3.6 The overview screen
The overview screen displays the most important values from different
devices on the network together in one screen. To display the overview,
press the centre button while the device list is displayed. The Blue Power
Panel can also be configured to display the overview screen
automatically after a period of inactivity (see chapter 4.2 for more
information). The appearance of the overview screen depends on which
type of overview has been configured. See chapter 4.3 for more
information.
3.7 Alarms
When a VE.Net device experiences a problem, it will generate an alarm.
The Blue Power Panel will display a message with information about the
alarm. Additionally, the Blue Power Panel can be configured to generate
an audible alarm, and/or close its relay contact.
To acknowledge the alarm, press the right soft-
button. This will hide the pop-up, and disable the
buzzer. However, this does not switch off the relay.
The relay will remain closed until the device that
generated the alarm indicates that the alarm
condition is no longer present.
6
move the cursor in order to edit different
characters.
To stop editing, press the right soft-button to save
the changes, or the left soft-button to restore the
old value.
As long as there are persisting alarm conditions, a
warning will be displayed at the top of the screen.
To view the details of the alarms, press the centre
button. It is not possible to display the overview
screen whilst there are persisting alarm conditions.
