- Page 1 ® MAYFIELD Imaging Overview and IFU Refresher MAYFIELD is a registered trademark of SM USA Inc. and is used by Integra under license. 0688771-1 0688771-1...
- Page 2 Halo System (this system is outside the scope of this training) MAYFIELD is a registered trademark of SM USA Inc. and is used by Integra under license. Budde is a registered trademark of Integra LifeSciences Corporation in the United States and/or other countries.
- Page 3 MAYFIELD Imaging: Head Clamp • Clamp: Head Clamp (Standard • Made of carbon-filled PEEK Configuration) • Little or no artifact • Only metal is the spring in the torque knob • Metal-free conversion accessory offers a completely metal free set-up (different torque knob) Metal Free Conversion Accessory...
- Page 4 MAYFIELD Imaging: Head Clamp • Standard Clamp XR2 Standard Torque Screw (439A1095) Head Clamp (Standard Configuration) XR2 Adult Rocker (439A1094) Swivel Lock Knob Skull Clamp Base or Body Plunger Starburst Attachment Metal Free Conversion Skull Clamp Ratchet Extension Accessory • Accessories XR2 Force Applicator, 439A1093 (included with metal free conversion kit, 439A1092)
- Page 5 MAYFIELD Imaging: Base Unit Base Unit • Base Unit: • Metal free zone around the head clamp attachment / scanning area Metal free zone • Width adjustable – 2 different sizes Item OR Table Width(s) Cross Bar Width (Side rail to side rail) A2079 19.5in to 24in Approx.
- Page 6 MAYFIELD Imaging: Base Unit Base Unit • Identification: Skull Clamp/Headrest Locking Knob Swivel Adaptor Link Arm Locking Knobs Yoke Crossbar Base Handle Side Rail Bracket Locking Lever Base Handle Adjustment Knob 10.Auxiliary Side Rail 11.Side Rail Bracket Locking 0688771-1 0688771-1...
- Page 7 MAYFIELD Imaging: Base Unit Accessories • Tri-Star Swivel Adapter, A2111 • Extension Arms 437A2224, 5 inch 437A2225, 7 inch 0688771-1 0688771-1...
- Page 8 MAYFIELD Imaging: Horseshoe Headrests Adult Horseshoe Headrest, A2010 Pediatric Horseshoe Headrest, A2011 Starburst to attach to standard swivel or tri-star swivel adapter 0688771-1 0688771-1...
- Page 9 MAYFIELD Imaging: Horseshoe Headrests Spine Table Adapter, A2600R Using the Spine Table Adapter with the Jackson Table Metal free zone 0688771-1 0688771-1...
- Page 10 MAYFIELD Imaging Radiolucent Products (XR2) Instructions for Use Refresher 0688771-1 0688771-1...
- Page 11 MAYFIELD Imaging Base Unit Review of Components Std. Swivel Adaptor (Blue ring) Rail end bracket Side Rail Locking Handle with Locking Lever Link Arm Base Handle (Yellow ring) Adjustment Knob Tri-Star Swivel Adaptor (Blue ring) (Available as an Accessory) 0688771-1 0688771-1...
- Page 12 Refresher on Instructions for Use Step 1. With the rail end bracket toggle locks loosened and the locking handles unlocked, hold the base unit as shown for attachment to the OR Table; grasp the side rails on the end brackets with each hand.
- Page 13 Refresher on Instructions for Use Step 2. Slide the base unit brackets onto the side rails of the operating room table. Note that locking handles are opening “up” and NOT DOWN 0688771-1 0688771-1...
- Page 14 Refresher on Instructions for Use Step 3. Secure the brackets to the side rails. Turning rail end bracket toggle locks Tighten securely to side rails Cautions: Keep finger clear of hinge points when closing the base unit locking levers. It is recommended that the levers be closed using the palm of the hand.
- Page 15 Refresher on Instructions for Use Step 4. Attaching the Link and Adaptor to the Base Unit Assembly. Note the color-coded sleeves – Line them up, yellow-to-yellow & blue-to-blue 0688771-1 0688771-1...
- Page 16 Refresher on Instructions for Use Step 5. Positioned to await attachment of the skull clamp. Locking handles are unlocked Link and swivel adaptor are connected but not tightened for easy movement and attachment to the skull clamp Note: The head section of the OR table can be attached prior to the patient entering the OR.
- Page 17 Refresher on Instructions for Use Step 6. With the skull clamp attached to the patient and in position, the Adaptor is brought up for attachment to the skull clamp Attach in this order Locking Handle 1. Attach swivel adaptor to skull clamp 2.
- Page 18 Refresher on Instructions for Use Step 7. With the system now locked and ready, confirm that all knobs and levers are locked and secure. 0688771-1 0688771-1...
- Page 19 Refresher on Instructions for Use Step 8. Knobs should not be overtightened. Over-tightening the mechanisms’ adjustment screws may result in damage to the unit. Please remember that overextending or overloading the base unit may result in unintended movement, shortened product life and/or damage to the unit 0688771-1 0688771-1...
