced by the Route table. A Route table entry exists that is referenced by the destination point code. Recovery 1.
  • Page 861 Command Rejected Messages E4200 Messages Recovery 1. Verify that the system contains only DSM cards and VSCCP APPLs with the Flexible GTT Load-Sharing feature turned on. Enter the rtrv-card command. If necessary, install DSM cards provisioned with the VSCCP application. 2.
  • Page 862 E4200 Messages Command Rejected Messages Recovery Re-enter the rtrv-data-gtt command specifying both the opc parameter and the cdgta parameter. E4443 Cmd Rej: CGGTA or CGPC or OPC must be specified Commands Used: rtrv-data-gtt If the cgssn parameter is specified, then either cggta or cgpc or opc parameter must be specified.
  • Page 863 Command Rejected Messages E4200 Messages E4448 Cmd Rej: Too many IP connection states per card Commands Used: chg-appl-sock, chg-assoc, ent-appl-sock, ent-as There are per card and per system limits on the maximum number of sockets supported: the maximum number of sockets per Local Host on SS7IPGW/IPGWI cards is 50, the maximum number of sockets per signaling link on IPLIM/IPLIMI cards is 1, and the maximum number of IP connections per system is 4000.
  • Page 864 E4200 Messages Command Rejected Messages Recovery Re-enter the chg-sccpopts command specifying a value of cgpc for the the GTT set type. E4455 Cmd Rej: CGGTASN/CGPCSN must be specified if CGSSN/SELID is specified Commands Used: chg-gttsel, ent-gttsel The cggtasn or the cgpcsn parameter must be specified if the cgssn and/or selid parameters are specified.
  • Page 865 Command Rejected Messages E4200 Messages Recovery Re-enter the command specifying a value for the selid parameter and GTTSN whose settype=cdgta. E4458 Cmd Rej: Common screening list feature is required Commands Used: chg-csl, dlt-csl, ent-csl An enabled feature that uses a common screening list must be specified using either a valid part number (pn) or feature name.
  • Page 866 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of these commands. E4461 Cmd Rej: Common screening list entry already exists Commands Used: ent-csl The specified digit string (ds) entry already exists for the specified feature and screening list.
  • Page 867 Command Rejected Messages E4200 Messages Refer to the Commands Manual for detailed information about the use of these commands. E4466 Cmd Rej: Common screening list is full Comands Used: ent-csl The common screening list for the specified feature is full. Recovery 1.
  • Page 868 E4200 Messages Command Rejected Messages 2. Verify the feature was purchased and installed in your system. Contact your Customer Care Center if you need assistance. 3. If you have purchased and installed the feature in your system, enable the feature. Enter the enable-ctrl-feat command and the appropriate part number and access key information.
  • Page 869 Command Rejected Messages E4200 Messages E4471 Cmd Rej: SSNSELID entry does not exist Commands Used: chg-gttsel The value specified for the cgssn and/or selid parameter does not exist in the SSNSELID table. If the specified cgssn and/or selid does not exist in SSNSELID table, it cannot be changed.
  • Page 870 E4200 Messages Command Rejected Messages Call your Customer Care Center if this error message appears again. E4479 Cmd Rej: MRNSET must be specified (only) if FGTTLS feature is enabled Commands Used: chg-gta, chg-gtt, chg-mrn, dlt-mrn, ent-gta, ent-gtt, ent-mrn, rtrv-mrn The Flexible GTT Loadsharing (FGTTLS) feature must be enabled before the mrnset parameter can be specified.
  • Page 871 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4482 Cmd Rej: Multiple groups are allowed only in default MRNSET Commands Used: ent-mrn You cannot add a group to an existing MRNSET that is not the default MRNSET. The default MRNSET can have any number of load sharing groups in order to maintain compatibility with existing functionality.
  • Page 872 E4200 Messages Command Rejected Messages Recovery 1. Display the GT Translations. Enter the rtrv-gtt or rtrv-gta commands. 2. Delete the specified pc from the GTT table. Enter the dlt-gtt or dlt-gta commands. 3. Delete the specified pc from the MRN table. Re-enter the dlt-mrn command. Call your Customer Care Center if this error message appears again.
  • Page 873 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4487 Cmd Rej: GTI domain doesn’t match CGGTASN/CGPCSN domain Commands Used: chg-gttsel, ent-gttsel The CgPA GTA GTT Set Name or CgPA PC GTT Set Name network domain does not match the network domain specified by the Global Title Indicator (gti/gtia/gtii/gtin/gtin24) parameter.
  • Page 874 E4200 Messages Command Rejected Messages Refer to the Commands Manual for detailed information about the use of these commands. E4490 Cmd Rej: Card type must be VXWSLAN for a 100Mbit link Commands Used: ent-dlk You specified a value of 100 for the speed parameter, but the specified card location is not provisioned for the SLAN Enhancement.
  • Page 875 Command Rejected Messages E4200 Messages Recovery Re-enter the command specifying a valid ds parameter value for the specified feature and list type. E4493 Cmd Rej: Common screening list DS length invalid Commands Used: chg-csl, ent-csl The specified digit string length is invalid for the screening feature and list type. The length of the digit string that is specified for the ds parameter must be valid for the screening feature and list type.
