Summary of Contents for Ouring 3DTALK-Knight
- Page 1 Knight Installation Instructions 3DTALK Knight...
-
Page 2: Table Of Contents
Jiangsu Ouring 3D Technology Co.,Ltd Contents 1.Product Introduction....................3 1.1Product Description......................3 1.2 Notice..........................3 2.Product profile......................4 2.1 Product Appearance....................4 2.2 Product data.......................15 3.Installing........................17 3.1 Feeding filament.......................18 3.2Adjusting ........................21 3.2.1.Adjusting of the extruder..................21 3.2.2 Adjusting of printing plate..................22 3.3 feeding water into the pump...................24... -
Page 3: Product Introduction
1．Introduction of product 1.1 Production Description 3DTALK-Knight is the high technology digital 3d printer produced by Ouring.It transports the consumables through the feeding pipe, through the wire feeder to the nozzle, and then the nozzle heats to melt the material, and the melted material is extruded through the nozzle in the form of thin wires. -
Page 4: Product Profile
Jiangsu Ouring 3D Technology Co.,Ltd 2.Product Profile 2.1 Product appearance ①Front （6） （5） （4） （7） （1） （2） （3） （1）USB （2）Touch （3）Power connector screen button （4）Right （5）Front （6）cover magazine door （7）Left magazine... - Page 5 Jiangsu Ouring 3D Technology Co.,Ltd ②Side （1） （2） （3） （4） （1）cover （2）front （3） （4） door magazine casing ③Back （1） （2） （3） （4） （1）back （2）fan （3） （4）Net port （DC220V/50Hz） panel Power port...
- Page 6 Jiangsu Ouring 3D Technology Co.,Ltd ④Inner Structure （1） （2） （4） （3） （1）extruder （2）right （3）printing （4）left magazine plate magazine ⑤Inner sight （1） （2） （2）heating part water tank for cooling...
- Page 7 Jiangsu Ouring 3D Technology Co.,Ltd ⑥ extruder sketch （1） （7） ） （2） （3） （6） （5） （4） （1）right （2）cooling fan （3）cooling air （4）right feeding tube flue extruder （5）left （6）adjusting （7）left extruder part feeding tube...
- Page 8 Jiangsu Ouring 3D Technology Co.,Ltd ⑦coordinates sketch...
- Page 9 Jiangsu Ouring 3D Technology Co.,Ltd ⑧function introduction red temperature number white temperature left extruder real time target left extruder temperature temperature set by the software red temperature white temperature right extruder real time target right extruder temperature temperature set by the software...
- Page 10 Jiangsu Ouring 3D Technology Co.,Ltd （the interface of printing ） The model document installed in the machine : the document printed in this Local machine will be stored in the local documen Document disk documen Inset the U disk into this machine : the document stored in this U disk...
- Page 11 Jiangsu Ouring 3D Technology Co.,Ltd pause Press this button when printing to pause.Press it again to continuing printing Stop Stop the printing （interface ） Set the language adjusting the plate...
- Page 12 Jiangsu Ouring 3D Technology Co.,Ltd Changing the filaments changing the connection initialize settings Update of software and hardware Basic information of machine （high class interface ）...
- Page 13 Jiangsu Ouring 3D Technology Co.,Ltd heating room Extruder Adjusting Check out if the room can be Adjust the distance of the heated normally.It can be heated extruder and the plate before printing Controlling Control the XY axis and Control the switch of fan manually...
- Page 14 Jiangsu Ouring 3D Technology Co.,Ltd Bottle of Feeding water X 1 Glue stick X 1 Notice : Please refer to the actual accessories for the accessories in the list of random accessories.
-
Page 15: Product Data
Jiangsu Ouring 3D Technology Co.,Ltd 2.2 DATA ①Specific 3DTALK - Knight Building 254 X 254 X 210mm Thickness 0.05mm - 0.5mm Volume accuracy Position Nozzle Z（2.5μ m）XY（11μ m） resolution diameter 0.2mm-0.8mm Quantity of Nozzle High strength hard nozzles material alloy... - Page 16 Jiangsu Ouring 3D Technology Co.,Ltd system Software Browser+ touch screen 220V Power 1000W Power International plug connection Knight material ABS、PLA、Wood、PETG、Bronze、DuPont Hytrel 4100 Environmental requirements Ambient temperature 15 ° C ~ 30 ° C ; Relative humidity 20% to 50%; Avoid moving the machine and strong vibration during printing work;...
