Aerco 62632006 Technical Instructions

AM Series Thermal Insulation Replacement Instruction
TECHNICAL INSTRUCTIONS
0
Thermal Insulation Replacement Kit # 62632006
For AM Series Models 399, 500, 750 and 1000
Each kit contains the parts necessary to service ONE burner.
Obtain one kit for each burner in the unit you are servicing.
ITEM 1:
P/N 60801149
Screw
(1 each)
ITEM 4:
P/N 60909011
THERMAL
INSULATION, BURNER
(1 each)
AM Series Thermal Insulation Replacement Kit # 62632006 Contents
ITEM # QTY.
1
1
2 1
3 1
4 1
5 1
6 1
The information contained in these instructions are subject to change without notice from
AERCO International, Inc. AERCO makes no warranty of any kind with respect to this
material, including, but not limited to, implied warranties of merchantability and fitness for
a particular application. AERCO International is not liable for errors appearing in this
manual. Nor for incidental or consequential damages occurring in connection with the
furnishing, performance, or use of this material.
07/28/2014 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288
Kit # 62632006
PART NUMBER
60801149 SCREW
n/a WASHER
60703047 O-RING
60909011 THERMAL INSULATION, BURNER
60701021 GASKET, WOOL
60909012 THERMAL INSULATION, HEAT EXCHANGER
Disclaimer
ITEM 2:
P/N n/a
WASHER
(1 each)
ITEM 5:
P/N 60701021
GASKET, WOOL
(1 each)
DESCRIPTION
TID-0120_0A
ITEM 3:
P/N 60703047
O-RING
(1 each)
ITEM 6:
P/N 60909012
THERMAL INSULATION,
HEAT EXCHANGER
(1 each)
Page 1 of 10
