  • Page 1 Weather Station for KNX Installation and Adjustment...

  • Page 2: Table Of Contents

    OR logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 ......................47 Linkage inputs of OR logic ........................ 47 Suntracer KNX • from software version 1.17, ETS programme version 1.4 • Status: 14.05.2010. Errors excepted. Subject to technical changes...
  • Page 3 Elsner Elektronik GmbH Steuerungs- und Automatisierungstechnik Herdweg 7 • D-75391 Gechingen • Germany Phone.: +49 (0) 70 56/93 97-0 • Fax: +49 (0) 70 56/93 97-20 info@elsner-elektronik.de • www.elsner-elektronik.de...

  • Page 4: Product Description

    Brightness and position of the sun: The current light intensity is measured by means of a sensor. At the same time, Suntracer KNX calculates the position of the sun (azimuth and elevation) on the basis of time and location. The necessary...

  • Page 5: Technical Data

    Configuration is accomplished by means of the KNX software ETS. The programme file for KNX software ETS (format VD2) is ready for download on the Elsner Elektronik website under www.elsner-elektronik.de in the “Service” menu. Technical data Housing: Plastic material Colour:...

  • Page 6: Pcb Layout

    Measurement range brightness: 0…150 000 lux Resolution: 1 lux at 0…120 lux 2 lux at 121…1 046 lux 63 lux at 1 047…52 363 lux 423 lux at 52 364…150 000 lux Accuracy: ±35% The following standards have been considered for the evaluation of the product in terms of electro magnetic compatibility: Transient emissions: •...

  • Page 7: 24 V Dc Version

    Cable connection to the rain sensor in the housing cover Opening for the cable for the voltage supply Tension clamp for voltage supply (230 V AC), suitable for massive conductors of up to 1.5 mm² or conductors with fine wires Opening for bus cable Slot for KNX clamp +/- Programming pushbutton for the teach-in of the device...

  • Page 8: Installation And Commissioning

    The weather station must only be operated as stationary system, i.e. only in a fitted state and after completion of all installation and start-up works, and only in the environment intended for this purpose. Elsner Elektronik does not assume any liability for changes in standards after publication of this instruction manual. Location Select an assembly location at the building where wind, rain and sun may be collected by the sensors unobstructedly.

  • Page 9: Attaching The Mount

    interfering fields of electrical consumers (e.g. fluorescent tubes, illuminated advertising, switching power supply units, etc.). Fig. 3: The weather station must be mounted onto a vertical wall (or pole). Fig.4: The weather station must be mounted horizontally in the lateral direction. Attaching the mount The weather station comes with a combination wall/pole mount.

  • Page 10: View Of Rear Side And Drill Hole Plan

    Fig. 7: An additional, optional accessory available from Elsner Elektronik is an articulated arm for flexible wall, pole or beam mounting of the weather station. Examples for the application of the hinge arm mounting: Ex.1: With the hinge arm mounting, the weather station projects from beneath the roof.

  • Page 11: Preparing The Weather Station

    Fig.8b: Dimensions of rear side of housing with bracket. Subject to change for technical enhancement Preparing the weather station Fig. 9 The weather station cover with the rain sensor snaps in on the left and right along the bottom edge (see Fig.). Remove the weather station cover. Proceed carefully, so as not to pull off the wire connecting the PCB in the bottom part with the rain sensor in the...

  • Page 12: Aligning The Dcf77 Antenna

    cover (soldered cable connection in case of 230 V AC version, cable with plug in case of 24 V DC version). Push the power supply and bus connection cable through the rubber seal on the bottom of the weather station and connect voltage LN and bus +/- to the provided clamps. Aligning the DCF77 antenna The antenna for DCF77 reception of date and time is located under the PCB in the housing.

  • Page 13: Details For The Installation

    Details for the installation Do not open weather station if water (rain) might ingress: even some drops might damage the electronic system. Observe the correct connections. Incorrect connections may destroy the weather station or connected electronic devices. Please take care not to damage the temperature sensor (small blank at the bottom part of the housing.) when mounting the weather station.