  • Page 876 E4200 Messages Command Rejected Messages Recovery Re-enter the rtrv-data-insrv command specifying the correct format and parameters. Refer to the Commands Manual for detailed information about the use of the rtrv-data-insrv command. E4497 Cmd Rej: ICNP feature must be activated Commands Used: rtrv-data-insrv The IntraCarrier Number Portability and IN Triggers (ICNP) feature must be enabled and turned on for the IN Service table to exist for data retrieval.
  • Page 877 Command Rejected Messages E4200 Messages E4498 Cmd Rej: The Prepaid IDP Query Relay Feature Must be Enabled Commands Used: chg-prefix The IDPR feature must be enabled before a prefix can be changed or provisioned for the Prepaid IDP Query Relay (IDPR) feature. Recovery 1.
  • Page 878 E4200 Messages Command Rejected Messages E4500 Cmd Rej: Prepaid IDP Query Relay feature must be ON when (N)SERV=IDPR Commands Used: ent-srvsel, rtrv-srvsel The Prepaid IDP Query Relay (IDPR) feature must be turned on before the idpr parameter value can be specified. Recovery 1.
  • Page 879 Command Rejected Messages E4200 Messages E4502 Cmd Rej: GTT must be on before IDPR can be enabled Commands Used: chg-feat You cannot turn on the IDPR feature with the Global Title Translation (GTT) feature turned off. The GTT feature must be enabled and turned on (gtt=on) before the IDPR feature can be enabled and turned on (idpr=on).
  • Page 880 E4200 Messages Command Rejected Messages 5. Turn on the GTT feature. Enter the chg-feat:gtt=on command. 6. Re-enter the enable-ctrl-feat command. Call your Customer Care Center if this error message appears again. E4504 Cmd Rej: IDPR cannot be enabled if ASM/TSM is present Commands Used: enable-ctrl-feat The IDPR feature cannot be enabled if ASM/TSM cards are present in the system.
  • Page 881 Command Rejected Messages E4200 Messages E4506 Cmd Rej: Must specify trigger type with an offset Commands Used: rtrv-data-insrv You specified an offset without specifying a trigger type (tt). A trigger type must be specified with an offset to determine the IN Service entry to output. Recovery Re-enter the rtrv-data-insrv command specifying both the tt and offset parameters.
  • Page 882 E4200 Messages Command Rejected Messages E4509 Cmd Rej: Translation entry already exists Commands Used: ent-gta The specified cgpc or opc translation entry already exists. Recovery Re-enter the ent-gta command specifying a different value for the cgpc or opc parameters. E4510 Cmd Rej: Translation entry does not exist Commands Used: chg-gta, dlt-gta The translation entry for the specified CgPA PC or OPC does not exist.
  • Page 883 Command Rejected Messages E4200 Messages Recovery ent-gttsel and rtrv-gttsel 1. Display the GTTSEL table. Enter the rtrv-gttsel command. 2. Re-enter the ent-gttsel or rtrv-gttsel commands specifiying a valid value for the cdgtasn or gttsn parameter that is provisioned in the database. E4512 Cmd Rej: CgPA GTT Selector doesn't exist in GTI-TT-NP(V)-NAI(V) Commands Used: chg-gttsel The specified cggta gttset/cgpc gttset parameter is not provisioned in the...
  • Page 884 E4200 Messages Command Rejected Messages Recovery - if a GTT selector contains two GTT sets To delete one of the GTT sets. Perform one of the following actions: • Re-enter the chg-gttsel command without specifying none for both the cdgtasn and the cggtasn parameters. •...
  • Page 885 Command Rejected Messages E4200 Messages E4517 Cmd Rej: CDGTASN must not be specified Commands Used: rtrv-gttsel You cannot specify the cdgtasn parameter in the rtrv-gttsel command, given the following two scenarios: When gti=2 and the tt parameter is specified. — OR — When gti=4 and the tt, np/naiv, nai/naiv parameters are specified.
  • Page 886 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying the same domain (either ansi or itu) for both the cgpcsn and gttsn parameters. E4522 Cmd Rej: OPCSN set domain must be the same as GTTSN set domain Commands Used: chg-gta, ent-gta The OPCSN set domain must be the same as the GTTSN set domain, i.e.
  • Page 887 Command Rejected Messages E4200 Messages Refer to the Commands Manual and the Database Administration Manual – Global Title Translation for more information about enabling this feature • Re-enter the command specifying the mapset parameter. Call your Customer Care Center if this error message appears again. E4524 Cmd Rej: Failed Reading MAP table Commands Used: chg-gsmmap-scrn, chg-gsms-opcode, chg-gta, chg-gtt, chg-map, dlt-gsmmap-scrn, dlt-gsms-opcode, dlt-gta,...
