1 Document information
1.1 Clarification of notation
Note: This type of paragraph calls readers attention to a notice or related theme.
IMPORTANT: This type of paragraph highlights a procedure, adjustment etc., which can cause a
damage or improper function of the equipment if not performed correctly and may not be clear at
first sight.
Example: This type of paragraph contains information that is used to illustrate how a specific function
works.
1.2 About this guide
InteliVision 5 is the 5,7" colour display unit for ComAp controllers. It is designed as a Plug and Play solution
and it presents a simple solution with high visibility of all engine and gen-set data, monitoring information in
colourful direction.
The new screens correspond to wide variety of daily usage and offer significant step ahead.
The compact size, robustness and user-friendly design of InteliVision 5 introduce the valuable solution for every
day usage where more information on the screen and display size is preferred alternative.
The same cut-out across all Comaps' products helps InteliVision 5 to be easily used as a replacement of or
alternative to IG-Display. Regardless of the size it can be also used as an alternative to IS-Display or
InteliVision 8.
InteliVision 5 is designed to be connected to the single controller only.
1.3 Legal notice
This End User's Guide/Manual as part of the Documentation is an inseparable part of ComAp's Product and
may be used exclusively according to the conditions defined in the "END USER or Distributor LICENSE
AGREEMENT CONDITIONS - COMAP CONTROL SYSTEMS SOFTWARE" (License Agreement) and/or in
the "ComAp a.s. Global terms and conditions for sale of Products and provision of Services" (Terms) and/or in
the "Standardní podmínky projektů komplexního řešení ke smlouvě o dílo, Standard Conditions for Supply of
Complete Solutions" (Conditions) as applicable.
ComAp's License Agreement is governed by the Czech Civil Code 89/2012 Col., by the Authorship Act
121/2000 Col., by international treaties and by other relevant legal documents regulating protection of the
intellectual properties (TRIPS).
InteliVision 5 - Global Guide
