TREND IQView4 Installation Instructions Manual

Important: Retain these instructions
conTenTS
1. Unpacking .....................................................................1
2. Storing ...........................................................................1
3. Installation Instructions .................................................1
3.1. Installation - Mounting ...................................................1
1 UnpackIng
2 SToRIng
+50 °C
-10 °C
(122 °F)
(14 °F)
H O
3 InSTallaTIon
3.1 Installation Mounting
1
Dimensions
185 mm (7.3")
c
0 °C
+45 °C
(32 °F)
(113 °F)
EMC (EN61326-1: 2006) Emissions: Class A
Warning: This is a class A product. In a domestic environment this
product may cause radio interference in which case the user may be
required to take adequate measures.
IQView4 Installation Instructions TG201038 Issue 4, 25/11/2009
0 90 %RH
2
32.5 mm (1.3")
7.5 mm (0.3")
0 %RH 80 %RH
H O
2
protection: Ip50
(if correctly fitted in panel)
Installation Instructions
Touch Screen Display
3.2 Installation - Configuration ............................................4
4. End User Licence Agreement .......................................6
5. Removal of Bezel ..........................................................7
6. Disposal .........................................................................7
IQView 4 IQview 4
!
_ ¥
It is recommended that the installation should
comply with the HSE Memorandum of Guidance
on Electricity at Work Regulations 1989.
For USA install equipment in accordance with
National Electric Code
WARNING
! Do not attempt to open the unit. Failure to comply
may cause damage to the unit
2
Mounting Requirements
a
b
The unit is UL rated as 'UL916 listed open energy
management equipment'
d
IQView4
IQView4
Installation Instructions
TG201038
IQView4 Manual
TE201041
IQView4 Template
IQview 4
IQview 4
Touch Screen Display
TG201037
Cut out
1