  • Page 888 E4200 Messages Command Rejected Messages E4527 Cmd Rej: Specified MAPSET does not exist Commands Used: chg-gsmmap-scrn, chg-gsms-opcode, chg=gta, chg-gtt, chg-map, dlt-map, ent-gsmmap-scrn, ent-gsms-opcode, ent-gta, ent-gtt, rtrv-gsmmap-scrn, rtrv-gsms-opcode, rtrv-gta, rtrv-gtt, rtrv-map The specified MAPSET must exist in the database. Recovery 1. Display the MAP table. Enter the rtrv-map command. 2.
  • Page 889 Command Rejected Messages E4200 Messages Recovery chg-gsms-opcode 1. Display the pc/ssn entries that are in the MAP table. Enter the rtrv-map command. 2. Re-enter the chg-gsms-opcode command specifying a valid pc/ssn that exists in the MAP table. Recovery ent-gsms-opcode 1. Display the pc/ssn entries that are in the MAP table. Enter the rtrv-map command.
  • Page 890 E4200 Messages Command Rejected Messages Recovery Re-enter the command specifying the action parameter as either forward, duplicate, or dupdisc and the mapset parameter. E4531 Cmd Rej: NMAPSET must be specified if FORCE is specified Commands Used: chg-gsms-opcode, chg-gsmmap-scrn The force parameter may be specified only if the new mapset id (nmapset) parameter is specified.
  • Page 891 Command Rejected Messages E4200 Messages Recovery 1. Display the RPC3/MAP table. Enter the rtrv-cspc command. 2. Reassign the specified cspc references in the RPC3/MAP table. Enter the chg-cspc command. 3. Delete the specified cspc from the RPC3/MAP table. Enter the dlt-cspc command.
  • Page 892 E4200 Messages Command Rejected Messages Recovery Detemine if the Origin based SCCP Routing feature is enabled. Enter the rtrv-ctrl-feat command. • If the Origin based SCCP Routing feature is enabled, re-enter the ent-gttset command specifying the settype parameter. • If the Origin based SCCP Routing feature is not enabled, enable the feature.
  • Page 893 Command Rejected Messages E4200 Messages E4539 Cmd Rej: Failed reading FPT table Commands Used: chg-frm-pwr, dlt-frm-pwr, dlt-shlf, ent-frm-pwr, rtrv-frm-pwr The Frame Power Threshold table is inaccessible. The Frame Power Threshold table must be accessible. Recovery Re-enter the command. Call your Customer Care Center if this error message appears again. E4540 Cmd Rej: Failed reading Assembly Power table Commands Used: rtrv-stp The Assembly Power table is inaccessible.
  • Page 894 E4200 Messages Command Rejected Messages Recovery 1. Determine which shelves are provisioned. Enter the rtrv-shlf command. 2. Re-enter the command specifying a value for the frame id parameter for a provisioned frame (shelf is provisioned in that frame). E4542 Cmd Rej: Failed deleting shelf as FPT entry is provisioned Commands Used: dlt-shlf If the equipped shelf is the only provisioned shelf in the frame, the Frame Power Threshold (FPT) entry cannot be configured for the corresponding frame in the...
  • Page 895 Command Rejected Messages E4200 Messages E4544 Cmd Rej: The IDPS for Prepaid Feature Must be Enabled Commands Used: enable-ctrl-feat The IDP Screening for Prepaid feature must be enabled before provisioning is allowed. NOTE: Once a feature that is controlled using a feature access key is permanently enabled, it cannot be disabled.
  • Page 896 E4200 Messages Command Rejected Messages Refer to the Commands Manual for detailed information about the use of the chg-ctrl-feat command. 4. Verify that the IDP Screening for Prepaid feature is turned on. Enter the rtrv-ctrl-feat command. Re-enter the chg-ctrl-feat command that generated this error message.
  • Page 897 Command Rejected Messages E4200 Messages 2. In the output of step 1, if an ASM or TSM card is present in the system, the APPL will be listed as SCCP, which is incompatible with the IDP Screening for Prepaid feature. To support the IDP Screening for Prepaid feature, the system requires a DSM card running the VSCCP application.
  • Page 898 E4200 Messages Command Rejected Messages Recovery Re-enter the inh-alm command specifying dur=timed and both the edate and the etime parameters. E4551 Cmd Rej: DISPLAY parameter is mandatory with DUR parameter Commands Used: rept-stat-alm The display parameter (disp) must be specified if the dur parameter is specified. Recovery Re-enter the rept-stat-alm command specifying both the dur parameter and the disp parameter.
  • Page 899 Command Rejected Messages E4200 Messages Re-enter the rept-stat-alm command without specifying edate parameter. E4554 Cmd Rej: DEV must be either slk, ls, or route if CLLI is specified Commands Used: rept-stat-alm The device parameter must be specified as either slk, ls, or route, if the clli parameter is specified.
  • Page 900 E4200 Messages Command Rejected Messages Recovery Re-enter the chg-m2pa-tset command specifying ver=rfc for the T2 timer. Call your Customer Care Center if this error message appears again. E4557 Cmd Rej: Timer value or SRCTSET required Commands Used: chg-m2pa-tset A timer value or M2PA timer set value (srctset) must be specified. If the srctset parameter is specified, no other timer values can be specified.
