- Page 1 Stellaris® LM3S9D90 Evaluation Kit User’s Manual User ’s Manual EK-LM3S9D90 -00 Co pyrigh t ©2 011 T exas In strumen ts...
- Page 2 Copyright Copyright © 2011 Texas Instruments, Inc. All rights reserved. Stellaris and StellarisWare are registered trademarks of Texas Instruments. ARM and Thumb are registered trademarks, and Cortex is a trademark of ARM Limited. Other names and brands may be claimed as the property of others.
-
Page 3: Table Of Contents
Table of Contents Chapter 1: Stellaris® LM3S9D90 Evaluation Kit Overview ................7 Kit Contents ................................ 8 Using the EK-LM3S9D90............................ 8 Features................................8 Chapter 2: Hardware Description ........................11 Evaluation Board .............................. 11 Functional Description ..........................11 In-Circuit Debug Interface Board ........................14 Functional Description .......................... - Page 4 List of Figures Figure 1-1. LM3S9D90 Evaluation Board ......................7 Figure 1-2. In-Circuit Debug Interface Board..................... 7 Figure 2-1. EK-LM3S9D90 Evaluation Board Block Diagram................11 Figure 2-2. GPIO Pads ............................ 12 Figure 2-3. JTAG/SWD Connector ........................12 Figure 2-4. PWR/UART Connector........................13 Figure 2-5.
- Page 5 List of Tables Table C-1. EK-LM3S9D90 Evaluation Board GPIO Usage................29 July 5, 2011...
- Page 6 July 5, 2011...
-
Page 7: Chapter 1: Stellaris® Lm3S9D90 Evaluation Kit Overview
USB PC port, and two shrouded header connectors for connection to the EK-LM3S9D90 board. Development of software for the EK-LM3S9D90 is simplified by using Texas Instruments’ comprehensive StellarisWare® peripheral driver library and ARM development tools from our tools partners. -
Page 8: Kit Contents
• Sourcery CodeBench development tools • Code Red Technologies development tools • Texas Instruments’ Code Composer Studio™ IDE – Complete documentation – Quickstart application source code – Stellaris® Firmware Development Package with example source code Using the EK-LM3S9D90 The recommended steps for using the EK-LM3S9D90 evaluation kit are: 1. - Page 9 – Includes full source code, example applications, and design files – Develop using tools supporting FastMATH from Keil, IAR, Code Sourcery, and Code Red (using a Stellaris evaluation kit or preferred ARM Cortex-M3 debugger) – Supported by Texas Instruments’ StellarisWare peripheral driver library July 5, 2011...
- Page 10 Stellaris® LM3S9D90 Evaluation Kit Overview July 5, 2011...
-
Page 11: Chapter 2: Hardware Description
Microcontroller, Reset, GPIO Pads, and JTAG (Schematic page 20) Microcontroller The evaluation board uses the Stellaris LM3S9D90 microcontroller. A 16 MHz crystal provides the main oscillator clock which can directly drive the ARM core clock or can drive an internal PLL to increase the core clock up to 80 MHz. -
Page 12: Figure 2-2. Gpio Pads
Hardware Description Reset A reset switch and R-C network connects to the microcontroller’s RSTn input. The reset signal is also connected to the JTAG/SWD connector J1 to allow reset control from the debugger. GPIO Pads Four groups of oversized board pads with a 0.1” spacing provide access to GPIO signals and standard 0.1”... -
Page 13: Figure 2-4. Pwr/Uart Connector
Stellaris® LM3S9D90 Evaluation Kit User’s Manual PWR/UART The PWR/UART connector J2 is used to provide 5 V power from the ICDI board and also to connect the LM3S9D90 UART0 signals. This is a 2x4 fine pitch (0.050") connector, see (Figure 2-4) for signal definition. The UART0 signals are connected to GPIO jumpers JR1 and JR2 and can be disconnected from connector J2 if required, see “GPIO Jumpers”... -
Page 14: In-Circuit Debug Interface Board
Hardware Description In-Circuit Debug Interface Board The ICDI board is used to download and debug programs on the EK-LM3S9D90 evaluation board, but can also be used for debug of other Stellaris boards. A block diagram is shown in Figure 2-5. Figure 2-5. -
Page 15: Figure 2-6. Jtag/Swd Connector J1
Stellaris® LM3S9D90 Evaluation Kit User’s Manual applies when the ICDI is used as the JTAG/SWD debugger and LED D2 (DEBUG ACTIVE) is lit on. In this case only one of the two connectors J1/J3 should be used. The ICDI can also be used as a 20-pin to 10-pin adapter for external JTAG debuggers. Note that the DEBUG ACTIVE LED must be off before connecting any external JTAG debuggers. - Page 16 Hardware Description JTAG / SWD Multiplexer (Schematic page 23) Buffers A set of tri-state buffers is used to multiplex JTAG and SWD signals, and also multiplex the UART VCP_TX signal with the SWO signal. LED D2 (DEBUG ACTIVE) is lit on when these buffers are enabled.