  • Page 14: Transmission Protocol

    Transmission protocol Units: Temperatures in degree Celsius Light in Lux Wind in meters per second The DCF signal may be slightly disturbed. It is possible that there is no radio clock reception for a longer period of time. Therefore only use the indicated time for synchronisation purposes of a clock which is operated parallel in your system.
  • Page 15 No. Name Function EIS type Flags Sun position azimuth C R T Sun position elevation C R T Switching output sun in sector 1 C R T Switching output sun in sector 2 C R T Switching output sun in sector 3 C R T Switching output sun in sector 4 C R T...
  • Page 16 No. Name Function EIS type Flags Wind force threshold value 1 Actual value C R T Wind force threshold value 2 Target value C R W Wind force threshold value 2 Actual value C R T Wind force threshold value 3 Target value C R W Wind force threshold value 3...
  • Page 17 No. Name Function EIS type Flags Switching output calendar time Period 2, C R T switch sequence 1 Activation time period 2, Calendar time C R W sequence 2 switch Switch off time period 2, Calendar time C R W sequence 2 switch Switching output calendar time...
  • Page 18 No. Name Function EIS type Flags Activation time Tuesday 3 Week time switch C R W Switch off time Tuesday 3 Week time switch C R W Activation time Tuesday 4 Week time switch C R W Switch off time Tuesday 4 Week time switch C R W Switching output week time...
  • Page 19 No. Name Function EIS type Flags 124 Switching output week time Thursday 3 C R T switch 125 Switching output week time Thursday 4 C R T switch 126 Activation time Friday 1 Week time switch C R W 127 Switch off time Friday 1 Week time switch C R W 128 Activation time Friday 2...
  • Page 20 No. Name Function EIS type Flags 154 Activation time Sunday 3 Week time switch C R W 155 Switch off time Sunday 3 Week time switch C R W 156 Activation time Sunday 4 Week time switch C R W 157 Switch off time Sunday 4 Week time switch C R W...
  • Page 21 No. Name Function EIS type Flags 189 OR logic 2 Switching output C R T 190 OR logic 2 8 Bit output A C R T 191 OR logic 2 8 Bit output B C R T 192 OR logic 3 Switching output C R T 193 OR logic 3...

  • Page 22: Setting Of Parameters

    Setting of parameters General settings Send all measured values cyclically 5 sec • 10 sec • 30 sec • … • 2 h Date and time are set by • DCF-signal and not sent • DCF-signal and sent cyclically • DCF-signal and sent on request •...

  • Page 23: Location

    Switching outputs cyclically send all 5 sec • 10 sec • 30 sec • … • 2 h Communication object • do not send switching output night • send in case of change (The output reacts with a delay of approx. 1 •...
  • Page 24 Town • postal code • coordinates 30 towns in Germany 5 towns in Austria 4 towns in the Switzerland 7 towns in other countries If the location coordinates are entered freely: The indication of the location is necessary for the calculation of the position of the sun with the help of date and time.

  • Page 25: Position Of The Sun

    The function “position of the sun” ist only possible in case of receipt of date and time. The calculation of the position of the sun is optimised for UTC -1...+3. The device therefore may only be applied within Europe. For other time zones, please use Suntracer KNX-GPS Weather Station. Azimuth and elevation • do not send •...

  • Page 26: Position Of The Sun In Sector 1 / 2 / 3 / 4 / 5

    Position of the sun in sector 1 / 2 / 3 / 4 / 5 If the position of the sun is defined by directions: Definition of the position of the sun by directions • azimuth and elevation Directions East • Southeast • Southwest • West Communication object (as in case of switching output night) switching output sun in sector 1 / 2 / 3 / 4 / 5...
  • Page 27 If the position of the sun is defined by azimuth and elevation: All data in ° (degree) Azimuth from 0 … 360 Azimuth up to 0 … 360 Elevation from 0 … 90 Elevation up to 0 … 90 Communication object (as in case of switching output night) switching output sun in sector 1 / 2 / 3 / 4 / 5 Direction of the sun (azimuth):...

  • Page 28: Temperature

    Temperature Measured value • do not send • send cyclically • send in case of change • send in case of change and cyclically From a temperature change of 0.5°C • 1°C • 2°C • 3°C • 4°C • 5°C Temperature offset in 0.1°C -50 …...

  • Page 29: Temperature Threshold 1 / 2 / 3 / 4

    Temperature threshold 1 / 2 / 3 / 4 If the threshold is set by parameters: Threshold value is set by Parameters Threshold value in 0.1°C -300 … 800...
  • Page 30 If the threshold is set by communication objects, a threshold which is valid until the first communication of a new threshold must be determined for the initial operation: Threshold value is set by Communication object Start threshold value in 0.1°C -300 …...
  • Page 31 In case of an already commissioned weather station, the threshold which has been communicated at last may be used: As soon as a threshold has been set by means of a parameter or by means of a communication object, the threshold set at last remains until a new threshold has been transmitted by a communication object.

  • Page 32: Wind Force

    Wind force Measured value • do not send • send cyclically • send in case of change • send in case of change and cyclically From a wind force change of 1 m/sec … 4 m/sec Threshold value 1 / 2 / 3 not active •...

  • Page 33: Wind Force Threshold 1 / 2 / 3

    Wind force threshold 1 / 2 / 3 Threshold value in 0.1 m/s 0 … 350 Hysteresis of the threshold value in 0.1 m/s 0 … 250 All other parameters correspond to the parameters of the temperature thresholds (see there).

