MiTAC Maestro 3070 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Maestro 3070/3080
User Manual
(Version 1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maestro 3070 and is the answer not in the manual?

Questions and answers

Related Manuals for MiTAC Maestro 3070

Summary of Contents for MiTAC Maestro 3070

  • Page 1 Maestro 3070/3080 User Manual (Version 1.0)

  • Page 2: Front View

    To know Maestro 3070/3080 Front View Please refer below picture showing and take note the real front view and function may differ depend on what the model you purchased. Webcam The Built-in webcam is 1.0M HD pixel with digital micro phone to allow your video with chats online.
  • Page 3 Speakers High definition sound quality brings you to enjoy great music world.

  • Page 4: Rear View

    Rear View Please refer below picture showing and take note the real rear view and function may differ depend on what the model you purchased. Stand Adjustable stand help you to position the system upright. Less screw design Two screws allows you open system easier. Power ON/OFF button Power ON/OFF switch allow you turn on/off your PC.
  • Page 6 System SKU Matrix Item Spec M3070 M3080 21.5" 23.6" Panel 16:9, 1920 x 1080, full HD support (for M3070) (for M3080) 65W Coffee lake CPU support Main board form factor Thin Mini-ITX Chipset Coffee lake H310 Memory x2 SO-DIMM slots, DDR4, 2666, up to 32GB Audio High definition audio codec SATA HDD...
  • Page 7 MB Information MB: PH12FEI...
  • Page 8 MB Placement:...
  • Page 9 Front Audio Header COM Port Header (RS232) DMIC Header PCIEx4 slot MiAPI header LGA1151 CPU socket Dual USB2.0 Header LVDS Backlight Header LVDS connector Front I/O Header SATA SATA Power SATA SATA Dual USB2.0 Header ATX 2pin ATX 4pin COM Port Header (RS232) COM Port Header (RS232) COM Port Header (RS232/422/485) RTC battery header...

  • Page 10: Connecting To The Internal Headers And Connectors

    Connecting to the Internal Headers and Connectors Front panel main header Front Panel Connector Figure 1 : Signal Name Description Signal Name Description Pull-up resistor (750 ) to [Out] Front panel LED (Green) HDD_POWER_LED POWER_LED_MAIN HDD_LED# [Out] Hard disk activity LED POWER_LED_ALT [Out] Front panel LED (Yellow) GROUND...
  • Page 11 Pins 2&3: jumper position for 19V Figure 2 : Inverter power voltage selection header signals Signal Name 12VDUAL_HDMI BKLT_PWR +19V_A Table 2: Inverter power voltage selection header signals Figure 3: LVDS Connector Signal Description TD0P LVDS Channel A diff data output - positive TD0N LVDS Channel A diff data output - negative TC0P...
  • Page 12 3.3V/5V/12V Selectable LCD power output 3.3V/5V/12V Selectable LCD power output VCC3 VCC3 CABLE_ID2 CABLE_ID2 Ground TCK0P LVDS Channel A diff data output - positive TCK0N LVDS Channel A diff data output - negative Ground Ground CABLE_ID3 CABLE_ID3 LVDS_DDC_SCL LVDS_DDC_SCL CABLE_ID1 CABLE_ID1 PS8625_BKLT_CTRL PS8625_BKLT_CTRL TCK1P...
  • Page 13 EDP_CPU_2- MAIN LINK EDP_CPU_2+ MAIN LINK Ground EDP_CPU_1- MAIN LINK EDP_CPU_1+ MAIN LINK Ground EDP_CPU_0- MAIN LINK EDP_CPU_0+ MAIN LINK Ground EDP_CPU_AUX+ Aux channel EDP_CPU_AUX- Aux channel Ground LCD_VCC Selectable LCD power output LCD_VCC Selectable LCD power output LCD_VCC Selectable LCD power output LCD_VCC Selectable LCD power output CABLE_ID2...
  • Page 14 CABLE_ID3 CABLE_ID3 Ground BKLT_EN BKLT_EN PCH_BACKLIGHT_PWM PCH_BACKLIGHT_PWM BKLT_PWR Selectable BKLT power output BKLT_PWR Selectable BKLT power output BKLT_PWR Selectable BKLT power output BKLT_PWR Selectable BKLT power output Table 4: 40-pin eDP data header pin-out reference Figure 5: LVDS inverter power header pin-out Signal Name Description LVDS_BKTEN_R...
  • Page 15 Figure 6: Dual USB2.0 pin-out Signal Signal 5V_USB 5V_USB Data (negative) Data (negative) Data (positive) Data (positive) Ground Ground Key (no pin) No Connect Table 6 Dual USB 2.0 Header...
  • Page 16 Figure 7: DMIC Cable pin-out Signal Name Description Power DMIC_DATA_R DMIC DATA DMIC_CLK_R DMIC CLOCK Ground Ground NO pin Table 7: DMIC Cable signals Figure 8: FP Audio pin-out Signal Name Description Front panel microphone input signal AUD_GND Ground used by analog audio circuits Microphone power / additional MIC input MIC_BIAS for stereo microphone support...
  • Page 17 Figure 9: Internal speaker pin-out Signal Name Front_L- Front_L+ Front_R+ Front_R- Internal header Table 9: signals Figure 10: Serial port header pin-out Signal Name RXD# TXD# Table 10 Serial port header pin-out...
  • Page 18 Figure 11 Processor fan header pin-out Signal Ground +12V CPU_FAN_TACH CPU_FAN_CTRL Table 11 fan header signals Figure 12: CMOS Clear Header CMOS Clear Clear CMOS Normal Table 12: CMOS Clear behavior...
  • Page 19 Figure 13: M.2 M key slot For Storage pin-out For Storage signals Table 13: M.2 M key slot...
  • Page 20 Figure 14: M.2 E key slot For wireless pin-out Table 14: M.2 E key slot For wireless signals Figure 15: SATA Power Cable pin-out Signal Name Description...
  • Page 21 VCC3 Power VCC3 Power VCC3 Power Ground Ground Ground Power Power Power Ground Ground +12V Power +12V Power +12V Power Table 15: SATA Power Cable signals Figure 16: SATA Header pin-out Signal Name Description Ground SATAHDR_TXP0_C SATA DATA Transmit(positive) SATAHDR_TXN0_C SATA DATA Transmit(negative) Ground SATAHDR_RXN0_C...
  • Page 22 Figure 17: Panel power Header pin-out Signal Name Description No pin 3.3V 3.3V option (default) 12V option LCD_VCC Send voltage to connector No pin 5V option Table 17: Panel power Header signal...
  • Page 23 Figure 18: Alternate Power LED Header pin-out Signal Name Main Color LED Alternative color LED Table 18: Alternate Power LED Header signal Figure 19: MiAPI Header Pin Net name Pin Net name MAPI_GPIO1 MAPI_GPIO2 MAPI_GPIO6 MAPI_GPIO3 MAPI_GPIO7 MAPI_GPIO4 MAPI_GPIO8 MAPI_GPIO5 MAPI_GPIO9 WD_Time MAPI_GPIO10...

