Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions..........................10 Features............................... 16 Installation..............................17 Starting up..............................21 Connections and controls........................24 Operating..............................31 7.1 Starting the device........................... 31 7.2 Main menu............................
Page 4
Table of contents 7.6 Functions in 7-channel DMX mode................... 48 Technical specifications........................50 Plug and connection assignments....................53 Troubleshooting............................54 Cleaning............................... 56 Protecting the environment......................57 LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. LED Mini Studio PAR One 40° LED Mini Studio PAR One 20°...
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...
Page 8
General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
Page 9
General information Warning signs Type of danger Warning – suspended load. Warning – danger zone. LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED technology. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
Page 11
Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
Page 12
Safety instructions DANGER! Electric shock caused by short-circuit Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. WARNING! Eye damage caused by high light intensity Never look directly into the light source.
Page 13
Safety instructions WARNING! Risk of injury caused by falling objects Make sure that the installation complies with the standards and rules that apply in your country. Always secure the device with a secondary safety attachment, such as a safety cable or a safety chain. Secure the barn door with a safety cable on the spotlight after installation.
Page 14
Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
Page 15
Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
Features Features Special features of the device: 7 × 10 W RGBW 4-in-1 LED chips Control via DMX (three different modes) and via buttons and display on the unit Built-in automatic show programmes Sound control Master / Slave mode Overheat protection Self-locking double bracket for floor placement or hanging Remote control, colour filter frame, 2 ×...
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
Page 18
Installation NOTICE! Risk of overheating The distance between light output and the illuminated surface must be more than 1.5 m (19.7in). Provide sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
Page 19
Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. Mounting options You can install the unit in hanging or standing position.
Installation Please note that this device must not be connected to a dimmer. Inserting batteries into the Push the lock of the battery holder towards the centre of the housing and pull out the battery remote holder like a drawer. Insert the batteries in the correct polarity according to the marking on the remote.
Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
Starting up Connections in master/slave When you configure a group of devices in master/slave mode, the first unit will control the mode other units for an automatic, sound-activated, synchronized show. This function is ideal when you want to start a show immediately. Connect the DMX output of the master device to the DMX input of the first slave device.
Connections and controls 1 LED 2 Locking screws for the bracket 3 Bracket for floor placement or hanging LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
Connections and controls 4 [DMX OUT] DMX output 5 [DMX IN] DMX input 6 Display 7 Buttons for menu control [ENTER] Confirms a selected value. Decreases the displayed value by one. Increases the displayed value by one. [MENU] Calls up the main menu or a submenu. 8 Mains cabling (power cord) with safety plug 9 Fuse holder for the fuse LED Mini Studio PAR One 40°...
Connections and controls 16 On / off switch 17 [DMX] Activates DMX mode. Then you can enter the DMX address with the number buttons 18 [SLAVE] Activates master / slave mode 19 [SPEED] Sets the running speed 20 [UP], [DOWN] Selects a programme or number.
Connections and controls 21 [0…9] Selects a programme number [R], [G], [B], [W] Selects a colour. [R], [G], or [B] for primary colours red, green and blue, [W] for white. Use the buttons to turn the respective colour on or off. When the color is indicated on the display of the device, you can adjust its intensity with [UP] or [DOWN] in a range from 0 to 255.
Operating Operating 7.1 Starting the device Connect the device to the power supply to start operation. After a few seconds, the display indicates that a reset is in progress. The device is then ready for use. 7.2 Main menu Press [MENU] to activate the main menu and select an operating mode. Use the arrow buttons to change the respectively displayed value.
Operating DMX address Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘Addr’ . Confirm the selection with [ENTER]. ð The display shows the current DMX address. Press the arrow buttons repeatedly until the display shows the desired DMX address (display shows ‘A001’...
Operating Sound control Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘SoUn’ . Confirm the selection with [ENTER]. Press the arrow buttons repeatedly until the display shows the desired value for the desired sound control mode (display shows ‘SoU1’ … ‘SoU5’ ). Confirm the selection with [ENTER].
