Instructions for the Victron Energy MONITORING PANEL with
DIGITAL MULTI CONTROL PANEL (DMC) and
This publication or parts thereof, may not be reproduced in any form, by any method, for any
purpose. For conditions of use and permission to use this manual for publication in other
than the English language, conctat Victron Energy B.V.
Victron Energy B.V. reserves the right to revise and improve its products as it sees fit. This
publication describes the state of this product at time of its publication and may not reflect at
all times in the future.
Introduction
The MONITORING PANEL with integratet Digital Multi Control Panel and Battery Monitor
BMV - 602 is a device that:
Monitors your battery status (battery voltage and current) and calculate the actual
state of charge of your battery
Monitors and signals AC voltage of three sources (shore, generator and inverter)
Monitors inverter current to the AC consumer
is a remote panel designed to work with all Multis/Quatro¨s and Multi/Quatro systems.
Operation
Installation
WARNING! Be sure that all AC power sources are switched off or disconnected
during installation.
Install the MONITORING PANEL in a dry, well ventilated area. The front of the panel
is attached using the four supplied screws. The MONITORING PANEL may be
mounted in the wall, using the four holes in the front of the panel.
The input cables from the shore, generator, inverter, digital multi control and battery
monitor should be connected according to the the wiring diagram (see figure 1). The
correct wire cross section must be applied for a safe installation. Under sized cables
can cause overheating of the cables.
Tighten all connections well in order to limit transition resistance as far as possible.
Loose connections can cause dangerous overheating of the teminals.
Adjustement of the MONITORING PANEL ist not recommended. After correct
instalation the MONITORING PANEL is ready for use.
BATTERY MONITOR BMV-602
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Blue Power BMV-602 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Victron energy Blue Power BMV-602

  • Page 1 English language, conctat Victron Energy B.V. Victron Energy B.V. reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at time of its publication and may not reflect at all times in the future.
  • Page 2 The wiring to the AC-inputs and outputs must be protected by fuses or miniature • circuits breaker which are suitable for the applied wire cross section. External earth leakage switches( RCD, RCCB) must also be integrated in the wiring All ground connections of the power sources and power consumers must be •...
  • Page 3 Specifications VE MONITORING PANEL Nominal voltage 200 - 250 V AC, Single phase 50 – 60 Hz Nominal frequency Input 1, Shore voltage 200 - 250 V, AC Input 2, Generator voltage 200 - 250 V, AC Input 3, Inverter output voltage 200 - 250 V AC Current transformer (CT) 50/5 A, 2 VA...
  • Page 4 Electrical and installation diagrams, outline drawings...
  • Page 5 MONITORING PANEL wiring with MULTI PLUS...
  • Page 6 MONITORING PANEL wiring with QUATTRO...