  • Page 901 Command Rejected Messages E4200 Messages Recovery 1. Determine which features are turned on in the system. Enter the rtrv-feat and rtrv-ctrl-feat commands. 2. Determine the total number of VSCCP cards provisioned in the system. Enter the rept-stat-sccp or rept-stat-sys command. •...
  • Page 902 E4200 Messages Command Rejected Messages E4564 Cmd Rej: CGGTASN set domain must be the same as GTTSN set domain Commands Used: chg-gta, ent-gta The name specified (either ansi or itu) for the GTT Set Name (gttsn) set domain, and the CGGTA Set Name (cggtasn) set domain, must be the same. Recovery Re-enter the command specifying the same name (either ansi or itu) for both the gttsn and cggtasn parameters.

  • Page 903: Table 2-42. Eagle 5 Iss Link Cards Not Supported

    Once the Origin-Based MTP Routing feature is turned on, any unsupported hardware (link cards) defined in Table 2-42 will auto-inhibit. Table 2-42. EAGLE 5 ISS Link Cards Not Supported Dual-Slot Card LIMDS0 LIMV35 LIMOCU ILA/EILA...
  • Page 904 E4200 Messages Command Rejected Messages Recovery Re-enter the ent/chg-rte command specifying a different DPC since the selected point code (APC or SAPC of an IPGWx linkset) is already assigned a single route. E4583 Cmd Rej: DISPLAY parameter is mandatory with FRM parameter Commands Used: rtrv-stp The display id (display) parameter must be specified if the frame id (frm) parameter is specified.
  • Page 905 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4585 Cmd Rej: Failed Reading SCCP Service Table Commands Used: chg-sccp-serv, dlt-sccp-serv, rtrv-mrn, rtrv-sccp-serv The SCCP Service Table is corrupt or cannot be found by the system. Recovery Re-enter the command.
  • Page 906 E4200 Messages Command Rejected Messages Recovery 1. Display the SCCP Service table. Enter the rtrv-sccp-serv command. 2. Change one of the existing point codes in the SCCP service group. Enter the chg-sccp-serv:pc=xxx-xxx-xxx:rc=xxx command where xxx-xxx-xxx is a point code in the SCCP service group from the output in step 1. E4590 Cmd Rej: Maximum point codes have been allocated to SCCP-SERV set Commands Used: chg-sccp-serv The specified SCCP service group is full.
  • Page 907 Command Rejected Messages E4200 Messages E4594 Cmd Rej: Feature associated with SERV must be ON or enabled Commands Used: chg-sccp-serv, rtrv-mrn, rtrv-sccp-serv The G-Flex feature must be enabled before the serv=gflex parameter can be specified. The G-Port feature must be enabled before the serv=gport parameter can be specified.
  • Page 908 E4200 Messages Command Rejected Messages E4597 Cmd Rej: DPC cannot be IPGWx APC or SAPC Commands Used: ent-appl-rtkey You cannot specify a DPC for a routing key that is the adjacent node (APC) or Secondary Adjacent Point Code (SAPC) for an IPGW linkset. Recovery 1.
  • Page 909 Command Rejected Messages E4200 Messages Call your Customer Care Center if this error message appears again. E4600 Cmd Rej: Must specify either SNAME or ASNAME or RC Commands Used: ent-appl-rtkey Either the sname or asname or rc parameters must be specified. Recovery Re-enter the ent-appl-rtkey command specifying either the sname or the asname or the rc paramenters.
  • Page 910 E4200 Messages Command Rejected Messages Table 2-43. Default Buffer Configuration Sizes Default Buffer Minimum Buffer Maximum Buffer Card Size (KB) Size (KB) Size (KB) DCM/IPGW EDCM/IPLIM EDCM/IPGW E5-ENET/IPLIM E5-ENET/IPGW Recovery 1. Determine the used and total sctp buffer space on the card and the card location.
  • Page 911 Command Rejected Messages E4200 Messages Recovery Re-enter the rtrv-data-gtt command specifying the cgpc parameter. E4607 Cmd Rej: Linkset referenced by exception route Commands Used: dlt-ls The specified linkset is referenced by an exception route. You cannot delete a linkset that is being used by an exception route. Recovery Perform one of the following actions: Re-enter the dlt-ls command specifying a linkset that is not referenced by an...
  • Page 912 E4900 Messages Command Rejected Messages E4900 Cmd Rej: Entry does not exist with specified GTIN24-TT-NP(V)-NAI(V) Commands Used: chg-srvsel, dlt-srvsel You specified an entry that does not match an existing gtin24, tt, np(v), nai(v), and ssn parameter combination as required. Recovery 1.
  • Page 913 Command Rejected Messages E4900 Messages E4903 Cmd Rej: If NGTI is 4, PC cannot be ANSI Commands Used: chg-gta, chg-gtt, ent-gta, ent-gtt You cannot specify an ANSI point code if the new GTI code (ngti) parameter is 4. If ngti=4, you cannot specify an ANSI point code; if you need an ANSI point code, specify ngti=2.
  • Page 914 E4900 Messages Command Rejected Messages 2-900 910-3638-001 Revision B, October 2006...
