- Page 1 Manual econ sens + econ sens+ pro 3-phase Power Meter with Logging Function Version 1.40...
-
Page 2: Table Of Contents
Installation Instructions ..................... 6 Mounting the device on the top hat rail ................6 Connecting the voltage path ....................6 Installing the econ sens + in a 690V grid ................9 Installing the current sensors ....................9 Connecting the data outputs ................... 11 S0-Interface ........................ - Page 3 Save submenu ..........................38 System submenu ..........................38 Contact menu ........................39 Manual menu ........................39 Initial Operation ......................40 Troubleshooting ....................... 41 Technical data ......................44 econ sens+ basic unit ......................44 econ sens+ measuring coils: ..................... 46 Default settings ......................... 46...
-
Page 4: Safety Instructions And Warranty Terms
Risk of potential damage to property or damage to the device if the appropriate safety measures are not taken. Information on disposal The econ sens+ energy consumption meter contains a small lithium battery. Never dispose of used batteries with normal household waste. They should be handed in at a collection point for used batteries. -
Page 5: Description
These waveforms are stored for several types of events. The econ sens + has a size of 16MB memory to store values, logs and events. It holds power logs per second for the last 2 days. It logs all measurements per minute for the last 39 days, per interval (10 or 15 Manual econ sens+ Version 1.40... -
Page 6: Special Features
When connecting the voltage path, the relevant safety regulations for work on electrical systems must be observed! Connections Overview S0 model Figure 1 shows the layout of the econ sens+ connections (S0 model) Figure 1: econ sens + connections (S0 model) Manual econ sens+ Version 1.40... -
Page 7: Overview Rs485 Model
Terminals for phases L1, L2 and L3 Terminals for the PE conductor “Extension” terminal. Is bridged with terminal L2 Ext: To avoid damage to the econ sens+, the maximum torque for tightening the terminals is < 2.5 Nm. Current path connections I1, I2, I3:... -
Page 8: Ethernet Connection
Reset: RS485 model The RS485 model of the econ sens + differs in its external appearance only by the absence of the lower right corner of the front panel (see Figure 4). All operating and display elements are identical to those of S0 model. -
Page 9: Installation Instructions
Mounting the device on the top hat rail The econ sens + energy consumption meter was designed for mounting on a top hat rail. The device is attached at an angle to the top hat rail with the upper retaining lug and locked into place with light downward pressure (see Fig. - Page 10 3-phase three-wire power system (without neutral conductor) Single-phase power system Fig. 7 shows the integration of the econ sens + into a 3-phase 4-wire power system. Figure 7: econ sens+ connection diagram to a 3-phase 4-wire power system The phases L1, L2 and L3 of the voltage path must be protected by means of automatic circuit breakers to prevent the system from being damaged in the event of a short circuit.
- Page 11 Safety Instructions and Warranty Terms If several econ sens+ devices are installed next to one another it is recommended that you use a clamping unit with series terminals. As a result it is easier to direct the fused voltage path in parallel to all devices.
-
Page 12: Installing The Econ Sens + In A 690V Grid
Installing the econ sens + in a 690V grid The econ sens + can also be used in a 690 V grid (IT-System). It should be noted that a neutral conductor is required. This is because the power supply of this device is itself designed for voltages on the primary side to 440Vrms. - Page 13 In the case of loss angles > +/-5°, the relative error of measurement is also greater and consequently also the relative deviation of the measured current calculated parameters (e.g. power). Figure 10: Loss angle of the current sensors Manual econ sens+ Version 1.40...
-
Page 14: Connecting The Data Outputs
Abbildung 11: Belegung der S0-Ausgänge und mögliches Anschlussschema The distance between the data logger and the econ sens + may be amount to max. 50 meter. When connecting a cable, a shielded cable is recommended *, as Belden YE00820. For shorter distances an unshielded cable can be used. -
Page 15: Rs485-Interface
2x2x0, 8, for example, Belden YE00820 or a Cat 5 network cable. The maximum length is 1200 meters. Figure 13: Assignment of the RS485 outputs (here with one econ sens+ as gateway) Manual econ sens+ Version 1.40... -
Page 16: Connecting The Network
Web Interface of the econ sens+ Accessing the web interface The web interface is accessed by entering the IP address of the econ sens+ in the address bar of the web browser (Firefox, IExplorer, GoogleChrome, etc.). The network default settings of the econ sens+... - Page 17 Accessing the web interface in a network with a DHCP server If the econ sens+ is located in a network in which there is a DHCP server available for automatic address assignment, it automatically adopts the address assigned to it by this server. You can identify which address the econ sens+ has been given in the DHCP Server.