  • Page 34: Brightness

    Brightness Measured value • do not send • send cyclically • send in case of change • send in case of change and cyclically From change in % 1 … 50 Threshold value 1 / 2 / 3 not active • active...

  • Page 35: Brightness Threshold Value 1 / 2 / 3

    Brightness threshold value 1 / 2 / 3 Threshold value in klux 1 … 99 Hysteresis of the threshold value in klux 0 … 99 All other parameters correspond to the parameters of the temperature thresholds (see there).

  • Page 36: Dawn

    Dawn Threshold value 1 / 2 / 3 Not active • active Dawn threshold value 1 / 2 / 3...

  • Page 37: Calendar Time Switch

    Threshold value in lux 1 … 1000 Hysteresis of the threshold value in lux 0 … 1000 All other parameters correspond to the parameters of the temperature thresholds (see there). Calendar time switch Period 1 / 2 / 3 not active • active...

  • Page 38: Calendar Time Switch Period 1 / 2 / 3

    Calendar time switch period 1 / 2 / 3 From: Month January … December 1 … 29 / 1 … 30 / 1 … 31 (depending on month) up to and including: Month January … December 1 … 29 / 1 … 30 / 1 … 31 (depending on month) Sequence 1 not active •...

  • Page 39: Calendar Time Switch Period 1 / 2 / 3, Sequence 1 / 2

    Calendar time switch period 1 / 2 / 3, sequence 1 / 2 Setting of switching times by Parameter • Communication objects Activation-time 0 … 23 hours Activation-time 0 … 59 minutes Switch-off time 0 … 23 hours Switch-off time 0 …...

  • Page 40: Week Time Switch

    Week time switch Monday … Sunday not active • active All 4 sequences of the selected day are always activated together.

  • Page 41: Weekly Watch Mon, Tue, Wed, Thu, Fri, Sat, Sun 1

    Weekly watch Mon, Tue, Wed, Thu, Fri, Sat, Sun 1 … 4 Setting of switching times by Parameter • Communication objects Activation-time 0 … 23 hours Activation-time 0 … 59 minutes Switch-off time 0 … 23 hours Switch-off time 0 … 59 minutes Shall sequence 1 / 2 / 3 / 4 be allocated to the do not allocate •...

  • Page 42: And Logic

    Sequence 1 Monday Sequence 1 Tuesday Sequence 1 Wednesday Sequ. 1 Week time switch OR 1 Thursday Sequence 1 Friday Sequence 1 Saturday Sequence 1 Sunday Sequence 1 AND logic Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 not active •...
  • Page 43 Logic output sends a 1 bit-object If logic = 1 ! object value 1 • 0 If logic = 0 ! object value 1 • 0 Communication object • in case of the change of logic AND logic 1 sends •...

  • Page 44: Linkage Inputs Of And Logic

    Use of the AND logic: Example automatic shading The AND logic can be used to set the conditions for shading, for example a brightness threshold value and sun in a certain area. The activation of shading after wind alarm and the blocking by manual operation were implied in this example, too. Sun in sector 1 one 1 bit object to the shading object of the...
  • Page 45 Calendar time switch 1. period Nr. 2 inverted Calendar time switch 2. period Nr. 1 Calendar time switch 2. period Nr. 1 inverted Calendar time switch 2. period Nr. 2 Calendar time switch 2. period Nr. 2 inverted Calendar time switch 3. period Nr. 1 Calendar time switch 3.
  • Page 46 Temperature threshold value 4 inverted Wind threshold value 1 Wind threshold value 1 inverted Wind threshold value 2 Wind threshold value 2 inverted Wind threshold value 3 Wind threshold value 3 inverted Week time switch Monday 1 Week time switch Monday 1 inverted Week time switch Monday 2 Week time switch Monday 2 inverted Week time switch Monday 3...
  • Page 47 Week time switch Saturday 1 inverted Week time switch Saturday 2 Week time switch Saturday 2 inverted Week time switch Saturday 3 Week time switch Saturday 3 inverted Week time switch Saturday 4 Week time switch Saturday 4 inverted Week time switch Sunday 1 Week time switch Sunday 1 inverted Week time switch Sunday 2 Week time switch Sunday 2 inverted...

  • Page 48: Or Logic

    OR logic Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 not active • active OR logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 Logic output sends a 1 bit-object •...
  • Page 49 AND logic output 6 AND logic output 6 inverted AND logic output 7 AND logic output 7 inverted AND logic output 8 AND logic output 8 inverted...
  • Page 50 Elsner Elektronik GmbH Steuerungs- und Automatisierungstechnik Herdweg 7 D-75391 Gechingen Germany Phone: +49 (0) 70 56/93 97-0 Fax: +49 (0) 70 56/93 97-20 info@elsner-elektronik.de http://www.elsner-elektronik.de...
