TRENCHERS
SERVICE MANUAL
1
PM-000111-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINI BIGFOOT and is the answer not in the manual?

Questions and answers

Related Manuals for Digga MINI BIGFOOT

Summary of Contents for Digga MINI BIGFOOT

  • Page 1 TRENCHERS SERVICE MANUAL PM-000111-A...
  • Page 2 PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 3 Contact Digga Australia for enquiries. For any spare or replacement parts, contact Digga Service and Spares or a local Digga representative. For identification purposes always try to have available the trencher type and serial number. This information may be necessary for verification of any component part numbers.

  • Page 4: Oil Change Schedule

    PLANETARY GEAR OIL The Trencher Planetary Unit is a sealed Unit. If there is any sign of oil leaks please contact your nearest DIGGA dealer before carrying out any repairs, as there can be other causes for seal leaks. OPERATING IN ASIA PACIFIC AND EUROPE The Planetary Drive Unit in the Trencher when operating in Asia Pacific and Europe uses the Gear Oil VALVOLINE EPG ISO 320 (mineral oil) for lubrication of gears and bearings.

  • Page 5: Table Of Contents

    OIL CHANGE SCHEDULE..........................4 TABLE OF CONTENTS........................... 5 DRIVE ASSEMBLY: DISASSEMBLY PROCEDURE..................6 DRIVE ASSEMBLY: MINI BIGFOOT - BIGFOOT - BIGFOOT XD - BIGFOOT XD HIGH FLOW....7 DRIVE ASSEMBLY: HYDRIVE - HYDRIVE XD..................... PLANETARY SUBASSEMBLY........................9 UNIT REASSEMBLY............................10 MAINTENANCE..............................

  • Page 6: Drive Assembly: Disassembly Procedure

    DRIVE ASSEMBLY: DISASSEMBLY PROCEDURE All parts should be inspected as they are removed from unit. Scribe or mark a line across the assembly mounting case, ring gear, and cover joints on outside of gearbox to assure proper orientation of assembly, oil fill/ drain plug, motor mounting, etc., as the unit is reassembled. Remove chain, boom, sprockets and seal protector.

  • Page 7: Drive Assembly: Mini Bigfoot - Bigfoot - Bigfoot Xd - Bigfoot Xd High Flow

    DRIVE ASSEMBLY: BIGFOOT - BIGFOOT XD - BIGFOOT XD HIGH FLOW REFER TO APPROPIATE EXPLODED VIEW DRAWING (Page 58-65) BIGFOOT XD HIGHFLOW MINI BIGFOOT BIGFOOT BIGFOOT XD 1. Inspect inner and outer bearing cups and cones. If either is damaged, the complete bearing assembly will need replacing.

  • Page 8: Drive Assembly: Hydrive - Hydrive Xd

    DRIVE ASSEMBLY: HYDRIVE - HYDRIVE XD REFER TO APPROPIATE EXPLODED VIEW DRAWING (Page 66-69) HYDRIVE HYDRIVE XD 1. Inspect inner and outer bearing cups and cones. If either is damaged, the complete bearing assembly will need replacing. 2. Remove inner and outer bearing races from output housing with the appropriate tool. 3.

  • Page 9: Planetary Subassembly

    PLANETARY SUBASSEMBLY Rotate planet gear to check for any abnormal noises or roughness in the primary planet bearings. At the same time, inspect planet gears for any damage or worn teeth. If replacement or further inspection is required, proceed as follows. Remove circlips from top plate and remove plate.

  • Page 10: Unit Reassembly

    UNIT REASSEMBLY Start with output housing assembly. Turn case upside down and position on table. Bottom seal end should be facing upward and install bearing cup with appropriate tooling. Install bottom seal applying a smear of Loctite 243 thread locker to outside of seal and fit using appropriate tooling. Ensure seal is flush with the housing.