  • Page 915 SEAS Error Messages Introduction ......................3–2 Message Listing and Description..............3–2 910-3638-001 Revision B, October 2006...
  • Page 916 SEAS Error Messages Introduction This chapter contains an index of all of the Signaling Engineering and Administration System (SEAS) error messages generated by the system. Descriptions include the SEAS commands that trigger the error messages, the equivalent system error messages and commands, and the explanatory text. SEAS error messages are generic pointers to system problems.

  • Page 917: Table 3-1. Seas Cross Reference Table

    SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-DSTN DIFC ENT-DSTN When a PC destination address is added, the STP shall determine whether the corresponding destination is an adjacent signaling point, as evidenced by a match against a far-end point code (FE PC) in its LINK SET entity-set.
  • Page 918 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-DSTN DAAS E2333 ENT-DSTN The STP shall validate the command to ensure that the specified destination address does not already exist in the DESTINATION entity set.
  • Page 919 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-DSTN IDNS E2875 ENT-DSTN If provisioning a cluster destination, it cannot have the same network identifier (NI) and network cluster (NC) codes of any previously defined alias ANSI point codes.
  • Page 920 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTT IDNS E2403 ENT-GTT If a range of GTAs is specified, the endpoint values must be of the same length.
  • Page 921 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTT SNEX E2419 ENT-GTA If a final GTT is specified (RI=SSN) with XLAT=DPC, and FORCE is not specified as "YES", PC must exist in the Remote Point Code/Mated Application table.
  • Page 922 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTT INCE E2453 ENT-GTT Subsystem table for primary remote point code is full. ADD-GTT INCE E2454 ENT-GTT Remote point code table is full. ADD-GTT RINC E2457...
  • Page 923 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTT SNEX E2466 ENT-GTA The Translation Type must match that of an existing ANSI GTT Selector which is assigned to a GTT Set.
  • Page 924 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTT IDNV ENT-GTA Alpha characters may not be specified for GTA. ADD-GTT SAAS ENT-GTT The DPC-SSN-GTA entity must not already exist in the ORDERED GLOBAL TITLE TRANSLATION entity set for that translation type in...
  • Page 925 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-GTWYLS IDNS E3658 ADD-GTWYLS Specifying ACTNAME via the supplier specific parameter block can only occur when NSFI is specified and equal to STOP. ADD-GTWYLS IPMS ADD-GTWYLS...
  • Page 926 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-LS IDNS E2332 ENT-LS Adjacent Point Code must not be defined as an alias. This rule is a system-specific rule that SEAS does not enforce.
  • Page 927 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-LS IDNS E2657 ENT-LS The STP shall search its DESTINATION entity set for a PC destination address matching the entered FE PC.
  • Page 928 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRAFTPC IDNS E2495 ENT-SCR-AFTP If ZONE is specified or re-specified as asterisk, AREA and ID must also be asterisk. If AREA is specified or re-specified as asterisk, ID must also be asterisk.
  • Page 929 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRBLKDPC IDNV ENT-SCR-BLKD The screen reference must begin with an alpha character. ADD-SCRBLKDPC IDNS E2136 ENT-SCR-BLKD At least one optional parameter must be specified.
  • Page 930 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRBLKDPC GNSR E2553 ENT-SCR-BLKD If NSFI is not equal to STOP or FAIL, NSR must be specified. ADD-SCRBLKDPC IDNS E2556 ENT-SCR-BLKD A complete point code must be...
  • Page 931 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRBLKOPC IDNS E2136 ENT-SCR-BLKO At least one optional parameter must be specified. ADD-SCRBLKOPC IDNS E2495 ENT-SCR-BLKO If ZONE is specified or re-specified as asterisk, AREA and ID must also be asterisk.
  • Page 932 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRBLKOPC IDNS E2556 ENT-SCR-BLKO A complete point code must be entered, i.e. ‘**’ may not be used for any of the parameters NI, NC or NCM in the case of SEAS commands.
  • Page 933 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRBLKOPC IPNS ENT-SCR-BLKO The Supplier Specific Parameter is not supported. ADD-SCRCDPA IDNS ENT-SCR-CDPA Ranges are not supported for SSN. ADD-SCRCDPA IDNV ENT-SCR-CDPA The screen reference must begin...
  • Page 934 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRCDPA INCE E2565 ENT-SCR-CDPA The command will be rejected if the Gateway Screening rules table already contains the max number of rules.
  • Page 935 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRCGPA GNSR E2553 ENT-SCR-CGPA NSR must be specified if NSFI is not STOP. ADD-SCRCGPA GNSR E2554 ENT-SCR-CGPA NSR must be NULL if the NSFI specified is STOP.
  • Page 936 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRDESTFL GCLII E2511 ENT-SCR-DESTF Point codes specified by NI-NC-NCM must be valid. ADD-SCRDESTFL GCMI E2512 ENT-SCR-DESTF Point codes specified by NI-NC-NCM must be valid.
  • Page 937 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRDPC IDNS E2495 ENT-SCR-DPC If ZONE is specified or re-specified as asterisk, AREA and ID must also be asterisk. If AREA is specified or re-specified as asterisk, ID must also be asterisk.
