OPERATING INSTRUCTIONS

Opening Door
If pin number has not been changed, default code is 1 2 3 4 4 (Model 20700) or 1 2 3 4 (Model 20710). If
pin number has already been programmed, default pin will not work until system is reset.
Opening Door with Biometric Sensor (Model 20700)
Please refer to the programing instructions on how to program finger print(s). Once fingerprint is
recorded, the vault can be opened by placing a programmed fingerprint on the biometric sensor.
1. Press '*' button located on the Touchpad (See Figure 18)
2. Place and hold finger on biometric sensor (See Figure 19)
3. Vault door will drop (See Figure 20)
Opening Door with Touchpad (Model 20700)
1. Press the '*' button located on the Touchpad
2. Wait five (5) seconds until beep, green LED light will flash once
3. Press current pin number and then press 'enter' button or '*' key
4. Vault door will drop
Opening Door with Numeric Keypad (Model 20710)
1. Enter pin number followed by the '#' key
2. Vault door will drop
Opening Door with Emergency Key Access
In an emergency, or electronic failure, the vault can be accessed by a key. The key slot is hidden behind the
logo name plate on the face of the vault.
1. Using Allen Wrench, unscrew logo plate (See Figure 21)
2. Turn key clockwise to unlock (See Figure 22)
3. Door will drop
Closing the Vault Door
1. Slowly lift door pushing up on the bottom of the door (See Figure 23)
2. Push upwards gently until door lock engages
