12
Visual LED Indicators (Sound Bar)
SOURCE INDICATORS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Above is a closeup of the source indicators.
TV (HDMI-ARC)
OPTICAL
BLUETOOTH
*
CHROMECAST BUILT-IN
Source indicators will illuminate in different colors to indicate the audio bitstream for non-streaming inputs.
PCM CONTENT
DOLBY CONTENT
DTS CONTENT
When streaming over Bluetooth, the 11th LED will always remain blue irrespective of the content.
*