  • Page 938 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRDPC GNFI E3271 ENT-SCR-DPC The NSFI must be valid for DPC screens. ADD-SCRDPC IPNS ENT-SCR-DPC The Supplier Specific Parameter is not supported.
  • Page 939 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCROPC IDNS E2556 ENT-SCR-OPC A complete point code must be entered, i.e. ‘**’ may not be used for any of the parameters NI, NC or NCM in the case of SEAS commands.
  • Page 940 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRSIO GHCI E2393 ENT-SCR-SIO If H0 is asterisk, H1 must be asterisk or not specified. ADD-SCRSIO GHCI E2488 ENT-SCR-SIO H0 and H1 must be specified is SI is less than or equal 2.
  • Page 941 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ADD-SCRTT IDNV ENT-SCR-TT The screen reference must begin with an alpha character. ADD-SCRTT GNRF E2552 ENT-SCR-TT The screen referenced by NSFI and NSR must already exist.
  • Page 942 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ANSI PC GCMI E2512 ANSI PC If a single value or range other than (000-255) is specified for NCM, then NC must be specified as a single value.
  • Page 943 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-MAP IEC=29 E3124 ENT-MAP Failed reading SS APPL table. ASGN-MAP SAAS E3290 ENT-MAP True point code cannot already exist in the MATED APPLICATIONS entity set.
  • Page 944 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-RTE INCE E2353 ENT-RTE At most six routes can be defined per routeset. ASGN-RTE SAAS E2355 ENT-RTE The STP must ensure that the ORDERED ROUTE entity set of the active database does not already contain a destination and linkset...
  • Page 945 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-RTE IDNS E2878 ENT-RTE Ordered routes cannot be assigned to a destination that is a member of a provisioned cluster (NI-NC-*); destinations comprising a cluster inherit their ordered routes from its cluster if NCAI is specified as NO.
  • Page 946 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SID IDNS E2186 CHG-SID STP capability point code must not have been previously defined as a route destination point code. ASGN-SID IDNS E2189...
  • Page 947 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SID IDNS CHG-SID A range of Capability Codes cannot be specified. ASGN-SID INPE CHG-SID “none” cannot be used with CLLI. ASGN-SLK IDNS E3768...
  • Page 948 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E2126 ENT-SLK Linkset APC type (ITU/ANSI) must match application type of card. ASGN-SLK IDNS E2131 ENT-SLK If application is ATMITU, then ATMANSI specific parameters, LSL and IP Link parameters shouldn’t be specified.
  • Page 949 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E2212 ENT-SLK The command is rejected if the E1LOC parameter is specified and the type of card specified by E1LOC is not LIME1.
  • Page 950 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E2748 ENT-SLK The command will be rejected if TS is not specified in the range of 1-24. ASGN-SLK IDNS E2972...
  • Page 951 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E3404 ENT-SLK VCI values 0..4 and 6..31 are reserved and cannot be specified. ASGN-SLK SESW E3404 ENT-SLK VCI values 0..4 and 6..31 are reserved and cannot be specified.
  • Page 952 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E3491 ENT-SLK The specified port is channel bridged with the parent port. ASGN-SLK IDNS E3494 ENT-SLK If specified link is A4, B4, …, A31, B31, card running must be HC-MIM - Link a4, b4,..., a31, b31 is invalid parameter for channel card.
  • Page 953 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code ASGN-SLK IDNS E4045 ENT-SLK If LSN references a link set which specifies MULTGC=YES, card application must be IPGWI or IPLIMI.
  • Page 954 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-DSTN DISI E2163 CHG-DSTN The STP shall validate the command instructions and ensure that, if a new destination identifier is specified, it is not equal to the STP’s own self-identity CLLI.
  • Page 955 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-DSTN IDNS E2868 CHG-DSTN The STP shall ensure that no argument for NCAI is entered if the destination address is not a cluster destination.
  • Page 956 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTT SNEX E2402 CHG-GTA The specified GTA range must exist for the specified GTT Set in the STP active data base (note that an exact match is not required).
  • Page 957 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTT SDNE E2417 CHG-GTT The specified Point Code must exist in routing table. NOTE: The following clause applies only to the DBS software base.
  • Page 958 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTT SNEX E2436 CHG-GTA If the new or existing RI=SSN and the new or existing XLAT=DPCSSN, then the new or existing PC-SSN must be populated in the Remote Point Code/Mated Application table, unless FORCE is specified as...
  • Page 959 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTT SNEX E2466 CHG-GTT The specified Translation Type must exist. CHG-GTT SEHW E2648 CHG-GTA Route table not accessible. CHG-GTT SEHW E2648 CHG-GTT Route table not accessible.
  • Page 960 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTT RINC CHG-GTT The resulting (new or retained) routing indicator (RI) and SSN must ensure that SSN is from the range 002-255 if and only if RI=D (1), denoting a specific SCCP subsystem at a signaling end-point.