  • Page 11: Maintenance

    MAINTENANCE ALWAYS ENSURE THAT THE HYDRAULIC MOTOR IS PRIMED WITH HYDRAULIC FLUID PRIOR TO USE FOLLOWING ANY REPAIRS TO THE TRENCHER, OR THE PARENT MACHINE IF A LEAK IS DETECTED WHILE CONNECTED TO THE TRENCHER. DO NOT ALLOW THE TRENCHER TO RUN WITHOUT OIL AT ANY TIME. NOSE ROLLER BEARING REPLACEMENT FIG 1 FIG 2...
  • Page 12 MAINTENANCE SPROCKET REPLACEMENT FOR BIGFOOT FIG 2 FIG 1 Slide the sprocket off the shaft and replace with new sprocket. It is Firstly remove ½” bolt holding the auger, then remove auger. recommended Anti-seize be applied to shaft before replacement of Using a 3/16”...
  • Page 13 MAINTENANCE NOTE: IF THE SPROCKET CANNOT BE REMOVED BY TAPPING WITH A HAMMER THEN A PULLER MAY HAVE TO BE USED. IMPORTANT: SHUT DOWN TRENCHER & MACHINE BEFORE ANY ADJUSTMENTS ARE MADE HYDRAULIC HOSE CONNECTION BOOM ADJUSTMENT SUPPLY FROM MACHINE 1.
  • Page 14 MAINTENANCE CHAIN ADJUSTMENT 1. To either adjust chain or remove chain – remove the ½" Bolts holding spanner to outer boom. (FIG 1) FIG 1 2. Use spanner supplied to wind adjuster nut clockwise for loosening, anti clockwise for tightening. (FIG 2) FIG 2 3.
  • Page 15 MAINTENANCE SEAL REPLACEMENT FIG 1 FIG 2 FIG 3 Before the seal can be replaced remove Before the seal can be replaced run Proceed to fit the seal by using a large punch retaining collar and sprocket as shown in some grease around the inside lip of the and gently tap the seal into place ensuring sprocket replacement.
  • Page 16 MAINTENANCE FITTING A TRENCHER CHAIN - MINI TRENCHER / BIGFOOT / BIGFOOT XD CAUTION: ALL WORK SAFE PRACTICES AND PROCEDURES MUST BE ADHERED TO AND APPROPRIATE PPE MUST BE WORN. 1. Start with the Trencher securely attached to a lifting device or machine, ensure the adjustable boom is fully retracted.
  • Page 17 MAINTENANCE FITTING A TRENCHER CHAIN - HYDRIVE / HYDRIVE XD CAUTION: ALL WORK SAFE PRACTICES AND PROCEDURES MUST BE ADHERED TO AND APPROPRIATE PPE MUST BE WORN. 1. Start with the Trencher securely attached to a lifting device or machine, ensure the adjustable boom is fully retracted. 2.

  • Page 18: Bearing Preload Chart

    BEARING PRELOAD CHART PD15 - PD22 PD25 - PD50 FORCE (in Kg) This is the force to keep the housing spinning slowly at a constant speed. The force required to start the spinning initially will be greater. This is not the correct reading.

  • Page 19: Mini Bigfoot Spare Parts

    SPARE PARTS MINI BIGFOOT TRENCHER...
  • Page 20 SPARE PARTS MINI BIGFOOT TRENCHER - PARTS LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 1/2 X 2 G8 UNC ZINC PLATED FA-000029 BOLT HEX 1/2 X 3.1/2 G8 UNC ZINC PLATED...
  • Page 21 MINI BIGFOOT - ANGLED FOOT WELDMENT TR-001400 MINI BIGFOOT - OUTER BOOM ASSEMBLY - 765 LONG TR-001409 TR-001419 MINI BIGFOOT - SIDE PLATE ASSEMBLY - 65SQ DANGER BAR TR-001445 SPOIL AUGER - MINI BIGFOOT WA-000004 WASHER COMMERCIAL 3/8 ZINC PLATED...

