1.
Description ........................................................................................... 3
1.1. Technical specifications ........................................................................................... 3
1.2. Notes on installation ................................................................................................ 5
1.2.1. Location ......................................................................................................... 5
1.3. Mounting the weather station ................................................................................. 6
1.3.1. Attaching the mount ..................................................................................... 6
1.3.2. View of rear side and drill hole plan ........................................................... 8
1.3.3. Preparing the weather station ..................................................................... 9
1.3.4. PCB layout ................................................................................................... 10
1.3.5. Mounting the weather station ................................................................... 11
1.4. Notes on mounting and commissioning .............................................................. 11
2.
Maintenance ....................................................................................... 12
3.
Transmission protocol ....................................................................... 13
3.1. List of all communication objects ......................................................................... 13
4.
Setting of parameters ........................................................................ 17
4.1. General settings ..................................................................................................... 17
4.2. Temperature ........................................................................................................... 18
4.2.1. Temperature threshold value 1 / 2 / 3 / 4 .................................................. 18
4.3. Wind force ............................................................................................................... 19
4.3.1. Wind threshold value 1 / 2 / 3 .................................................................... 19
4.4. Brightness ............................................................................................................... 21
4.4.1. Brightness threshold value 1 / 2 / 3 ........................................................... 21
4.5. Dawn ....................................................................................................................... 21
4.5.1. Dawn threshold value 1 / 2 / 3 .................................................................... 21
4.6. AND Logic ............................................................................................................... 21
4.6.1. AND Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 .............................................................. 21
4.6.2. Linkage inputs of AND logic ...................................................................... 22
4.7. OR Logic .................................................................................................................. 23
4.7.1. OR Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 ................................................................ 23
4.7.2. Linkage inputs of OR logic ......................................................................... 24
Elsner Elektronik GmbH • Herdweg 7 • D-75391 Gechingen • Germany
Weather Station Suntracer KNX basic • from software version 1.06, ETS programme version 1.1
Date of issue: 29.06.2012. Errors excepted. Subject to technical changes.
1
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Suntracer KNX basic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for elsner elektronik Suntracer KNX basic

Summary of Contents for elsner elektronik Suntracer KNX basic

  • Page 1: Table Of Contents

    4.7.2. Linkage inputs of OR logic ................. 24 Elsner Elektronik GmbH • Herdweg 7 • D-75391 Gechingen • Germany Weather Station Suntracer KNX basic • from software version 1.06, ETS programme version 1.1 Date of issue: 29.06.2012. Errors excepted. Subject to technical changes.
  • Page 2 Explanation of symbols Installation, inspection, commissioning and troubleshooting of the device must only be carried out by a competent electrician. Tis manual is subject to changes and is going to be adapted to new software versions. The revision state (software version and date) can be found in the footer of the contents. If yor device has got a new software version, please check www.elsner-elektronik.de “Service”...

  • Page 3: Description

    230 V AC version: max. 20 mA 24 V DC version: max. 100 mA Residual ripple 10% Data output KNX +/- bus terminal plug Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.
  • Page 4 EN 60730-1:2000 Section EMV (23, 26, H23, H26) • EN 50090-2-2:1996-11 + A1:2002-01 • EN 61000-6-1:2004 The product has been tested for the above mentioned standards by an accredited EMV laboratory. Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 5: Notes On Installation

    Temperature variations from such sources of inter- ference must be corrected in the ETS in order to ensure the specified accuracy of the sensor (temperature offset). Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 6: Mounting The Weather Station

    Fasten the mount vertically onto the wall or pole. Fig. 3 When wall mounting: flat side on wall, crescent- Collar shaped collar upward. Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.
  • Page 7 Fig. 7 Example uses of the hinge arm mounting: Fit- ting to a pole with worm drive hose clips Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 8: View Of Rear Side And Drill Hole Plan

    Fig. 8 a+b Drill hole plan Dimensions of rear side of housing with bracket. Sub- ject to change for technical enhancement. Langloch 7,5 x 5 mm Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 9: Preparing The Weather Station

    LN and bus +/- to the provided clamps. For 24V devices the connection cable must be plugged in between the cover and circuit board. Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 10: Pcb Layout

    Opening for the cable for the voltage supply Opening for bus cable Slot for KNX clamp +/- Programming pushbutton for the teach-in of the device Programming LED Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 11: Mounting The Weather Station

    After the auxiliary voltage has been applied, the device will enter an initialisation phase lasting 5 seconds. During this phase no information can be received via the bus. Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 12: Maintenance

    As a precaution, the device should always be separated from power supply for maintenance works (e.g. deactivate or remove fuse). Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Technical changes reserved. Errors reserved.

  • Page 13: Transmission Protocol

    Highest measured temperature Sends max. tempe- C R T value rature Min/max temperature reset Reset of tempera- C R W ture Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.
  • Page 14 Actual value C R T Brightness threshold value 3 Target value C R W Brightness threshold value 3 Actual value C R T Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.
  • Page 15 C R T AND logic 7 8 Bit output A C R T AND logic 7 8 Bit output B C R T Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.
  • Page 16 C R T OR logic 8 8 Bit output A C R T OR logic 8 8 Bit output B C R T Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 17: Setting Of Parameters

    Maximum telegram quota 1 • 2 • 3 • 5 • 10 • 20 telegrams per second Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 18: Temperature

    Activation delay none • 1 s • 1 min... • 2 h Switch-off delay none • 1 s • 1 min... • 2 h Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 19: Wind Force

    Start threshold value in 0,1 m/s 0 … 350; 40 valid until 1. communication (only if the value communicated last is „not“ maintained or „after restoration of voltage“) Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.
  • Page 20 • send status of the switching output Einstellung möglich) • if switching output = 1 => send 1 • if switching output = 0 => send 0 Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 21: Brightness

    Logic output sends one 1 bit object if logic = 1 object value 1 • 0 if logic = 0 object value 1 • 0 Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 22: Linkage Inputs Of And Logic

    Brightness threshold value 1 inverted Brightness threshold value 2 Brightness threshold value 2 inverted Brightness threshold value 3 Brightness threshold value 3 inverted Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 23: Or Logic

    1. / 2. / 3. / 4. Input • do not use • all switching events which the sensor pro- vides (see “Linkage inputs of the OR logic”) Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.

  • Page 24: Linkage Inputs Of Or Logic

    AND logic output 6 inverted AND logic output 7 AND logic output 7 inverted AND logic output 8 AND logic output 8 inverted Weather Station Suntracer KNX basic • Date of issue: 29.06.2012 • Errors excepted. Subject to technical changes.