Operating Selection of constant colour Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘CoLo’ . Confirm the selection with [ENTER]. Press the arrow buttons to select a constant colour ( ‘Co01’ … ‘Co51’ ). Confirm the selection with [ENTER].
Operating Selection of colour macro Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘CoLo’ . Confirm the selection with [ENTER]. Press the arrow buttons to select the desired colour macro. Display: ‘Co01’ … ‘Co05’...
Operating Selection of mixed colour Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘CoLo’ . Confirm the selection with [ENTER]. Press the arrow buttons repeatedly until the display shows ‘AtF’ . Confirm the selection with [ENTER]. Press the arrow buttons to select the colour you want to adjust.
Operating Automatic show Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘AUto’ . Confirm the selection with [ENTER]. Press the arrow buttons repeatedly until the display shows the desired value for the desired auto show programme ( ‘AUt1’ … ‘AUt5’ ). Confirm the selection with [ENTER].
Operating Software version Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘ver’ . ð The currently installed software version is displayed. Temperature Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘tEnP’...
Operating Remote control Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘reno’ . Confirm the selection with [ENTER]. Press the arrow buttons to select ‘on’ if you want to activate remote control and ‘oFF’...
Operating Master / slave mode Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘SLAv’ . Confirm the selection with [ENTER]. Press the arrow buttons to select ‘SLA’ if you want to activate slave mode. Confirm the selection with [ENTER].
Operating DMX mode Press [MENU] to activate the main menu. Press the arrow buttons repeatedly until the display shows ‘Chnd’ . Confirm the selection with [ENTER]. Press the arrow buttons repeatedly until the display shows the desired DMX channel mode ( ‘1Ch’ = 1 channel, ‘4Ch’ = 4 channels, ‘7Ch’ = 7 channels). Confirm the selection with [ENTER].
Operating 7.4 Functions in 1-channel DMX mode Channel Value Function 1…4 Without function 5…9 10…14 Green 15…19 Blue 20…24 White 25…29 Colour macro 1 30…34 Colour macro 2 35…39 Colour macro 3 40…44 Colour macro 4 45…49 Colour macro 5 50…54 Colour macro 6 LED Mini Studio PAR One 40°...
Operating Channel Value Function 245…249 Colour macro 45 250…255 Colour macro 46 7.5 Functions in 4-channel DMX mode Channel Value Function 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) LED Mini Studio PAR One 40°...
Operating 7.6 Functions in 7-channel DMX mode Channel Value Function 0…255 Master dimmer (0 % bis 100 %) 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…7...
Page 49
Operating Channel Value Function 48…63 Colour change 3 64…79 Colour change 4 80…95 Colour change 5 96…111 Multicolour strobe effect 112…127 Fade effect 128…143 Colour synchronization 144…159 Colour change, shutter closing 160…175 Fade out and colour change 176…191 Fade in and colour change 192…207 Fade-in-out effect 208…223...
Technical specifications Technical specifications LED Mini Studio LED Mini Studio PAR One 20° PAR One 40° Light source 7 × RGBW 4in1 LED, 10 W Optical properties Beam angle 20° 40° Control Infrared remote control Control protocol DMX 512 Number of DMX channels 1, 4 or 7 Input connections DMX control...
Page 51
Technical specifications LED Mini Studio LED Mini Studio PAR One 20° PAR One 40° Fuse 5 mm × 20 mm, 2 A, 250 V, fast-acting Degree of protection IP20 Battery remote control Battery type Lithium button cell, 3 V, CR 2025 Mounting options Standing, hanging Dimensions (W ×...
Page 52
Technical specifications Further information LED Mini Studio PAR One LED Mini Studio PAR One 20° 40° Number of LEDs Power of the individual LEDs Colour mixture RGBW RGBW LED type x-in-1 x-in-1 Base housing Fanless Remote control Included Included Wireless DMX Housing colour Black Black...
Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...
Troubleshooting Troubleshooting NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation.
Page 55
DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
Page 58
Notes LED Mini Studio PAR One 40° LED Mini Studio PAR One 20° LED-PAR...