  • Page 22: Bigfoot 900 Dig Spare Parts

    SPARE PARTS BIGFOOT TRENCHER 900 DIG PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 23 SPARE PARTS BIGFOOT TRENCHER 900 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 3/8 X 3/4 G8 UNC ZINC PLATED FA-000052 BOLT HEX 5/16 X 1.1/4 G8 UNC ZINC PLATED FA-000063...
  • Page 24 SPARE PARTS BIGFOOT TRENCHER 900 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE NOSE ROLLER SQUARE PIN - TRENCHER COMMON PARTS TR-000029 DRIVE SPROCKET COLLAR - TRENCHER COMMON PARTS TR-000031 DRIVE SPROCKET 1.5/8” PITCH 12 TOOTH - TRENCHER COMMON PARTS TR-000035 BOOM ADJUSTER ROD 1”...

  • Page 25: Bigfoot 700 Dig Spare Parts

    SPARE PARTS BIGFOOT TRENCHER 700 DIG...
  • Page 26 SPARE PARTS BIGFOOT TRENCHER 700 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 3/8 X 3/4 G8 UNC ZINC PLATED FA-000052 BOLT HEX 5/16 X 1.1/4 G8 UNC ZINC PLATED FA-000063...
  • Page 27 SPARE PARTS BIGFOOT TRENCHER 700 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE NOSE ROLLER SQUARE PIN - TRENCHER COMMON PARTS TR-000029 DRIVE SPROCKET COLLAR - TRENCHER COMMON PARTS TR-000031 DRIVE SPROCKET 1.5/8” PITCH 12 TOOTH - TRENCHER COMMON PARTS TR-000035 BOOM ADJUSTER ROD 1”...

  • Page 28: Bigfoot Xd 900 Dig Spare Parts

    SPARE PARTS BIGFOOT XD TRENCHER 900 DIG PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 29 SPARE PARTS BIGFOOT XD TRENCHER 900 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE FA-000026 BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 FA-000033 BOLT HEX 1/2 X 3 G8 UNC ZINC PLATED FA-000052 BOLT HEX 3/8 X 3/4 G8 UNC ZINC PLATED FA-000063...
  • Page 30 SPARE PARTS BIGFOOT XD TRENCHER 900 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE NOSE ROLLER PIN WASHER - TRENCHER COMMON PARTS TR-000050 2” NOSE ROLLER SQUARE PIN - 1.5” SQ - TRENCHER COMMON PARTS TR-000053 NOSE ROLLER SPACER 2” - HYDRIVE XD TRENCHER TR-000054 DRIVE SPROCKET 2”...

  • Page 31: Bigfoot Xd 1200 Dig Spare Parts

    SPARE PARTS BIGFOOT XD TRENCHER 1200 DIG...
  • Page 32 SPARE PARTS BIGFOOT XD TRENCHER 1200 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 1/2 X 3 G8 UNC ZINC PLATED FA-000033 BOLT HEX 3/8 X 3/4 G8 UNC ZINC PLATED FA-000052...
  • Page 33 SPARE PARTS BIGFOOT XD TRENCHER 1200 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE 2” NOSE ROLLER SQUARE PIN - 1.5” SQ - TRENCHER COMMON PARTS TR-000053 NOSE ROLLER SPACER 2” - HYDRIVE XD TRENCHER TR-000054 DRIVE SPROCKET 2” PITCH 11 TOOTH - TRENCHER COMMON PARTS TR-000060 CHAIN RUBBER - BIGFOOT XD TRENCHER TR-000246...

  • Page 34: Bigfoot Xd 1500 Dig Spare Parts

    SPARE PARTS BIGFOOT XD TRENCHER 1500 DIG PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 35 SPARE PARTS BIGFOOT TRENCHER 1500 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 1/2 X 3 G8 UNC ZINC PLATED FA-000033 BOLT HEX 3/8 X 3/4 G8 UNC ZINC PLATED FA-000052...
  • Page 36 SPARE PARTS BIGFOOT TRENCHER 1500 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE NOSE ROLLER SPACER 2” - HYDRIVE XD TRENCHER TR-000054 DRIVE SPROCKET 2” PITCH 11 TOOTH - TRENCHER COMMON PARTS TR-000060 CHAIN RUBBER - BIGFOOT XD TRENCHER TR-000246 NOSE ROLLER ASSEMBLY - 2”...

