AMPLATZER
TorqVue
™
Device Description
The AMPLATZER
TorqVue
™
Optional components of the AMPLATZER
system is designed to provide a pathway through which devices are introduced into the chambers and coronary vasculature of
the heart or into the peripheral vasculature. The body of the delivery catheter is radiopaque for visibility under fluoroscopy.
Note: Not made with natural rubber latex.
E
Figure 1. AMPLATZER
TorqVue
™
A. Loader – Introduces a device into the delivery catheter.
B. Hemostasis valve with extension tube and stopcock – Allows flushing of the delivery system and controls back-bleeding.
C. Delivery catheter – Provides a pathway through which a device is delivered.
D. Delivery wire (optional) – Attaches to a device for controlling its movement through the delivery catheter.
E. Plastic vise (optional) – Attaches to the delivery wire, serving as a "handle" for detaching (unscrewing) the delivery wire from a
device.
Indications for Use
The AMPLATZER
TorqVue
™
the chambers and coronary vasculature of the heart or in the peripheral vasculature.
Contraindications
None known.
™ Indicates a trademark of the Abbott group of companies.
‡ Indicates a third party trademark, which is property of its respective owner.
Pat. http://www.abbott.com/patents
© 2018 Abbott. All Rights Reserved.
™
LP Delivery System
Instructions for Use
LP low-profile delivery system consists of a delivery catheter, loader, and hemostasis valve.
™
TorqVue
LP delivery system are a delivery wire and plastic vise. The delivery
™
™
A
D
LP Delivery System components
™
LP delivery system is intended to provide a pathway through which devices are introduced within
™
B
C
1
ARTEN600038215A
2018-09
Manufacturing facility:
Abbott Medical
5050 Nathan Lane North
Plymouth, MN
55442 USA
+1 855 478 5833
+1 651 756 5833
