Controller
Option
port
A
RS232(1)
B
RS485(1)
RS232(2)*
C
**
D
RS485(2)*
Note:
* RS232 or RS485 (1) direct connection can be used. They cannot be used simultaneously.
** Only available in IG-NTC / IS-NT-BB
InteliVision 5 - Global Guide
RS232(1) mode = DIRECT
RS485(1)conv. = DISABLED
Possible only for the concrete controllers firmwares where the setpoint RS485(1)
conv. in the setpoint group Comms is available
RS485(1) mode = DIRECT
RS485(1)conv. = ENABLED
RS232(2) mode = DIRECT
RS485(2)conv. = DISABLED
RS232(2) mode = DIRECT
RS485(2)conv. = ENABLED
Settings in the controller