  • Page 24: Bios Specification

    MITAC Desktop Board PH12FEI BIOS Specification MAIN PAGE Main Advanced Chipset Security Boot Save & Exit Item help BIOS Information BIOS Vender American Megatrends Core Version 5.13 Compliancy UEFI 2.6 ; PI 1.4 BIOS Version D7980A01...
  • Page 25 Build Date 04/21/2017 ME FW Version 11.8.50.3399 Processor Information Intel(R) CORE(TM) i5-8500 CPU @ 3.00GHz Memory Information Total Memory 32768 MB DIMM#1 16384 MB (DDR4) →←: Select Screen DIMM#2 16384 MB (DDR4) Memory Frequency 2133 MHz ↑↓: Select Item Enter: Select SATA1 Empty +/- : Change Opt.
  • Page 26 Field Name Total Memory Value Display the installed memory size. Comment This field is not selectable. There is no help text associated with it. Field Name DIMM#[1:2] Help Memory in the DIMM. Comment This field is not selectable. There is no help text associated with it. Field Name Memory Frequency Value...

  • Page 27: Advanced Page

    ADVANCED PAGE Main Advanced Chipset Security Boot Save & Exit ►CPU Configuration Item help ►Trusted Computing ►ACPI Settings ►SMART Settings ►Super IO Configuration ►NCT6116D HW Monitor →←: Select Screen ►S5 RTC Wake Settings ↑↓: Select Item ►Network Stack Configuration Enter: Select ►NVMe Configuration +/- : Change Opt F1: General Help...
  • Page 28 Field Name NVMe Configuration Help NVMe Device Options Setting. Comment Press Enter when selected to go into the associated Sub-Menu.

  • Page 29: Cpu Configuration

    CPU CONFIGURATION Main Advanced Chipset Security Boot Save & Exit CPU Configuration Item help Type Intel(R) Core(TM) CPU i5-7300U @ 2.60 GHz 0x806E9 Speed 2700 MHz L1 Data Cache 32 KB x 2 L1 Code Cache 32 KB x 2 L2 Cache 256 KB x 2 L3 Cache...
  • Page 30 Field Name L2 Cache Default Value L2 Cache Size Comment This field is not selectable. There is no help text associated with it. Field Name L3 Cache Default Value L3 Cache Size Comment This field is not selectable. There is no help text associated with it. Field Name L4 Cache Default Value...