-
Page 17: Chapter 3: Software Development
C H A P T E R 3 Software Development This chapter provides general information on software development as well as instructions for Flash memory programming. Software Description The software provided with the EK-LM3S9D90 provides access to all of the peripheral devices supplied in the design. - Page 18 Software Development To program example applications into the EK-LM3S9D90 evaluation board using the ICDI board: 1. Install LM Flash Programmer on a Windows PC. 2. Connect the 10-wire ribbon cable to the 10-pin header on the ICDI board and to the 10-pin header on the EK-LM3S9D90 board.
-
Page 19: Appendix A: Schematics
A P P E N D I X A Schematics This section contains the schematics for the EK-LM3S9D90 evaluation board and also the BD-ICDI debug board. EK-LM3S9D90 Evaluation Board Microcontroller, Reset, and Headers on page 20 Ethernet, USB, and Power on page 21 BD-ICDI Board USB to JTAG, SWD, Headers, and Power on page 22 JTAG/SWD Multiplexer on page 23... - Page 20 Microcontroller, Reset, and Headers Revision History Revision Date Description VBUS 2/24/2009 First release for prototypes. 4/15/2009 Released to production. PA0/U0RX PB0/USB0ID USBID PA1/U0TX PB1/USB0VBUS TP18 1/21/2010 DC regulators U2 and U4 replaced for TI parts. PA2/SSI0CLK PB2/I2C0SCL TP19 PA3/SSI0FSS PB3/I2C0SDA TP20 6/17/2011 Add option to install either LM3S9B90 or LM3S9D90...
- Page 21 Ethernet, USB, and Power Revision History 3.3V Revision Date Description USB Micro AB VBUS 2/24/2009 First release for prototypes. 0.1uF 0.01uF VBUS 4/15/2009 Released to production. VBUS PA0/U0RX PB0/USB0ID USBID PA1/U0TX PB1/USB0VBUS TP18 Note: 1/21/2010 DC regulators U2 and U4 replaced for TI parts. PA2/SSI0CLK PB2/I2C0SCL 49.9...
- Page 22 DEBUG ACTIVE 0.1uF 0.1uF 0.1uF 0.1uF AGND AVDD 25.000 MHz 16.000 MHz 4.7uF PQ1LA333MSPQ GREEN_LED TI AEC - Austin Texas Instruments RESET 0.1uF 18pF 18pF 18pF 18pF LM3S9B90/LM3S9D90 CVDD 108 Wild Basin Rd. 108 Wild Basin Rd. Suite 350 Suite 350...
- Page 23 JTAG/SWD Multiplexer Revision History Revision Date Description FT_SK VBUS FT_DO 2/24/2009 First release for prototypes. 4/15/2009 Released to production. PA0/U0RX PB0/USB0ID USBID PA1/U0TX PB1/USB0VBUS TP18 FID1 FID2 FID3 1/21/2010 DC regulators U2 and U4 replaced for TI parts. PA2/SSI0CLK PB2/I2C0SCL TP19 40 Mil Pad 40 Mil Pad...
- Page 24 July 5, 2011...
-
Page 25: Appendix B: Connection Details
A P P E N D I X B Connection Details This appendix contains the following sections: Component Locations (see page 25) Board Dimensions (see page 26) Board Connectivity (see page 27) References (see page 27) Component Locations Figure B-1. EK-LM3S9D90 Evaluation Board Component Locations Figure B-2. -
Page 26: Board Dimensions
Board Dimensions Board Dimensions Figure B-3. EK-LM3S9D90 Evaluation Board Dimensions 4.00 0.07 0.07 Ø 0.100 0.34 1.40 0.07 0.07 0.07 0.07 Figure B-4. In-Circuit Debug Interface Board Dimensions 2.50 0.07 0.07 Ø 0.100 1.40 0.07 0.07 0.07 July 5, 2011... -
Page 27: Board Connectivity
– RealView MDK web site, www.keil.com/arm/rvmdkkit.asp – IAR Embedded Workbench web site, www.iar.com – Sourcery CodeBench development tools web site, www.codesourcery.com/gnu_toolchains/arm – Code Red Technologies development tools web site, www.code-red-tech.com – Texas Instruments’ Code Composer Studio™ IDE web site, www.ti.com/ccs July 5, 2011... - Page 28 References July 5, 2011...
-
Page 29: Appendix C: Microcontroller Gpio Assignments
A P P E N D I X C Microcontroller GPIO Assignments The following table shows the LM3S9D90 GPIOs used by the EK-LM3S9D90 board. All other GPIOs are available for use and accessible on the test pads. Table C-1. EK-LM3S9D90 Evaluation Board GPIO Usage Port Function Board Signal... - Page 30 July 5, 2011...
