Dear Customer:
You are now the proud owner of one of the finest and most modern
appliance that today's technology can produce. You and your new hob
are going to make a great team together. Once you have tried the
Induction technology, you will probably not be going back to any other
types of electrical cook tops again. But first you should get to know the
product so as to gain the maximum benefit from it. This book contains
information on how to operate and care for your hob so that you may
gain the maximum benefit from it. Please read all the instructions,
carefully before operating the hob and store this book in a safe place for
future reference.
CREATE RECORD FOR FUTURE USE
Purchase Date : __________________________
Model Number: __________________________
Serial Number : __________________________
NOTE
The Serial and Model numbers may be found on the serial
number and rating label located under the hob.
QUESTIONS?
Pls Write To :
Kollektion Distribution Sdn. Bhd.
Lot 11A, Jalan 223, Section 51A,
46100 Petaling Jaya,
Selangor Darul Ehsan, Malaysia
For Toll- Free Telephone Support:
Care Line 1-800-881-770
For Online and Product Information:
www.kollektion.com.my
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LKIH-7122W and is the answer not in the manual?

Questions and answers

Related Manuals for Lebensstil Kollektion LKIH-7122W

Summary of Contents for Lebensstil Kollektion LKIH-7122W

  • Page 1 Dear Customer: You are now the proud owner of one of the finest and most modern appliance that today’s technology can produce. You and your new hob are going to make a great team together. Once you have tried the Induction technology, you will probably not be going back to any other types of electrical cook tops again.

  • Page 2: Safety Instructions

    Safety Instructions IMPROTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance. Save these instructions for future reference. This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given. WARNING This symbol will help alert you to situations concerning your personal safety INFOMATION/PRACTICAL TIPS This symbol will provide information’s that are useful to you...
  • Page 3  The installation and connection of the new appliance MUST be carried out by qualified personnel  Repairs to the appliance are only to be carried out by approved service personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. If your appliance needs repairing, please contact the nearest Service Centre.
  • Page 4 Rated Wattage Dimensions in mm Model Voltage Range (W x L x H) 220- 3540 – 3700W LKIH-7122W 240V 420 x 720 x 47 (L-2300W x R- 1400W) 50Hz Note: L – Left Cooking Zone R – Right Cooking Zone...
  • Page 5 Model Appearance Induction Hob Model  LKIH-7122W LKIH-7122W...

  • Page 6: Hob Installation

    (Please refer Fig. 1) 50 mm 50 mm 30 mm Fig. 1 50 mm  For operational purposes it is best to ensure there is sufficient ventilation available. As shown in the diagram below. (Fig. 2)  Groove Opening LKIH-7122W...

  • Page 7: Electrical Connection

    760 mm 130 mm 50 mm Fig. 2 Electrical Connection WARNING Always ensure the mains have been turned off when connecting the wiring to the hob or when disconnecting the wiring from the  Before connecting, check that the nominal voltage of the appliance, which is the voltage stated on the rating label (shown in Fig.
  • Page 8 Power Connection Diagram and Power Rating Label Fig. 3...
  • Page 9 Lebensstil Kollektion Induction Hobs are operated through a user friendly touch panel that are labelled clearly for easy operation of each function, which has an audible sound when any key is operated Operation Guide Read These Instructions Carefully Before Using The Hob Fig.
  • Page 10 Symbol Description Function On/Off Key Activates the Left Cooking Zone Power Regulator Key Decreases Power Level of Left Cooking Zone Power Regulator Key Increases Power Level of Left Cooking Zone Activates the Left Cooking Zone’s Outer Booster Key Heating Element Timer Key Controls the Timer Functions Timer Control Key...
  • Page 11 Symbol Description Function Left Cooking Zone Shows the Selected Power Level of Power Level the Left Cooking Zone Indicator Left Cooking Zone Indicates Timer Set for Left Timer Indicator Cooking Zone Timer Hour Display Indicates Hour Set Timer Minute Indicates Minute Set Display Right Cooking Zone Indicates Timer Set for Right...
  • Page 12 The Power Level Indicator of the cooking zone selected would continue to flash in sequential until a Power Level is selected. Note: (a) If a Power Level is not selected within 10 sec of activation, the hob would automatically shut OFF. (b) The duration when the Power Level is flashing is the “Standby Mode”...
  • Page 13 – 4. To cancel the Timer, use the key to count down the timer 0 : 00 back to 5. The timer function can used without the activation of the cooking zone (e.g. to time the duration for meat marinating), however the setting would be reset upon activation of the cooking zones.

  • Page 14: Booster Function

    Booster Function 1. When the cooking zone has been activated, touch the key of the corresponding cooking zone once, this would immediately increase the power level to the maximum power level (Level 6) available. To decrease the power level use keys.
  • Page 15 Cookware Selection And Material Type Selecting The Correct Cookware  The magnetic sensors within the induction elements requires the use of cookware made of magnetic metallic material in order to start the heating process at the cooking zones.  When purchasing pans, look for cookware specifically identified by the manufacturer for use with induction cook tops.
  • Page 16 Correct Method Of Using Cookware On The Induction Hob - Flat bottom and straight sides. - Pan size bottom meets or exceeds the recommended minimum requirement which is 90mm (measuring method as per Fig. 7) for cooking zone use. - Pan is properly balanced and rests completely on the cook top surface.

  • Page 17: General Care And Cleaning

     Please take note that any of the above mentioned conditions would cause uneven heating of the cookware and affect the cooking results.  As the induction elements have a pan detection feature, when a non metallic or a cookware with a pan size bottom lesser than the minimum requirement of 90mm is used, all the indicators bars of the power zone indicator would continuously flash indicating a pan detection failure”...
  • Page 18 CAUTION Do Not use steam cleaner for cleaning or cleansing of the hob WARNING Do Not use a ceramic glass cleaner when the hob is still hot. The fumes can be hazardous to your health, and can chemically damage the ceramic-glass surface. For Light to Moderate Soil ceramic glass cleaner Apply a few drops...
  • Page 19 Do Not Use The Following On The Induction Hob  Abrasive cleaner and scouring pads, such as metal and some nylon pads, may scratch the hob top, making it more difficult to clean.  Do not use harsh cleaners such as chlorine bleach, ammonia or oven cleaners, as they may etch or discolour the hob top.
  • Page 20 used is of Induction compatible material ands meets the minimum pan size requirement.  Cookware had been removed from the cooking zone before switching OFF. Place cookware back on the cooking zone or if finished cooking turn OFF the affected Cooking Zone. Induction Hob Timer Display Shows E3 Error ...
  • Page 21 Food Not Heating Evenly Or Poor Cooking Results  Many factors could affect cooking results. Adjust the recipe’s recommended power levels or cooking times.  Improper cookware had been used, ensure cookware used is of a recommended material type and of a proper heated surface size. ...

  • Page 22: Warranty Information

    Areas Of Discolouration On Ceramic Hob Surface  Mineral deposits from water and food. Wet surface with water and sprinkle on a ceramic glass cleaner. Clean away with a damp paper towel or fluff-free cloth until the stain disappears. Wipe away remaining paste away, then apply a small amount of ceramic glass cleaner and polish with a clean paper towel or fluff- free cloth.
  • Page 23 It can be found on or under the cooker, or on the packaging document. For damages due to improper usage, the service centre shall levy a reasonable charge. 8. Our products conform completely to the national safety standards. Only qualified personnel are allowed to repair them WARNING ! Do Not modify the internal structure of the Hob...
