30" (76.2
INSTRUCTIONS D'INSTALLATION
t
able de CuiSSon au Gaz de Style CommerCial de
30
po
COOKTOP SAFETY ........................................................................2
INSTALLATION REQUIREMENTS .................................................4
Tools and Parts .............................................................................4
Location Requirements ................................................................5
Electrical Requirements: U.S.A. Only ..........................................8
Gas Supply Requirements ...........................................................8
INSTALLATION INSTRUCTIONS .................................................10
Install Cooktop ...........................................................................10
Make Gas Connection ...............................................................10
Install Griddle Tray ......................................................................11
Complete Installation .................................................................12
GAS CONVERSIONS ....................................................................13
Propane Gas Conversion ...........................................................13
Natural Gas Conversion .............................................................16
Save for local electrical inspector's use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
IMPORTANT :
Conserver ces instructions à l'usage de l'inspecteur des installations électriques local.
Installateur : Remettre les instructions d'installation au propriétaire.
Propriétaire : Conserver les instructions d'installation pour référence ultérieure.
INSTALLATION INSTRUCTIONS
C
ommerCial
), 36" (91.4
Cm
For residential use only
(76,2
), 36
Cm
Pour utilisation résidentielle uniquement
Table of Contents / Table des matières
-S
G
tyle
aS
),
Cm
and
(91,4
)
po
Cm
SÉCURITÉ DE LA TABLE DE CUISSON .....................................19
EXIGENCES D'INSTALLATION ...................................................21
Outils et pièces ...........................................................................21
Exigences d'emplacement .........................................................22
Spécifications électriques : É.-U. seulement .............................25
Spécifications de l'alimentation en gaz .....................................25
INSTRUCTIONS D'INSTALLATION .............................................27
Installation de la table de cuisson ..............................................27
Raccordement au gaz ................................................................27
Installer le plateau d'égouttement .............................................28
Terminer l'installation ..................................................................29
CONVERSIONS POUR CHANGEMENT DE GAZ ......................30
Conversion pour l'alimentation au propane ..............................30
Conversion au gaz naturel .........................................................33
www.kitchenaid.com (U.S.A.) www.kitchenaid.ca (Canada)
C
ooktop
48" (121.9
48
(121,9
et
po
)
Cm
)
Cm
Advertisement
Table of Contents
Related Manuals for KitchenAid W11179813A
Summary of Contents for KitchenAid W11179813A
-
Page 1: Table Of Contents
Installer: Leave installation instructions with the homeowner. Homeowner: Keep installation instructions for future reference. IMPORTANT : Conserver ces instructions à l’usage de l’inspecteur des installations électriques local. Installateur : Remettre les instructions d’installation au propriétaire. Propriétaire : Conserver les instructions d’installation pour référence ultérieure. W11179813A www.kitchenaid.com (U.S.A.) www.kitchenaid.ca (Canada) -
Page 2: Cooktop Safety
COOKTOP SAFETY WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - Page 3 IMPORTANT: Do not install a ventilation system that blows air downward toward this gas cooking appliance. This type of ventilation system may cause ignition and combustion problems with this gas cooking appliance resulting in personal injury or unintended operation. In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gas fitter qualified or licensed by the State of Massachusetts.
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Tools Needed Adjustable wrench Tape measure Marker or pencil Pipe wrench Flat-blade screwdriver 15/16" (24 mm) combination wrench Wrench or channel lock pliers Pipe-joint compound Noncorrosive leak-detection solution... -
Page 5: Location Requirements
Parts Supplied Mobile Home - Additional Installation Requirements Check that all parts are included. The installation of this cooktop must conform to the Manufactured Home Construction and Safety Standard, Burner grates ■ Title 24 CFR, Part 3280 (formerly the Federal Standard for Burner caps ■... - Page 6 36" (91.4 cm) models 48" (121.9 cm) models A. 27 ⁄ " (70.8 cm) C. 3 prong grounding-type power supply cord B. 47 ⁄ " (121.6 cm) D. Model/serial/rating plate (located on the underside of the cooktop A. 27 ⁄ "...