  • Page 37: Hydrive 900 Dig Spare Parts

    SPARE PARTS HYDRIVE TRENCHER 900 DIG...
  • Page 38 SPARE PARTS HYDRIVE TRENCHER 900 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING HOUSING FL208 - 2 HOLE BE-000006 BEARING RING UC208-24RT BE-000018 BOLT HEX 1/2 X 1.1/4 G8 UNC ZINC PLATED FA-000025 BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 3.1/4 G8 UNC ZINC PLATED FA-000031...
  • Page 39 SPARE PARTS HYDRIVE TRENCHER 900 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE SPROCKET WASHER SPACER - TRENCHER COMMON PARTS TR-000008 NOSE ROLLER PIN WASHER - TRENCHER COMMON PARTS TR-000026 NOSE ROLLER SQUARE PIN - TRENCHER COMMON PARTS TR-000029 DRIVE SPROCKET 1.5/8”...

  • Page 40: Hydrive 1200 Dig Spare Parts

    SPARE PARTS HYDRIVE TRENCHER 1200 DIG PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 41 SPARE PARTS HYDRIVE TRENCHER 1200 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING HOUSING FL208 - 2 HOLE BE-000006 BEARING RING UC208-24RT BE-000018 BOLT HEX 1/2 X 1.1/4 G8 UNC ZINC PLATED FA-000025 BOLT HEX 1/2 X 1 G8 UNC ZINC PLATED FA-000026 BOLT HEX 1/2 X 3.1/4 G8 UNC ZINC PLATED FA-000031...
  • Page 42 SPARE PARTS HYDRIVE TRENCHER 1200 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE SPROCKET WASHER SPACER - TRENCHER COMMON PARTS TR-000008 NOSE ROLLER PIN WASHER - TRENCHER COMMON PARTS TR-000026 NOSE ROLLER SQUARE PIN - TRENCHER COMMON PARTS TR-000029 DRIVE SPROCKET 1.5/8”...

  • Page 43: Hydrive Xd 1200 Dig Spare Parts

    SPARE PARTS HYDRIVE XD TRENCHER 1200 DIG...
  • Page 44 SPARE PARTS HYDRIVE XD TRENCHER 1200 DIG - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING HOUSING F208 - 4 HOLE BE-000007 BEARING RING UC208-24RT BE-000018 BOLT HEX 1/2 X 1.1/4 G8 UNC ZINC PLATED FA-000025 BOLT HEX 1/2 X 2.1/2 G8 UNC ZINC PLATED FA-000027 BOLT HEX 1/2 X 3.1/4 G8 UNC ZINC PLATED FA-000031...
  • Page 45 SPARE PARTS HYDRIVE XD TRENCHER 1200 DIG - PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE 2” NOSE ROLLER SQUARE PIN - 1.5” SQ - TRENCHER COMMON PARTS TR-000053 NOSE ROLLER SPACER 2” - HYDRIVE XD TRENCHER TR-000054 DRIVE SPROCKET 2” PITCH 11 TOOTH - TRENCHER COMMON PARTS TR-000060 BOOM ADJUSTER ROD 1”...

