Summary of Contents for Digital Doc IRIS
- Page 1 USB 2.0 Intraoral Camera Camera Installer Powered by Congratulations on your purchase of the IRIS camera. This manual will guide you step by step through the installation and setup of your new camera. Manual MA0023 REV C Digital Doc LLC...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Instructions 2. Cautions 3. Important Safeguards 4. System Requirements / Compatible Software 5. START HERE Installing the Iris Camera Driver 6. Installer Setup 1 7. Installer Setup 2 8. Installer Setup 3 9. Installer Setup Finish 10. -
Page 3: Safety Instructions
Safety Instructions This symbol alerts the user that important literature concerning the operations and maintenance of this unit have been included. Therefore, it should be read carefully in order to avoid any problems. CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. -
Page 4: Cautions
Do not place a container with water or liquid, or any small metallic objects on this unit. If water, liquid, or any metallic object enters this unit, disconnect the USB cable immediately and contact Digital Doc. If smoke, abnormal sound or smell occurs, disconnect the USB cable and contact Digital Doc. -
Page 5: Important Safeguards
Important Safeguards Installation Read and follow Instructions- All of the safety and operating instructions should be read before the intraoral camera is operated. Follow operating and usage instructions. Retain instructions - The safety and operating instructions should be retained for future reference Heed warnings - Comply with all warnings on the camera and in the operating instructions This camera should be operated only from the type of power source indicated. - Page 6 USB 2.0 interface with high power port CD-ROM or DVD drive Imaging Software Internet connectivity recommended Windows XP Professional or above with a minimum of Service Pack 2 IRIS Compatible Imaging Software AbelDent Kodak Digital Imaging OEM Versions of Apteryx Adstra...
- Page 7 Installing the IRIS START HERE Camera Driver Step 1: The first step in the installation is to determine if you are using a 32 or 64bit operating system. RIGHT click on Computer Select Start from the left or top and select Properties of your task bar.
-
Page 8: Installer Setup 1
DO NOT connect the camera Installer Setup 1 until you have completed the driver installation Step 2: Insert the driver disc from the side panel of this manual into your CD drive. Step 3: Browse to your CD ROM drive and Choose either the 32-bit (X86) 64-bit (X64) driver file and double click to open. -
Page 9: Installer Setup Finish
Step 9: Select the Software you will be Choose Install after using to view images from the confirming your Software camera and then choose next. selection If your Software is not listed please contact Digital Doc 1.800.518.1102 Select your Software here... - Page 10 Installer Setup 3 If at any point during the installation a “Windows Security” prompt appears, select Continue Anyway (Win XP) or Install (Win 7) Step 10: Choose Next once the Status bar has filled DO NOT close any command / DOS and the drivers have screens during the installation transferred...
-
Page 11: Installer Setup Finish
Digital Doc website for setup instructions on your specific software Along with the camera driver package you will now have a file under All Programs called Digital Doc. This file contains utilities for testing the camera as well as refresh and restart services. Continue... -
Page 12: Connecting The Camera
If the Step 3 : camera is moved Plug the camera cable into the IRIS handpiece. from one port to another When attached, the camera status light will blink on either the computer or green. -
Page 13: Connecting The Camera 2
Digital Doc IRIS Driver Step 8: When the installation is complete choose Finish It is recommended that upon completion of this step you refresh the driver by choosing. START - ALL PROGRAMS - DIGITAL DOC - UTILITIES - REFRESH DRIVERS... -
Page 14: The Iris Handpiece Sheaths
Do not use any abrasive cleaners such as Glutaraldehyde or Discide. Stainless Steel front housing The IRIS camera will automatically shut off after 10 Minutes, if the camera is left idle. Mirror / Anatomic Image Dual Capture... - Page 15 Heat is a factor in any Controls electronic device, It is recommended that the IRIS camera be turned OFF when not in use and not exceed continued use Please see the Practice of more then 10Min.
- Page 16 IRIS Sheaths The IRIS camera will come with a sample pack of sheaths. These sheaths are designed for intra-oral use only. When applying the sheaths, slide the handpiece with the LED’s facing down under the white flap. Push the handpiece in until the end of the sheath is taut, then peel away the top blue layer and the bottom paper layer.
-
Page 17: Iris Camera Accessories
IRIS Camera Accessories Protective Sleeves USB 2.0 1 Box (500 units) Powered Hub Part Number Part Number SH0004 4011565 USB Cable with adapter 15 Ft. Part Number CA0050 USB Cable with adapter 6 Ft. Part Number CA0052-B It is not recommended to... -
Page 18: Trouble Shooting
USB port. The steps below will walk you through the Driver Refresh program for recovery 1.800.518.1102 of these systems. If your issue is not resolved please contact Digital Doc at 1.800.518.1102 Choose START, All Programs. Select Digital Doc, Utilities. Under Utilities select Refresh Drivers. -
Page 19: Warranty, Tech Support & Repair Procedures
Digital Doc LLC does agree to replace any defective camera, free of charge, during the first nintey (90) days from the date of purchase. After the first ninety (90) days, Digital Doc LLC, will repair under warranty the defective item and pay the shipping to return the repaired item to the customer. - Page 20 Digital Doc LLC 4511 Golden Foothill Parkway, Suite # 1 El Dorado Hills, CA. 95762 1.800.518.1102 www.digi-doc.com...