  • Page 31: Trusted Computing

    TRUSTED COMPUTING (OPTIONAL) Main Advanced Chipset Security Boot Save & Exit Item help TPM20 Device Found Vender : NTC Firmware Version: 1.3 Security Device Support [Enable] →←: Select Screen Pending operation [None] ↑↓: Select Item TPM2.0 UEFI Spec Version [TCG_2] Enter: Select +/- : Change Opt F1: General Help...

  • Page 32: Smart Settings

    ACPI Sleep State [S3 (Suspend to RAM)] +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Reset ESC: Exit Version 2.18.1264. Copyright (C) 2017 American Megatrends, Inc. Field Name Enable ACPI Auto Configuration Default Value [Disabled] Possible Value...

  • Page 33: Super Io Configuration

    Help Run SMART Self Test on all HDDs during POST. SUPER IO CONFIGURATION Main Advanced Chipset Security Boot Save & Exit SIO Configuration Item help Super IO Chip NCT6116D ►Serial Port 1 Configuration →←: Select Screen ►Serial Port 2 Configuration ↑↓: Select Item ►Serial Port 3 Configuration Enter: Select...
  • Page 34 2.5.1 Serial Port 1 Configuration Main Advanced Chipset Security Boot Save & Exit Serial Port 1 Configuration Item help →←: Select Screen Serial Port [Enabled] ↑↓: Select Item Device Settings IO=3E8h; IRQ=7; Enter: Select +/- : Change Opt Change Settings [Auto] F1: General Help Mode Configuration...
  • Page 35 →←: Select Screen Serial Port [Enabled] ↑↓: Select Item Device Settings IO=2E8h; IRQ=7; Enter: Select +/- : Change Opt Change Settings [Auto] F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Reset ESC: Exit Version 2.18.1264. Copyright (C) 2017 American Megatrends, Inc. Field Name Serial Port Default Value...
  • Page 36 2.5.3 Serial Port 3 Configuration Main Advanced Chipset Security Boot Save & Exit Serial Port 3 Configuration Item help →←: Select Screen Serial Port [Enabled] ↑↓: Select Item Device Settings IO=2F0h; IRQ=7; Enter: Select +/- : Change Opt Change Settings [Auto] F1: General Help F2: Previous Values...
  • Page 37 2.5.4 Serial Port 4 Configuration Main Advanced Chipset Security Boot Save & Exit Serial Port 4 Configuration Item help →←: Select Screen Serial Port [Enabled] ↑↓: Select Item Device Settings IO=3F8h; IRQ=4; Enter: Select +/- : Change Opt Change Settings [Auto] F1: General Help F2: Previous Values...
  • Page 38 NCT6116D HW MONITOR Main Advanced Chipset Security Boot Save & Exit PC Health Status Item help →←: Select Screen CPU temperature : xx °C ↑↓: Select Item CPU VR temperature : xx °C DIMM temperature Enter: Select : xx °C CPU Fan Speed : xxxx RPM +/- : Change Opt...

  • Page 39: S5 Rtc Wake Settings

    S5 RTC WAKE SETTINGS Main Advanced Chipset Security Boot Save & Exit Wake system from S5 [Disabled] Item help →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...

  • Page 40: Network Stack Configuration

    NETWORK STACK CONFIGURATION Main Advanced Chipset Security Boot Save & Exit Item help Network stack [Disabled] →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Reset ESC: Exit Version 2.18.1264.

  • Page 41: Nvme Configuration

    NVME CONFIGURATION Main Advanced Chipset Security Boot Save & Exit NVMe Configuration Item help →←: Select Screen No NVME Device Found ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Reset ESC: Exit Version 2.18.1264.
  • Page 42 CHIPSET PAGE Main Advanced Chipset Security Boot Save & Exit ►System Agent (SA) Configuration Item help ►PCH-IO Configuration →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Reset ESC: Exit Version 2.18.1264.

  • Page 43: System Agent (Sa) Configuration

    SYSTEM AGENT (SA) CONFIGURATION Main Advanced Chipset Security Boot Save & Exit System Agent (SA) Configuration Item help ►Graphics Configuration →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...
  • Page 44 3.1.1 Graphics Configuration Main Advanced Chipset Security Boot Save & Exit Graphics Configuration Item help DVMT Pre-Allocated [64M] →←: Select Screen DVMT Total Gfx Mem [256M] ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...