  • Page 961 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-GTWYLS GNFI E2494 CHG-GTWYLS The NSFI must be in the range (STOP, OPC, DPC, BLKDPC, BLKOPC, SIO). CHG-GTWYLS GNRF E2552 CHG-GTWYLS The NSFI/NSR combo must exist.
  • Page 962 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-LS IDNS E2167 CHG-LS The specified Adjacent Point Code must not match any of the STP’s capability codes as specified in its self-identity.
  • Page 963 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-LS IDNS E2341 CHG-LS The point code types of the old APC and the new APC must match. This rule is a system-specific rule that SEAS does not enforce.
  • Page 964 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-LS IDNS E2657 CHG-LS APC must have been previously defined. This rule is a system specific rule that SEAS does not enforce. SEAS’s view of the database requires that Destination entities be validated against Link Set entities.
  • Page 965 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-LS IDNS E2866 CHG-LS TFATCABMLQ is invalid for C-link sets unless ss7opts lsrestrict is on. For C-link sets it is never a primary route (except to reach STP’s mate).
  • Page 966 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-MAP SNEX E2445 CHG-MAP PC and SSN are not primary applications. CHG-MAP SNEX E2452 CHG-MAP Remote point code does not exist in MAP table.
  • Page 967 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-RTE LSTI E2349 CHG-RTE The STP must ensure that, if a specified destination address is a network cluster address (NI-NC), the linkset Type of the linkset used in the ordered route is not inconsistent with cluster routing, i.e., that the...
  • Page 968 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-RTE IDNS E2885 CHG-RTE If the specified destination address is a full point code address (NI-NC-NCM) and is a member of a provisioned cluster (NI-NC-*), attributes of the ordered routes assigned to it cannot be changed if...
  • Page 969 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRAFTPC IDNV CHG-SCR-AFTP The screen reference must begin with an alpha character. CHG-SCRAFTPC IDNS E2495 CHG-SCR-AFTP If ZONE is specified or re-specified as asterisk, AREA and ID must also be asterisk.
  • Page 970 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRBLKDPC IDNV CHG-SCR-BLKD The screen reference must begin with an alpha character. CHG-SCRBLKDPC IDNS E2136 CHG-SCR-BLKD At least one optional parameter must be specified.
  • Page 971 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRBLKDPC IDNV E2527 CHG-SCR-BLKD NNI, NNC, NNCM, NAREA, NZONE, NID, NMSA, NSSA, NSP, and NPC must not equal C, when changing a screening entry who’s NSFI is equal to FAIL.
  • Page 972 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRBLKDPC GAEX E2558 CHG-SCR-BLKD The new blocked DPC given by NNI-NNC-NNC, NZONE-NAREA-NID, NMSA-NSSA-NSP, or NNPC must not already exist as specified or within an existing range of DPCs.
  • Page 973 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRBLKOPC GCMI E2512 CHG-SCR-BLKO Point codes specified by NI-NC-NCM or NNI-NNC-NNCM must be valid. CHG-SCRBLKOPC GNFI E2547 CHG-SCR-BLKO NSFI can not be FAIL when changing a continue entry.
  • Page 974 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRBLKOPC GNFI E3271 CHG-SCR-BLKO The NSFI must be valid for BLKOPC screens. CHG-SCRBLKOPC GNEX E3272 CHG-SCR-BLKO The blocked OPC defined by NI-NC-NCM, ZONE-AREA-ID, MSA-SSA-SP, or NPC must already exist in the screening reference.
  • Page 975 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRCDPA GNSR E2554 CHG-SCR-CDPA NSR must be NULL if the NSFI specified is STOP. CHG-SCRCDPA GNII E2564 CHG-SCR-CDPA ANSI point code value 000-000-000, and ITU-International point code value 0-000-0 are not allowed.
  • Page 976 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRCGPA IDNS E2556 CHG-SCR-CGPA A complete point code must be entered using one and only one of the four point code types represented by NI-NC-NCM, ZONE-AREA-ID, MSA-SSA-SP, or NPC.
  • Page 977 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRDESTFL IDNS E2495 CHG-SCR-DEST If ZONE is specified or re-specified as asterisk, AREA and ID must also be asterisk. If AREA is specified or re-specified as asterisk, ID must also be asterisk.
  • Page 978 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRDESTFL GNII E2564 CHG-SCR-DEST ANSI point code value 000-000-000, and ITU-International point code value 0-000-0 are not allowed. CHG-SCRDESTFL GNEX E2573 CHG-SCR-DEST The screen reference must exist for...
  • Page 979 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRDPC IDNV E2527 CHG-SCR-DPC NNI, NNC, NNCM, NAREA, NZONE, NID, NMSA-NSSA-NSP, and NPC must not equal C, when changing a screening entry who’s NSFI is equal to FAIL.
  • Page 980 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCR-ISUP IDRE E2060 CHG-SCR-ISUP Low bound exceeds upper bound of range – ISUPMT/TUPMT. SEAS is not applicable for TUP. CHG-SCR-ISUP IDMS E2396...
  • Page 981 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCR-ISUP IDNV E3506 CHG-SCR-ISUP ISUP Message Type must be valid (SEAS only). CHG-SCROPC GNFI CHG-SCR-OPC The NSFI must be valid for OPC screens.
