Summary of Contents for Bennett Marine SST System
- Page 1 Installation Instructions...
- Page 2 Step 1 Position the trim tabs against the transom and check to see that the upper 9/32" Mounting Holes for mounts of the hydraulic actuators do not center on an inside obstruction. If 1/4" Fasteners they do, reposition tabs slightly outboard. The further outboard the tabs are mounted, the greater the lateral (side-to-side) control.
- Page 3 Step 6 Install Hydraulic Power Unit (HPU) in a convenient location with a dry environment. Important: The HPU must be mounted in a dry enough location to avoid submersion and drenching. Allow space above the HPU so that it may be slid into its mounting bracket (about 3").
- Page 4 For the SST system the top portion of the Actuator and the Actuator Shaft are electrically isolated. Therefore the Trim Plane and the upper part of the Actuator must be individually protected or integrated into a bonding system.