  • Page 46: Head Start Crumber Spare Parts

    SPARE PARTS HEADSTRART CRUMBER - TR-001344 SCRAPER SHOE SIZE ORDER CODE 150MM SS-000006 200MM SS-000007 PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 47 SPARE PARTS HEADSTRART CRUMBER - TR-001344 - PART LIST REF NO. DESCRIPTION ORDER CODE BOLT HEX 5/16 X 1.1/4 G8 UNC ZINC PLATED FA-000063 NUT NYLOC 5/16 UNC GR5 ZP FA-000094 SCREW BUTTON HEAD SOCKET M10 X 16 G10.9 ZP FA-000106 SCRAPER ARM PIN A - (280008) - 97MM OAL, 91MM SL, 12.7MM DIA.
  • Page 48 SPARE PARTS HEADSTRART XD CRUMBER - TR-001453 SCRAPER SHOE SIZE ORDER CODE 150MM TR-000635 200MM TR-000636 250MM TR-000954 PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 49 SPARE PARTS HEADSTRART XD CRUMBER - TR-001453 - PARTS LIST REF NO. DESCRIPTION ORDER CODE NUT NYLOC 3/8 UNC GR5 ZP FA-000093 SCREW BUTTON HEAD SOCKET M10 X 16 G10.9 ZP FA-000106 BOLT HEX 3/8 X 1.1/4 G8 UNC ZINC PLATED FA-000149 SCRAPER ARM PIN A - (280008) - 97MM OAL, 91MM SL, 12.7MM DIA.

  • Page 50: Chain Spare Parts

    SPARE PARTS MEASURE CUT WIDTH FROM TIP OF THE TOOTH TO 100MM TIP OF THE TOOTH AT THE WIDEST STATION COMPLETE CHAINS - EARTH REF NO. DESCRIPTION ORDER CODE COMPLETE EARTH CHAIN - 100MM CUT COMPLETE EARTH CHAIN - 150MM CUT PLEASE SEE COMPLETE EARTH CHAIN - 200MM CUT PRICEBOOK...
  • Page 51 SPARE PARTS COMPLETE CHAINS - COMBO REF NO. DESCRIPTION ORDER CODE COMPLETE COMBO CHAIN - 100MM CUT COMPLETE COMBO CHAIN - 150MM CUT PLEASE SEE COMPLETE COMBO CHAIN - 200MM CUT PRICEBOOK COMPLETE COMBO CHAIN - 250MM CUT COMPLETE COMBO CHAIN - 300MM CUT COMPLETE CHAINS - DIGGATAC REF NO.
  • Page 52 SPARE PARTS 1 5/8” CHAIN OPTIONS AND BUILD CODES PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 53 SPARE PARTS 1 5/8” CHAIN PARTS LIST REF NO. DESCRIPTION ORDER CODE CHAIN SPACER CH-000001 CHAIN SPACER CH-000002 CHAIN SPACER CH-000003 CHAIN - SPACER BLOCK CH-000004 CHAIN - SPACER BLOCK CH-000005 CHAIN - TOOTH SPACER CH-000014 CHAIN - TOOTH SPACER CH-000015 CHAIN - SPACER BLOCK CH-000061...
  • Page 54 SPARE PARTS 1 5/8” CHAIN PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE BOLT HEX UNC ZINC PLATED FA-000061 NUT NYLOC ZINC PLATED FA-000093 BOLT HEX G8 UNC ZINC PLATED FA-000227 CUP TOOTH RIGHT W-000083 DIGGATAC LEFT HAND W-000086 DIGGATAC RIGHT HAND W-000088 DIGGATAC CENTRE TOOTH 5 W-000090...
  • Page 55 SPARE PARTS 2” CHAIN OPTIONS AND BUILD CODES...
  • Page 56 SPARE PARTS 2” CHAIN PARTS LIST REF NO. DESCRIPTION ORDER CODE 17 2” CHAIN CH-000020 2” CHAIN - TOOTH SPACER CH-000024 2” CHAIN - TOOTH SPACER CH-000026 2” - 17mm CHAIN SPACER CH-000028 2” - 34mm CHAIN SPACER 2” - 46mm CHAIN SPACER CH-000032 CH-000036 2”...
  • Page 57 SPARE PARTS 2” CHAIN PARTS LIST (CONT) REF NO. DESCRIPTION ORDER CODE W-000092 2IN DIGGATAC RIGHT W-000094 2IN DIGGATAC LEFT 2IN DIGGATAC CENTRE W-000096 W-000099 2” CUP TOOTH RIGHT...