  • Page 982 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCROPC GAEX E2558 CHG-SCR-OPC The new OPC, given by NNI-NNC-NNC, NZONE-NAREA-NID, NMSA-NSSA-NSP, or NNPC must not already exist as specified or within an existing range of OPCs.
  • Page 983 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRSIO GHCI E2490 CHG-SCR-SIO For screening entries containing SI>2, H0 and H1, must not be specified. CHG-SCRSIO GHCI E2490 CHG-SCR-SIO For screening entries containing SI>2 or NSI>2, H0, H1, NH0, and NH1...
  • Page 984 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SCRSIO IDNS CHG-SCR-SIO The current NIC can not be specified as “**”. CHG-SCRSIO IDNS CHG-SCR-SIO The current PRI can not be specified as “**”.
  • Page 985 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHG-SLK IPNS CHG-SLK New encryption option (nencr) cannot be specified. CHG-SLK IPNS CHG-SLK New equipment options (neqopts) cannot be specified CHG-SLK IPNS CHG-SLK...
  • Page 986 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code CHK-UNREF-ENT IPEX CHK-UNREF-EN No more than 10 Entity Set Names may be specified. DISC-SLK IDNS E3494 DLT-SLK If specified link is A4, B4, …, A31, B31, card running must be HC-MIM - Links a4, b4,..., a31, b31 are invalid parameter for channel card.
  • Page 987 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DISC-SLK IDNS E3771 DLT-SLK PORT B not supported for device (IPLIM, IPLIMI, SS7IPGW, IPGWI,ATMANSI). ). Starting with IP7 SG Release 2.1, this error code will not be used for dlt-slk commands related to IPLIM and IPLIMI cards.
  • Page 988 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-DSTN IDRE E2886 DLT-DSTN Destination address must be a full or a cluster point code. DLT-DSTN IDNV E2955 DLT-DSTN Network Routing is only valid if the NRT feature is ON.
  • Page 989 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-GTT IDNC E2420 DLT-GTT If a range of GTAs is specified, the end of range value must be greater than the start of range value.
  • Page 990 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-LS SMEX E2342 DLT-LS The specified link set must have no assigned members. DLT-LS SNEX E2346 DLT-LS The linkset to be deleted must already exist in the STP active database.
  • Page 991 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-RTE SGRD E2356 DLT-RTE The STP must ensure that, for Point Code and Capability Code destinations, if an Ordered GTT object exists with this destination, at least one other entity must exist in the Ordered Route entity set for that...
  • Page 992 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-RTE IDNV E2886 DLT-RTE Destination address (DPC/da) must be a full or a cluster point code. DLT-RTE IDNV E2955 DLT-RTE Network Routing is only valid if the NRT feature is ON.
  • Page 993 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRAFTPC GNEX E2559 DLT-SCR-AFTPC The ATFPC or AFTPC range defined by NI-NC-NCM, ZONE-AREA-ID, MSA-SSA-SP, or NPC must already exist in the screening reference. DLT-SCRAFTPC IDRE E2564...
  • Page 994 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRBLKDPC IDNS E2556 DLT-SCR-BLKD A complete point code must be entered, i.e. ‘**’ may not be used for any of the parameters NI, NC or NCM in the case of SEAS commands.
  • Page 995 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRBLKOPC GREF E2498 DLT-SCR-BLKO The last entry deleted may not be referenced by another screening entry. DLT-SCRBLKOPC GCLI E2511 DLT-SCR-BLKO Point codes specified by NI-NC-NCM must be valid.
  • Page 996 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRCDPA GFII E2508 DLT-SCR-CDPA The SCMGI D parameter must be specified for SSN=1. DLT-SCRCDPA GCLI E2511 DLT-SCR-CDPA Point codes specified by NI-NC-NCM must be valid.
  • Page 997 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRCGPA IDNS E2556 DLT-SCR-CGPA A complete point code must be entered using one and only one of the four point code types represented by NI-NC-NCM, ZONE-AREA-ID, MSA-SSA-SP, or NPC.
  • Page 998 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRDESTFLD IDNV E2527 DLT-SCR-DESTF NNI, NNC, NNCM, NAREA, NZONE, NID, NMSA-NSSA-NSP, and NPC must not equal C, when changing a screening entry who’s NSFI is equal to FAIL.
  • Page 999 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCRDPC IDNV E2527 DLT-SCR-DPC NNI, NNC, NNCM, NAREA, NZONE, NID, NMSA-NSSA-NSP, and NPC must not equal C, when changing a screening entry who’s NSFI is equal to FAIL.
  • Page 1000 SEAS Error Messages Table 3-1. SEAS Cross Reference Table SEAS System System SEAS Command Error Error Explanatory Text Command Code Code DLT-SCR-ISUP IDNV E3303 DLT-SCR-ISUP SEAS only: VALUE 'x' FOR <> PARAMETER IS NOT VALID. DLT-SCR-ISUP IDRE E3306 DLT-SCR-ISUP SEAS only: VALUE 'x' OUT OF RANGE FOR <>...