-
Page 18: Home Menu
Safety Instructions and Warranty Terms Home menu Figure 12: "Home" menu screen On the home screen of the econ sens + you find the following information: 1. Menu bar to navigate the individual menus of the econ sens+ 2. Device name and current time/date 3. -
Page 19: Meter Menu
Safety Instructions and Warranty Terms Meter menu Econ sens+ displays the measured values in tabular form in the Meter menu. This table is shown in Fig. 17. + table of measured values Figure 13: econ sens The following are displayed: the voltages of the phases L1, L2, L3, the corresponding currents, as well as the active and the reactive power per phase and the “power factor”... - Page 20 In the above example this means that on phase L1 power is only consumed and on phase L2 power is only generated. If power is both consumed and generated at the same time on one phase, econ sens+ shows the sum of the two.
-
Page 21: Installation Check Routine „Installation Check
Safety Instructions and Warranty Terms Installation check routine „Installation check“ The econ sens + has a small installation check routine, called "installation check". General, assumed that measurement coils were installed correctly, and the measured load has a power factor of >0.71 (phase shift between <45... - Page 22 The measured power is exclusively produced and there is a little or no consumed power b) The power factor of the connected load is actually <0,71 Therefore, always be careful to correct installation of the measuring coils and their assignment to the voltage path to avoid misunderstandings. Manual econ sens+ Version 1.40...
-
Page 23: Graph Menu
Using File-> Save page as… in your browser you can transfer the text file to your PC. There are two Download options to choose from; the only difference between them is the use of different separators (comma or point) in decimal numbers Manual econ sens+ Version 1.40... -
Page 24: Events Menu
EN 50160. This function is optional available (Pro-version). Settings menu The Settings menu is used for the parameterization of the econ sens+. All settings required for the operation of the device can be performed in the corresponding submenus. The main page of the menu shows status information. -
Page 25: General Information On Saving Settings
1. Time setting using NTP time server If the econ sens+ is in a network in which a time server with NTP protocol is available, the device can adopt the time and date from this server. To do this, activate the Adopt time and date from time server select box. -
Page 26: Network Submenu
Activate select box Date and time = set time manually. When you click on Accept, the system time and date of the econ sens+ are compared with the values in the Set time manually field. Copy e.g. the time settings of your PC into this field. -
Page 27: Electrical Submenu
(e.g. USA), as well as in power systems with 230/400 V and 400/690 V. Different power frequencies (50 und 60 Hz) can also be represented. For the configuration of the power system, in which econ sens + will be used, there are only a few settings to be made. - Page 28 As a general rule, you will use the econ sens+ in a power system or measure the power consumption of a consumer that is supplied with 3 phases and a neutral conductor. Symmetrical consumers, e.g.
- Page 29 Figure 29: Custom Settings menu “Electrical” (Pro version) With an optional activation key the econ sens + can be extended to the Pro version. The limits for event recording are carried out in this table (Figure 29). "Apply settings to EN501060" by selecting the limits are set to default values according to the above standard.
- Page 30 A waveform is stored for this event. Default Value: 8% Current limit The 3 supply phases are checked. Currents above maximum current range are detected. A waveform is stored for this event. Default Value: 3000Arms Manual econ sens+ Version 1.40...
- Page 31 The 3 supply phases are checked. Total harmonic distortions of a current above 2% are detected. A waveform is is stored for this event. Default Value 100% Time change Changes to the internal clock time are logged. Manual econ sens+ Version 1.40...
-
Page 32: Events (Proversion) Submenu
Safety Instructions and Warranty Terms Events (Proversion) submenu For each event up to 6 parameters are logged when the event occurs. Unused parameters are 0. Manual econ sens+ Version 1.40... -
Page 33: Pulses / S Submenu
In practice, electric meters often have a pulse constant (here K) in pulses/kWh. To convert X into this constant K: K pulses 1000 1000 In our example, this means: Practice has shown that a pulse rate of 100 pulses/kWh (= 10 Wh/pulse) is entirely sufficient. Manual econ sens+ Version 1.40... -
Page 34: Modbus Pulses / S (S0/Rs 485-Variante) Submenu
This is a time in milliseconds, allowed values are 0..3600000. Modbus Events Flag minimum activity time for modbus event flags, can be set via HTML minimum activity time (ms) modbus settings. This is a time in milliseconds, allowed values are 0..3600000. Manual econ sens+ Version 1.40... - Page 35 Voltage (Present value) L1-L2 u(L2) Voltage (Present value) L2-L3 u(L3) Voltage (Present value) L3-L1 un(L1) Voltage (Present value) L1-N un(L2) Voltage (Present value) L2-N un(L3) Voltage (Present value) L3-N i(L1) Current (Present value) i(L2) Current (Present value) Manual econ sens+ Version 1.40...
