FEBL62Q1577RB-01
ML62Q1577 Reference Board
User's Manual
Issue Date: January 19, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML62Q1577 and is the answer not in the manual?

Questions and answers

Related Manuals for LAPIS Semiconductor ML62Q1577

Summary of Contents for LAPIS Semiconductor ML62Q1577

  • Page 1 FEBL62Q1577RB-01 ML62Q1577 Reference Board User's Manual Issue Date: January 19, 2018...
  • Page 2 US Export Administration Regulations and the Foreign Exchange and Foreign Trade Act. 13) This document, in part or in whole, may not be reprinted or reproduced without prior consent of LAPIS Semiconductor. Copyright 2018 LAPIS Semiconductor Co., Ltd.

  • Page 3: Table Of Contents

    ML62Q1577 Reference Board User’s Manual Table of Contents Overview ................................1 1.1. Features ................................1 1.2. ML62Q1577 Reference Board Outline Drawing .................... 2 Function of ML62Q1577 Reference Board ......................3 2.1. Power Circuit ..............................3 2.2. Connector for EASE1000 (CNE) ........................4 2.3.
  • Page 4 ML62Q1577 Reference Board User’s Manual Preface This manual describes about the ML62Q1577 Reference Board : RB-D62Q1577TB100. Refer to following documents when necessary. – ML62Q1500 Group User’s Manual Describes about the microcontroller ML62Q1500 Group. – EASE1000 User’s Manual Describes about the On-chip emulator EASE1000.

  • Page 5: Overview

    1. Overview 1.1. Features ML62Q1577 Reference Board is for learning how to use the ML62Q1577, on which adding external user components if necessary. Using ML62Q1577 Reference Board with LAPIS Semiconductor’s on-chip emulator EASE1000 delivered with the software development environments, help user’s software development and debugging and programming the Flash.

  • Page 6: Ml62Q1577 Reference Board Outline Drawing

    ML62Q1577 Reference Board User’s Manual 1.2. ML62Q1577 Reference Board Outline Drawing Fig. 1 show the ML62Q1577 Reference Board. Jumper ・PWR ・J2 ・J1 ・P20 ・P21 ・P22 Fig. 1 ML62Q1577 Reference Board Outline Drawing FEBL62Q1577RB...

  • Page 7: Function Of Ml62Q1577 Reference Board

    ML62Q1577 Reference Board User’s Manual 2. Function of ML62Q1577 Reference Board 2.1. Power Circuit can select the input from 3.3VOUT of EASE1000 or CN1_3pin / CN2_2pin by PWR jumper. VTref ML62Q1577 3.3VOUT 2,4,6,8,10,12 UVDD Fig. 2 Power Circuit [Note] The power supply ON/OFF procedure in case of setting PWR jumper to the USR-side, and using EASE1000.

  • Page 8: Connector For Ease1000 (Cne)

    Fig. 3 EASE1000 Interface [Note] P00/TEST0 pin: P00/TEST0 pin of ML62Q1577 is initially set as the pulled-up input mode. When using EASE1000 do not set it as an output mode by the application program, otherwise EASE1000 cannot communicate with the ML62Q1577.

  • Page 9: Led (P20, P21, P22)

    ML62Q1577 Reference Board User’s Manual 2.3. LED (P20, P21, P22) P20-P22 of the ML62Q1577 are ports that can directly drive a LED. The Ports are connected to the LEDs through jumper-chip. Remove the jumper-chip when not using the LEDs. Remove when not using the LEDs Fig.

  • Page 10: P75, P74, P73, P72, P71

    2.5. P75, P74, P73, P72, P71 P75 to P71 are connected with CN1 using jumper chip. ML62Q1577 Reference Board can not use C5. C6, C7 and C8. Therefore please do not mount various parts on C5, C6, C7 and C8.

  • Page 11: User Interface

    ML62Q1577 Reference Board User’s Manual 3. User Interface Table 2 show the pin list of the ML62Q1577 Reference Board user interface connector CN1 and CN2. Table 2 ML62Q1577 Reference Board CN1/CN2 NAME NAME NAME NAME XT0/PIO0 XT1/PIO1 N.C. RESET_N P00/TEST0 N.C.

  • Page 12: Precaution For Use

    (1) The ML62Q1577 Reference Board is an unfinished product and intended for research and development and for expert use in the research and development facility only. The ML62Q1577 Reference Board is not intended for use for volume production or parts thereof.

  • Page 13: Pcb Specification, Bom And Schematic

    ML62Q1577 Reference Board User’s Manual 5. PCB specification, BOM and Schematic 5.1. ML62Q1577 Reference Board PCB specification Fig. 7 shows the Reference Board PCB dimensional outline drawing and layout of components. PCB part number: RB-D62Q1577TB100 Dimension: 55.88mm x 93.98mm FEBL62Q1577RB...
  • Page 14 ML62Q1577 Reference Board User’s Manual Fig. 7 Reference Board PCB dimensional outline drawing and layout of components (Top view) FEBL62Q1577RB...

  • Page 15: Ml62Q1577 Reference Board Bom

    Using CN1 and CN2, the diameter of connector pin should use the connector below 0.8mm, such as 0.5mm. The parts may be changed into another parts with equivalent part special quality. 5.3. ML62Q1577 Reference Board Schematic The next page shows the schematic of ML62Q1577 Reference Board FEBL62Q1577RB...
  • Page 16 ML62Q1577 Reference Board User’s Manual FEBL62Q1577RB...

  • Page 17: Revision History

    ML62Q1577 Reference Board User’s Manual Revision History Page Document No. Issue Date Description Previous Edition Edition FEBL62Q1577RB-01 January 19, – – First edition. 2018 FEBL62Q1577RB...
