Summary of Contents for Sunbeam HE2300
- Page 1 Oscillating Twinheat Ceramic Heater Instruction Booklet HE2300 2400W Oscillating Twinheat Ceramic Heater Please read these instructions carefully and retain for future reference.
-
Page 2: Table Of Contents
Sunbeam’s Safety Precautions Safety Precautions for your Heater Sunbeam’s Total Safety System Features of your Oscillating Twinheat Ceramic Heater Using your Oscillating Twinheat Ceramic Heater Troubleshooting guide Care and cleaning... -
Page 3: Sunbeam's Safety Precautions
Sunbeam’s Safety Precautions Sunbeam are very safety conscious when designing and manufacturing consumer products, but it is essential that the product user also exercise care when using an electrical appliance. Listed below are precautions which are essential for the safe use of an electrical appliance: • ... -
Page 4: Important Instructions - Retain For Future Use
Sunbeam’s Safety Precautions • This heater becomes hot during use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (90cm) away from the front of the heater and keep them away from the sides and rear. • Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left unattended. • Always unplug the heater when not in use. • Do not use outdoors. • Do not run the cord of the heater under carpeting. Do not cover the cord with throw rugs, runners or other floor coverings. Arrange the cord away from traffic areas where it will not be tripped over. Important instructions – retain for future use. If you have any concerns regarding the performance and use of your appliance, please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line. Ensure the above safety precautions are understood. • Do not locate the heater immediately below a socket outlet. -
Page 5: Sunbeam's Total Safety System
Sunbeam’s Total Safety System Safety auto shut off Your Sunbeam Twinheat Ceramic Heater is equipped with a safety system that detects any abnormally high temperatures within the heater and automatically shuts it off to prevent overheating. Thermal back-up fuse In addition to this automatic cut-off, your heater contains a thermal back-up fuse to provide additional back-up protection. If the heater is in an overheat situation, the back-up fuse will open, stopping the power flow to the heating element and fan. This fuse cannot be reset, so in the event that the back-up fuse is activated, the heater will need to be replaced. -
Page 6: Features Of Your Oscillating Twinheat Ceramic Heater
Features of your Oscillating Twinheat Ceramic Heater Power ON light Illuminates to indicate that the heater is connected to the power outlet and is switched on. Ceramic element The 2400 watt ceramic element is more efficient than other element types as it converts more electricity into heat that is transferred into the room. It also self-regulates the energy flow depending on the temperature for added safety. If the ceramic gets too hot, electricity cannot pass through it. Ceramic elements are safer than other element types, as they operate at temperatures below the ignition temperature of highly flammable materials like tissue paper. Oscillation function The heater oscillates 70 degrees to provide greater heat distribution. Simply press the OSC button (OSC) to activate this function. Two heat settings Two heat settings allow you to adjust the heat and airflow of the heater. When using the thermostat, select setting 2 to reach the desired heat level more quickly. Fan setting Ideal for circulating cool air in summer, the fan setting operates the fan without heat. - Page 7 Mode selector dial The mode selector dial operates the heater. Select heat setting 1 or 2, or fan. Thermostat dial The adjustable thermostat allows you to select the desired heat level, and automatically switches the heater on and off to maintain the desired temperature. Twin housing The revolutionary vertical twin housing has a 90 degree swivel on separate elements to provide wider heat distribution.
-
Page 8: Using Your Heater
Using your heater HE00 Oscillating Twinheat Ceramic Heater 1. P lace the heater on a flat level surface and ensure that the air intake and outlet are clear of obstructions. 2. I nsert the plug into a 230/240V power outlet and turn the power on. 3. T urn the thermostat dial to the highest setting by rotating the dial clockwise as far as it will turn. 4. T urn the mode dial to the desired heat setting, I or II. 5. T o use the fan without heat, set the thermostat dial to the lowest setting and select the fan setting on the mode selector dial. Setting the thermostat 1. S et the thermostat to the highest setting by turning the dial clockwise as far as it will turn. 2. ... - Page 9 Adjusting the swivel housing The revolutionary vertical twin housing direct the airflow in two directions for maximum heat distribution. Carefully rotate each housing to direct the airflow in the desired direction. Do not swivel the unit beyond the point of resistance...
-
Page 10: Troubleshooting Guide
Troubleshooting guide Troubleshooting guide If your heater fails to operate check the following: • Make sure the electrical outlet or circuit breaker is working. • Check for obstructions. If you find an obstruction, turn the heater off and follow the reset instructions above. • Check that the thermostat is not set too low. Turn the thermostat dial clockwise Care and cleaning Ensure that the heater is switched off and disconnected from the power outlet before cleaning. Carefully wipe the exterior of the heater with a soft damp cloth and dry thoroughly with a dry cloth. Over time, dust may accumulate on the front grilles. This can be removed by wiping with a damp cloth. Store the heater in a cool dry place when not in use. Store the heater in its carton if possible. - Page 11 Year Replacement Guarantee We are so confident of the quality of our product, should this appliance develop any malfunction within years of purchase ( Months commercial use) due to faulty materials or manufacture, we will replace it for you absolutely free. Should you experience any difficulties ...
- Page 12 Consumer Hotline In Australia Visit www.sunbeam.com.au Or call 00 0 0 In New Zealand Visit www.sunbeam.co.nz Or call 000 is a registered Trademark of Sunbeam. Made in China. Due to minor changes in design or otherwise, the product may differ from the one shown in this leaflet. ©...
