- Page 1 USERS MANUAL DIGI-DOC.COM 800-518-1102...
-
Page 2: Installation
AVAILABLE ONLINE. THEREFORE, IT SHOULD BE READ ❏ If smoke, abnormal sound or smell occurs, disconnect CAREFULLY IN ORDER TO AVOID ANY PROBLEMS. the battery and contact Digital Doc. ❏ Do not apply impacts to this unit C AU T I O N... - Page 3 Congratulations on your purchase of the Digital Doc LUM G2. This manual will guide you through the setup and use of the LUM G2. STEP 1: Install the LUM G2 software from the USB Drive. Or to download the latest version of software, go to WWW.DIGI-DOC.COM.
- Page 4 STEP 2: Attach the Base section to the Tip section. The top end of the Base fits over the bottom of the Tip. Slide it straight down firmly until it clicks. Tip Section Base Section To Remove: Grasp the Base with your thumb on top and extended over the joint onto the Tip section.
- Page 5 STEP 3: Attaching the LUM G2 to the IRIS 2.0 camera. 1. Use the LUM G2 program to turn the camera lights OFF and the image to Black and White. 2. Put a Camera Sheath over camera BEFORE inserting the camera into the LUM G2 3.
- Page 6 STEP 4: Turn the LUM G2 light LUM G2 lights ON button on back and OFF using the light button on the back. Tip: Camera Focus should be in the #1 position and camera lights TURNED OFF when using the LUM G2.
- Page 7 STEP 5: Position the rubber arms around the tooth with the LUM G2 light turned ON. View through the camera, capture and save.
- Page 8 The Use Of Sub-Illumination And Advanced Digital Technology, For Enhanced Crack & Caries Detection Power Sub-illumination is a detection method that provides the most information easily. It visually represents whether a crack or caries is present. It is based on a law of physics, namely that a beam of light will continue to penetrate through a substance until is meets a space, after which the light beam is reflected.
- Page 9 Disinfecting the LUM G2: 1. Separate the Tip section from the Body section 2. Disinfect the Tip section by autoclave 3. Spray or wipe down the Base section with Ethyl Alcohol (Digi-doc wipes or spray CoEfect by GC) Tip Section...
- Page 10 Battery Replacement: The LUM G2 is battery powered with a Li-ION CR-2032 non-rechargeable coin cell. Remove the battery tray found at the end of the Base section by pulling out the tray cap. Only replace with the recommended model battery.
-
Page 11: Warranty
In the event a product is returned by the dealer, or the end user, and the warranty has expired, Digital Doc LLC reserves the right to collect a reasonable fee from the end user for services mutually agreed upon. Digital Doc LLC does agree to replace any defective unit, free of charge, during the first thirty (30) days from the date of purchase. - Page 12 USERS MANUAL DIGI-DOC.COM 800-518-1102 4789 Golden Foothill Parkway El Dorado Hills, CA 95762 LUM G2-1805...