  • Page 58: Gearbox Spare Parts

    SPARE PARTS GB-002297 -TRENCHER GEARBOX ASSEMBLY - MINI BIGFOOT PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 59 SPARE PARTS GB-002297 -TRENCHER GEARBOX ASSEMBLY - MINI BIGFOOT - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER 362A-368A BE-000021 BOLT HEX M10 X 110 G8.8 ZINC PLATED FA-000002 NUT NYLOC M10 CL8 ZP FA-000097 KEY STEEL GB-000005...
  • Page 60 SPARE PARTS GB-002840 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 61 SPARE PARTS GB-002840 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER 362A-368A BE-000021 BOLT HEX M10 X 110 G8.8 ZINC PLATED FA-000002 NUT NYLOC M10 ZINC PLATED FA-000097 KEY - LOCK - 7.94 X 19 GB-000005 RING GEAR - S2 - ALL RATIOS GB-000011...
  • Page 62 SPARE PARTS GB-003325 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT XD PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 63 SPARE PARTS GB-003325 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT XD - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER 362A-368A BE-000021 BOLT HEX M10 X 110 G8.8 ZINC PLATED FA-000002 NUT NYLOC M10 ZINC PLATED FA-000097 KEY - LOCK - 7.94 X 19 GB-000005 RING GEAR - S2 - ALL RATIOS GB-000011...
  • Page 64 SPARE PARTS GB-002703 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT XD HIGH FLOW PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 65 SPARE PARTS GB-002703 -TRENCHER GEARBOX ASSEMBLY - BIGFOOT XD HIGH FLOW - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER BE-000021 NUT NYLOC FA-000097 SCREW SOCKET HEAD CAP UNC ZINC PLATED FA-000115 SCREW SOCKET HEAD CAP ZINC PLATED FA-000126 KEY STEEL GB-000005...
  • Page 66 SPARE PARTS GB-000626 -TRENCHER GEARBOX ASSEMBLY - HYDRIVE PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 67 SPARE PARTS GB-000626 -TRENCHER GEARBOX ASSEMBLY - HYDRIVE - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER BE-000021 BOLT HEX ZINC PLATED FA-000002 NUT NYLOC ZP FA-000097 KEY STEEL GB-000005 RING GEAR - S2 - ALL RATIOS GB-000011 LOCKNUT WITH BUILT IN SPACER - S2 GB-000159 GEARSET - 23 SPLINE CARRIER - 14T BELL MOTOR SUN GEAR...
  • Page 68 SPARE PARTS GB-000636 -TRENCHER GEARBOX ASSEMBLY - HYDRIVE XD PM-000111-A Trencher: Service and Repair Manual - November 2014...
  • Page 69 SPARE PARTS GB-000636 -TRENCHER GEARBOX ASSEMBLY - HYDRIVE XD - PARTS LIST REF NO. DESCRIPTION ORDER CODE BEARING TAPERED ROLLER BE-000021 BOLT HEX G8.8 ZINC PLATED FA-000002 NUT NYLOC M10 CL8 ZP FA-000097 KEY STEEL GB-000005 RING GEAR - S2 - ALL RATIOS GB-000011 LOCKNUT WITH BUILT IN SPACER - S2 GB-000159...

  • Page 70: Contact Information

    For further information on spare parts please contact one of the Digga sales office below your closest authorised Digga Dealer. DIGGA INTERNATIONAL SALES OFFICES ASIA PACIFIC NORTH AMERICA EUROPE DIGGA HEAD OFFICE - BRISBANE DIGGA NORTH AMERICA DIGGA EUROPE 4 Octal St, Yatala QLD 4207...
  • Page 72 Australian Designed and Manufactured PM-000111-A PM-000111-A Trencher: Service and Repair Manual - November 2014...