- Page 36 Reactive Energy, Rückspeisung (Actual count) kvarh Q- L2 Reactive Energy, Rückspeisung (Actual count) kvarh Q- L3 Reactive Energy, Rückspeisung (Actual count) kvarh U (N) Voltage (Present value) Modbus Register – Present value/actual count part 1 Manual econ sens+ Version 1.40...
- Page 37 Magnitude Variation Rapid Voltage Change Flicker Severity Voltage Dip Voltage Interruption Temporary Overvoltage Transient Overvoltage Voltage Unbalance Harmonic Voltage Current Trigger Frequency Drift Vector Surge Neutral Overvoltage Power Harmonic Current Time Change Table Modbus – Events Manual econ sens+ Version 1.40...
- Page 38 Harmonic Voltage limit Current Trigger Frequency Drift limit Vector Surge limit Neutral Overvoltage limit Harmonic Current limit Event halflife time Modbus System Register Name Register Serial number Year Month Hour Minute Second Table Modbus general registers Manual econ sens+ Version 1.40...
- Page 39 255 and port number 502. Other values are possible. This modbus interface can be used on devices that do not have an RS485 connection. Modbus RTU When the econ sens+ is used as a Modbus server over RS485, only the serial line parameters are required. Modbus-Gateway When the econ sens+ is used as a Modbus Gateway, all parameters are required.
-
Page 40: Pass Submenu
Within 60 s, enter the old user name and the old password. Ensure that there is a tick in the “Accept requested changes” box. Click on Accept to save the new password and, if applicable, the new user name. Manual econ sens+ Version 1.40... -
Page 41: Save Submenu
Safety Instructions and Warranty Terms Save submenu The Save submenu is used to save or restore settings from the non-volatile memory of the econ sens+. Settings that have been made in the menus are lost when the supply voltage is switched off, if they have not been saved by selecting Store changes in permanent memory. -
Page 42: Contact Menu
With this function, the network analysis and event recording (Pro version) are activated by key. Contact menu By clicking on the Contact menu item, you will automatically be routed to the official website of econ solutions GmbH, http://www.econ-solutions.de, where you will find information on further econ- solutions products and also of course on the econ sens+. -
Page 43: Initial Operation
Initial Operation For initial operation of the econ sens+ proceed as follows: 1.) Before you switch the device on, check that all cable connections to the econ sens + are in place as described in the previous chapters. 2.) Switch on the circuit breakers in the voltage path; all three indicator LEDs should then light up. -
Page 44: Troubleshooting
The pulse weighting in the Pulses/s menu is set too high -> The pulse outputs of the econ sens+ allow for a maximum pulse rate of 10 Hz. Lower the pulse rate to a lower value. How to calculate the maximum admissible pulse rate is explained in the chapter Pulses/s. - Page 45 ) econ sens+ has a new IP address -> If you are operating the econ sens+ in a network with a DCHP server, ensure in the DHCP server that the device always received the same IP address (IP reservation).
- Page 46 Safety Instructions and Warranty Terms maintenance work, etc.), it may be that the sens+ has received a new IP address without you noticing. Manual econ sens+ Version 1.40...
-
Page 47: Technical Data
Safety Instructions and Warranty Terms Technical data econ sens+ basic unit mechanical Dimensions (W x H x D) [mm] 94 x 23 x 121 Equipment class IP 20 electrical Operating voltage range 70..350 (betw. U1,U2,U3 and N) Terminal cross-section Voltage inputs mm²... - Page 48 Safety Instructions and Warranty Terms Dimensions / Manual econ sens+ Version 1.40...
-
Page 49: Econ Sens+ Measuring Coils
0...1600 0..3200 Resolution Rel. error +/- 1 Default settings Network By default the econ sens+ searches for a DHCP server; if there is no DCHP server in the network, the following applies: IP address: 192.168.0.1 Subnet mask: 255.255.255.0 Standard gateway 192.168.0.254...
