PW1000, PW1500, PW1750
Awning
EN
Operating manual . . . . . . . . . . . . . . . . . . . . 12
Markise
DE
Bedienungsanleitung . . . . . . . . . . . . . . . . . 31
Store extérieuru
FR
Notice d'utilisation . . . . . . . . . . . . . . . . . . .50
Toldo
ES
Instrucciones de uso . . . . . . . . . . . . . . . . . .70
Toldo
PT
Manual de instruções . . . . . . . . . . . . . . . . .90
Tenda da sole
IT
Istruzioni per l'uso . . . . . . . . . . . . . . . . . . . 110
Zonnescherm
NL
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . . 129
Markise
DA
Betjeningsvejledning . . . . . . . . . . . . . . . . 148
Markis
SV
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . . 166
Markise
NO
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . . 184
AWNINGS
PERFECTWALL
More information https://www.caravansplus.com.au
Markiisi
FI
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 202
Синусоидальный инвертор
RU
Инструкция по эксплуатации . . . . . . . . . 221
Markiza
PL
Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 240
Markíza
SK
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 259
Markýza
CS
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 278
Előtető
HU
Használati utasítás. . . . . . . . . . . . . . . . . . . 296
Markiza
SL
Navodilo za uporabo . . . . . . . . . . . . . . . . 314
EL
. . . . . . . . . . . . . . . . 332

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PerfectWall PW1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic PerfectWall PW1000

Summary of Contents for Dometic PerfectWall PW1000

  • Page 1 AWNINGS PERFECTWALL Markiisi Käyttöohje ......202 Синусоидальный инвертор Инструкция по эксплуатации ..221 Markiza Instrukcja obsługi .
  • Page 2 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 3 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 4 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 5 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 6 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 7 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 8 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 9 PW1000, PW1500, PW1750 More information https://www.caravansplus.com.au...
  • Page 10 PW1000, PW1500, PW1750 15 – 25 Nm More information https://www.caravansplus.com.au...

  • Page 11: Table Of Contents

    PW1000, PW1500, PW1750 WARNING! • This instruction manual must be read and understood before the device is operated, cleaned or serviced. • This product must be mounted by a specialist. Improper assembly can lead to serious injury. Alterations to the product can be extremely dangerous and lead to serious injury or damage to the device.

  • Page 12: Notes On Using The Instruction Manual

    PW1000, PW1500, PW1750 Notes on using the instruction manual Notes on using the instruction manual WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product.
  • Page 13 Safety instructions PW1000, PW1500, PW1750 • Retract the awning if strong winds, heavy rain or snowfall are imminent. • Make sure that water or snow does not accumulate on the fabric. Otherwise this could damage the awning or the awning arms could collapse and cause severe or fatal injury.

  • Page 14: Scope Of Delivery

    PW1000, PW1500, PW1750 Scope of delivery • Only retract the awning when the fabric is free of debris (branches, leaves or similar). Otherwise the awning may be damaged when it is retracted. • Keep the awning free of dirt to prevent abrasions, stains and mildew. •...

  • Page 15: Accessories

    Special awning cleaner Repair Kit Awning repair patch Intended use The PerfectWall PW1000, PW1500 and PW1750 are awnings are suitable for instal- lation on motor homes or caravans. The awnings may only be used while the vehicle is stationary. More information https://www.caravansplus.com.au...

  • Page 16: Technical Description

    PW1000, PW1500, PW1750 Technical description Technical description PerfectWall PW1000, PW1500 and PW1750 are awnings which can be extended and retracted using a hand crank. The PerfectWall PW1500 and PW1750 awnings can optionally also be extended and retracted with a 12 V motor that is controlled by switch or remote control.