-
Page 17: Installing
Jiangsu Ouring 3D Technology Co.,Ltd 3.Installing and using Installing steps 1 - 3 After the equipment is taken out of the package, it is placed in a horizontal position, and the fixed strip and the protective cotton inside the equipment are completely taken out;... -
Page 18: Feeding Filament
Jiangsu Ouring 3D Technology Co.,Ltd 3.1 Feeding materials Feeding materials steps 1 - 8 Separate the nozzle that needs to be fed from the corresponding tube; the specific method is as follows: Continue to press down on the blue gasket on the feed nozzle and pull out the... - Page 19 Jiangsu Ouring 3D Technology Co.,Ltd (Note: The feeding end of the left feeding box of the feeding box is the left nozzle; the feeding end of the feeding port of the right box is the right nozzle. The material wire exposed by the nozzle end pipe is straightened, and the "wire feeder handle"...
- Page 20 Jiangsu Ouring 3D Technology Co.,Ltd Turn on the power, press the "Power Switch" button at the device power jack, and click the front panel "Switch button" After the system displays the main interface data is normal, click the “Settings” button and select the “In/Return”...
-
Page 21: Adjusting
Jiangsu Ouring 3D Technology Co.,Ltd Note: When you need to withdraw the material from the device, please select the corresponding returning nozzle through “L” and “R” in the “In/Return” interface, and set the appropriate withdrawal by“ ” / “ ” Feed the temperature and click the “Return”... -
Page 22: Adjusting Of Printing Plate
Jiangsu Ouring 3D Technology Co.,Ltd function, "OK to calibrate the print head?" appears, click "OK" When the device nozzle stops running in the middle of the platform, control the height of the platform by controlling the “” button. When the nozzle just touches the platform, click “Start Calibration”. - Page 23 Jiangsu Ouring 3D Technology Co.,Ltd Click "Next" when the nozzle stops running. When the nozzle stops running at the first point on the platform, the following two situations occur: SItuation 1 : situation 2 The “leveling device indicator” is always When the nozzle stops at this point and the on.
-
Page 24: Feeding Water Into The Pump
Jiangsu Ouring 3D Technology Co.,Ltd 3.3 Feeding water When the printed model material needs to set the cabin temperature, please add water to the printer's water pump in advance, and cool down the heat in each motor in the equipment. The water pump is added as follows:... - Page 25 Jiangsu Ouring 3D Technology Co.,Ltd After turning on the "cabin temperature heating" function, the water in the "kettle" is inverted in the "water reservoir", and in the "cabin temperature heating" state, the water level line in the "water reservoir" is maintained by inverting the aqueous solution.
-
Page 26: 4、Instructions Of Printing Material
Jiangsu Ouring 3D Technology Co.,Ltd 4.Instructions of printing material materials ABS Printing Select suitable quality quality thickness Nozzle:0.4mm，Thickness 0.1mm Shell Suggestion 0.8mm - 1.2mm thickness - 0.2mm Printing Temperat Suggestion： Suggestion：80℃ speed ure of if thickness 0.1 then the speed... - Page 27 Jiangsu Ouring 3D Technology Co.,Ltd nozzle for the support extrusion head.) preparati Before printing the model, please apply the matching printing glue on the surface of the platform that is in contact with the model in advance to ensure that the...
- Page 28 Jiangsu Ouring 3D Technology Co.,Ltd PLA+ PLA+ Printing quality ， thickness Shell 0.8mm - 1.2mm Nozzle:0.4mm Thickness thickness 0.1mm - 0.2mm Printing Suggestion: PLA can be printed in Suggestion： speed the normal temperature without Temperat if thickness 0.1 then the speed...
