PROGRAMMING INSTRUCTIONS (MODEL 20700)
Adding Additional Users
Up to five (5) additional users can be added to the system. To ensure safety please keep all codes secret.
1.
Press '*' button and wait for five (5) seconds
2.
Press '2' and hold for three (3) seconds. One (1) beep, followed by three (3) beeps will indicate the
system is in Enroll Mode. Green LED will flash
3.
Center and place Administrator finger on biometric sensor. When fingerprint is recognized, a beep
will sound. *Green light will continue to flash
4.
Immediately place new finger on sensor. Once finger is recorded, beep will sound. The fingerprint is
now recorded
* If invalid Admininstrator finger is entered the system will return to normal mode.
Performing Master Reset
A Master Reset should only be performed to clear the memory. Once the reset is performed, the system will
return to factory defaults and all fingerprints are erased.
1.
Open vault door (See Figure 9)
2.
Press '*' button. Wait five (5) seconds (See Figure 10)
3.
Press and hold 'reset' button (See Figure 11)
4.
While holding the 'reset' switch, press the '*' button once. Continue to hold 'reset' button
for 10 seconds until green light beeps 3 times
5.
Administrator pin is now set back to default (1 2 3 4 4). ALL fingerprints have been cleared
9
11
10
11