  • Page 17: Operating The Awning

    Operating the awning PW1000, PW1500, PW1750 Operating the awning Observe the safety instructions in chapter “Safety instructions” on page 13. Note on the vehicle location NOTICE! • Park the vehicle so that no debris (branches, leaves or similar) gets on to the fabric.
  • Page 18 PW1000, PW1500, PW1750 Operating the awning NOTICE! Beware of damage. The fabric of the awning should not hang down at the edges, and must remain taut at all times. If the fabric hangs down, it could rub against the arms and become damaged. The fabric used for long awnings should not sag in the middle.
  • Page 19 Operating the awning PW1000, PW1500, PW1750 ➤ Press the button of the switch or the remote control until the awning is extended to the required position. Position the struts vertically and back under the lead rail every 30 cm so that the awning stays secured at all times. ➤...
  • Page 20 PW1000, PW1500, PW1750 Operating the awning Mounting the tension rafter (fig. c, page 7) Awnings with a length of 4 metres or more need to have a tension rafter fitted in the middle of the awning. This prevents the awning from sagging. ➤...
  • Page 21 Operating the awning PW1000, PW1500, PW1750 ➤ Double-check that the awning is fully retracted before starting your journey. The lead rail should be right up against the housing. ➤ Remove the hand crank from the holder on the awning. NOTICE! Beware of damage. If the awning is retracted when wet, extend it again and let the fabric dry out at the next opportunity.
  • Page 22 PW1000, PW1500, PW1750 Operating the awning Unrolling the blind (only PW1750) ➤ Open the lock in the middle of the lead rail (fig. d, page 8). ➤ Push the brackets on the right and left into the rails of the roller blind (fig. e, page 8).
  • Page 23 Operating the awning PW1000, PW1500, PW1750 Adjusting the 12 V motor (only PW1500/PW1750, optional) NOTE The 12 V motor is pre-assembled in the roller tube. ➤ If the awning no longer fully closes or opens, then adjust the 12 V motor (fig. l, page 10).

  • Page 24: Cleaning And Maintenance

    – Leave the fabric to dry. NOTE The manufacturer recommends: To clean the cloth, use the Dometic awning cleaner (ref. no. 9600000165, available from your service partner). Lubricating ➤ If required, lubricate the joints of the awning with paraffin wax, teflon oil or silicone oil.
  • Page 25 Cleaning and maintenance PW1000, PW1500, PW1750 Checking WARNING! Do not use the awning if any settings or maintenance work are required. If you discover any damage, please contact a service partner in the respective country (see addresses on the back of the manual). ➤...

  • Page 26: Troubleshooting

    PW1000, PW1500, PW1750 Troubleshooting Patching small holes in the fabric You can patch any small holes in the fabric or parts where the coating has come off: ➤ Use a cotton cloth to rub around the damaged area with a small amount of liquid vinyl plaster (ref.

  • Page 27: Warranty

    Warranty PW1000, PW1500, PW1750 Warranty The statutory warranty period applies. If the product is defective, please contact your retailer or the manufacturer's branch in your country (see the back of the instruction manual for the addresses). For repair and guarantee processing, please include the following documents when you send in the device: •...

  • Page 28: Technical Data

    PW1000, PW1500, PW1750 Technical data Technical data PerfectWall PW1000 Width: 2.6 m 3.5 m 4.5 m Extended: 2.5 m Weight: 18.6 kg 21 kg 24 kg 27 kg 30 kg PerfectWall PW1500 Width: 1.5 m 2.6 m 3.5 m Extended: 2.5 m...
  • Page 29 Technical data PW1000, PW1500, PW1750 12 V motor (only PW1500 and PW1750) Connection voltage: 12 Vg (11 – 15 V) Amperage: Output power: 84 W Torque: 35 Nm Inspection/certification: More information https://www.caravansplus.com.au...
  • Page 30 AUSTRIA Dometic (Pty) Ltd. Dometic Austria GmbH MEXICO Regional Office Neudorferstraße 108 Dometic Mx, S. de R. L. de C. V. South Africa & Sub-Saharan Africa A-2353 Guntramsdorf Circuito Médicos No. 6 Local 1 2 Avalon Road +43 2236 908070 Colonia Ciudad Satélite...
