- Page 1 STIHL KM 111 R, 131, 131 R Instruction Manual...
-
Page 3: Table Of Contents
Main Parts Specifications Maintenance and Repairs Disposal EC Declaration of Conformity This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process with electronic systems. KM 111 R, KM 131, KM 131 R... -
Page 4: Kombisystem
Manual fuel pump Therefore, some changes, modifications and improvements may not be covered in this manual. Operate manual fuel pump Tube of grease Intake air: Summer operation Intake air: Winter operation Handle heating KM 111 R, KM 131, KM 131 R... -
Page 5: Safety Precautions And Working Techniques
See also notes on "Clothing and Equipment" in the instruction manual of the KombiTool you are using. KM 111 R, KM 131, KM 131 R... - Page 6 To avoid damage, do not Do not fuel a hot engine – fuel may spill throw the machine to the ground when and cause a fire. practicing. KM 111 R, KM 131, KM 131 R...
- Page 7 (e.g. reduced field of vision), problems KM 111 R, KM 131, KM 131 R...
- Page 8 Inspect the ignition lead (insulation in off the engine before changing the Have all other work performed by a good condition, secure connection). KombiTool or attachment. servicing dealer. Check the condition of the muffler. KM 111 R, KM 131, KM 131 R...
-
Page 9: Approved Kombitools
"Mounting the Loop Handle" Not approved for KombiEngines with bike handle Limited suitability for KombiEngines with bike handle Not approved for KM 131 or KM 131 R not approved for KM 111 R KM 111 R, KM 131, KM 131 R... -
Page 10: Mounting The Loop Handle
Insert bolts (7) in the holes – and between the loop handle and control screw them into the barrier bar as handle. far as possible Always leave the barrier bar attached. KM 111 R, KM 131, KM 131 R... -
Page 11: Mounting The Bike Handle
(2) firmly together. Release the wing screw (3) – the clamps are loose once the wing screw has been released. They are pushed apart by the two springs (4 and 5). KM 111 R, KM 131, KM 131 R... - Page 12 NOTICE above to swing the handles up and Do not kink the throttle cable or lay it in turn the handlebar clockwise. tight radii – make sure the throttle trigger moves freely. KM 111 R, KM 131, KM 131 R...
-
Page 13: Adjusting The Throttle Cable
Use a canister approved for storing Use only high-quality brand-name fuel. Pour oil into canister first, then gasoline with a minimum octane rating add gasoline and mix thoroughly. of 90 – leaded or unleaded. KM 111 R, KM 131, KM 131 R... -
Page 14: Fueling
Opening the Tank Cap regulations and environmental requirements. Turn the cap counterclockwise until it can be removed from the tank opening. Remove the tank cap. KM 111 R, KM 131, KM 131 R... -
Page 15: Starting / Stopping The Engine
The choke knob must engage in automatically to the Run position when it position. is released: The ignition is switched on again after the engine stops – the engine is then ready to start. KM 111 R, KM 131, KM 131 R... - Page 16 Check that all settings are correct. Press down the throttle trigger Check that there is fuel in the tank lockout and open the throttle – the and refuel if necessary. choke knob moves to the run KM 111 R, KM 131, KM 131 R...
-
Page 17: Operating Instructions
For longer out-of- service periods – see "Storing the Machine". Install the filter element (3) in the filter housing and fit the cover. Insert the screws (1) and tighten them down firmly. KM 111 R, KM 131, KM 131 R... -
Page 18: Adjusting The Carburetor
1/2 to 3/4 turn in the same direction. WARNING If the attachment continues to run when the engine is idling, have your machine checked and repaired by your servicing dealer. KM 111 R, KM 131, KM 131 R... -
Page 19: Storing The Machine
Arcing may occur if the adapter nut (1) is loose or missing. Working in an easily combustible or explosive atmosphere may cause a fire or an explosion. This can result result in serious injuries or damage to property. KM 111 R, KM 131, KM 131 R... -
Page 20: Maintenance And Care
Have cleaned by servicing dealer If power is low or cranking effort very high, have valve clearance checked Valve clearance and, if necessary, adjusted by servicing dealer Check Spark arresting screen in muffler Clean or replace KM 111 R, KM 131, KM 131 R... - Page 21 All accessible screws and nuts (not adjust- Retighten ing screws) Check Antivibration elements Have replaced by servicing dealer Safety labels Replace Only if there is a noticeable loss of engine power STIHL recommends an authorized STIHL servicing dealer. KM 111 R, KM 131, KM 131 R...
-
Page 22: Main Parts
13 Wing screw 14 Throttle cable retainer 15 Carrying ring 16 Choke lever 17 Air filter cover 18 Fuel tank 19 Loop handle 20 Barrier bar 21 Coupling sleeve 22 Wing screw Serial Number KM 111 R, KM 131, KM 131 R... -
Page 23: Specifications
... 5.0 m/s Inlet valve: 0.10 mm KM 131 R: 3.4 m/s ... 6.1 m/s Noise and vibration data measurements Exhaust valve: 0.10 mm include idling and rated maximum speed in the following ratios. KM 111 R, KM 131, KM 131 R... -
Page 24: Maintenance And Repairs
The applicable exhaust emission requirements are fulfilled by the intended usage and maintenance described in this instruction manual. The type approval expires if the engine is modified in any way. KM 111 R, KM 131, KM 131 R... -
Page 25: Ec Declaration Of Conformity
KombiTools approved by STIHL for use with this KombiEngine. Technical documents deposited at: ANDREAS STIHL AG & Co. KG Produktzulassung (Product Licensing) The year of manufacture and serial number are applied to the product. KM 111 R, KM 131, KM 131 R... - Page 26 English KM 111 R, KM 131, KM 131 R...
