Dometic A&E Two Step Series User Manual page 4

5. To Close Awning:
A. Return Awning to Travel Position
Pinch Point Hazard. When awning is closed,
bottom arm assemblies will fold down and
against back channel. To avoid personal in-
jury and/or property damage, keep pinch
points clear of objects and people.
Fig. 6
Fig. 7
R O LL
U P
1. Remove sun screen if installed. In one hand gently
pull on the pull strap while using the pull rod to flip
the Safe-T-Lock™ Lever down into the "ROLL UP"
position. See FIG. 7.
Have a firm grip on the pull strap before mov-
ing the Safe-T-Lock™ Lever to the "ROLL UP"
position. Do not allow the awning to close
uncontrolled. Damage to the awning and/or
RV may occur.
2. Before the awning begins to roll up, insert end of
pull rod into the pull strap loop and let the awning
roll in, controlling the speed with the rod in hand.
See FIG. 8.
Pinch
Point
Pinch
Point
4
Fig. 8
B. Lock Awning For Travel
FIG. 9
1. Secure each arm assembly by locking the travel
lock. Push down on the travel lock assembly
to secure. See FIG. 9. The awning is now com-
pletely closed and ready for travel.
A&E TWO STEP AWNING HELPFUL HINTS:
• Whenever the awning is wet while rolled up, as soon as
conditions allow, roll it out and let it dry before rolling it up
again. This will help prevent the formation of mildew and
add greatly to the life of the awning.
• Mildew does not form on the fabric itself, but on the
accumulated dust, dirt and grime. Periodically clean vinyl
or woven acrylic fabric using a mixture of 1/4 cup of dish
soap and 1/4 cup of bleach mixed with 5 gallons of warm
water. Liberally slosh the mixture on the top of the fabric
and roll the awning up for 5 minutes. This will apply the
mixture to the bottom as well. Roll it back out and hose off
with fresh water. Repeat if necessary. Allow to dry before
rolling up.
• Always make sure the awning is fully extended before
opening the entry door.
WHEN TO GET MORE HELP:
This User's Guide is intended to provide practical instruc-
tion for the sequential operation of the A&E Two Step Patio
Awning. If malfunctions occur that cannot be corrected by
reviewing this Guide, contact a Dometic Service Center or
a qualified service technician.
RO LL
UP
Lock