  • Page 45: Pch-Io Configuration

    PCH-IO CONFIGURATION Main Advanced Chipset Security Boot Save & Exit PCH-IO Configuration Item help ►SATA And RST Configuration ►HD Audio Configuration →←: Select Screen ↑↓: Select Item Wake on LAN [Disabled] Enter: Select DeepSx Power Policies [Enable in S4-S5] +/- : Change Opt State After G3 [S5 State] F1: General Help...
  • Page 46 3.2.1 SATA And RST Configuration Main Advanced Chipset Boot Security Save & Exit SATA And RST Configuration Item help SATA Mose Selection [AHCI] →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...
  • Page 47 3.2.2 HD Audio Configuration Main Advanced Chipset Boot Security Save & Exit HD Audio Subsystem Configuration Settings Item help HD Audio [Enable] →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...

  • Page 48: Security Page

    SECURITY PAGE Main Advanced Chipset Security Boot Save & Exit Password Description Item help If Only the Administrator's password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup.
  • Page 49 Help Customizable Secure Boot settings Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Secure Flash Update Help Secure Flash Update support Comment Press Enter when selected to go into the associated Sub-Menu.

  • Page 50: Hdd Password Configuration

    HDD SECURITY Main Advanced Chipset Security Boot Save & Exit HDD Password Description : Item help Allows Access to Set, Modify and Clear HardDisk User and Master Passwords. User Password need to be installed for Enabling Security. Master Password can be Modified only when successfully unlocked with Master Password in POST.

  • Page 51: Secure Boot

    SECURE BOOT Main Advanced Chipset Security Boot Save & Exit System Mode Setup Item help →←: Select Screen Secure Boot Enable [Disabled] ↑↓: Select Item Not Active Enter: Select Secure Boot Mode [Custom] +/- : Change Opt F1: General Help ►...
  • Page 52 ► Restore Factory Keys ► Reset To Setup Mode ► Export Secure Boot variables ► Enroll Efi Image ► Device Guard ready ► Remove ‘UEFI CA’ from DB →←: Select Screen ► Restore DB defaults ↑↓: Select Item Enter: Select Secure Boot variable Size Key#...
  • Page 53 b)EFI_CERT_X509 (DER encoded) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHA256,384,512 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256) Key Source: Factory,External,Mixed Press Enter when selected to go into the associated Sub-Menu “Key Management”. comment Field Name Key Exchange Key Default Value Size:0, Key#:0, Key source: No Key Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate in:...
  • Page 54 Key Source: Factory,External,Mixed comment Press Enter when selected to go into the associated Sub-Menu. Field Name OsRecovery Signatures Default Value Size:0, Key#:0, Key source: No Key Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate in: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER encoded) c)EFI_CERT_RSA2048 (bin)
  • Page 55 BOOT PAGE Main Advanced Chipset Security Boot Save & Exit Boot Configuration Item help Setup Prompt Timeout Bootup NumLock State [On] Boot Mode Select [UEFI] →←: Select Screen FIXED BOOT ORDER Priorities ↑↓: Select Item Boot Option #1 [USB Floppy] Boot Option #2 [CD/DVD] Enter: Select...
  • Page 56 Default Value [USB Floppy] Possible Value Hard Disk, USB Hard Disk, USB CD/DVD, USB Key, USB Floppy , USB Lan, Network Help Sets the system boot order Field Name Boot Option #2 Default Value [USB CD/DVD] Possible Value Hard Disk, USB Hard Disk, USB CD/DVD, USB Key, USB Floppy , USB Lan, Network Help Sets the system boot order...
  • Page 57 Drives. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name (UEFI) Hard Disk Drive BBS Priorities Help Specifies the Boot Device Priority sequence from available Hard Disk Drives. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name (UEFI) NETWORK Drive BBS Priorities Help...
  • Page 58 (LIST BOOT DEVICE TYPE) DRIVE BBS PRIORITIES Main Advanced Chipset Security Boot Save & Exit Boot Option #1 [Boot Device Name 1] Item help Boot Option #2 [Boot Device Name 2] →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help F2: Previous Values F3: Optimized Defaults...
  • Page 59 Version 2.18.1264. Copyright (C) 2017 American Megatrends, Inc. Field Name Discard Changes and Exit Help Exit system setup with without saving any changes. Field Name Save Changes and Reset Help Reset the system after saving the changes. Field Name Discard Changes and Rest Help Reset system setup without saving any changes.
  • Page 60 RECOVERY PAGE (ACTIVE FOR 4.3 SECURE FLASH UPDATE ONLY) Main Advanced Chipset Security Boot Save & Exit Recovery Please select block you want to update Item help Reset NVRAM [Disabled] ►Process with flash update →←: Select Screen ↑↓: Select Item Enter: Select +/- : Change Opt F1: General Help...

This manual is also suitable for:

Maestro 3080
