GAS SUPPLY APPLICATION GUIDE
Natural Gas or Propane
Modulating & Condensing
Boilers and Water Heaters
Applies to the following models:
Boilers
•
AM 399B
•
AM 500B
•
AM 750B
•
AM 1000B
Water Heaters
•
AM 399W
•
AM 500W
•
AM 750W
•
AM 1000W
04/08/2014
Page 1 of 8
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288
Gas-Fired Boilers and Water Heaters
Pending
Pending
399 / 500 / 750 / 1000
AM Gas Supply Piping Example
GF-146-G
TAG-0073_0B
PR1 04/08/2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aerco AM Series
Summary of Contents for Aerco AM Series
-
Page 1: Water Heaters
• AM 399W • AM 500W • AM 750W • AM 1000W Pending AM Gas Supply Piping Example 04/08/2014 Page 1 of 8 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 PR1 04/08/2014... - Page 2 GAS PRESSURE REQUIREMENTS ........... 3 GAS PIPING ..................4 GAS SUPPLY MAIN SIZING.............. 5 GAS HEADER SIZING ............... 5 Page 2 of 8 PR1 04/08/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288...
-
Page 3: Gas Pressure Requirements
3. GAS PRESSURE REQUIREMENTS The AERCO AM Series of boilers and water heaters require a stable gas input pressure. The inlet supply to the unit must be at least 3 “ W.C. when firing at maximum input. Maximum allowable gas pressure is 13”... -
Page 4: Gas Piping
DO NOT EXCEED 13” W. C. on the inlet side of the unit at any time. Page 4 of 8 PR1 04/08/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288... - Page 5 A typical gas piping header diagram for two AERCO AM Series boilers is illustrated in Figure 2. Header should be located above or behind boiler. Gas piping should not be installed directly over top or front of any part of boiler.
- Page 6 RIGHT side: 4’’ (100 mm) • LEFT side: 4’’ (100 mm) • BACK of the boiler: 20’’ (500 mm) Page 6 of 8 PR1 04/08/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288...
- Page 7 TAG-0073_0B FRONT VIEW SIDE VIEW Figure 3: AM 399/500 Clearances FRONT VIEW SIDE VIEW Figure 4: AM 750/1000 Clearances Page 7 of 8 PR1 04/08/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288...
- Page 8 TAG-0073_0B Change Log: Date Description Changed By 04/08/2014 Rev A: Release Curtis Harvey © AERCO International, Inc., 2014 www.aerco.com Page 8 of 8 PR1 04/08/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288...