-
Page 7: Cabinet Requirements
Gas and Electric Connection Locations A. Grounded 3 prong outlet should be located on left-hand side of the cutout 16" (40.6 cm) max. from enclosure sidewall B. 10" (25.4 cm) min. clearance from countertop to top of the outlet C. 14" (35.6 cm) countertop to the gas supply line D. -
Page 8: Electrical Requirements: U.s.a. Only
Electrical Requirements: Gas Supply Requirements U.S.A. Only WARNING Explosion Hazard Use a new CSA International approved gas supply line. Install a shut-off valve. Securely tighten all gas connections. If connected to propane, have a qualified person make sure gas pressure does not exceed 14" (36 cm) water column. - Page 9 Gas Supply Line Gas Pressure Regulator The gas pressure regulator supplied with this cooktop must Provide a gas supply line of 3/4" (1.9 cm) rigid pipe to the ■ be used. The inlet pressure to the regulator should be as cooktop location. A smaller size pipe on longer runs may follows for proper operation: result in insufficient gas supply.
-
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS Install Cooktop Make Gas Connection WARNING WARNING Excessive Weight Hazard Use two or more people to move and install cooktop. Failure to do so can result in back or other injury. Write down the model and serial numbers before installing the cooktop. -
Page 11: Install Griddle Tray
You will need to determine the fittings required depending on your installation. 4. Place cooktop into the countertop cutout. NOTE: Check that the front edge of the cooktop is parallel to the front edge of the countertop. If repositioning is needed, lift entire cooktop up from cutout to avoid scratching the countertop. -
Page 12: Complete Installation
Complete Installation Install Burner Caps Check Operation of Cooktop Burners Place burner caps on top of burner. If burner caps are not Push in and turn each Control Knob to . properly positioned, surface burners may not light and burner NOTE: You will hear a clicking sound while the line clears. -
Page 13: Gas Conversions
GAS CONVERSIONS IMPORTANT: Gas conversions from Natural gas to Propane gas 2. Remove spring retainer from the cap by turning the spring must be done by a qualified installer. retainer counterclockwise. Locate the “LP” and “NAT” position on the spring retainer. Turn over the spring retainer WARNING so the “LP”... - Page 14 To Convert Surface Burners from Natural Gas to Adjusting Simmer Low Setting on Surface Burners Propane for Propane 1. If the burner grates are installed, remove them. 1. Unplug cooktop or disconnect power. 2. Remove burner cap. 2. Using the square bit screwdriver, remove the surface burner control knobs and bezels.
- Page 15 6. With the burner ON (the burner will have to be lit manually Complete Installation with a lighter), and set to simmer LOW, adjust the simmer flame down to the proper BTU level. Using a 1/8" x 4¼" 1. Refer to the “Make Gas Connection” section for properly (3.2 mm x 10.8 cm) flat blade screwdriver, turn the simmer connecting the cooktop to the gas supply.
-
Page 16: Natural Gas Conversion
3. Tighten the gas pressure regulator cap by using a large flat‑ Natural Gas Conversion blade screwdriver, turning the regulator cap clockwise. 4. Test the gas pressure regulator and gas supply line. 1. Turn the manual shut‑off valve to the closed position. The regulator must be checked at a minimum 1"... -
Page 17: W11179813A
Use the following chart to find the exact orifice spud 4. Remove the console and set it aside. placement. 5. Locate the appropriate low‑turndown screw for the Natural Gas Orifice Spud/Hood Chart appropriate burner on the given valve. The low‑turndown screw for the left rear, right rear, center rear, and center front Burner burner valves (aluminum) is located through the center of the... -
Page 18: Important
6. With the burner ON (the burner will have to be lit manually Complete Installation with a lighter), and set to simmer LOW, adjust the simmer flame down to the proper BTU level. Using a 1/8" x 4¼" 1. Refer to the “Make Gas Connection” section for properly (3.2 mm x 10.8 cm) flat blade screwdriver, turn the simmer connecting the cooktop to the gas supply.
